Cisco GS7000 Operating instructions

4037424 Rev A
Cisco GS7000
DOCSIS Status Monitor Transponder
Installation and Operation Guide

For Your Safety
Explanation of Warning and Caution Icons
Avoid personal injury and product damage! Do not proceed beyond any symbol
until you fully understand the indicated conditions.
The following warning and caution icons alert you to important information about
the safe operation of this product:
You may find this symbol in the document that accompanies this product.
This symbol indicates important operating or maintenance instructions.
You may find this symbol affixed to the product. This symbol indicates a live
terminal where a dangerous voltage may be present; the tip of the flash points
to the terminal device.
You may find this symbol affixed to the product. This symbol indicates a
protective ground terminal.
You may find this symbol affixed to the product. This symbol indicates a
chassis terminal (normally used for equipotential bonding).
You may find this symbol affixed to the product. This symbol warns of a
potentially hot surface.
You may find this symbol affixed to the product and in this document. This
symbol indicates an infrared laser that transmits intensity-modulated light
and emits invisible laser radiation or an LED that transmits intensity-
modulated light.
Important
Please read this entire guide. If this guide provides installation or operation
instructions, give particular attention to all safety statements included in this guide.

Notices
Trademark Acknowledgments
 Cisco and the Cisco logo are trademarks or registered trademarks of Cisco
and/or its affiliates in the U.S. and other countries. A listing of Cisco's
trademarks can be found at www.cisco.com/go/trademarks.
 GainMaker is a registered trademark of Cisco Systems, Inc.
 Cheetah is a trademark of Cheetah Technologies, LP.
 DOCSIS is a registered trademark of Cable Television Laboratories, Inc.
 Other third party trademarks mentioned are the property of their respective
owners.
 The use of the term partner does not imply a partnership relationship between
Cisco and any other company.(1009R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Copyright
© 2011 Cisco and/or its affiliates. All rights reserved. Printed in the United States of
America.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.

4037424 Rev A iii
Contents
Important Safety Instructions vii
Chapter 1 Introduction 1
Model GS7000 Node Description .......................................................................................... 2
Overview...................................................................................................................... 2
Physical Description ................................................................................................... 2
Transponder Description........................................................................................................ 5
Overview...................................................................................................................... 5
Parts List....................................................................................................................... 6
Technical Support Contact Information ..................................................................6
Connectors ................................................................................................................... 6
Connector Summary................................................................................................... 8
Chapter 2 Installation 9
Provisioning the Transponders in the Network................................................................ 10
Your Network Information .................................................................................................. 11
Security....................................................................................................................... 11
Cable Modem Configuration File........................................................................................ 12
Sample Configuration File....................................................................................... 12
Installing the Transponder ................................................................................................... 13
GS7000 Node Installation ........................................................................................13
GS7000 Optical Hub Installation ............................................................................18
Configuring the Transponder Using the SA-HMS-FIBERNODEGS7000 MIB.............. 21
Downloading Module Firmware Using the CTLP-DOWNLOAD-MIB ........................ 24
OIDs Used for Module Firmware Download....................................................... 24
Checking the LEDs ................................................................................................................ 26
LED Status Summary ...............................................................................................27
Chapter 3 Provisioning the SNMP Manager 29
MIB Files.................................................................................................................................. 30
Management Information Base (MIB) Files .......................................................... 30
Management Information Base (MIB) Files .......................................................... 31
Additional Supported Management Information Base (MIB) Files...................31

Contents
iv 4037424 Rev A
Acquiring the Transponders by the SNMP Manager .......................................................33
Chapter 4 Using the Craft Port 35
Overview................................................................................................................................. 36
Web Page Access.................................................................................................................... 37
Console Access ....................................................................................................................... 38
OIDs for Usernames, Passwords, Telnet Access for Console Access ................ 38
TelnetIpStackInterfaces OID Values and Descriptions .......................................38
Telnet Access Matrix ................................................................................................ 39
Chapter 5 Using the Web Interface 43
Overview................................................................................................................................. 44
Configuring the Sysname and Syslocation OIDs .............................................................. 45
Configuration Pages .............................................................................................................. 46
Configuration Data Page ......................................................................................... 46
GS7000 Configuration Data Page ........................................................................... 47
Status Page for Software Information ................................................................................. 51
Status Page for Connection Information ............................................................................ 52
Status Page for the SNMP Event Log.................................................................................. 53
HMS Fiber Node Data Page ................................................................................................. 54
HSIA Diagnostics Page: Ping Command............................................................................56
Input Parameters....................................................................................................... 56
Controlling the Ping Test......................................................................................... 57
Test Results ................................................................................................................ 57
Simultaneous Access ................................................................................................ 58
HSIA Diagnostics Page: Traceroute Command................................................................. 59
Input Parameters....................................................................................................... 59
Controlling the Traceroute Test.............................................................................. 60
Test Results ................................................................................................................ 60
Simultaneous Access ................................................................................................ 61
Traceroute Legal Agreement................................................................................... 61
RF Constellation Page ........................................................................................................... 63
Controls ...................................................................................................................... 63
Downstream Data ..................................................................................................... 64
Interpreting QAM Constellation Data by Visual Inspection.............................. 64

