Cisco 2610 - Router - EN User manual

Quick Start Guide
CISCO 2610 ROUTER
CABLING AND SETUP
1
Take Out What You Need
2
Connect Cables
3
Run Cisco Fast Step
4
Finish the Cabling
5
Network Information - Optional
Fax machine
PBX Telephone
Windows NT
4.0 server
Windows 95
Novell network
Home office PC
Laptop with internal
modem for mobile commuter
Public Service Telephone
Network (PSTN)
Cisco 2610

2
1Take Out What You Need
Quick Start Guide and
Fast Step CD-ROM
Router
Thisguideexplainshowtocableandsetupyour
Cisco 2610 router with the following
configuration:
• 8- or 16-port internal analog modem in the
network module slot.
• 2 empty WAN interface card slots with a
blank panel in each slot.
Begin by taking out the following items from the
box.
Note: If your router has a different hardware
configuration, refer to the Cisco 2600 Series
Hardware Installation Guide for information on
how to install and set up your router.
1Quick Start Guide (this guide) with
1 Cisco Fast Step CD-ROM (attached)
1 Cisco 2610
CD-ROM
POWER
RPS ACTIVITY
Cisco 2600
SERIES

3
1Take Out What You Need (continued)
Cables and Power Cord
1 yellow Ethernet 10BaseT cable
(to connect to a 10BaseT hub)
1 flat, light-blue console cable with
1 RJ-45 adapter, labeled TERMINAL
(RJ-45-to-DB-9 or RJ-45-to-DB-25)
8 or 16 pink modem cables (RJ-11)
1 black power cord

4
5Connect the appropriate network module
cable(s) to your network.
For information on connecting network modules,
refer to the Cisco Network Modules Hardware
Installation Guide included in your router package.
2Connect Cables
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2A/S
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2T
AUX
CONSOLE
ETHERNET 0 ACT
LINK
100-240V– 1A
50/60 Hz 47 W
MODEMS
EN
IN USE
IN USE
16AM
15 14 13 12 11 10 98
76543210
Installing a Network Module
Use this procedure, if required, to install an 8- or
16-port analog modem network module in a
Cisco 2610 router.
Look for a network module in the slot labeled 1 on
the left-rear of the router. If there is an analog
modem network module already installed, continue
to cable the router as described in this guide.
If you need to install an analog modem network
module, follow this procedure:
1Use a Phillips screwdriver to remove the screws
that hold the metal plate over the network
module slot cover and remove the metal
covering plate.
2Holdthenetworkmodule by the handle and line
the module up with the guides on either side of
the slot.
3Push the module into place until the edge
connector is securely seated in the connector on
the motherboard. Ensure that each of the
module’scaptivescrewsline upwiththeirholein
the chassis.
4Secure the captive mounting screws into the
holes of the chassis using a Phillips screwdriver.

5
Connect the Ethernet Cable
Position the router so you can reach the rear panel.
The cables and the router’s ports are color-coded to
help you make the right connections.
1Connect one end of the yellow Ethernet cable
into the yellow Ethernet 10BaseT (RJ-45) port
labeled ETHERNET 0/0 on the rear panel of
your router.
2Connect the other end of the yellow Ethernet
cable into any available port on your 10BaseT
hub or switch (not included).
3Make sure a PC (running Windows NT 4.0 or
Windows 95) is connected to the Ethernet LAN.
You will use this computer in the procedure on
page 9 to run Cisco Fast Step software to
configure the router.
2Connect Cables (continued)
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2A/S
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2T
AUX
CONSOLE
ETHERNET 0 ACT
LINK
100-240V– 1A
50/60 Hz 47 W
10BaseT cable
Ethernet 10BaseT
port (RJ-45)
Ethernet hub
(sold separately)
MODEMS
EN
IN USE
IN USE
16AM
15 14 13 12 11 10 98
76543210

6
2Connect Cables (continued)
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2A/S
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2T
AUX
CONSOLE
ETHERNET 0LINK
100-240V– 1A
50/60 Hz 47 W
Console port
(RJ-45)
RJ-45-to-DB-9 or
RJ-45-to-DB-25 adapter
MODEMS
EN
IN USE
IN USE
16AM
15 14 13 12 11 10 98
76543210
Connect the Console Cable
1Connect the light-blue console cable to the
light-blue port labeled CONSOLE on the rear
panel of the router.
2Connect the other end of the light-blue console
cable to an RJ-45 adapter.
Use either the RJ-45-to-DB-9 adapter or the
RJ-45-to-DB-25 adapter, depending on your
local PC.
3Attach the adapter to a serial port on the PC
running Windows NT 4.0 or Windows 95.

