Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600
Series Routers with Cisco IOS Release 12.2SR
This publication lists the supported hardware for Cisco 7600 series routers with Cisco IOS Release 12.2
SR.
Use this publication with the Cross-Platform Release Notes for Cisco IOS Release 12.2SR.
Contents
This publication contains these sections:
•Document Revision History, page 2
•Supported Hardware, page 7
•Unsupported Hardware, page 118
•Related Documentation, page 120
•Obtaining Documentation, Obtaining Support, and Security Guidelines, page 121

2
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Document Revision History
Document Revision History
Revision Date Change Summary
OL-10362-13 July, 2010 Added the following for Cisco IOS release 15.0(1)S:
•Support for the ACE30-MOD-K9 service module.
•Support for SPA-1xOC3-ATM-V2, SPA-3xOC3-ATM-V2 on
SIP- 200 and SIP- 400.
•Support for SPA-1xOC12-ATM-V2 on SIP- 400
•Support for SPA-2X1GE-SYNCE on SIP-400
•Support for DWDM-XFP-C optics to ES+ 10GE line cards
and 10GE SPAs.
•Support for GLC-GE-100FX optics to ES20 GE, ES+ GE line
cards and 1GE SPAs.
•Support for ONS-SC-OC3-EL optics to ATM and POS SPAs.

3
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Document Revision History
OL-10362-12 April, 2010 Added the following for Cisco IOS release 12.2(33)SRE1:
•Added support for 40 DWDM SFPs to RSP 720:
– RSP720-3C-GE
– RSP-720-3CXL-GE
– RSP720-3C-10GE
– RSP-720-3CXL-10GE
•Added support for 8 additional DWDM SFPs
(DWDM-SFP-3346, DWDM-SFP-3739, DWDM-SFP-4134,
DWDM-SFP-4532, DWDM-SFP-4931, DWDM-SFP-5332,
DWDM-SFP-5736, DWDM-SFP-6141) to:
– WS-SUP32-10GE-3B
– WS-SUP32-GE-3B
– WS-X6724-SFP
– WS-X6748-SFP
•Added support for 8 additional CWDM SFPs
(CWDM-SFP-1470, CWDM-SFP-1490, CWDM-SFP-1510,
CWDM-SFP-1530, CWDM-SFP-1550, CWDM-SFP-1570,
CWDM-SFP-1590, CWDM-SFP-1610) to RSP 720:
– RSP720-3C-GE
– RSP-720-3CXL-GE
– RSP720-3C-10GE
– RSP-720-3CXL-10GE
•Added support for XFP-10G-MM-SR to the following line
cards and SIPs:
– 7600ES+2TG3C, 7600ES+2TG3CXL
– 7600ES+4TG3C, 7600ES+4TG3CXL
– 76-ES+XC-20G3C, 76-ES+XC-20G3CXL
– 76-ES+XC-40G3C, 76-ES+XC-40G3CXL
– 76-ES+XT-2TG3C, 76-ES+XT-2TG3CXL
– 76-ES+XT-4TG3C, 76-ES+XT-4TG3CXL
– 76-ES+T-2TG3CXL, 76-ES+T-20G3CXL
– 76-ES+T-4TG3CXL, 76-ES+T-40G3CXL
– SIP-400, SIP-600 on 10GE SPA
•Added support for WAN/OTN to the following line cards:
– 76-ES+XC-20G3C
– 76-ES+XC-20G3CXL
– 76-ES+XC-40G3C
– 76-ES+XC-40G3CXL
Revision Date Change Summary

