Cisco 8100 Series Manual

Hardware Installation Guide for Cisco 8100 Series Routers
First Published: 2021-03-17
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

©2021 Cisco Systems, Inc. All rights reserved.

CONTENTS
Cisco 8100 Series Routers Overview 1
CHAPTER 1
Cisco 8100 Series Routers 1
Field Replaceable Units 2
Prepare for Installation 7
CHAPTER 2
Safety Guidelines 7
Compliance and Safety Information 8
Laser Safety 8
Energy Hazard 9
Preventing Electrostatic Discharge Damage 9
Cautions and Regulatory Compliance Statements for NEBS 10
Installation Guidelines 10
Procure Tools and Equipment 11
Accessory Kit 11
Prepare Your Location 12
Prepare Yourself 13
Prepare Rack for Chassis Installation 14
Clearance Requirements 15
Installing the Chassis 17
CHAPTER 3
Rack Mount the Chassis 17
Rack-Mount the Chassis in a 4-Post Rack 17
Ground the Chassis 19
Connect AC Power to the Chassis 20
Connect DC Power to the Chassis 22
Hardware Installation Guide for Cisco 8100 Series Routers
iii

Connect Router to the Network 25
CHAPTER 4
Port Connection Guidelines 25
Transceiver and Cable Specifications 26
Connecting a Console to the Router 26
Connect the Management Interface 27
Install and Remove QSFP Transceiver Modules 28
Installing the Transceiver Module 28
Connect Interface Ports 30
Connect a Fiber-Optic Port to the Network 31
Disconnect Optical Ports from the Network 31
Maintain Transceivers and Optical Cables 31
Replace Chassis Components 33
CHAPTER 5
Replace Fan Modules for Cisco 8100 Series Routers 33
Replace Power Supply 35
LEDs 37
CHAPTER 6
Chassis LEDs 37
Fan Tray LED 38
Power Supply LEDs 39
Port Status LEDs 41
Hardware Installation Guide for Cisco 8100 Series Routers
iv
Contents

CHAPTER 1
Cisco 8100 Series Routers Overview
•Cisco 8100 Series Routers, on page 1
•Field Replaceable Units, on page 2
Cisco 8100 Series Routers
The Cisco 8100 Series Routers utilizes Cisco’s new Router-on-Chip (RoC) model to deliver full routing
functionality with a single ASIC per router. The RoC architecture is distinguished from System-on-Chip (SoC)
switches by supporting large forwarding tables, deep buffers, more flexible packet operations, and enhanced
programmability.
The Cisco 8100 series routers include the following variants:
•Cisco 8102-64H - It provides 6.4 Tbps of network bandwidth with dramatically lower power consumption
than contemporary 10 Tbps systems. The Cisco 8102 Router is a fixed port, high density, two rack unit
form-factor router. Supported ports include 64 x 100G QSFP28.
• Cisco 8102-64H-O - It provides 6.4 Tbps of network bandwidth with dramatically lower power
consumption than contemporary 10 Tbps systems. The Cisco 8102 Router is a fixed port, high density,
two rack unit form-factor router. Supported ports include 64 x 100G QSFP28. The Cisco 8102-64H-O
supports the open-source network operating system SONiC (Software for Open Networking in the Cloud).
• Cisco 8101-32FH - It provides 12.8Tbps of network bandwidth. The Cisco 8101-32FH Router is a fixed
port, high density, one rack unit form-factor router. Supported ports include 32 x 400G QSFP-DD. The
functionality and installation of this router is similar to that of Cisco 8201-32FH. The Hardware Installation
Guide for Cisco 8201-32FH is available here.
Hardware Installation Guide for Cisco 8100 Series Routers
1

Figure 1: Cisco 8102-64H Router—Front View
32 QSFP28 ports1
32 QSPF28 ports2
Figure 2: Cisco 8102-64H Router—Rear View
Fan Tray
Three Fans: FT0, FT1, and FT2
1
PSU-0 and PSU-12
Ground Lug Location3
Field Replaceable Units
The router has two field replaceable units (FRUs):
• Fan Module
Hardware Installation Guide for Cisco 8100 Series Routers
2
Cisco 8100 Series Routers Overview
Field Replaceable Units