Contents
4037424 Rev A v
MTA Status Page.................................................................................................................... 70
MTA DHCP Page................................................................................................................... 71
MTA Quality of Service (QoS) Page.................................................................................... 72
MTA Provisioning Page........................................................................................................ 73
MTA Event Log Page ............................................................................................................ 74
Appendix A Technical Information 75
Cable Pinout Details .............................................................................................................. 76
Ethernet Cable ........................................................................................................... 76
Upgrading the Transponder Firmware .............................................................................. 77
Chapter 6 Customer Support Information 79
Support Telephone Numbers............................................................................................... 80
Glossary 81
Index 91

Important Safety Instructions
4037424 Rev A vii
Important Safety Instructions
Read and Retain Instructions
Carefully read all safety and operating instructions before operating this equipment,
and retain them for future reference.
Follow Instructions and Heed Warnings
Follow all operating and use instructions. Pay attention to all warnings and cautions
in the operating instructions, as well as those that are affixed to this equipment.
Terminology
The terms defined below are used in this document. The definitions given are based
on those found in safety standards.
Service Personnel - The term service personnel applies to trained and qualified
individuals who are allowed to install, replace, or service electrical equipment. The
service personnel are expected to use their experience and technical skills to avoid
possible injury to themselves and others due to hazards that exist in service and
restricted access areas.
User and Operator - The terms user and operator apply to persons other than service
personnel.
Ground(ing) and Earth(ing) - The terms ground(ing) and earth(ing) are synonymous.
This document uses ground(ing) for clarity, but it can be interpreted as having the
same meaning as earth(ing).
Electric Shock Hazard
This equipment meets applicable safety standards.
WARNING:
To reduce risk of electric shock, perform only the instructions that are
included in the operating instructions. Refer all servicing to qualified service
personnel only.
Electric shock can cause personal injury or even death. Avoid direct contact with
dangerous voltages at all times.
Know the following safety warnings and guidelines:
 Only qualified service personnel are allowed to perform equipment installation
or replacement.

Important Safety Instructions
viii 4037424 Rev A
 Only qualified service personnel are allowed to remove chassis covers and access
any of the components inside the chassis.
Equipment Placement
WARNING:
Avoid personal injury and damage to this equipment. An unstable mounting
surface may cause this equipment to fall.
To protect against equipment damage or injury to personnel, comply with the
following:
 Install this equipment in a restricted access location (access restricted to service
personnel).
 Make sure the mounting surface or rack is stable and can support the size and
weight of this equipment.
Strand (Aerial) Installation
CAUTION:
Be aware of the size and weight of strand-mounted equipment during the
installation operation.
Ensure that the strand can safely support the equipment’s weight.
Pedestal, Service Closet, Equipment Room or Underground Vault Installation
WARNING:
Avoid the possibility of personal injury. Ensure proper handling/lifting
techniques are employed when working in confined spaces with heavy
equipment.
 Ensure this equipment is securely fastened to the mounting surface or rack
where necessary to protect against damage due to any disturbance and
subsequent fall.
 Ensure the mounting surface or rack is appropriately anchored according to
manufacturer‘s specifications.
 Ensure the installation site meets the ventilation requirements given in the
equipment‘s data sheet to avoid the possibility of equipment overheating.
 Ensure the installation site and operating environment is compatible with the
equipment‘s International Protection (IP) rating specified in the equipment‘s data
sheet.