4
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Document Revision History
OL-10362-11 December, 2009 Added the following for Cisco IOS release 12.2(33)SRE:
•Added support for the following ES+ Combo cards:
– 76-ES+XC-40G3CXL
– 76-ES+XC-40G3C
– 76-ES+XC-20G3CXL
– 76-ES+XC-20G3C
– SFP-GE-T/S/L/Z support on X6724/X6748
– DWDM-X2-xx.xx and X2-10GB-LRM, X2 10GB-ZR
support on 7600 cards (RSP720-10GE and
WS-X6708-10GE)
– DWDM-X2-xx.xx and X2-10GB-LRM, X2 10GB-ZR
support on 7600 cards (RSP720-10GE and
WS-X6708-10GE)
– Enabled support for additional DWDM SFPs
(DWDM-SFP-3346, DWDM-SFP-3739,
DWDM-SFP-4134, DWDM-SFP-4532,
DWDM-SFP-4931, DWDM-SFP-5332,
DWDM-SFP-5736, DWDM-SFP-6141) in ES+ and
ES+Combo
– Enabled support for additional DWDM SFPs
(DWDM-SFP-3346, DWDM-SFP-3739,
DWDM-SFP-4134, DWDM-SFP-4532,
DWDM-SFP-4931, DWDM-SFP-5332,
DWDM-SFP-5736, DWDM-SFP-6141) in
ES20/SIP400/SIP600 (HW)
– PWR-4500-DC Power Supply
•76-ES+XT-2TG3C
•76-ES+XT-4TG3C
•Support for ES+ transport card is extended to12.2(33) SRE
•Added support for SFP-OC3-LR1to SPA-1XCHSTM1/OC3
on SIP-400
OL-10362-10 May, 2009 Added the following for Cisco IOS release 12.2(33)SRD4:
•Added support for the following ES+ transport cards:
– 76-ES+T-20G
– 76-ES+T-40G
– 76-ES+T-2TG
– 76-ES+T-4TG
Revision Date Change Summary

5
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Document Revision History
OL-10362-9 May, 2009 Added the following for Cisco IOS release 12.2(33)SRD2:
•Added support for SFP-GE-T, SFP-GE-S, SFP-GE-L, and
SFP-GE-Z to WS-X6724-SFP and WS-X6748-SFP line
cards.
•Added support for ONS-SC-155-EL to the
SPA-1ChOC3-CE-ATM on the SIP-400 and to the
SPA-1XCHSTM1/OC3 on the SIP-400.
OL-10362-8 February, 2009 Added the following for Cisco IOS release 12.2(33)SRD1:
•76-ES+XT-2TG3CXL
•76-ES+XT-4TG3CXL
OL-10362-7 October, 2008 Added the following for Cisco IOS release 12.2(33)SRD:
•7600-ES+2TGCXL
•7600-ES+2TG3C
•7600-ES+4TGCXL
•7600-ES+4TG3C
•7600-ES+40G3C
•7600-ES+20G3CXL
•7600-ES+20G3C
•7600-ES+40G3CXL
•CWDM SFP Support
•DWDM SFP Support
•XFP-10GER-OC192IR= Version 2 XFP support
•SFP-GE-T= with ES40 Line Card Support
•XFP-10GZR-OC192LR+= XFP Support
•support BX optics (GLC-BX-U=, GLC-BX-D=) with GE
SPA (SIP line cards), ES20 & ES40 line cards
•DWDM XFP support
•SPA-8X1FE-TX-V2 and SPA-4X1FE-TX-V2 Support on
SIP-400
•Network Analysis Modules (NAMs) Support for
RSP720-10GE
OL-10362-6 May, 2008 Added the following for Cisco IOS release 12.2(33)SRC1:
•SPA-4XT-Serial SPA support on SIP-200
•Additional DWDM XFP support for ES20 line card, SIP-400,
and SIP-600
Revision Date Change Summary