• Power Supply Unit
Both the FRUs support OIR (Online Insertion and Removal).
Fan Module
The router has three latched fan modules that installs into the chassis from the rear. Fans cool the system and
maintain proper airflow through the system. The fan modules work with N+1 redundancy.
Figure 3: Fan Module - Cisco 8102-64H
Fan1
Table 1: Fan Module PIDs
Fan Module PID
FAN-2RU-PI-V2
The color of the fan module is Burgundy.
Port side intake
FAN-2RU-PE-V2
The color of the fan module is Blue.
Port side exhaust
Power Supply Unit
The router has two PSUs that install into the chassis from the rear. The PSUs work with 1+1 redundancy and
the router supports two AC or two power supplies. The PSUs can be:
• AC to DC type - 650W
• DC to DC type - 930W
The PSUs provide 12V power to the entire system.
Table 2: PIDs for Power Supply Unit
DC PIDAC PID
• PSU930W-DCPI
• PSU930W-DCPE
• PSU650W-ACPI
• PSU650W-ACPE
Hardware Installation Guide for Cisco 8100 Series Routers
3
Cisco 8100 Series Routers Overview
Field Replaceable Units

Figure 4: Power Supply Unit
SSD Card
The router has a removable Solid State Drive (SSD) card. We recommend to remove the SDD card before
shipping the hardware for a Return Merchandise Authorization (RMA) request. Removal of the SSD card
enforces customer data security while performing an RMA.
You can access the SSD card by using the hatch provided on the top panel. To remove the SSD card, follow
the instructions mentioned on the printed label on the hatch.
Figure 5: Remove the Hatch
Hardware Installation Guide for Cisco 8100 Series Routers
4
Cisco 8100 Series Routers Overview
Field Replaceable Units

Figure 6: SSD Card Removal Instructions
Hardware Installation Guide for Cisco 8100 Series Routers
5
Cisco 8100 Series Routers Overview
Field Replaceable Units

Hardware Installation Guide for Cisco 8100 Series Routers
6
Cisco 8100 Series Routers Overview
Field Replaceable Units

CHAPTER 2
Prepare for Installation
The images in this chapter are only for representational purposes, unless specified otherwise. The chassis'
actual appearance and size may vary.
Note
Statement 1071—Warning Definition
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work
on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard
practices for preventing accidents. Use the statement number provided at the end of each warning to locate
its translation in the translated safety warnings that accompanied this device.
SAVE THESE INSTRUCTIONS
Warning
•Safety Guidelines, on page 7
•Compliance and Safety Information, on page 8
•Laser Safety, on page 8
•Energy Hazard, on page 9
•Preventing Electrostatic Discharge Damage, on page 9
•Cautions and Regulatory Compliance Statements for NEBS, on page 10
•Installation Guidelines, on page 10
•Procure Tools and Equipment, on page 11
•Prepare Your Location , on page 12
•Prepare Yourself , on page 13
•Prepare Rack for Chassis Installation, on page 14
•Clearance Requirements, on page 15
Safety Guidelines
Before you perform any procedure in this document, review the safety guidelines in this section to avoid
injuring yourself or damaging the equipment. The following guidelines are for your safety and to protect the
equipment. Because the guidelines do not include all hazards, be constantly alert.
Hardware Installation Guide for Cisco 8100 Series Routers
7

• Keep the work area clear, smoke and dust-free during and after installation. Do not allow dirt or debris
to enter into any laser-based components.
• Do not wear loose clothing, jewelry, or other items that could get caught in the router or other associated
components.
• Cisco equipment operates safely when used in accordance with its specifications and product-usage
instructions.
• If potentially hazardous conditions exist, do not work alone.
• Take care when connecting multiple units to the supply circuit so that wiring is not overloaded.
• This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority
or an electrician if you are uncertain about whether suitable grounding is available.
• When installing or replacing the unit, the ground connection must always be made first and disconnected
last.
• To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules (such as power supplies, fans, or cards); these types of handles are not designed to
support the weight of the unit.
• Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when
servicing.
Compliance and Safety Information
The Cisco 8000 Series Routers are designed to meet the regulatory compliance and safety approval requirements.
For detailed safety information, see Regulatory Compliance and Safety Information—Cisco 8000 Series
Routers.
Laser Safety
Statement 1051—Laser Radiation
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams or
view directly with optical instruments.
Warning
Hardware Installation Guide for Cisco 8100 Series Routers
8
Prepare for Installation
Compliance and Safety Information