7
2Connect Cables (continued)
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2A/S
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2T
AUX
CONSOLE
ETHERNET 0LINK
100-240V– 1A
50/60 Hz 47 W
MODEMS
EN
IN USE
IN USE
16AM
15 14 13 12 11 10 98
76543210
RJ-11 jack
RJ-11 modem cable
Analog modem
port (RJ-11)
Connect the Modem Cables
The Cisco 2610 router comes with an 8- or 16-port
internal analog modem module. Use these ports to
connect up to 16 modems.
1Connectone endofthe pinkmodemcable toone
of the numbered modem ports (also pink) on the
router’s rear panel.
2Connect the other end of the pink modem cable
to an RJ-11 telephone wall jack or an RJ-11
outlet in your wiring closet.
Timesaver Start by connecting only one
modem. After you have configured the
router settings for this modem and
completed the procedure on page 9
successfully, connect and set up the
remaining modems.
12
6
93
If you followed the suggestion, in the Timesaver
section on this page, and only connected one cable,
you will have to connect the remaining modem
cables after you configure and test the router. See
page 10, for information on how to finish the
cabling.

8
2Connect Cables (continued)
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2A/S
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN WIC
2T
AUX
CONSOLE
ETHERNET 0 ACT
LINK
100-240V– 1A
50/60 Hz 47 W
Power outlet
Power switch
MODEMS
EN
IN USE
IN USE
16AM
15 14 13 12 11 10 98
76543210
Connect Power and
Turn On the Router
1Connect one end of the black power cord to the
power connector on the router’s rear panel.
2Connect the other end of the power cord to an
electrical outlet.
3Turn ON the power switch on the rear panel.
ThegreenPower LEDontherouter’s frontpanel
blinks, as the router initializes, then stays on
when fully initialized. (It might take a moment
before this light goes on.)
4Perform a quick visual inspection to ensure the
following:
—Therouterispluggedin,thepoweristurned
on, and the Power LED on the front panel
displays a solid green light. (If not, you
cannot install the Cisco Fast Step software.)
—The link LED (labeled LNK) next to the
Ethernetport,displays asolidgreenlight.(If
this is not a solid light, check your cabling.)
—Each modem port you are currently setting
up has a pink modem cable connected to it.
—Each pink modem cable connected to a
modem port is also connected to an RJ-11
telephone wall jack or outlet.
You are now finished cabling the router and one or
more modems. The next section explains how to run
Cisco Fast Step software so you can use the router in
your network.

9
3Run Cisco Fast Step
InstallandRunCiscoFastStep
1InserttheCiscoFastStepCD-ROM(attachedto
inside back cover of this guide) into the
CD-ROM drive of the local PC to which you
connected the LAN on page 5.
2The Fast Step install program starts Setup.exe
automatically. If it does not, follow these steps:
(a) Double-click the My Computer icon.
(b) Double-click the CD icon.
(c) Double-click the Setup.exe icon.
The install program prompts you for the
information it needs to install Cisco Fast Step,
then copies the software onto your hard drive.
Timesaver Cisco Fast Step software
prompts you for network information
according to the routing protocols you
select. Before you run the software, make
sureyouhavethisinformationavailableor
know where to get it (usually from the
network administrator).
For your convenience, a form prompting
you for setup information is on page 11.
12
6
93
Set Up the Router
Using Fast Step
Once installed, the Cisco Fast Step Setup program
starts automatically. Follow the onscreen
instructions to guide you through configuring and
testing the router.
Verify Connectivity
Performthis testtoverifythemodemconnectionand
the router configuration are good. This section
assumestheremote PCyouareusingfor thetestruns
Windows NT 4.0 or Windows 95.
1Double-click the My Computer icon on the
desktop of the remote PC.
2Double-click the Dial-Up Networking folder. (If
youdo not find this folder, refer to the Microsoft
documentation to install the software.)
3Double-click the Make New Connection icon.
4Follow the onscreen instructions to create and
name a new connection icon to test the modem
connection and the router configuration. When
prompted for the area code and telephone
number, enter the appropriate number of the
modem you are testing.
5Double-click the new connection icon you
created in Step 4 and enter the username and
password (as defined when setting up Fast Step).
Verify that the telephone number is the correct
number for the modem you are testing.
6Go to page 10 to connect the remaining modem
cables, if necessary.