6
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Document Revision History
OL-10362-5 April, 2008 Added the following for Cisco IOS release 12.2(33)SRB3:
•DWDM XFP support on Cisco 7600 ES20 line card and
SIP-600
•SFP-GE-T support on Cisco 7600 ES20 line card, SIP-400,
and SIP-600
•CWDM SFP support on Cisco 7600 ES20 line card
OL-10362-4 January, 2008 Added the following for Cisco IOS release 12.2(33)SRC:
•SPA-2CHT3-CE-ATM on SIP-400
•WS-X6708-10G-3C, WS-X6708-10G-3CXL
•RSP720-3C-10GE, RSP720-3CXL-10GE
•SPA-1X10GE-L-V2 on the SIP-400
•SPA-1xCHSTM1/OC3 on the SIP-400
•SFP-GE-T Support on the SIP-400, SIP-600, and Ethernet
Services 20G line cards
•SPA-2XCT3/DS0, SPA-4XCT3/DS0 support on SIP-400
•SPA-8XCHT1/E1 on the SIP-400
•SPA-2XT3/E3, SPA-4XT3/E3 support on SIP-400
•Wireless Services Module (WiSM)
OL-10362-3 June, 2007 Added the following for Cisco IOS release 12.2(33)SRB1:
•Cisco 7606-S router chassis
•Cisco 7603-S router chassis
•1500 W DC input (PWR-1500-DC) power supply
•XFP-10GZR-OC192LR Gigabit Ethernet Transceiver
Module
•Cisco 7600 Series ACE 20 HW for Session Border Controller
Revision Date Change Summary

7
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Supported Hardware
These sections describe the hardware supported in Cisco IOS Release 12.2SR:
•Supervisor Engines, page 8
•Policy Feature Cards, page 24
•Distributed and Centralized Forwarding Cards, page 26
•XENPAKs, page 32
•X2 Modules, page 33
•Small Form-Factor Pluggable Modules (SFPs), page 42
•10-Gigabit Ethernet Transceiver Modules, page 43
•DWDM-XFP Modules, page 43
•Power over Ethernet Daughtercards, page 46
•10/100/1000 Ethernet Switching Modules, page 47
•Fast Ethernet Switching Modules, page 50
•Ethernet/Fast Ethernet (10/100) Switching Modules, page 52
•Ethernet Switching Modules, page 56
•Optical Services Modules (OSMs), page 56
•SPA Interface Processors (SIPs), page 59
•SIP-400 Combinations, page 60
•Services SPA Carrier (SSC), page 68
OL-10362-2 February, 2007 Added the following for Cisco IOS release 12.2SRB:
•RSP 720
•Policy Feature Card 3C
•Policy Feature Card 3CXL
•Distributed Forwarding Card 3CXL
•SFP-GE-S, SFP-GE-L, SFP-GE-Z
•1-Port and 24-Port Channelized CEoP SPAs
•Ethernet Services 20G line cards
•Application Control Engine (ACE) Module
•Service Application Module for IP
•6000 W DC power supply
•Cisco 7609-S router chassis
OL-10362-1 May, 2006 Initial version
Revision Date Change Summary

8
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
•Services SPAs, page 69
•Enhanced FlexWAN Module, page 69
•Enhanced FlexWAN Module Port Adapters, page 69
•Ethernet Services 20G Line Cards, page 70
•Ethernet Services 40G Line Cards, page 76
•ES+ Transport line cards start here, page 91
•Fan Trays, page 113
•Power Supplies, page 114
•Chassis, page 115
Note • Use the values in the “Power Required” column to determine the exact power requirements for your
configuration to ensure that you are within the power budget.
•Daughtercard power is shown separately.
•Enter the show power command to display current system power usage.
Supervisor Engines
•Supervisor Engine 720, page 8
•Supervisor Engine 32, page 10
•Route Switch Processor 720, page 13
Supervisor Engine 720
•Supervisor Engine 720 Common Features, page 9
•Supervisor Engine 720 with PFC3BXL, page 9
•Supervisor Engine 720 with PFC3B, page 10

9
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Supervisor Engine 720 Common Features
•Integrated 720-Gbps Switch Fabric
•64-MB bootflash device
•2 CompactFlash Type II slots (disk0 and disk1)
Note Some Supervisor Engine 720 Release 12.2SR images are larger than the bootflash device
and must be stored on a CompactFlash card.
•Two Ethernet uplink ports:
– 1-MB packet buffer per port
– Port 1—Gigabit Ethernet SFP
– Port 2—Configurable as Gigabit Ethernet SFP or 10/100/1000 Mbps RJ-45
•QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
•Port grouping:
– Number of ports: 2
– Number of port groups: 1
– Port ranges per port group: 1–2
•Supervisor Engine 720 requires a high-capacity fan tray (see the “Fan Trays” section on page 113)
Supervisor Engine 720 with PFC3BXL
Note There are no memory upgrade options for WS-SUP720-3BXL.
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
WS-SUP720-3BXL 7.82 A@42 V Supervisor Engine 720 with PFC3BXL:
•1-GB DRAM
•Policy Feature Card 3BXL (PFC3BXL); see the
“RSP720-3C-10GE” section on page 19
•Multilayer Switch Feature Card 3 (MSFC3):
– 1-GB DRAM
– 64-MB bootflash
12.2(33)SRA

