De Haardt GX-120 User manual

Xtra.CDI Shutdown Transponder
Quick Start Guide
GX-120 & GX-160
Safety notice
All products are designed as supplement to make karting safer, but cannot replace safe track procedures.
If equipment fails, the normal operating procedure must still be adequate to safely operate the track.
Visit www.de-haardt.com for more information about the Xtra.CDI Shutdown Transponder and products.
For technical issues or questions about the Xtra.CDI Shutdown Transponder.
contact: [e-mail].
FOLLOW THESE STEPS FOR A QUICK
SETUP OF THE XTRA.CDI SHUTDOWN
TRANSPONDER
Before you start
Listed below are the model numbers of the engines currently in production.
De Haardt has verified that this manual is applicable to these models.
If you want to connect the Xtra.CDI Shutdown Transponder to a dierent
engine model, it is recommended to contact: [e-mail]
GX-120 GX-160
RHQ4 RHG4
RHQ4

Mount the Xtra.CDI Shutdown Transponder
as high as possible on a preferably flat
plastic surface with the connector facing
downwards, using three countersunk M5
bolts and lock-nuts. This ensures optimum
radio sensitivity.
Mounting the Xtra.CDI Shutdown Transponder
1
Connecting the engine
Take the ‘SUPPLY’ cable with the
two wires ends and combine the
blue wire with the blue wire of the
‘ENGINE+BRAKE’ cable. Combine
the brown ‘SUPPLY’ wire with the
brown ‘ENGINE+BRAKE’ wire.
Connect the combined brown
wire with the engine switch cable.
Connect the remaining brown
wire with the black cable from
the engine.
Connect the combined blue wire
to the chassis of the engine.
1.
2.
3.
Usage of the yellow/green wire is not needed for the setup of the
Xtra.CDI Shutdown Transponder, leave the wire hanging.
2
To power the Xtra.CDI Shutdown Transponder with a battery
visit: www.de-haardt.com for the full product manual.

Before setting the kart number make sure other karts in the
area are turned o.
The last step is to test if the following functions of the Xtra.CDI
Shutdown Transponder are working properly.
First test is to change the speed of the kart with the speed
buttons ‘SPD1(slowest), SPD2, SPD3 and SPD4 (fastest)’.
Second test is to stop all the engines by using the Xtra.Remote Control.
Start the engine and press ‘SHIFT’ followed by the ‘STOP’ button.
Set the kart number with the Xtra.Remote Control
Test the Xtra.CDI Shutdown Transponder
3
4
!
Turn on the Xtra.Remote Control by
pressing the button.
Press the button to enter the
configuration menu and enter the
default PINcode ‘0000’.
In the configuration menu press the
upper left button.
1.
2.
For the full setup and configuration of the Xtra.Remote Control
visit: www.de-haardt.com for the full product manual.
Enter the serial number displayed
on the front of the Xtra.CDI
Shutdown Transponder and press
or to connect.
Enter the desired kart number and
press to assign it to the Xtra.CDI
Shutdown Transponder.
