Product Overview
This section contains the following:
•Product Overview, on page 1
•General Description, on page 1
•SKU Information, on page 2
•Cisco IR1101 Series Platform Features, on page 3
•Front Panel Icons and LEDs, on page 12
•Supported Cisco Antennas and Antenna Accessories, on page 14
•Modem Support, on page 14
•Power Supply, on page 17
•RJ45 Ports, on page 18
•Ethernet and Optical SFP Modules, on page 19
•DSL SFP Module, on page 20
Product Overview
This chapter provides an overview of the features available for the Cisco IR1101 Industrial Integrated Services
Router and its Expansion Module. It contains the following sections:
Prior to installing this device read the Regulatory Compliance and Safety Information .
Note
General Description
The Cisco IR1101 Industrial Integrated Services Router is a next generation modular industrial router which
has a base module with additional Pluggable Modules that can be added. The Pluggable Module provides the
flexibility of adding different interfaces to the IR1101 platform, for example, a cellular module.
The IR1101 ISR also has an Expansion Module that adds key capabilities such as dual LTE Pluggables,
mSATA SSD FRU, SFP, and Digital GPIO connections.
Product Overview
1

Figure 1: The IR1101 Industrial Integrated Services Router
SKU Information
The following table lists the different SKUs available for the Cisco IR 1101.
Table 1: Supported SKUs for Cisco IR1101
DescriptionSKU ID
IR1101 Base UnitIR1101-K9
Expansion Module with 1 GE SFP, 1 Pluggable Module, 1 Digital I/O Connector, and 1 mSATA SSD
Slot.
IRM-1100-SPMI
Expansion Module with 1 GE SFP and1 Pluggable Module.IRM-1100-SP
100 GB mSATA SSDIR1100-SSD-100G
Optional AC power adapter with 110/220V AC and 88-300V DC input (Temperature: -40C to 60C)PWR-IE50W-AC
Din rail kit and mounting screws for horizontal and vertical mountingIR1101-DINRAIL(=)
Din rail kit for the Expansion ModuleIRM-1100-DINRAIL
Wall mount kitIR1101-WALLMNT(=)
Product Overview
2
Product Overview
SKU Information

Cisco IR1101 Series Platform Features
This section describes the different components of the router.
Cisco IR1101 Base Router
The following lists the hardware platform features for the Cisco IR1101.
• External Power Entry
• Nominal: 12 to 48VDC
• Absolute min/max: 9.6 to 60VDC
• Typical current: 0.82A to 0.22A
• Maximum current: 0.91A to 0.28A
• 4-pin 3.8 mm EURO power connector
• External Reset/Recovery Push Button
• Gigabit Ethernet Combo RJ45+SFP connector.
• RJ45 connector will support IEEE802.3 Ethernet over copper wiring standards of 10Base-T,
100Base-TX, and 1000Base-T
• SFP port will support 1000Base-X or 100Base-FX Fiber Ethernet standard SFP
• LAN Ports
• 4x RJ45 10/100 Fast Ethernet
• Serial Port
• 1 x RJ45 RS232 Port (DTE)
• USB Ports
• 1x USB 2.0 Type A Host Port
• 1x USB 2.0 mini USB Type B console port
• Compliance
• Class A EMC or better
• IP30 compliant when vertical and ports downward
• Industrial temperature [-40ºC to +60ºC, 13.8Kft (operating), 15Kft (non-operating)]
• One alarm input
The following graphic shows the IR1101 ISR base router.
Product Overview
3
Product Overview
Cisco IR1101 Series Platform Features

Figure 2: Cisco IR1101 Industrial Integrated Services Router
The following graphics show the IR1101 Base Module Front.
Figure 3: Cisco IR1101 Integrated Services Router with USB covers in place
DetailsItem
USB 2.0 Port Cover1
Mini-USB Console Cover2
Product Overview
4
Product Overview
Cisco IR1101 Base Router

