Cisco 850 Series User manual

CHAPTER
1-1
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
1
Cisco 850 Series and Cisco 870 Series
Access Routers Cabling and Setup
Quick Start Guide
Contents
•Cisco One-Year Limited Hardware Warranty Terms, page 1-2
•Locate the Product Serial Number, page 1-4
•Before Installation, page 1-4
•Connect the Antenna to the Wireless Router (Optional), page 1-8
•Connect the Power-over-Ethernet Module to the Cisco 870 Series Router
(Optional), page 1-10
•Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers,
page 1-12
•Connect the Router, page 1-17
•Install SDM and Configure the Router, page 1-19
•Related Documentation, page 1-20
•Obtaining Documentation, page 1-21
•Documentation Feedback, page 1-22
•Cisco Product Security Overview, page 1-23
English

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Cisco One-Year Limited Hardware Warranty Terms
1-2
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
•Obtaining Technical Assistance, page 1-24
•Obtaining Additional Publications and Information, page 1-27
Cisco One-Year Limited Hardware Warranty Terms
There are special terms applicable to your hardware warranty and various services
that you can use during the warranty period. Your formal Warranty Statement,
including the warranties and license agreements applicable to Cisco software, is
available on Cisco.com. Follow these steps to access and download the Cisco
Information Packet and your warranty and license agreements from Cisco.com.
1. Launch your browser, and go to this URL:
http://www.cisco.com/univercd/cc/td/doc/es_inpck/cetrans.htm
The Warranties and License Agreements page appears.
2. To read the Cisco Information Packet, follow these steps:
a. Click the Information Packet Number field, and make sure that the part
number 78-5235-03A0 is highlighted.
b. Select the language in which you would like to read the document.
c. Click Go.
The Cisco Limited Warranty and Software License page from the
Information Packet appears.
d. Read the document online, or click the PDF icon to download and print
the document in Adobe Portable Document Format (PDF).
Note You must have Adobe Acrobat Reader to view and print PDF
files. You can download the reader from Adobe’s website:
http://www.adobe.com
3. To read translated and localized warranty information about your product,
follow these steps:
a. Enter this part number in the Warranty Document Number field:
78-10747-01C0
b. Select the language in which you would like to view the document.

1-3
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Cisco One-Year Limited Hardware Warranty Terms
c. Click Go.
The Cisco warranty page appears.
d. Read the document online, or click the PDF icon to download and print
the document in Adobe Portable Document Format (PDF).
You can also contact the Cisco service and support website for assistance:
http://www.cisco.com/public/Support_root.shtml.
Duration of Hardware Warranty
One (1) Year
Replacement, Repair, or Refund Policy for Hardware
Cisco or its service center will use commercially reasonable efforts to ship a
replacement part within ten (10) working days after receipt of a Return Materials
Authorization (RMA) request. Actual delivery times can vary, depending on the
customer location.
Cisco reserves the right to refund the purchase price as its exclusive warranty
remedy.
To Receive a Return Materials Authorization (RMA) Number
Contact the company from whom you purchased the product. If you purchased the
product directly from Cisco, contact your Cisco Sales and Service Representative.
Complete the information below, and keep it for reference.
Company product purchased from
Company telephone number
Product model number
Product serial number
Maintenance contract number

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Locate the Product Serial Number
1-4
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Locate the Product Serial Number
The serial number label for the router is located on the rear of the chassis, above
the Ethernet LAN ports. (See Figure 1-1.)
Figure 1-1 Product Serial Number Location
Before Installation
•Check Items Shipped with the Router
•Nonwireless Routers
•Read the Safety Warnings and Guidelines
•Remove the Caution Sticker
Check Items Shipped with the Router
Table 1-1 lists the quantity of the items that are shipped with each router model in
the Cisco 850 series and the Cisco 870 series routers. Figure 1-2 depicts the
items.
Verify that the items listed in Table 1-1 were shipped with the router. If any of the
items is missing or damaged, contact your customer service representative.