10
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Supervisor Engine 720 with PFC3B
Note
•Use WS-F6K-PFC3BXL= to upgrade a WS-SUP720-3B with a PFC3BXL. WS-F6K-PFC3BXL=
includes 1 GB memory upgrades for the Supervisor Engine 720 and the MSFC3. Refer to this
publication for more information:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/78_16220.ht
ml
•WS-SUP720-3B requires atleast 1-GB DRAM to support software version12.2(33) SRE and later
releases.
•Use MEM-SUP720-SP-1GB= for Switch Processor (SP) memory upgrade and MEM-MSFC3-1GB=
for Route Processor(RP) memory upgrade. For more information, see
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Config_Notes/OL_20611.h
tml
Supervisor Engine 32
Note Supervisor Engine 32 does not support this hardware:
•WS-SUP720-3B
•WS-F6K-PFC3BXL—Policy Feature Card 3BXL (PFC3BXL)
•Distributed Forwarding Cards (DFCs) (installed DFCs do not power up with a Supervisor Engine
32)
•Switch Fabric Modules
•These switching modules:
– WS-X6704-10GE—4-port 10-Gigabit Ethernet XENPAK
– WS-X6748-SFP—48-port Gigabit Ethernet SFP
– WS-X6724-SFP—24-port Gigabit Ethernet SFP
– WS-X6816-GBIC—16-port Gigabit Ethernet GBIC
– WS-X6748-GE-TX—48-port 10/100/1000 RJ-45
•7600-SIP-600—SPA Interface Processor-600
•Optical Services Modules (OSMs)
•CISCO7603—3-slot chassis
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
WS-SUP720-3B 7.50 A@42 V Supervisor Engine 720 with PFC3B:
•512-MB DRAM
•Policy Feature Card 3B (PFC3B); see the
“RSP720-3C-10GE” section on page 19
•Multilayer Switch Feature Card 3 (MSFC3):
– 512-MB DRAM
– 64-MB bootflash
12.2(33)SRA

11
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
•These service modules:
– WS-SVC-AON-1-K9—Application-Oriented Networking Module
– WS-SVC-AGM-1-K9—Anomaly Guard Module
– WS-SVC-ADM-1-K9—Traffic Anomaly Detector Module
– WS-SVC-MWAM-1—Multi-Processor WAN Application Module
•Supervisor Engine 32 does not support these software features and commands:
– Protocol independent multicast (PIM) snooping designated-router flooding configurability
– NetFlow version 9
– Egress multicast replication
– Multicast replication mode detection
– All fabric configuration commands
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
WS-SUP32-10GE-3B 2.39 A@42 V Supervisor Engine 32:
•One 10/100/1000 Mbps RJ-45 port
•WS-SUP32-10GE—two Gigabit Ethernet ports
(requires XENPAKs)
•WS-SUP32-GE—eight Gigabit Ethernet SFP ports (requires
Gigabit Ethernet SFPs)
•512-MB DRAM
•256-MB bootflash
•Policy Feature Card 3B (PFC3B); see the
“RSP720-3C-10GE” section on page 19
•Multilayer Switch Feature Card 2A (MSFC2A):
– 512-MB DRAM
– 64-MB bootflash
12.2(33)SRA
WS-SUP32-GE-3B 1.89 A@42 V
Software Version SFPs Supported
12.2(33) SRE onwards DWDM-SFP-3033=

