Cisco 3745 User manual

Quick Start Guide
Cisco 3745 Router
INCLUDING LICENSE AND WARRANTY
1Cisco 90-Day Limited Hardware Warranty Terms
2Documents, Equipment, and Tools
3Install Chassis
4Connect Cables
5Power Up the Router
6Perform Initial Configuration
7Interface Numbering
8Where to Go Next
9Obtaining Documentation
10 Documentation Feedback
11 Cisco Product Security Overview
12 Product Alerts and Field Notices
13 Obtaining Technical Assistance
14 Obtaining Additional Publications and Information

2
1 Cisco 90-Day Limited Hardware Warranty Terms
The following are terms applicable to your hardware warranty. Your formal Warranty Statement, including the warranty
applicable to Cisco software, appears in the Cisco Information Packet that accompanies your Cisco product.
Duration of Hardware Warranty: Ninety (90) Days
Replacement, Repair or Refund Procedure for Hardware: Cisco or its service center will use commercially reasonable efforts to
ship a replacement part within ten (10) working days after receipt of the RMA request. Actual delivery times may vary
depending on Customer location. Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.
To Receive a Return Materials Authorization (RMA) Number
Please contact the party from whom you purchased the product. If you purchased the product directly from Cisco, contact your
Cisco Sales and Service Representative
Complete the form below, and keep it for reference:
Product warranty terms and other information applicable to Cisco products are available at the following URL:
http://www.cisco.com/go/warranty
Consult the above website or your Cisco Sales and Service Representative for a complete listing of Cisco products and applicable warranties.
2 Documents, Equipment, and Tools
User Documentation
All the documents described here are available online on Cisco.com. To be sure of obtaining the latest information, you should
access the online documentation.
To view or print a document in its original page format, access the online document, and click on the PDF icon.
For information about accessing user documentation, see the “Where to Go Next” section on page 24.
Items Included with Cisco 3745 Routers
•Rack-mount brackets; ground lug; power cords
•RJ-45-to-DB-9 adapter cable for console connection
•RJ-45-to-DB-25 adapter cable for modem connection
•Ethernet cables for LAN interface (two)
•Cisco Information Packet
•Cisco 90 Day Limited Hardware Warranty Terms
•Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Regulatory Compliance and Safety Information document
•Cisco Router and Security Device Manager (SDM) Quick Start Guide document (if VPN bundle is installed on your router)
•Cisco 3745 Modular Routers Quick Start Guide (this document)
Product purchased from
Their telephone number
Product number and Serial number
Maintenance Contract number

3
Items Not Included
Individual items in this list may be required for your particular application:
•Screws for installing the chassis in a rack
•PC running terminal emulation software for administrative access, or modem for remote administrative access
•Cables for WAN and voice interfaces and for additional LAN interfaces
•Tools: Number 2 Phillips screwdriver; ESD-preventive wrist strap

4
3 Install Chassis
Safety Information
For safety information you need to know before working on your Cisco router, refer to the Cisco 2600 Series, Cisco 3600 Series,
and Cisco 3700 Series Regulatory Compliance and Safety Information document that accompanied this device.
Note To see translations of the warnings that appear in this publication, refer to the Cisco 2600 Series, Cisco 3600 Series,
and Cisco 3700 Series Regulatory Compliance and Safety Information document.
Warning Definition
Warning IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each
warning to locate its translation in the translated safety warnings that accompanied this device.
Statement 1071
SAVE THESE INSTRUCTIONS
Waarschuwing
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan
veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij
elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard praktijken
om ongelukken te voorkomen. Voor een vertaling van de waarschuwingen die in deze publicatie
verschijnen, dient u de vertaalde veiligheidswaarschuwingen te raadplegen die bij dit apparaat
worden geleverd.
Opmerking BEWAAR DEZE INSTRUCTIES.
Varoitus
TÄRKEITÄ TURVALLISUUTEEN LIITTYVIÄ OHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan. Ennen kuin
työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä vaaroista ja
tavanomaisista onnettomuuksien ehkäisykeinoista. Tässä asiakirjassa esitettyjen varoitusten
käännökset löydät laitteen mukana toimitetuista ohjeista.
Huomautus SÄILYTÄ NÄMÄ OHJEET
Attention
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant causer
des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des
dangers posés par les circuits électriques et familiarisez-vous avec les procédures couramment
utilisées pour éviter les accidents. Pour prendre connaissance des traductions d'avertissements
figurant dans cette publication, consultez les consignes de sécurité traduites qui accompagnent cet
appareil.
Remarque CONSERVEZ CES INFORMATIONS