1-5
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Before Installation
Table 1-1 Items Shipped with Cisco 850 Series and Cisco 870 Series Routers
Item
Cisco 851 and
Cisco 871
Cisco 857 and
Cisco 877 Cisco 876 Cisco 878
Ethernetcable(straight-through)1111
DSL1cable
1. DSL = digital subscriber line. Used for an asynchronous digital subscriber line (ADSL) or multirate symmetrical
high-data-rate digital subscriber line (G.SHDSL).
Not applicable 12
2. An RJ-11-to-RJ-11 straight-through cable is shipped, unless an RJ-11-to-RJ-11 crossover cable is specified.
13
3. An RJ-11-to-RJ-11 straight-through cable is shipped, unless an RJ-11-to-RJ-11 crossover cable or an RJ-11-to-RJ-45 cable
is specified.
13
ISDN4S/T cable
4. ISDN = Integrated Services Digital Network.
Not applicable Not applicable Optional Optional
Consolecable 1111
Console-auxiliary5cable
5. Console-auxiliary cable is used to connect the router console port to an asynchronous modem for dial backup or remote
management.
Optional Optional Optional Optional
Poweradapter 1111
Power cord6
6. Power cords are ordered as applicable to country or geographic region.
1111
Cisco documentation7
7. Includes the Regulatory Compliance and Safety Information for Cisco 800 Series Routers document and the Cisco 850 Series
and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide (this document). Also includes the Declarations
of Conformity and Regulatory Information for Cisco Access Products with 802.11a/b/g and 802.11b/g Radios document for
wireless models.
1 1 1 1
Cisco Router and Security
Device Manager (SDM)
software CD
1111
Swivel-mount dipole antenna
(wireless router models only)
Cisco 851:
1 antenna
Cisco 871:
2 antennas
Cisco 857:
1antenna
Cisco 877:
2 antennas
22

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Before Installation
1-6
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Figure 1-2 Items Included with the Cisco 850 Series and Cisco 870 Series Routers
The following cables are not included with the router. You need to order them
separately.
•Modem cable—For connecting the router console port to an asynchronous
modem for dial backup and remote management.
•Orange ISDN S/T cable—For connecting devices to the ISDN S/T port.
Caution Both LAN and WAN ports can use RJ-45 connectors. Use caution when
connecting cables to these connectors. To avoid damage to the router, do not
connect telephone-network voltage (TNV) circuits (such as ISDN or DSL
circuits) to safety extra-low voltage (SELV) circuits (such as LAN circuits).
1Yellow Ethernet cable 5Black power cord for adapter
2Lavender DSL cable (optional) 6Product documentation
3Light blue console cable 7Cisco SDM software CD
4Router power adapter 8Swivel-mount dipole antenna (wireless router
models only)
6
7
120730
5
2
3
48

1-7
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Before Installation
Nonwireless Routers
Portions of this guide do not apply to nonwireless models of the Cisco 850 series
and Cisco 870 series routers. Some illustrations show the router with antennas
attached, whereas the nonwireless routers do not have antennas or antenna
connectors on the back panel. However, except for the “Connect the Antenna to
the Wireless Router (Optional)” section, the connection procedures are the same
for wireless and nonwireless router models.
Read the Safety Warnings and Guidelines
Before you begin to connect your router, read the Regulatory Compliance and
Safety Information for Cisco 800 Series Routers document that is shipped with the
router. This document provides important safety warnings and guidelines.
Remove the Caution Sticker
Locate the yellow caution label that covers the LAN ports. Simply peel off the
label and the LAN ports are ready for use. Be sure that you do not connect ISDN
telephone lines to these LAN ports.