12
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
DWDM-SFP-3112=
DWDM-SFP-3190=
DWDM-SFP-3268=
DWDM-SFP-3425=
DWDM-SFP-3504=
DWDM-SFP-3582=
DWDM-SFP-3661=
DWDM-SFP-3819=
DWDM-SFP-3898=
DWDM-SFP-3977=
DWDM-SFP-4056=
DWDM-SFP-4214=
DWDM-SFP-4294=
DWDM-SFP-4373=
DWDM-SFP-4453=
DWDM-SFP-4612=
DWDM-SFP-4692=
DWDM-SFP-4772=
DWDM-SFP-4851=
DWDM-SFP-5012=
DWDM-SFP-5092=
DWDM-SFP-5172=
DWDM-SFP-5252=
DWDM-SFP-5413=
DWDM-SFP-5494=
DWDM-SFP-5575=
DWDM-SFP-5655=
DWDM-SFP-5817=
DWDM-SFP-5898=
DWDM-SFP-5979=
DWDM-SFP-6061=
Software Version SFPs Supported
Software Version SFPs Supported
12.2(33) SRE1, 15.0(1)S DWDM-SFP-3346=

13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Note See this publication for Supervisor Engine 32 hardware information:
http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/hardware/Module_Installation/Su
p_Eng_Guide/supe_gd.html
Route Switch Processor 720
RSP 720 Common Features
•Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps small form pluggable (SFP) module; port
2 is configurable with either a 1-Gbps SFP module or a 10/100/1000-Mbps RJ-45
•Integrated 720-Gbps switch fabric
•Two CompactFlash Type II slots (on front panel) and 2-GB internal CompactFlash (1 GB each for
RP and SP)
•Requires larger power supplies and a high-speed fan tray
•QoS port architecture (Rx/Tx) is 1p1q4t/1p2q2t
DWDM-SFP-3739=
DWDM-SFP-4134=
DWDM-SFP-4532=
DWDM-SFP-4931=
DWDM-SFP-5332=
DWDM-SFP-5736=
DWDM-SFP-6141=

14
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
RSP720-3C-GE
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
RSP720-3C-GE 6.66 A@42 V Route Switch Processor 720 with PFC3C:
•Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps
small form pluggable (SFP) module; port 2 is configurable
with either a 1-Gbps SFP module or a 10/100/1000-Mbps
RJ-45
•Integrated 720-Gbps switch fabric
•PFC3C and MSFC4 with 512-MB bootflash, 4-MB
NVRAM, 4-MB ROMMON, and several DRAM options:
– Route processor (RP): 1- to 4-GB DRAM (default 1
GB)
– Switch processor (SP): 1- to 2-GB DRAM (default 1
GB)
•2 CompactFlash Type II slots (on front panel) and 2-GB
internal CompactFlash (1 GB each for RP and SP)
•Requires larger power supplies and a high-speed fan tray
•QoS port architecture (Rx/Tx) is 1p1q4t/1p2q2t
12.2(33)SRB
Software Version SFPs Supported
12.2(33) SRE1, 15.0(1)S CWDM-SFP-1470=
CWDM-SFP-1490=
CWDM-SFP-1510=
CWDM-SFP-1530=
CWDM-SFP-1550=
CWDM-SFP-1570=
CWDM-SFP-1590=
CWDM-SFP-1610=
GLC-BX-D
GLC-BX-U
SFP-GE-T
SFP-GE-S
SFP-GE-L
DWDM-SFP-3033=
DWDM-SFP-3112=
DWDM-SFP-3190=

15
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
DWDM-SFP-3268=
DWDM-SFP-3425=
DWDM-SFP-3504=
DWDM-SFP-3582=
DWDM-SFP-3661=
DWDM-SFP-3819=
DWDM-SFP-3898=
DWDM-SFP-3977=
DWDM-SFP-4056=
DWDM-SFP-4214=
DWDM-SFP-4294=
DWDM-SFP-4373=
DWDM-SFP-4453=
DWDM-SFP-4612=
DWDM-SFP-4692=
DWDM-SFP-4772=
DWDM-SFP-4851=
DWDM-SFP-5012=
DWDM-SFP-5092=
DWDM-SFP-5172=
DWDM-SFP-5252=
DWDM-SFP-5413=
DWDM-SFP-5494=
DWDM-SFP-5575=
DWDM-SFP-5655=
DWDM-SFP-5817=
DWDM-SFP-5898=
DWDM-SFP-5979=
DWDM-SFP-6061=
DWDM-SFP-3346=
DWDM-SFP-3739=
DWDM-SFP-4134=
DWDM-SFP-4532=
DWDM-SFP-4931=
DWDM-SFP-5332=
DWDM-SFP-5736=
DWDM-SFP-6141=
Software Version SFPs Supported