The following graphic shows the front panel details of the Cisco IR1101.
Figure 4: Cisco IR1101 Front Panel
Table 2:
SFP GE WAN1
USB 2.02
RJ45 GE WAN3
Serial Port4
FE LAN Ports 1-45
Grounding Point (on side of device)6
DC Power and Alarm Input7
Mini-USB Console8
Reset Button9
Pluggable Module10
Cisco IRM-1100-SPMI Expansion Module
The following graphic shows the IR-1100-SPMI Expansion Module.
Product Overview
5
Product Overview
Cisco IRM-1100-SPMI Expansion Module

Figure 5: IR-1100-SPMI Expansion Module
The following lists the hardware platform features for the Cisco IR-1100-SPMI:
• 1 GE SFP
• 1 Pluggable slot
• 1 Digital I/O connector
• 1 mSATA SSD slot
Figure 6: IR-1100-SPMI Expansion Module Details
Product Overview
6
Product Overview
Cisco IRM-1100-SPMI Expansion Module

4 GPIO + 1 Return (Digital I/O)1
SFP Connector2
Pluggable Module3
mSATA SSD Slot4
Digital I/O LEDs5
Digital I/O Connector
The Digital I/O connector has 4 GPIO connections plus 1 Return connection. The Digital I/O supports Both
Dry and Wet contacts up to 60Volts.
• Dry contact is isolated from a voltage source (or “No Volt”), with an embedded relay function (NPN
transistor), usually used to indicate an event. For example: open/close, alarm.
• Wet contact is a contact with external power (+3.3V to +60V, max 150mA of current allowed at high
voltage) applied, usually used to energize something. For example: solenoid, light.
The following graphic shows the connector.
Digital I/O is only supported on IOS-XE version 16.12.1 and above.
Note
The default state of the Digital I/O is input, the open-collector is open (off).
Note
Figure 7: Digital I/O connector
The pinouts for the Digital I/O are described in the following table.
Table 3: Digital I/O Pinouts
DescriptionDirectionNamePin
#
Digital IO 1I/ODIO11
Digital IO 2I/ODIO22
Digital IO 3I/ODIO33
Product Overview
7
Product Overview
Digital I/O Connector

DescriptionDirectionNamePin
#
Digital IO 4I/ODIO44
Digital IO Common ReturnReturnReturn5
Digital Input and Output Specifications are described in the following tables.
Digital Input Specification is considered “dry contact”, and Digital Output Specification is considered “wet
contact”.
Table 4: Digital Input Specification
UnitMaximumMinimumSpecification
Volts602.2Input Voltage High
Volts1.2-Input Voltage Low
uA0.68mA
Note1
-Input Current
Note1: Current is flowing out of the terminal although it is an input, i.e. sourcing. The current is flowing in
the terminal for the output, i.e. sinking.
Table 5: Digital Output Specification
NotesUnitMaximumMinimumSpecification
No external voltage
applied.
Volts2.5Output Voltage High
No external voltage
applied.
Volts0.4-Output Voltage Low
Ohms3.3K – 1%3.3K – 1%Internal Pull-up
Resistance
Volts3-Internal Pull-up Voltage
External resistance
required to limit current
to 200mA.
Volts603.3External Pull-up Voltage
mA200Sink Current
Common features of the Digital I/O are:
• Withstands up to 60V applied at the terminal.
• Reverse voltage protected and causes no damage to the equipment.
• Digital input and output can coexist on different channel.
Product Overview
8
Product Overview
Digital I/O Connector