Statement 1055—Class 1/1M Laser
Invisible laser radiation is present. Do not expose to users of telescopic optics. This applies to Class 1/1M
laser products.
Warning
Statement 1255—Laser Compliance Statement
Pluggable optical modules comply with IEC 60825-1 Ed. 3 and 21 CFR 1040.10 and 1040.11 with or without
exception for conformance with IEC 60825-1 Ed. 3 as described in Laser Notice No. 56, dated May 8, 2019.
Warning
Energy Hazard
The routers can be configured for a DC power source. Do not touch terminals while they are live. Observe
the following warning to prevent injury.
Statement 1086—Power Terminals
Hazardous voltage or energy may be present on power terminals. Always replace cover when terminals are
not in service. Be sure uninsulated conductors are not accessible when cover is in place.
Warning
Preventing Electrostatic Discharge Damage
Many router components can be damaged by static electricity. Not exercising the proper electrostatic discharge
(ESD) precautions can result in intermittent or complete component failures. To minimize the potential for
ESD damage, always use an ESD-preventive antistatic wrist strap (or ankle strap) and ensure that it makes
adequate skin contact.
Check the resistance value of the ESD-preventive strap periodically. The measurement should be 1–10
megohms.
Note
Before you perform any of the procedures in this guide, attach an ESD-preventive strap to your wrist and
connect the leash to the chassis.
Hardware Installation Guide for Cisco 8100 Series Routers
9
Prepare for Installation
Energy Hazard

Cautions and Regulatory Compliance Statements for NEBS
The NEBS-GR-1089-CORE regulatory compliance statements and requirements are discussed in this section.
The intrabuilding port(s) of the equipment or subassembly, which is the management Ethernet port, must use
shielded intrabuilding cabling/wiring that is grounded at both ends. Statement 7003
Warning
The intrabuilding port(s) of the equipment or subassembly, which is the management Ethernet port, must not
be metallically connected to interfaces that connect to the OSP or its wiring. These interfaces are designed
for use as intrabuilding interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require
isolation from the exposed OSP cabling. The addition of Primary Protectors is not sufficient protection in
order to connect these interfaces metallically to OSP wiring. Statement 7005
Warning
This equipment shall be connected to AC mains provided with a surge protective device (SPD) at the service
equipment complying with NFPA 70, the National Electrical Code (NEC). Statement 7012
Warning
This equipment is suitable for installations utilizing the Common Bonding Network (CBN). Statement 7013
Warning
The battery return conductor of this equipment shall be treated as (DC-I). Statement 7016
Warning
This equipment is suitable for installation in Network Telecommunications Facilities. Statement 8015
Warning
This equipment is suitable for installation in locations where the NEC applies. Statement 8016
Warning
Installation Guidelines
Before installing the chassis, ensure that the following guidelines are met:
• Site is properly prepared so that there is sufficient room for installation and maintenance.
• Operating environment is within the ranges that are listed in Environment and Physical specifications.
For more details on environmental requirements, see Cisco 8000 Series Routers Data Sheet.
• Chassis is mounted at the bottom of the rack if it is the only unit in the rack.
Hardware Installation Guide for Cisco 8100 Series Routers
10
Prepare for Installation
Cautions and Regulatory Compliance Statements for NEBS

• When mounting the chassis in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
chassis in the rack.
• Airflow around the chassis and through the vents is unrestricted.
• Cabling is away from sources of electrical noise, such as radios, power lines, and fluorescent lighting
fixtures. Make sure that the cabling is safely away from other devices that might damage the cables.
• Each port must match the wave-length specifications on each end of the cable, and the cable must not
exceed the stipulated cable length.
Cisco 8000 Series Routers function in operating temperatures of up to 40°C at sea level. For every 300 meters
(1000 ft) elevation upto 1800 meters (6000 ft), the maximum temperature is reduced by 1°C. For more details
on environmental requirements, see Cisco 8000 Series Routers Data Sheet.
Note
For fixed-port routers that support port side exhaust fans and power supplies, the maximum temperature is
reduced by 5°C (for example, 35°C at sea level or 30°C at 1500 meters).
Note
Procure Tools and Equipment
Obtain these necessary tools and equipment for installing the chassis:
• Number 1 and number 2 Phillips screwdrivers with torque capability to rack-mount the chassis.
• 3/16-inch flat-blade screwdriver.
• Tape measure and level.
• ESD wrist strap or other grounding device.
• Antistatic mat or antistatic foam.
• Two-hole ground lug (1).
• A crimping tool specified by the lug manufacturer that is large enough to accommodate the girth of the
lug.
• Wire-stripping tool.
Accessory Kit
The following table contains the accessory kit PID and the items present in the accessory kit of the routers.
The rack mount kit present in the accessory kit contains the screws and brackets required for installation.
Hardware Installation Guide for Cisco 8100 Series Routers
11
Prepare for Installation
Procure Tools and Equipment