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Antenna to the Wireless Router (Optional)
1-8
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Connect the Antenna to the Wireless Router
(Optional)
The Cisco 850 series wireless routers support the use of a single 2.4-GHz antenna.
(See Figure 1-3.) The Cisco 870 series wireless routers support the use of two
2.4-GHz antennas. (See Figure 1-4.)
Figure 1-3 Cisco 857 Wireless Router with Single Antenna
ADSLoPOTS
LAN
FE0 FE1 FE2 FE3
Cisco 857W
CONSOLE
AUX
RESET
+5,+12 VDC
122242
SN: XXXNNNNXXXX

1-9
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Antenna to the Wireless Router (Optional)
Figure 1-4 Cisco 871 Wireless Router with Two Antennas
To connect the antenna or antennas to a wireless router, follow these steps:
Step 1 Attach each antenna to a reverse-polarity threaded Neill-Concelman (RP-TNC)
connector on the back of the router and tighten the connector hand-tight.
Step 2 After you connect the antenna to the back of the router, orient the antenna so that
it is straight up.
LAN
FE0 FE1 FE2 FE3
Cisco 871W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
RIGHT / PRIMARY
1
0
WAN
FE4
122241
SN: XXXNNNNXXXX

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Power-over-Ethernet Module to the Cisco 870 Series Router (Optional)
1-10
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Connect the Power-over-Ethernet Module to the
Cisco 870 Series Router (Optional)
Power-over-Ethernet (PoE) is supported on the Cisco 870 Series routers only. If
you purchased a PoE module, connect all four Ethernet cables on the PoE module
to the four LAN Ethernet ports on the Cisco 870 Series router. (See Figure 1-5.)
Make sure that you connect all four Ethernet cables.
If the cables are too close together for easy insertion, move the plastic cable guard
away from the connector end of the cables.
Caution To ensure proper PoE module operation, do not connect the PoE module power
supply to the PoE module before you connect the PoE module to the router.
Although Figure 1-5 shows the Cisco 871 router connected to a PoE module, this
connection works for all router models in the Cisco 870 series.
Note When you connect a device (such as a PC or IP phone) to the PoE module, you
may notice a 1- to 2-second delay before the LED indicator for the port comes on.

1-11
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Power-over-Ethernet Module to the Cisco 870 Series Router (Optional)
Figure 1-5 Connecting the PoE Module to the Router
1Cisco 870 series router 5Router power adapter
2Ethernet cables on the PoE module (four
RJ-45 connectors in series)
6PoE power plug
3PoE module 7Router power plug
4PoE power adapter
122351
+5,+12 VDC
LEFT
RIGHT/ PRIMARY
LAN
FE0F
E1F
E2FE3
Cisco 871W
CONSOLE
AUX
RESET
1
0
WAN
FE4
1
2
4
6
To LAN
3210
PWR
3
5
7
SN: XXXNNNNXXXX

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers
1-12
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Typical Installations of the Cisco 850 Series and
Cisco 870 Series Routers
Typical installations of the Cisco 850 series and Cisco 870 series routers are
depicted in Figure 1-6 through Figure 1-9, as follows:
•Cisco 851 and Cisco 871 router—See Figure 1-6.
•Cisco 857 and Cisco 87 router—See Figure 1-7.
•Cisco 876 router—See Figure 1-8.
•Cisco 878 router—See Figure 1-9.
Figure 1-6 shows a typical installation of a Cisco 851 or Cisco 871 router. This
figure shows the back panel of a Cisco 871 router, which has two Universal Serial
Bus (USB) ports. The Cisco 851 router does not have any USB ports; however,
the connections on the other ports are the same for both the Cisco 851 and the
Cisco 871 routers.

1-13
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers
Figure 1-6 Typical Installation of a Cisco 851 or Cisco 871 Router
1Ethernet connection to an external switch 4Console port
2Ethernet connection to a PC 5Power adapter
3WAN connection using a broadband modem to
the Internet
LAN
4321
Cisco 871W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
RIGHT / PRIMARY
1
0
WAN
FE4
FE0 FE1 FE2 FE3
1X
2X
1X
2X
1
Internet
Internet
1 2 5
34
122237
SN: XXXNNNNXXXX

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers
1-14
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Figure 1-7 shows a typical installation of a Cisco 857 or Cisco 877 router.
Figure 1-7 Typical Installation of a Cisco 857 or a Cisco 877 Router
1Ethernet connection to an external switch 4Console port
2Ethernet connection to a PC 5Power adapter
3ADSL-over-POTS connection
RIGHT / PRIMARY
ADSLoPOTS
ETHERNET LAN
3210
Cisco 877W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
FE4 FE3 FE2 FE1
1X
2X
1X
2X
1
1 2 5
3
122238
4
SN: XXXNNNNXXXX