16
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Note
•There are no memory-only upgrade options for RSP720-3C-GE.
•The following hardware and features are not supported by the RSP720-3C-GE:
– CISCO7603 router, OSR-7609 router (supported in SRA but not later releases).
– Optical Service Modules (OSMs), FlexWAN module (Enhanced FlexWAN module is
supported).
– In-service software upgrade (ISSU) is not supported in Cisco IOS Release 12.2SRB.
•The RSP720-3C-GE supports the SPA-IPSEC-2G beginning with Cisco IOS Release 12.2(33)SRC.
RSP720-3CXL-GE
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
RSP720-3CXL-GE 7.33 A@42 V Route Switch Processor 720 with PFC3CXL:
•Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps
small form pluggable (SFP) module; port 2 is configurable
with either a 1-Gbps SFP module or a 10/100/1000-Mbps
RJ-45
•Integrated 720-Gbps switch fabric
•PFC3CXL (high-capacity) and MSFC4 with 512-MB
bootflash, 4-MB NVRAM, 4-MB ROMMON, and several
DRAM options:
– Route processor (RP): 1- to 4-GB DRAM (default 2
GB)
– Switch processor (SP): 1- to 2-GB DRAM (default 1
GB)
•2 CompactFlash Type II slots (on front panel) and 2-GB
internal CompactFlash (1 GB each for RP and SP)
•Requires larger power supplies and a high-speed fan tray
•QoS port architecture (Rx/Tx) is 1p1q4t/1p2q2t
12.2(33)SRB
Software Version SFPs Supported
12.2(33) SRE1, 15.0(1)S CWDM-SFP-1470=

17
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
CWDM-SFP-1490=
CWDM-SFP-1510=
CWDM-SFP-1530=
CWDM-SFP-1550=
CWDM-SFP-1570=
CWDM-SFP-1590=
CWDM-SFP-1610=
DWDM-SFP-3033=
DWDM-SFP-3112=
DWDM-SFP-3190=
DWDM-SFP-3268=
DWDM-SFP-3425=
DWDM-SFP-3504=
DWDM-SFP-3582=
DWDM-SFP-3661=
DWDM-SFP-3819=
DWDM-SFP-3898=
DWDM-SFP-3977=
DWDM-SFP-4056=
DWDM-SFP-4214=
DWDM-SFP-4294=
DWDM-SFP-4373=
DWDM-SFP-4453=
DWDM-SFP-4612=
DWDM-SFP-4692=
DWDM-SFP-4772=
DWDM-SFP-4851=
DWDM-SFP-5012=
DWDM-SFP-5092=
DWDM-SFP-5172=
DWDM-SFP-5252=
Software Version SFPs Supported

18
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Note
•There are no memory-only upgrade options for RSP720-3CXL-GE.
•The RSP720-3CXL SP has one miniDIMM socket that accepts any vendor's 2GB DIMM. However,
the RSP720-3CXL RP has two miniDIMM sockets. You must use the DIMMs from the same vendor
for these sockets.
•The following hardware and features are not supported by the RSP720-3CXL-GE :
– Unsupported chassis: CISCO7603, OSR-7609 (supported in SRA but not later releases).
– Unsupported modules: Optical Service Modules (OSMs), FlexWAN module (Enhanced
FlexWAN module is supported).
– In-service software upgrade (ISSU) is not supported in Cisco IOS Release 12.2SRB.
•The RSP720-3CXL-GE supports the SPA-IPSEC-2G beginning with Cisco IOS Release
12.2(33)SRC.
DWDM-SFP-5413=
DWDM-SFP-5494=
DWDM-SFP-5575=
DWDM-SFP-5655=
DWDM-SFP-5817=
DWDM-SFP-5898=
DWDM-SFP-5979=
DWDM-SFP-6061=
DWDM-SFP-3346=
DWDM-SFP-3739=
DWDM-SFP-4134=
DWDM-SFP-4532=
DWDM-SFP-4931=
DWDM-SFP-5332=
DWDM-SFP-5736=
DWDM-SFP-6141=
Software Version SFPs Supported