Important Safety Instructions
4037424 Rev A ix
Connecting to Utility AC Power
Important: If this equipment is a Class I equipment, it must be grounded.
 If this equipment plugs into an outlet, the outlet must be near this equipment,
and must be easily accessible.
 Connect this equipment only to the power sources that are identified on the
equipment-rating label, which is normally located close to the power inlet
connector(s).
 This equipment may have two power sources. Be sure to disconnect all power
sources before working on this equipment.
 If this equipment does not have a main power switch, the power cord connector
serves as the disconnect device.
 Always pull on the plug or the connector to disconnect a cable. Never pull on the
cable itself.
Connection to Network Power Sources
Refer to this equipment‘s specific installation instructions in this manual or in
companion manuals in this series for connection to network ferro-resonant AC
power sources.
AC Power Shunts
AC power shunts may be provided with this equipment.
Important: The power shunts (where provided) must be removed before installing
modules into a powered housing. With the shunts removed, power surge to the
components and RF-connectors is reduced.
CAUTION:
RF connectors and housing seizure assemblies can be damaged if shunts are
not removed from the equipment before installing or removing modules from
the housing.
Grounding (Utility AC Powered Equipment in Pedestals, Service Closets, etc.)
This section provides instructions for verifying that the equipment is properly
grounded.
Safety Plugs (USA Only)
This equipment may be equipped with either a 3-terminal (grounding-type) safety
plug or a 2-terminal (polarized) safety plug. The wide blade or the third terminal is
provided for safety. Do not defeat the safety purpose of the grounding-type or
polarized safety plug.

Important Safety Instructions
x 4037424 Rev A
To properly ground this equipment, follow these safety guidelines:
 Grounding-Type Plug - For a 3-terminal plug (one terminal on this plug is a
protective grounding pin), insert the plug into a grounded mains, 3-terminal
outlet.
Note: This plug fits only one way. If this plug cannot be fully inserted into the
outlet, contact an electrician to replace the obsolete 3-terminal outlet.
 Polarized Plug - For a 2-terminal plug (a polarized plug with one wide blade
and one narrow blade), insert the plug into a polarized mains, 2-terminal outlet
in which one socket is wider than the other.
Note: If this plug cannot be fully inserted into the outlet, try reversing the plug.
If the plug still fails to fit, contact an electrician to replace the obsolete 2-terminal
outlet.
Grounding Terminal
If this equipment is equipped with an external grounding terminal, attach one end of
an 18-gauge wire (or larger) to the grounding terminal; then, attach the other end of
the wire to a ground, such as a grounded equipment rack.
Safety Plugs (European Union)
 Class I Mains Powered Equipment –Provided with a 3-terminal AC inlet and
requires connection to a 3-terminal mains supply outlet via a 3-terminal power
cord for proper connection to the protective ground.
Note: The equipotential bonding terminal provided on some equipment is not
designed to function as a protective ground connection.
 Class II Mains Powered Equipment –Provided with a 2-terminal AC inlet that
may be connected by a 2-terminal power cord to the mains supply outlet. No
connection to the protective ground is required as this class of equipment is
provided with double or reinforced and/or supplementary insulation in
addition to the basic insulation provided in Class I equipment.
Note: Class II equipment, which is subject to EN 50083-1, is provided with a
chassis mounted equipotential bonding terminal. See the section titled
Equipotential Bonding for connection instructions.
Equipotential Bonding
If this equipment is equipped with an external chassis terminal marked with the IEC
60417-5020 chassis icon ( ), the installer should refer to CENELEC standard EN
50083-1 or IEC standard IEC 60728-11 for correct equipotential bonding connection
instructions.

Important Safety Instructions
4037424 Rev A xi
General Servicing Precautions
WARNING:
Avoid electric shock! Opening or removing this equipment’s cover may
expose you to dangerous voltages.
CAUTION:
These servicing precautions are for the guidance of qualified service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you
are qualified to do so. Refer all servicing to qualified service personnel.
Be aware of the following general precautions and guidelines:
 Servicing - Servicing is required when this equipment has been damaged in any
way, such as power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into this equipment, this equipment has been exposed to rain
or moisture, does not operate normally, or has been dropped.
 Wristwatch and Jewelry - For personal safety and to avoid damage of this
equipment during service and repair, do not wear electrically conducting objects
such as a wristwatch or jewelry.
 Lightning - Do not work on this equipment, or connect or disconnect cables,
during periods of lightning.
 Labels - Do not remove any warning labels. Replace damaged or illegible
warning labels with new ones.
 Covers - Do not open the cover of this equipment and attempt service unless
instructed to do so in the instructions. Refer all servicing to qualified service
personnel only.
 Moisture - Do not allow moisture to enter this equipment.
 Cleaning - Use a damp cloth for cleaning.
 Safety Checks - After service, assemble this equipment and perform safety
checks to ensure it is safe to use before putting it back into operation.
Electrostatic Discharge
Electrostatic discharge (ESD) results from the static electricity buildup on the human
body and other objects. This static discharge can degrade components and cause
failures.
Take the following precautions against electrostatic discharge:
 Use an anti-static bench mat and a wrist strap or ankle strap designed to safely
ground ESD potentials through a resistive element.
 Keep components in their anti-static packaging until installed.