1-15
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers
Figure 1-8 shows a typical installation of a Cisco 876 router.
Figure 1-8 Typical Installation of a Cisco 876 Router
1Ethernet connection to an external switch 4ADSL-over-ISDN connection
2Ethernet connection to a PC 5Console port
3ISDN S/T connection 6Power adapter
ADSL o ISDN
ISDN S/T
LAN
FE0 FE1 FE2 FE3
Cisco 876W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
RIGHT / PRIMARY
1X
2X
1X
2X
1
1 2 6
122239
5
4
3
SN: XXXNNNNXXXX

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Typical Installations of the Cisco 850 Series and Cisco 870 Series Routers
1-16
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Figure 1-9 shows a typical installation of a Cisco 878 router.
Figure 1-9 Typical Installation of a Cisco 878 Router
1Ethernet connection to an external switch 4G.SHDSL connection
2Ethernet connection to a PC 5Console port
3ISDN S/T connection 6Power adapter
G.SHDSL
ISDN S/T
LAN
FE0 FE1 FE2 FE3
Cisco 878W
CONSOLE
AUX
RESET
+5,+12 VDC
LEFT
RIGHT / PRIMARY
1X
2X
1X
2X
1
1 2 64
3
122240
5
SN: XXXNNNNXXXX

1-17
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Router
Connect the Router
Connect the router, referring to the typical installation for your router model as
shown in the “Typical Installations of the Cisco 850 Series and Cisco 870 Series
Routers” section on page 1-12.
Follow these steps to connect the router to the power supply, to your local
network, and to your service provider:
Step 1 Wireless models only: Make sure that you have attached the antennas to the router
as described in the “Connect the Antenna to the Wireless Router (Optional)”
section on page 1-8.
Step 2 If you are using a PoE module, make sure that it is connected to the router (see
“Connect the Power-over-Ethernet Module to the Cisco 870 Series Router
(Optional)” section on page 1-10). Connect the Ethernet devices to the PoE
module, not to the router.
Step 3 If you are connecting more than four PCs to the router, connect the router to a
switch or hub by using a yellow Ethernet cable, as shown in Figure 1-6 through
Figure 1-9.
Step 4 Connect a PC directly to your router, as shown in Figure 1-6 through Figure 1-9.
Turn off the PC so that it will obtain an IP address from the router when it is turned
on. You can connect additional PCs to the remaining numbered Ethernet ports.
Step 5 The console port is a service port to which you can connect a terminal or PC in
order to configure the software by using the command-line interface (CLI) or to
troubleshoot problems with the router. If you need access to the router console,
connect a PC or terminal to the console port.
Note By connecting the console port to an asynchronous modem using the
optional router modem cable, you can add dial backup and remote
management capabilities to the router.
Step 6 Cisco 851 and Cisco 871 routers only: Connect the second yellow Ethernet cable
between the router Ethernet WAN port and an available port on an installed digital
subscriber line (DSL), cable, or long-reach Ethernet modem as shown in
Figure 1-6.