• LED Indicator: provision-able, On: Active, Off: Non-active.
• Electrical isolation: 2000 VDC.
• 4kV Surge protected (IEC 61000-4-5).
IR-1100-SPMI Expansion Module LEDs
There are 6 LEDs in the Expansion Module. Four LEDs show the status of digital input and output. One LED
shows the SFP port status and one LED shows the mSATA status. The LED behavior is shown in the following
table.
Table 6: Expansion Module LEDs
DefinitionLED
Off - InactiveSolid Yellow- ActiveDigital I/O as Input
Off - InactiveSolid Yellow- ActiveDigital I/O as Output
Off - No LinkSolid Yellow - Port link with no activityFlashing Yellow - Port link healthy with activitySFP
Off - Not powered on or no activityFlashing Green - mSATA being accessedmSATA
Cisco IR-1100-SP Expansion Module
The IR-1100-SP Expansion Module is the same as the IR-1100-SPMI module, without the Digital I/O and
mSATA components.
The following lists the hardware platform features for the Cisco IR-1100-SP:
• 1 GE SFP (see the supported list of SFP’s here: SFP Module, page 26 )
• 1 Pluggable slot
Cisco Pluggable Module
The Pluggable Module provides the flexibility of adding different interfaces to the IR1101 platform, for
example, a cellular module.
Pluggable LTE Module
Highlights of the LTE Pluggable Module are:
• All Cellular interfaces are supported through a Pluggable Module
• Micro-Sim, 3FF size. Cisco recommends Industrial Temp micro SIMs that are rated from -40C to +105C.
The following two figures show an example of a Pluggable Module. In this case, the LTE Pluggable Module.
Product Overview
9
Product Overview
IR-1100-SPMI Expansion Module LEDs

Figure 8: LTE Pluggable Module (front)
LTE-Main SMA1
GPS SMA2
Micro USB Debug Port3
LTE-Div SMA4
Figure 9: LTE Pluggable Module (with antennas)
LTE Category 18 Pluggable Module
This module has a new smaller form factor SMA Diversity Antenna for usability and Micro-USB port access.
Product Overview
10
Product Overview
LTE Category 18 Pluggable Module

The P-LTEAP18-G pluggable module must be installed in the IR1101 Base. It cannot be used in the IRM-1100
Expansion Module.
Note
Figure 10: LTE Pluggable - P-LTEAP18-GL
DescriptionItem
Main 0 Antenna1
Diversity 1 Antenna2
Diversity 0 Antenna3
Main 1 Antenna4
Micro USB Debug Port5
Installing or replacing the SIM modules is covered in Pluggable Module
P-LTEAP18-GL Frequency Bands
The following table provides the global frequency bands available.
Antennas must be attached to the RF connectors as listed below for proper bands service.
Note
DescriptionItem
B1, B2(B25), B3, B4(B66), B5(B26,B18,B19), B8, B12(B17), B13, B14,
B20, B28, B29, B39, B71, B41
MAIN 0 and DIV 0
B7, B30, B32, B38, B40, B41, B42, B46, B48, B2(B25)MAIN 1 and DIV 1
Product Overview
11
Product Overview
LTE Category 18 Pluggable Module

mSATA Module
Mini-SATA, or mSATA, is a low-profile interface connector that enables more effective Serial ATA (SATA)
integration in small form-factor drives roughly the size of a business card, such as solid state disks (SSDs).
The mSATA Pluggable Module plugs into the IR-1100-SPMI Expansion Module. The following figure shows
the mSATA Pluggable Module.
Figure 11: mSATA Pluggable Module
Highlights of the mSATA Pluggable Module are:
• Provides an additional 100GB of additional flash memory storage
• Main purpose is to provide space to store application data for IOx
• Field Replaceable unit, but is not hot-swappable.
Front Panel Icons and LEDs
The IR1100 Series uses icons to show the different features of the device. The following two tables provide
details.
Table 7: Icons with LEDs
Description/ActivityIconDescription/ActivityIcon
Alarm - Alarm Input Status
Off — Normal operation
Red - Alarm State on the Alarm Input
System - Power and System Status.
Off — No power
Green Steady on — Normal operation
Green Flashing — Boot up phase or in ROM Monitor
mode
Amber Steady on — Power is OK but possible internal
failure
Product Overview
12
Product Overview
mSATA Module