5
Warnung
WICHTIGE SICHERHEITSANWEISUNGEN
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer Körperverletzung
führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie sich der mit
elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur Vermeidung von
Unfällen bewusst. Übersetzungen der in dieser Veröffentlichung enthaltenen Warnhinweise sind im
Lieferumfang des Geräts enthalten.
Hinweis BEWAHREN SIE DIESE SICHERHEITSANWEISUNGEN AUF
Avvertenza
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone.
Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai
circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti. Per le traduzioni
delle avvertenze riportate in questo documento, vedere le avvertenze di sicurezza che accompagnano
questo dispositivo.
Nota CONSERVARE QUESTE ISTRUZIONI
Advarsel
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette varselssymbolet betyr fare. Du befinner deg i en situasjon som kan forårsake personskade. Før
du utfører arbeid med utstyret, bør du være oppmerksom på farene som er forbundet med elektriske
kretssystemer, og du bør være kjent med vanlig praksis for å unngå ulykker. For å se oversettelser av
advarslene i denne publikasjonen, se de oversatte sikkerhetsvarslene som følger med denne enheten.
Merk TA VARE PÅ DISSE INSTRUKSJONENE
Aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. O utilizador encontra-se numa situação que poderá ser
causadora de lesões corporais. Antes de iniciar a utilização de qualquer equipamento, tenha em
atenção os perigos envolvidos no manuseamento de circuitos eléctricos e familiarize-se com as
práticas habituais de prevenção de acidentes. Para ver traduções dos avisos incluídos nesta
publicação, consulte os avisos de segurança traduzidos que acompanham este dispositivo.
Nota GUARDE ESTAS INSTRUÇÕES
¡Advertencia!
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular
cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los
procedimientos estándar de prevención de accidentes. Vea las traducciones de las advertencias que
acompañan a este dispositivo.
Nota GUARDE ESTAS INSTRUCCIONES
Varning!
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.
Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna
till vanliga förfaranden för att förebygga olyckor. Se översättningarna av de varningsmeddelanden som
finns i denna publikation, och se de översatta säkerhetsvarningarna som medföljer denna anordning.
OBS! SPARA DESSA ANVISNINGAR

6

7
Aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões
corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os
circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o número
da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de segurança
traduzidos que acompanham o dispositivo.
GUARDE ESTAS INSTRUÇÕES
Advarsel
VIGTIGE SIKKERHEDSANVISNINGER
Dette advarselssymbol betyder fare. Du befinder dig i en situation med risiko for legemesbeskadigelse.
Før du begynder arbejde på udstyr, skal du være opmærksom på de involverede risici, der er ved
elektriske kredsløb, og du skal sætte dig ind i standardprocedurer til undgåelse af ulykker. Brug
erklæringsnummeret efter hver advarsel for at finde oversættelsen i de oversatte advarsler, der fulgte
med denne enhed.
GEM DISSE ANVISNINGER

8

9
Warning This unit is intended for installation in restricted access areas. A restricted access area can be accessed only
through the use of a special tool, lock and key, or other means of security. Statement 1017
Warning Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and
watches). Metal objects will heat up when connected to power and ground and can cause serious burns or weld
the metal object to the terminals. Statement 43
Warning This equipment has been designed for connection to TN and IT power systems. Statement 1007
Warning To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage
(TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN ports
both use RJ-45 connectors. Use caution when connecting cables. Statement 1021
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of
a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if
you are uncertain that suitable grounding is available. Statement 1024
Warning Blank faceplates and cover panels serve three important functions: they prevent exposure to hazardous voltages
and currents inside the chassis; they contain electromagnetic interference (EMI) that might disrupt other
equipment; and they direct the flow of cooling air through the chassis. Do not operate the system unless all cards,
faceplates, front covers, and rear covers are in place. Statement 1029
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles on
modules (such as power supplies, fans, or cards); these types of handles are not designed to support the weight
of the unit. Statement 1032
Warning Ultimate disposal of this product should be handled according to all national laws and regulations. Statement 1040