19
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
RSP720-3C-10GE
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
RSP720-3C-10GE 7.33 A@42 V Route Switch Processor 720 with uplink ports:
•Two 10 Gigabit Ethernet (10-GE) uplink ports support
10-Gbps X2 modules
•Three Gigabit Ethernet (1-GE) uplink ports: two ports support
1-Gbps small form-factor pluggable (SFP) module; one port
supports 10/100/1000-Mbps RJ-45 connector
•Integrated 720-Gbps switch fabric
•PFC3C and MSFC4 with 512-MB bootflash, 4-MB
NVRAM, 4-MB ROMmon, and several DRAM options:
– Route processor (RP): 1- to 2-GB DRAM (default 1
GB)
– Switch processor (SP): 1- to 2-GB DRAM (default 1
GB)
•One CompactFlash Type II slot (on front panel) and one
2-GB internal CompactFlash (1 GB each for RP and SP)
•Requires larger power supplies and a high-speed fan tray
•QoS port architecture, 10-GE ports (Rx/Tx): 8q8t/1p7q8t
(CoS)
•QoS port architecture, 1-GE ports (Rx/Tx): 2q8t/1p3q8t
12.2(33)SRC
Software Version SFPs Supported
12.2(33) SRE1, 15.0(1)S CWDM-SFP-1470=

20
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Note
•Cisco IOS Release 12.2(33)SRE adds X2-DWDM and X2-10GB-LRM, X2 10GB-ZR support.
•There are no memory-only upgrade options for the RSP720-3C-10GE.
•The RSP720-3C-10GE does not support the following chassis and modules:
– Unsupported chassis: Cisco 7603 and 7606.
Note Cisco 7613 backplane supports RSP720-3C-10GE and RSP720-3CXL-10GE from
12.2(33)SRE2 onwards.
– Unsupported modules: Services modules (excluding the Network Analysis Module) , Optical
Service Modules (OSMs), FlexWAN module.
•The RSP720-3C-10GE supports the following 10-Gigabit Ethernet optics: X2-10GB-LR,
X2-10GB-ER, X2-10GB-SR, X2-10GB-CX4, and X2-10GB-LX4.
•The RSP720-3C-10GE supports the following Gigabit Ethernet optics: GLC-SX-MM,
GLC-LH-SM, GLC-ZX-SM, GLC-T, SFP-GE-S, SFP-GE-L, SFP-GE-T, GLC-BX-D, and
GLC-BX-U.
In Cisco IOS Release 12.2(33)SRE, the RSP720-10GE adds support for the following features:
•High-availability features such as NonStop Forwarding with Stateful Switchover (NSF/SSO) and
In-Service Software Upgrade (ISSU) are supported.
•The uplinks on the standby RSP720-10GE are active.
•Broadband Aggregation features are supported.
In Cisco IOS Release 12.2SRC, the RSP720-10GE does not support the following features, which are
supported on the RSP720:
CWDM-SFP-1490=
CWDM-SFP-1510=
CWDM-SFP-1530=
CWDM-SFP-1550=
CWDM-SFP-1570=
CWDM-SFP-1590=
CWDM-SFP-1610=
DWDM-SFP-3346=
DWDM-SFP-3739=
DWDM-SFP-4134=
DWDM-SFP-4532=
DWDM-SFP-4931=
DWDM-SFP-5332=
DWDM-SFP-5736=
DWDM-SFP-6141=
Software Version SFPs Supported