Description/ActivityIconDescription/ActivityIcon
Red, Green, and Blue User Configurable
LED
VPN
Off — No VPN tunnel
Steady Green — At least one VPN tunnel is up
RJ45 Fast Ethernet Ports -Link Status 0:1
Off — No link
Steady Green — Link is up
Flashing — Transmitting and Receiving
data
Gigabit Ethernet Combo Port
Off — No Link
Solid Green — Copper Link up, no activity
Flashing Green — Copper Link up, with activity
Solid Amber — SFP Link up, no activity
Flashing Amber — SFP Link up, with activity
Digital I/O
Off - InactiveSolid Yellow- Active
mSATA Storage
Off - Not powered on or no activityFlashing Green -
mSATA being accessed
Table 8: Icons only
DescriptionIconDescriptionIcon
USB 2.0 Type A Port for Storage and NetworkingUSB 2.0 Console Mini-B Connector
Reset ButtonGrounding point (located on side of device)
DC Power ReturnDC Power Input (12V to 48V)
Alarm INAlarm Return
Product Overview
13
Product Overview
Front Panel Icons and LEDs

DescriptionIconDescriptionIcon
WarningSerial Ports
Expansion Module (Bottom or Right side)Expansion Module (Top or Left side)
Memory
The Cisco IR1101 uses flash memory and main memory. The flash memory contains the Cisco OS software
image and the boot flash contains the ROMMON boot code. The memory includes:
• 4 GB DRAM (soldered down)
• 4 GB onboard flash memory
Reset Button
The Reset button resets the router configuration to the default configuration set by the factory. To restore the
router configuration to the default configuration set by the factory, use a standard size #1 paper clip with wire
gauge 0.033 inch or smaller and simultaneously press the reset button while applying power to the router.
Supported Cisco Antennas and Antenna Accessories
The IR1101 must have a Pluggable Module with antenna ports installed in order to connect antennas. The
base unit does not have any wireless capabilities on its own.
The Antenna Selection and Installation chapter lists the supported Antennas and Accessories for the Cisco
IR1101 with a wireless Pluggable Module. For detailed information about Cisco Antennas for the Industrial
Routers, please refer to the following guide:
Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide:
http://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing-combined/industrial-routers-and-industrial-wireless-antenna-guide.html
Modem Support
The Cisco IR1101 wireless Pluggable Module uses the Sierra Wireless series modems. The software download
page can be found here:
https://software.cisco.com/download/navigator.html?mdfid=286288566&flowid=76082
The following tables provide the technology details for the modems.
Product Overview
14
Product Overview
Memory

Table 9: Modem Technology Supported
Technology SupportedDescriptionModem UsedSKU ID
LTE CAT4: B4, B13U.S. (Verizon) Single
Micro SIM
WP7601-GP-LTE-VZ
LTE CAT4:B2,B4,B5,B12
3G UMTS DC-HSPA+, HSPA+, HSPA,
WCDMA: B2,B4, B5
North America (AT&T)
Dual Micro SIM
WP7603-GP-LTE-US
LTE CAT4: B1, B3, B8, B11, B18, B19, B21
3G UMTS HSPA+
JapanWP7605-GP-LTE-JN
LTE CAT4: B1,B3, B7, B8, B20, B28
3G UMTS DC-HSPA+, HSPA+, HSPA,
WCDMA
GPRS/EDGE: 900/1800
Europe Dual Micro SIMWP7607-GP-LTE-GB
LTE CAT4: B1, B3, B5, B8, B40, B41*
3G UMTS DC-HSPA+
* B41 supported frequency range: (2535–2655
MHz)
India and ChinaWP7608-GP-LTE-IN
LTE CAT4: B2, B4, B5, B12, B13, B14, B17,
B66
3G UMTS DC-HSPA+, HSPA+, HSPA,
WCDMA
North AmericaWP7610-GP-LTE-MNA
Product Overview
15
Product Overview
Modem Support