10
Installing the Chassis
You can set the chassis on a desktop or install it in a rack. See the applicable instructions in the following sections:
•Rack-Mounting the Chassis, page 10
•Installing on a Desktop, page 11
Note Cisco 3745 routers are not designed for wall-mounting.
Rack-Mounting the Chassis
The standard accessory kit contains brackets for mounting the chassis in a 19-inch rack. You can order an optional accessory
kit with brackets and instructions for mounting the chassis in a 23- or 24-inch rack.
You can mount the chassis in the following ways:
•Front panel forward
•Back panel forward
•Center mount with either front or back panel forward
Attaching Brackets
Attach the mounting brackets to the chassis as shown in Figure 1, Figure 2, or Figure 3, using the screws provided in the bracket
kit. Attach the second bracket to the opposite side of the chassis. Use a number 2 Phillips screwdriver to install the bracket
screws.
Note Some 19-inch racks have power strips on the back vertical rails that block cable access to power supplies. Be sure to
choose an orientation that provides unrestricted access to the back panel.
Figure 1 Bracket Installation—Front Panel Forward
Cisco 3700
SERIES
63384

11
Figure 2 Bracket Installation—Back Panel Forward
Figure 3 Bracket Installation—Back Panel Forward, Center-Mount Rack
Note The brackets can also be installed with the front panel forward.
Installing the Chassis in a Rack
Install the chassis in the rack. Rack-mounting screws are not provided with the router. Use two screws for each side (supplied
with the rack).
Installing on a Desktop
Caution If you place the Cisco 3745 on a desktop, do not place anything on top of the router that weighs more than
10 pounds (4.5 kg). Excessive weight on top could damage the chassis.
Grounding the Chassis
You must connect the chassis to a reliable earth ground; the ground wire must be installed in accordance with local electrical
safety standards.
•For NEBS-compliant grounding, use AWG 6 (13 mm2) wire and the ground lug provided in the accessory kit.
•For NEC-compliant grounding, use AWG 14 (2 mm2) or larger wire and a user-supplied ring terminal.
63387
EN
V0
BANK 3 BANK 2 BANK 1 BANK 0
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLR E2 CTRLR E1
AL
LP
CD
EN
V0
BANK 3 BANK 2 BANK 1 BANK 0
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLR E2 CTRLR E1
AL
LP
CD
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN
WIC
2T
63388
EN
V0
BANK 3 BANK 2 BANK 1 BANK 0
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLR E2 CTRLR E1
AL
LP
CD
EN
V0
BANK 3 BANK 2 BANK 1 BANK 0
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLR E2 CTRLR E1
AL
LP
CD
SEE MANUAL BEFORE INSTALLATION
SERIAL 1
SERIAL 0
CONN CONN
WIC
2T

12
•For EN/IEC 60950-compliant grounding, use AWG 18 (1 mm2) or larger wire and a user-supplied ring terminal.
To connect the chassis to a reliable earth ground, perform the following steps:
Step 1 Strip one end of the ground wire to the length required for the ground lug or terminal.
•For the NEBS ground lug—approximately 0.75 in. (20 mm)
•For user-provided ring terminal—as required
Step 2 Crimp the ground wire to the ground lug or ring terminal, using a crimp tool of the appropriate size.
Step 3 Attach the ground lug or ring terminal to the chassis as shown in Figure 4 or Figure 5. For the ground lug, use the two
screws with captive locking washers provided. For a ring terminal, use one of the screws provided. Use a number 2
Phillips screwdriver, and tighten the screws to a torque of 8 to 10 in-lb (0.9 to 1.1 N-m).
Step 4 Connect the other end of the ground wire to a grounding point at your site.
Figure 4 NEBS-Compliant Chassis Ground Connection Using Ground Lug
Figure 5 Chassis Ground Connection Using Ring Terminal
72123
EN
V0
BANK4 BANK3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK4 BANK3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK 4 BANK3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK4 BANK 3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
SEEMANUALBEFOREINSTALLATION
SERIAL1
SERIAL0
CONNCONN
WIC
2T
SEEMANUALBEFOREINSTALLATION
SERIAL1
SERIAL0
CONNCONN
WIC
2T
SEEMANUALBEFOREINSTALLATION
DSU
56K
CD
AL
LP
RD
TD
Ground lug
attachment
103015
EN
V0
BANK4 BANK3 BANK2 BANK 1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK4 BANK3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK4 BANK 3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
EN
V0
BANK4 BANK3 BANK2 BANK1 BANK0
NM-HDV
VWIC
2MFT-E1
SEE
MANUAL
BEFORE
INSTALLATION
CTRLRE2CTRLRE1
AL
LP
CD
SEEMANUALBEFOREINSTALLATION
SERIAL1
SERIAL0
CONNCONN
WIC
2T
SEEMANUALBEFOREINSTALLATION
SERIAL1
SERIAL0
CONNCONN
WIC
2T
SEEMANUALBEFOREINSTALLATION
DSU
56K
CD
AL
LP
RD
TD
Ring terminal
attachment