Items in Accessory Kit -1Accessory Kit-1Router
Rack mount kit and ground lug kit8100-2RU-KITCisco 8102 Router
Prepare Your Location
This section illustrates how the building that houses the chassis must be properly grounded to the earth ground.
Unless specified otherwise, the image is only for representational purposes. The rack's actual appearance and
size may vary.
Note
This image is only for representational purposes. Your grounding requirement depends on your building.
Note
Hardware Installation Guide for Cisco 8100 Series Routers
12
Prepare for Installation
Prepare Your Location

Figure 7: Building with Rack Room Connected to Earth Ground
Prepare Yourself
This section illustrates how to prepare yourself before removing the chassis from the sealed antistatic bag.
The figures show how to cuff the ESD strap around the wrist and the ground cord that connects the cuff to
the ground. ESD wrist straps are the primary means of controlling static charge on personnel.
Hardware Installation Guide for Cisco 8100 Series Routers
13
Prepare for Installation
Prepare Yourself

Figure 8: Wearing the ESD Strap
Prepare Rack for Chassis Installation
Install the Cisco 8100 Series Routers on a standard 19 inch, Electronic Industries Alliance (EIA) rack with
mounting rails that conform to English universal hole spacing according to Section 1 of the
ANSI/EIA-310-D-1992 standard.
The Cisco 8102-64H-O router rack mount kit contains the rack mounting brackets for 19-inch rack. To install
the chassis in a 23-inch rack or an ETSI rack, you need adapter plates to accommodate the 19-inch rack mount
brackets.
Note
The spacing between the posts of the rack must be (EIA-310-D-1992 19-inch rack compatible) wide enough
to accommodate the width of the chassis.
Before you move the chassis or mount the chassis into the rack, we recommend that you do the following:
Hardware Installation Guide for Cisco 8100 Series Routers
14
Prepare for Installation
Prepare Rack for Chassis Installation

Step 1 Place the rack at the location where you plan to install the chassis.
Step 2 (Optional) Secure the rack to the floor.
To bolt the rack to the floor, a floor bolt kit (also called an anchor embedment kit) is required. For information on bolting
the rack to the floor, consult a company that specializes in floor mounting kits (such as Hilti; see Hilti.com for details).
Make sure that floor mounting bolts are accessible, especially if annual retorquing of bolts is required.
Ensure that the rack in which the chassis is being installed is grounded to earth ground.
Note
Clearance Requirements
The chassis requires front-to-back airflow. Leave at least 6.0 in. (15.24 cm) front and rear clearance for air
intake or exhaust. We recommend that you have at least 6.0 in. (15.24 cm) of space in front of the chassis to
provide room to maneuver the cables to make the required connections. Leave an extra 6.0 in. (15.24 cm) rear
clearance for removal and installation of power supplies and fan modules.
Figure 9: Clearances Required Around the Chassis for Cisco 8102-64H
6.0 in. (15.24 cm) rear
clearance for air
intake/exhaust.
4Chassis1
More 6.0 in. (15.24 cm)
rear clearance for removal
and installation of power
supplies and fan modules.
56.0 in. (15.24 cm) front
clearance for air
intake/exhaust.
2
Hardware Installation Guide for Cisco 8100 Series Routers
15
Prepare for Installation
Clearance Requirements

20.01 in. (50.82 cm)
Chassis depth.
3
Hardware Installation Guide for Cisco 8100 Series Routers
16
Prepare for Installation
Clearance Requirements