Technology SupportedDescriptionModem UsedSKU ID
Multimode LTE 3.0 for carriers that operate
FDD LTE 700-MHz (band 28), 850-MHz
(band 5 CLR), 850-MHz (bands 18 and 19
Low), 900-MHz (band 8), 1500-MHz (band
21), 1800-MHz (band 3), 2100-MHz (band 1),
or 2600-MHz (band 7) networks; the
multimode Cisco LTE Advanced 3.0 NIMs
are backward-compatible with UMTS and
DC-HSPA+: 800 MHz (band 19 Japan), 850
MHz (band 5), 850 MHz (band 6 Japan), 900
MHz (band 8), 1800 MHz (band 9), 2100 MHz
(band 1), and TD-SCDMA 39.
Multimode LTE Advanced 3.0 for carriers that
operate TDD LTE 1900 MHz (band 39), 2300
MHz (band 40), 2500 MHz (band 41), or 2600
MHz (band 38).
Multimode LTE Advanced 3.0 for carrier
aggregation band combinations:
1+(8,18,19,21); 3+(5,7,19,28); 7+(5,7,28);
19+21, 38+38, 39+39, 40+40, and 41+41.
APACEM7430P-LTEA-LA
Multimode LTE Advanced 3.0 for carriers that
operate FDD LTE 700-MHz (band 12),
700-MHz (band 29), 800-MHz (band 20),
850-MHz (band 5 CLR), 850-MHz (bands 26
Low), 900-MHz (band 8), 1800-MHz (band
3), 1900-MHz (band 2), 1900-MHz (PCS band
25), 1700-MHz and 2100-MHz (band 4 AWS),
2100-MHz (band 1), 2300-MHz (band 30), or
2600-MHz (band 7) networks. The multimode
Cisco LTE Advanced 3.0 NIMs are backward
compatible with Universal Mobile
Telecommunications Service (UMTS) and
Dual-Carrier High-Speed Packet Access Plus
(DC-HSPA+): 850-MHz (band 5), 900-MHz
(band 8), 1800-MHz (band 3), 1900-MHz
(band 2), 1700-MHz and 2100-MHz (band 4
AWS), and 2100-MHz (band 1).
Multimode LTE Advanced 3.0 for carriers that
operate TDD LTE 2500-MHz (band 41).
Multimode LTE Advanced 3.0 for carrier
aggregation band combinations: 1+8;
2+(2,5,12,13,29); 3+(7,20); 4+(4,5,12,13,29);
7+(7,20); 12+30, 5+30, and 41+41.
USA, Canada, Europe,
Latin America
EM7455P-LTEA-EA
Product Overview
16
Product Overview
Modem Support

Technology SupportedDescriptionModem UsedSKU ID
LTE bands 1-5, 7, 8, 12-14, 17, 18-20, 25, 26,
28-30, 32, 38-43, 46, 48, 66, and 71.
FDD LTE 600 MHz (band 71), 700 MHz
(bands 12, 13, 14, 17, 28, and 29), 800 MHz
(band 20), 850 MHz (bands 5, 18, 19, and 26),
900 MHz (band 8), 1500 MHz (band 32), 1700
MHz (bands 4 and 66), 1800 MHz (band 3),
1900 MHz (bands 2 and 25), 2100 MHz (band
1), 2300 MHz (band 30), 2600 MHz (band 7).
TDD LTE 1900 MHz (band 39), 2300 MHz
(band 40), 2500 MHz (band 41), 2600 MHz
(band 38), 3500 MHz (bands 42 and 48), 3700
MHz (band 43), 5200 MHz (band 46).
United States, Europe,
Canada, Japan, Australia
and New Zealand.
LM960AP18P-LTEAP18-GL, Cisco
LTE Advanced Pro
Pluggable 3GPP Category
18
Supported only
in the IR1101
Base Unit. Not
supported in the
IRM-1100
Expansion
Module.
Note
GNSS is not
supported on the
CAT18 module.
Note
Table 10: GNSS Technology Support
SupportReceive (Rx) Band MHzRF BandTechnology
Supported1575.42 +/- 1.023GPSGNSS
Not
Supported
1597.52 - 1605.92GLONASS
Not
Supported
1575.42 +/- 2.046Galileo
Not
Supported
1561.098 +/- 2.046BeiDou
Power Supply
The Cisco IR1101 comes with an external DC power connector. The 4-pin power entry connector (receptacle)
is mounted to the unit. The 4-pin power entry mating connector (plug) is attached to the receptacle. It is
removed during installation and used to connect to the DC power source, then reattached to provide power
to the unit.
Product Overview
17
Product Overview
Power Supply