Important Safety Instructions
xii 4037424 Rev A
 Avoid touching electronic components when installing a module.
Fuse Replacement
To replace a fuse, comply with the following:
 Disconnect the power before changing fuses.
 Identify and clear the condition that caused the original fuse failure.
 Always use a fuse of the correct type and rating. The correct type and rating are
indicated on this equipment.
Batteries
This product may contain batteries. Special instructions apply regarding the safe use
and disposal of batteries:
Safety
 Insert batteries correctly. There may be a risk of explosion if the batteries are
incorrectly inserted.
 Do not attempt to recharge ‗disposable‘ or ‗non-reusable‘ batteries.
 Please follow instructions provided for charging ‗rechargeable‘ batteries.
 Replace batteries with the same or equivalent type recommended by
manufacturer.
 Do not expose batteries to temperatures above 100°C (212°F).
Disposal
 The batteries may contain substances that could be harmful to the environment
 Recycle or dispose of batteries in accordance with the battery manufacturer‘s
instructions and local/national disposal and recycling regulations.
 The batteries may contain perchlorate, a known hazardous substance, so special
handling and disposal of this product might be necessary. For more information
about perchlorate and best management practices for perchlorate-containing
substance, see www.dtsc.ca.gov/hazardouswaste/perchlorate.

Important Safety Instructions
4037424 Rev A xiii
Modifications
This equipment has been designed and tested to comply with applicable safety, laser
safety, and EMC regulations, codes, and standards to ensure safe operation in its
intended environment. Refer to this equipment's data sheet for details about
regulatory compliance approvals.
Do not make modifications to this equipment. Any changes or modifications could
void the user‘s authority to operate this equipment.
Modifications have the potential to degrade the level of protection built into this
equipment, putting people and property at risk of injury or damage. Those persons
making any modifications expose themselves to the penalties arising from proven
non-compliance with regulatory requirements and to civil litigation for
compensation in respect of consequential damages or injury.
Accessories
Use only attachments or accessories specified by the manufacturer.
Electromagnetic Compatibility Regulatory Requirements
This equipment meets applicable electromagnetic compatibility (EMC) regulatory
requirements. Refer to this equipment's data sheet for details about regulatory
compliance approvals. EMC performance is dependent upon the use of correctly
shielded cables of good quality for all external connections, except the power source,
when installing this equipment.
 Ensure compliance with cable/connector specifications and associated
installation instructions where given elsewhere in this manual.
EMC Compliance Statements
Where this equipment is subject to USA FCC and/or Industry Canada rules, the
following statements apply:
FCC Statement for Class A Equipment
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when this equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case users will be required to
correct the interference at their own expense.

Important Safety Instructions
xiv 4037424 Rev A
Industry Canada - Industrie Canadiene Statement
This apparatus complies with Canadian ICES-003.
Cet appareil est confome à la norme NMB-003 du Canada.
CENELEC/CISPR Statement with Respect to Class A Information Technology Equipment
This is a Class A equipment. In a domestic environment this equipment may cause
radio interference in which case the user may be required to take adequate
measures.

4037424 Rev A 1
This manual describes the installation and operation of the Cisco
GS7000 DOCSIS Status Monitor Transponder module.
1Chapter 1
Introduction
In This Chapter
 Model GS7000 Node Description ......................................................... 2
 Transponder Description....................................................................... 5

Chapter 1 Introduction
2 4037424 Rev A
Model GS7000 Node Description
Overview
This section contains a brief physical and functional description of the Model GS7000
Node.
For complete information about the Model GS7000 Node, refer to Model GS7000
GainMaker Scaleable 4-Port Node Installation and Operation Guide, part number 4013584.
Physical Description
The Model GS7000 Node is the latest generation 1 GHz optical node platform which
uses a completely new housing designed for optimal heat dissipation. The housing
has a hinged lid to allow access to the internal electrical and optical components.
The housing also has provisions for strand, pedestal, or wall mounting.
The base of the housing contains:
 an RF amplifier module
 AC power routing
 forward and reverse configuration modules (configuration will vary)
The lid of the housing contains:
 a fiber management tray and track (included in all nodes)
 optical receiver and transmitter modules (configuration will vary)
 EDFA (erbium-doped fiber amplifier) modules and optical switch modules
(for hub node application)
 power supplies (one or two)
 a status monitor/local control module (optional)
Not every Model GS7000 Node will contain all of these modules. The Model GS7000
Node is a versatile node that can be configured to meet network requirements.
The following illustration shows the external housing of the Model GS7000 Node.

Model GS7000 Node Description
4037424 Rev A 3

Chapter 1 Introduction
4 4037424 Rev A
The following illustration shows the Model GS7000 Node internal modules and
components. This model is the 4-way forward segmentable node. The 2-way
forward segmentable node has a different RF amplifier module.