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Connect the Router
1-18
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Follow the instructions provided with your broadband modem to determine which
port on the modem to connect to. Turn on the broadband modem if it is not already
turned on.
Step 7 Cisco 871 router only: Connect supported USB devices such as flash memory
modules or eTokens to the two USB ports. For more information, see the
Cisco Access Router USB Flash Module and USB eToken Hardware Installation
Guide. Proceed to Step 12.
Step 8 Cisco 857 and Cisco 877 routers only: Connect the ADSLoPOTS port on the
router to the telephone wall jack by using the lavender DSL cable. If the ADSL
line is also used for voice communication, you can prevent disruption to data
communication by connecting the router to an ADSL splitter, or by installing
microfilters between telephones or fax equipment and the wall jack. Proceed to
Step 12.
Caution Both LAN and WAN ports can use RJ-45 connectors. Use caution when
connecting cables to these connectors. To avoid damage to the router, do not
connect telephone-network voltage (TNV) circuits (such as ISDN or DSL
circuits) to safety extra-low voltage (SELV) circuits (such as LAN circuits).
Step 9 Cisco 876 and Cisco 878 routers only: For dial backup and remote management,
you can connect the ISDN S/T port to a Network Termination (NT1) box or an
ADSL splitter, using the orange ISDN S/T cable (ordered separately). Continue
to Step 10 or proceed to Step 11, as appropriate for your router model.
Step 10 Cisco 876 routers only: Connect the DSL cable to the ADSLoISDN port on the
router and to the ADSL splitter or wall socket. If you are using an ADSL splitter,
connect the splitter to the wall socket using a Category 5 unshielded twisted-pair
cable. Proceed to Step 12.
Step 11 Cisco 878 routers only: Connect the DSL cable to the G.SHDSL port on the router
and to the wall socket.
Step 12 All router models: Connect power to the router, and turn on the router. Be sure to
use the power supply that was shipped with the router. Other power supplies will
not connect to the router.
The green OK LED on the front panel of the router lights up when you connect
the router to a power source. The router is now ready for use.
If the green OK LED does not turn on, see the “Troubleshooting” chapter in the
Cisco 850 Series and Cisco 870 Series Routers Hardware Installation Guide.

1-19
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Install SDM and Configure the Router
Note For Cisco 857, Cisco 876, Cisco 877, and Cisco 878 routers, the DSL line
must have been provisioned by your service provider and must be
correctly configured. Check the carrier detect (CD) status on the ADSL
CD LED or G.SHDSL CD LED on the router. If the ADSL CD LED or
G.SHDSL CD LED does not light up, check with your service provider.
Step 13 If you have connected a PoE module to the router, connect the PoE module power
supply to the input jack on the back panel of the PoE module. The green LED on
the PoE front panel lights up and power is provided to devices connected to the
PoE.
See the Cisco 870 Series Routers Hardware Installation Guide for detailed
connection instructions.
Install SDM and Configure the Router
To install Cisco SDM for configuring the router, follow these steps:
Step 1 Connect a PC to any router LAN port, as shown in Figure 1-7, Figure 1-8 and
Figure 1-9.
Step 2 Insert the Cisco SDM software CD into the CD drive of the PC. An installation
wizard is launched from the CD. Install Cisco SDM by following the instructions
on the installation wizard user interface.
Step 3 Use Cisco SDM to configure the router by following the instructions in the
Cisco Router and Security Device Manager (SDM) Quick Start Guide.

Chapter 1 Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
Related Documentation
1-20
Cisco 850 Series and Cisco 870 Series Access Routers Cabling and Setup Quick Start Guide
78-16262-04
Related Documentation
This document describes the basic process of cabling and setting up the Cisco 850
series and Cisco 870 series routers. See the following documents for more
information:
•Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation
Guide—Provides detailed cabling and hardware information for the
Cisco 850 series and Cisco 870 series routers.
•Cisco Router and Security Device Manager (SDM) Quick Start
Guide—Provides step-by-step instructions for configuring the router and
wireless features by using the Cisco SDM web-based GUI.
•Cisco 850 Series and Cisco 870 Series Access Routers Software
Configuration Guide—Provides software configuration information and
examples for the Cisco 850 and Cisco 870 series routers.
•Cisco Access Router Wireless Configuration Guide—Provides wireless
software configuration information for Cisco access routers, including the
Cisco 850 series and Cisco 870 series.
•Upgrading Memory in Cisco 800 Series Routers—Provides information
about upgrading memory in the Cisco 800 series routers.
•Regulatory Compliance and Safety Information for Cisco 800 Series and
SOHO Series Routers—Provides regulatory compliance and safety
information about Cisco 800 series and SOHO series routers.
•Cisco Access Router USB Flash Module and USB eToken Hardware
Installation Guide—Provides information about installing USB flash memory
modules and eTokens.
These documents are available on the World Wide Web. You can access the most
current Cisco documentation on the World Wide Web at the following sites:
•http://www.cisco.com
•http://www-china.cisco.com
•http://www-europe.cisco.com