13
4 Connect Cables
Warning Do not work on the system, or connect or disconnect cables during periods of lightning activity. Statement 1001
Caution To comply with Telcordia NEBS GR-1089-Core and EN 300386 requirements, you must use foil twisted-pair cable
that is properly grounded at both ends.
System Management Connections
The connections described in Table 1 provide system management access.
Power Connections
Warning Read the installation instructions before connecting the system to the power source. Statement 1004
Note The installation must comply with all required electrical codes applicable at the installation site.
Connecting Routers to AC Power
If your router uses AC power, connect it to a 15 A, 120 VAC (10 A, 240 VAC) circuit with overcurrent protection.
Note The input voltage tolerance limits for AC power are 85 and 264 VAC.
Warning AC connected units must have a permanent ground connection in addition to the power cable ground wire.
NEBS-compliant grounding satisfies this requirement. Statement 284
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than:
15A, 120VAC (10A, 240VAC). Statement 1005
Connecting Routers to DC Power
If your router has a DC-input power supply, follow the directions in this section for proper wiring.
Table 1 System Management Connections
Port Color Connected to: Cable
Console Light blue PC or ASCII terminal communication port (usually labeled COM) RJ-45-to-DB-9 adapter cable
Auxiliary Black Modem for remote access RJ-45-to-DB-25 adapter cable

14
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than:
20A, 60VDC. Statement 1005
Warning Use copper conductors only. Statement 1025
DC Wiring Requirements
A Cisco 3745 router with a DC-input power supply requires copper wire for the power connections. Table 2 summarizes the
wiring requirements.
Wiring Procedure for DC Input
To connect the router to a DC power source, perform the following steps:
Step 1 Remove power from the DC circuit. To ensure that power is removed from the DC circuit, locate the circuit breaker for
the DC circuit, switch the circuit breaker to the OFF position, and tape the circuit-breaker switch in the OFF position.
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Tip Secure all power cabling when installing this unit to avoid disturbing field-wiring connections.
Step 2 Strip the wires to the appropriate length for the terminals. The strip length is 1/8 to 3/16 inch (3 to 5 mm) for Molex
number 19073-0009 terminals and for AMP/Tyco number 52961 terminals.
Table 2 DC Wiring Requirements for Cisco 3745 Routers
Installed Power Supply DC Input
DC Input Wire
Size
Safety Ground
Wire Size Wire Terminal (Lug)
Overcurrent
Protection
Nominal 24/48 VDC1
Identified by the following printed
label:
1. The input voltage tolerance limits for nominal 24/48 V power supplies are 18 and 72 VDC.
24 - 36 V, 15 A AWG 12
(3.0 mm2)
AWG 12
(3.0 mm2),
minimum
Amp/Tyco No.
52961 or equivalent
20 A
maximum
36 - 60 V, 7 A AWG 12 or 14
(3.0 or 2.0 mm2)
AWG 12
(3.0 mm2),
minimum
For AWG 12:
Amp/Tyco No.
52961 or equivalent
For AWG 14: Molex
No. 19099-0017 or
equivalent
20 A
maximum
Nominal 48 VDC2
Identified by the following printed
label:
2. The input voltage tolerance limits for nominal 48 V power supplies are 38 and 72 VDC.
48 - 60 V, 10 A AWG 14 or 16
(2.0 or 1.2 mm2)
AWG 14
(2.0 mm2),
minimum
For AWG 14 or 16:
Molex No.
19099-0017 or
equivalent
20 A
maximum
100-240V 50/60Hz 10A
OR Input +/- 24-36 V 15 A
36-60 V 7 A
!
CISCO 3745
~
100-240V 50/60Hz, 10A
OR 48-60V , 10A
!
CISCO 3745
~