Figure 12: Power Connector Pin-Outs
DescriptionNamePin
Number
DC Power Positive InputDC In +1
DC Power ReturnDC In -2
Alarm CommonALM
REF
3
Alarm InputALM IN4
RJ45 Ports
The IR1101 supports one ISOLATED RS232 port which conforms to EIA-561 standard.
The RJ45 pinouts are shown in the following graphic.
Figure 13: S0 Characteristics
The RS232 port is a DTE and its pin out is shown in the following table.
Table 11: S0 Details
DTEAbbreviationDescriptionPin Number
<—DSR/RIDCE Ready, Ring Indicator1
<—DCDReceived Line Signal Detector2
Product Overview
18
Product Overview
RJ45 Ports

DTEAbbreviationDescriptionPin Number
—>DTRDTE Ready3
COMSignal Ground4
<—RxDReceived Data5
—>TxDTransmitted Data6
<—CTSClear To Send7
—>RTSRequest To Send8
Ethernet and Optical SFP Modules
The IR1101 Ethernet and Optical SFP modules provide connections to other devices. These field-replaceable
transceiver modules provide the uplink interfaces. The Ethernet and Optical modules can be either copper or
optical. Details are in the two tables listed below.
The Local connectors (LCs) provide the fiber-optic connection. RJ-45 connectors allow copper connections.
You can use any combination of the supported SFP modules listed in the table that follows.
The IR1101 is designed to operate in the Industrial temperature range (-40C to +85C internal component
temperature range) and therefore cannot support commercial rated SFPs.
Note
Table 12: Supported Gigabit SFPs
DOMIndustrial
-40C to
+85C
Extended
-5C to
+85C
Commercial
0C to +70C
FiberDistanceGE SFP
YESMMF220-550 mGLC-SX-MM-RGD
YESMMF/SMF550m/10 kmGLC-LX-SM-RGD
YESYESSMF70 kmGLC-ZX-SM-RGD
YESYESMMF220-550 mSFP-GE-S
YESYESMMF/SMF550 m/10 kmSFP-GE-L
YESYESSMF70 kmSFP-GE-Z
Product Overview
19
Product Overview
Ethernet and Optical SFP Modules

Table 13: Supported FE SFPs
DOMIndustrial
-40C ~
+85C
Extended
-5C ~
+85C
Commercial
0C ~ +70C
FiberDistanceFE SFP
YESMMF2 kmGLC-FE-100FX-RGD
YESSMF10 kmGLC-FE-100LX-RGD
For the most up-to-date list of supported SFP models for Cisco Industrial Ethernet switches, see
http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/compatibility/matrix/OL_6981.html#wp138176
DSL SFP Module
This section provides an example of installing and removing the DSL SFP module.
Prior to installing the DSL SFP Module, please note the following statements:
Attention
1. Follow all of warning notices and instructions marked on the product or in the user manual.
2. Do not install telephone wiring during a lightning storm.
3. The device should be installed by a service/skilled person on stationary pluggable equipment and connected
to a socked-outlet with a protective earthing conductor to building earth.
4. External paired conductor cable should be minimum wire diameter of 0.4 mm, shall have the current
limited to 1.3 A.
5. Please disconnect RJ45/RJ11 line before disconnect the power supply.
The following photo shows the DSL SFP Module:
SFP-VADSL2+-I was evaluated to country specific regulatory requirements only. The product was not
evaluated to IEC 61850-3 and IEEE1613 substation / utility standards.
Note
Product Overview
20
Product Overview
DSL SFP Module