10
Thissection applies only if your areconnecting more
than one modem.
If you connected one modem in the procedure on
page 7, you are now ready to cable the rest of your
modems. How you do this depends on the way you
organize your workspace and your own personal
preferences.
The following suggested procedure helps you
simplify the job by keeping the connections neat and
orderly and by providing a reliable process.
1Make sure you can reach the router’s rear panel.
2Pick up a pink modem cable and connect one
end into one modem port (also pink) of the
access server.
3Repeat Step 2 with the remaining pink modem
cables.
4Connect the other end of each of the pink
modem cables from Step 3 into an RJ-11 wall
jack or into an RJ-11 outlet in your wiring
closet.
5Tie-wrap your cable bundles.
6To help with maintenance and troubleshooting,
write down the access server port number and
telephone wall jack for each modem. Keep this
record in a safe place.
4Finish the Cabling

11
5Network Information - Optional
This appendix is provided to help you gather and organize the information you need to run the Cisco Fast Step
software on page 9.
Login/Security Information
Router name:
Router password (for read-only access):
Super secret password (for read/write access):
IP Routing
LAN-Side IP Address
IP address:
Subnet mask:
Dial-In-Side IP Address
Specify the starting range (up to 16 in range) or IP
address list.
Range start:
Note: You can also enter a list of dial-in addresses
instead of a range, or you can specify DHCP.
IP address list:
Internet router IP address (optional):

12
5Network Information - Optional (continued)
IPX Routing
IPX network number of LAN side of router:
IPX Frame type (802.3, 802.2, Ethernet II, or SNAP):
ARAP Routing
ARAP network number:
Zone name:
Cable range start:
Cable range end:
Type of Security
User list user IDs:
User list password:
Cisco security server IP address:
Cisco security server key:

13

14

15

16

17

Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
European Headquarters
Cisco Systems Europe s.a.r.l.
Parc Evolic, Batiment L1/L2
16 Avenue du Quebec
Villebon, BP 706
91961 Courtaboeuf Cedex
France
http://www-europe.cisco.com
Tel: [phone]
Fax: [phone]
Americas
Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
Fax: [phone]
Asia Headquarters
Nihon Cisco Systems K.K.
Fuji Building, 9th floor
3-2-3 Marunouchi
Chiyoda-ku, Tokyo 100
Japan
http://www.cisco.com
Tel: [phone]
Fax: [phone]
Copyright © 1998 Cisco Systems, Inc. All rights reserved. Printed in USA. AccessPath, AtmDirector, the CCIE logo, CD-PAC, Centri, the Cisco Capital logo, CiscoLink, the Cisco NetWorks logo, the Cisco Powered
Network logo, the Cisco Press logo, ClickStart, ControlStream, DAGAZ, Fast Step, FireRunner, IGX, JumpStart, Kernel Proxy, LoopRunner, MGX, Natural Network Viewer, NetRanger, NetSonar, Packet, PIX,
Point and Click Internetworking, Policy Builder, RouteStream, Secure Script, SMARTnet, SpeedRunner, Stratm, StreamView, The Cell, TrafficDirector, TransPath, VirtualStream, VlanDirector, Workgroup Director,
and Workgroup Stack are trademarks; Changing the Way We Work, Live, Play, and Learn and Empowering the Internet Generation are service marks; and BPX, Catalyst, Cisco, Cisco IOS, the Cisco IOS logo,
Cisco Systems, the Cisco Systems logo, Enterprise/Solver, EtherChannel, FastHub, FastPacket, ForeSight, FragmentFree, IPX, LightStream, MICA, Phase/IP, StrataSphere, StrataView Plus, and SwitchProbe are
registered trademarks of Cisco Systems, Inc. in the U.S. and certain other countries. All other trademarks mentioned in this document are the property of their respective owners. 9805R
Cisco Systems has more than 200 offices in the following countries. Addresses, phone numbers, and fax numbers are listed on the
Cisco Connection Online Web site at http://www.cisco.com.
Argentina •Australia •Austria •Belgium •Brazil •Canada •Chile •China (PRC) •Colombia •Costa Rica •Czech Republic •Denmark
England •France •Germany •Greece •Hungary •India •Indonesia •Ireland •Israel •Italy •Japan •Korea •Luxembourg •Malaysia
Mexico •The Netherlands •New Zealand •Norway •Peru •Philippines •Poland •Portugal •Russia •Saudi Arabia •Scotland •Singapore
South Africa •Spain •Sweden •Switzerland •Taiwan, ROC •Thailand •Turkey •United Arab Emirates •United States •Venezuela
Printed in the USA on recycled paper containing 10% postconsumer waste.
DOC-785473=
78-5473-01