15
Step 3 Crimp the terminals onto the DC power input wires.
Warning When stranded wiring is required, use approved wiring terminations, such as closed-loop or spade-type with
upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the
insulation and conductor. Statement 1002
Step 4 Remove the plastic cover from the terminal block. Save it for reinstallation after you finish wiring.
Step 5 Connect the DC power input wires to the terminal block, as shown in Figure 6.
Warning The illustration shows the DC power supply terminal block. Wire the DC power supply as illustrated. The proper
wiring sequence is ground to ground, positive to positive, and negative to negative. The ground wire should always
be connected first and disconnected last. Statement 239
Warning An exposed wire lead from a DC-input power source can conduct harmful levels of electricity. Be sure that no
exposed portion of the DC-input power source wire extends from the terminal block plug. Statement 122
Caution Do not overtorque the terminal block screws. The recommended torque is 8.0 ±0.5 in-lb (0.9 ±0.05 N-m).
Figure 6 Terminal Block Connections for DC Input Power
Step 6 Install the plastic cover over the terminal block.
Warning The safety cover is an integral part of the product. Do not operate the unit without the safety cover installed.
Operating the unit without the cover in place will invalidate the safety approvals and pose a risk of fire and
electrical hazards. Statement 117
Step 7 Secure the wires using cable ties.
Step 8 If your router has a second power supply installed, repeat Step 1 through Step 7 for the second power supply.
Step 9 Turn on power to the DC circuit.
Connecting Routers to the Cisco Redundant Power System
If your router uses the Cisco Redundant Power System (RPS), refer to the Cisco RPS Hardware Installation Guide for
instructions about the power connections.To locate these documents, see the “Where to Go Next” section on page 24.
103041
0V (return)
Positive polarity input
Safety ground
0V (return)
Negative polarity input
Safety ground
Negative DC input Positive DC input

16
WAN, LAN, and Voice Connections
The connections and cables listed here are described in detail in the following documents:
•Cisco 3700 Series Hardware Installation Guide
•Cisco Network Modules Hardware Installation Guide
•Cisco Interface Cards Installation Guide
•Cisco Modular Access Router Cable Specifications
For information about accessing these documents, see the “Where to Go Next” section on page 24.
Table 3 summarizes some typical WAN, LAN, and voice connections for Cisco 3745 routers.
Table 3 WAN, LAN, and Voice Connections
Port or Connection Port Type, Color Connected to: Cable
FastEthernet RJ-45, yellow, Ethernet hub or switch Straight-through Ethernet
T1/E1 WAN RJ-48C/CA81A, blue T1 or E1 network RJ-48 T1
Cisco serial 60-pin D-sub CSU/DSU and serial network or
equipment
Cisco serial transition cable that matches
the signaling protocol (EIA/TIA-232,
EIA/TIA-449, V.35, X.21, or
EIA/TIA-530) and the serial port operating
mode (DTE or DCE).1
1. See the Cisco Modular Access Router Cable Specifications document for information about selecting these cables.
Cisco Smart serial Cisco Smart compact
connector, blue
CSU/DSU and serial network or
equipment. For WIC-2T and
WIC-2A/S only
DSL RJ-11C/CA11A,
lavender
Network demarcation device for
service provider’s DSL interface
RJ-11
T1 digital voice RJ-48C/CA81A, tan Digital PBX RJ-48 T1 cable
Analog voice FXS RJ-11, gray Telephone, fax RJ-11
Analog voice FXO RJ-11, pink Central office, analog PBX RJ-11
Analog voice E&M RJ-11, brown Analog PBX RJ-11
BRI S/T WAN
(external NT1)
RJ-48C/CA81A, red NT1 device or private integrated
network exchange (PINX)
RJ-48
BRI U WAN
(built-in NT1)
RJ-49C/CA-A11,
orange
ISDN network RJ-49
CT1/PRI T1 External T1 CSU DB-15 T1 serial cable
CT1/PRI-CSU T1 RJ-48C/CA81A interface RJ-48 straight-through
CE1/PRI E1 E1 network DB-15 to BNC, DB-15 to DB-15,
DB-15 to twinax, or DB-15 to RJ-45
56/64-kbps DSU/CSU 8-pin modular, blue RJ-48S interface RJ-48 straight-through

17
5 Power Up the Router
Checklist for Power-Up
You are ready to power on the Cisco router if the following steps are completed:
•The chassis is securely mounted.
•Power and interface cables are connected.
•Your PC terminal emulation program is configured for 9600 baud, 8 data bits, 1 stop bit, and no parity.
•You have selected passwords for access control.
•You have determined the IP addresses for the Ethernet and serial interfaces.
Front Panel Indicators
The following indicator LEDs provide power, activity, and status information:
•SYS—System status:
– Blinking green during boot-up—System is booting
– Continuous green—System booted and OK
– Blinking green continuing after boot-up—System is in ROM monitor mode
– Amber—System malfunction
•ACT—Activity:
– Blinking or continuous green during system activity, such as interrupts and packet transfers
•SYS PS1 or SYS PS2—Chassis power supply number 1 or number 2 status:
– Off—Powered off, not installed, or faulty
– Continuous green—Installed and operating
– Amber—Installed and powered off or faulty
•–48V PS1 or –48V PS2—IP power module number 1 or number 2 status:
– Off—Faulty or not installed
– Continuous green—Installed and operating
– Amber—Installed and powered off or faulty
Power-Up Procedure
To power up your Cisco router and verify that it goes through its initialization and self-test, perform this procedure. When the
power-up procedure is finished, the Cisco router is ready to be configured.
Note To view the boot sequence through a terminal session, you must have a console connection to the Cisco router before
it powers on.
Step 1 Make sure that your PC is powered up and connected as described in the “Checklist for Power-Up” section.
Step 2 Move the power switch to the ON position. The fan operates, and the SYS PS LED is continuous green for each power
supply that is in use. The SYS LED blinks while the system boots, and it is continuous green after the system boots. If
this does not happen, see the power-on procedure in the Cisco 3700 Series Hardware Installation Guide.
Note If no Cisco IOS image is loaded on the Cisco 3745, the router enters ROMMON mode, and the system LED blinks.

18
Messages begin to appear in your terminal emulation program window.
Caution Do not press any keys on the keyboard until the messages stop. Any keys pressed during this time are interpreted
as the first command typed when the messages stop, which might cause the router to power off and start over. It
takes a few minutes for the messages to stop.
You may see different startup messages:
•If you see the following messages, the router has booted with a configuration file and is ready for initial configuration using
the Cisco Router and Security Device Manager (SDM):
yourname con0 is now available
Press RETURN to get started.
See the “Initial Configuration Using Cisco Router and Security Device Manager” section on page 19 to learn how to
configure your router using SDM or to learn how to obtain SDM and install it on your router.
•If you see the following messages, the router has booted and is ready for initial configuration using the setup command
facility or the command-line interface (CLI).
--- System Configuration Dialog ---
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
Would you like to enter the initial configuration dialog? [yes/no]:
To learn how to use the setup command facility to configure the router, see the “Initial Configuration Using the Setup
Command Facility” section on page 19. To learn how to use the CLI to configure the router, see the “Initial Configuration
Using the CLI (Manual Configuration)” section on page 21.
Note If the rommon 1> prompt appears, your system has booted in ROM monitor mode. For information on the ROM
monitor, see the router rebooting and ROM monitor information in the Cisco IOS Configuration Fundamentals
Configuration Guide for your Cisco IOS software release.
You can access this document at the locations described in the “Where to Go Next” section on page 24.
6 Perform Initial Configuration
You can configure your router by using one of the following methods:
•Cisco Router and Security Device Manager (SDM)—If your router was purchased with a VPN bundle, SDM is installed on
the router. For instructions on configuring your router by using SDM, refer to the Cisco Router and Security Device
Manager (SDM) Quick Start Guide that shipped with your router. See the “Initial Configuration Using Cisco Router and
Security Device Manager” section on page 19 for additional information.
•Setup command facility—You can use the setup command facility to configure basic router information. After the
configuration file has been created, you can use the CLI or SDM to perform additional configuration. See the “Initial
Configuration Using the Setup Command Facility” section on page 19 for additional information.
•Command-line interface (CLI)—If you prefer to use the Cisco IOS CLI, see the “Initial Configuration Using the CLI
(Manual Configuration)” section on page 21 for instructions on how to use the CLI.
Note You need to understand how interfaces are numbered so that you know which interface you are configuring. If you need
help with interface and port numbering, see the “Interface Numbering” section on page 22.

19
Initial Configuration Using Cisco Router and Security Device Manager
If the following messages appear at the end of the startup sequence, Cisco Router and Security Device Manager (SDM) is
installed on your router:
yourname con0 is now available
Press RETURN to get started.
For instructions on configuring your router by using SDM, refer to the Cisco Router and Security Device Manager (SDM) Quick
Start Guide.
Tip If the messages above do not appear, SDM and the Cisco Router and Security Device Manager (SDM) Quick Start Guide
were not shipped with your router. If you want to use SDM, you can download the latest version of SDM and
instructions for installing it on your router from the following location:
http://www.cisco.com/pcgi-bin/tablebuild.pl/sdm
To obtain the SDM quick start guide, SDM release notes, and other SDM documentation, go to www.cisco.com/go/sdm
and click the Technical Documentation link.
Initial Configuration Using the Setup Command Facility
This section shows how to use the setup command facility to configure a hostname for the router, set passwords, and configure
an interface for communication with the management network. If you see the following messages at the end of the startup
sequence, the setup command facility has been invoked automatically:
--- System Configuration Dialog ---
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
Would you like to enter the initial configuration dialog? [yes/no]:
The setup command facility prompts you for basic information about your router and network, and it creates an initial
configuration file.The prompts vary, depending on your router model, the installed interface modules, and the software image.
The following example and the user entries (in bold) are shown as examples only.
For interface numbering information, see the “Interface Numbering” section on page 22.
Note If you make a mistake while using the setup command facility, you can exit and run the setup command facility again.
Press Ctrl-c, and enter setup at the privileged EXEC mode prompt (3700#).
Step 1 To proceed using the setup command facility, enter yes.
Would you like to enter the initial configuration dialog? [yes/no]: yes
Step 2 When the following messages appear, press Return to enter basic management setup:
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
Basic management setup configures only enough connectivity
for management of the system, extended setup will ask you
to configure each interface on the system
Would you like to enter basic management setup? [yes/no]: yes

20
Step 3 Enter a hostname for the router (this example uses 3745):
Configuring global parameters:
Enter hostname [Router]: 3745
The enable secret is a password used to protect access to privileged EXEC and configuration modes. This
password, after entered, becomes encrypted in the configuration.
Step 4 Enter an enable secret password. This password is encrypted (more secure) and cannot be seen when viewing the
configuration:
Enter enable secret: xxxx
The enable password is used when you do not specify an enable secret password, with some older software
versions, and some boot images.
Step 5 Enter an enable password that is different from the enable secret password. This password is not encrypted (less secure)
and can be seen when viewing the configuration:
Enter enable password: xxxx
The virtual terminal password is used to protect access to the router over a network interface.
Step 6 Enter the virtual terminal password, which prevents unauthenticated access to the router through ports other than the
console port:
Enter virtual terminal password: xxxx
Step 7 Respond to the following prompts as appropriate for your network:
Configure SNMP Network Management? [yes]: yes
Community string [public]:
Step 8 A summary of the available interfaces is displayed:
Note The interface numbering that appears is dependent on the type of Cisco modular router platform and on the
installed interface modules and cards.
Current interface summary
Controller Timeslots D-Channel Configurable modes Status
T1 3/0 24 23 pri/channelized Administratively up
T1 3/1 24 23 pri/channelized Administratively up
Any interface listed with OK? value "NO" does not have a valid configuration
Interface IP-Address OK? Method Status Protocol
FastEthernet0/0 unassigned NO unset up down
FastEthernet0/1 unassigned NO unset up down
Step 9 Select one of the available interfaces for connecting the router to the management network:
Enter interface name used to connect to the
management network from the above interface summary: fastethernet0/0
Step 10 Respond to the following prompts as appropriate for your network:
Configuring interface FastEthernet0/0:
Use the 100 Base-TX (RJ-45) connector? [yes]:
Operate in full-duplex mode? [no]: yes
Configure IP on this interface? [yes]:
IP address for this interface: 10.1.1.1
Subnet mask for this interface [255.0.0.0] : 255.255.0.0
Class A network is 10.0.0.0, 16 subnet bits; mask is /16
