Cisco ASR 1000 Series User manual

Removing and Replacing FRUs from the Cisco
ASR 1000 Series Routers
This chapter describes procedures for removing and replacing field-replaceable units (FRUs) from Cisco ASR
1000 Series Routers:
•Removing and Replacing Cisco ASR 1000 Series Route Processors, on page 1
•Removing and Replacing Cisco ASR 1000 Series Route Processor Internal Hard Drive, on page 4
•Removing and Replacing the Hard Drive on the Cisco ASR 1002-X Router, on page 13
•Removing and Replacing the Hard Drive on the Cisco ASR 1001 Router, on page 16
•Removing and Replacing the Cisco ASR 1000 Series DIMM Memory Modules, on page 19
•Removing and Replacing Cisco ASR 1000 Router eUSB Devices, on page 40
•Removing and Replacing Cisco ASR 1000 Series Router 1 GB USB Flash Token Memory Stick, on
page 47
•Minimum Requirements of eUSB Devices Supported on Cisco ASR 1000 Series Routers, on page 49
•Removing and Replacing Cisco ASR 1000 Series Embedded Service Processors, on page 50
•Removing and Replacing Cisco ASR 1000 Series Router SPAs and SPA Interface Processors, on page
53
•Removing and Replacing the Cisco ASR 1006 Router Power Supplies, on page 57
•Removing and Replacing the Cisco ASR 1004 Router Power Supplies, on page 71
•Removing and Replacing the Cisco ASR 1002 Router Power Supplies, on page 80
•Removing and Replacing the Cisco ASR 1013 Router Power Supplies, on page 98
•Removing and Replacing the Cisco ASR 1001 Router Power Supplies, on page 107
•Repacking the Router, on page 119
Removing and Replacing Cisco ASR 1000 Series Route
Processors
Keep in mind the following points before you remove and replace a Cisco ASR 1000 Series route processor:
• The Cisco ASR 1002 Router and the Cisco ASR 1002-F Router support only the integrated Cisco
ASR1002-RP1.
• If you have two Cisco ASR 1000 Series route processors in the Cisco ASR 1006 or Cisco ASR 1013
router and you want to remove one, do not power down the router. Remove the route processor and insert
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
1

a new one because high availability provides for the other route processor to take on the processing tasks
for the router.
• The Cisco ASR 1001 Router and the Cisco ASR 1002-X Router support an integrated route processor,
embedded services processor, and SIP.
The following sections describe the procedures for removing and replacing the Cisco ASR 1000 Series RP1
and Cisco ASR1000-RP2 in your Cisco ASR 1000 chassis. This section contains these topics:
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to any card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Removing the Cisco ASR 1000 Series Route Processor from the Cisco ASR
1006, Cisco ASR 1004, and Cisco ASR 1013 Routers
To remove the Cisco ASR 1000 Series route processor (RP1 or RP2) from the Cisco ASR 1006 Router, Cisco
ASR 1004 Router and Cisco ASR 1013 Router, follow this procedure:
SUMMARY STEPS
1. Slip on an ESD-preventive wrist strap and attach it to a chassis surface.
2. If connected, remove any I/O cables from the Cisco ASR 1000 Series route processor.
3. Using a number 2 Phillips or a 3/16-inch flat-blade screwdriver, loosen the two captive screws on the
faceplate of the Cisco ASR 1000 Series route processor.
4. Using the handles on both sides of the module, with two hands gently slide the module out of the chassis
slot.
5. Place the Cisco ASR 1000 Series route processor module on an antistatic surface with its printed circuit
board components facing upward or in a static shielding bag.
DETAILED STEPS
Step 1 Slip on an ESD-preventive wrist strap and attach it to a chassis surface.
Step 2 If connected, remove any I/O cables from the Cisco ASR 1000 Series route processor.
Step 3 Using a number 2 Phillips or a 3/16-inch flat-blade screwdriver, loosen the two captive screws on the faceplate of the
Cisco ASR 1000 Series route processor.
Step 4 Using the handles on both sides of the module, with two hands gently slide the module out of the chassis slot.
Handle the Cisco ASR 1000 Series route processor by the carrier edges only; never touch the printed circuit
board components or connector pins.
Warning
Step 5 Place the Cisco ASR 1000 Series route processor module on an antistatic surface with its printed circuit board components
facing upward or in a static shielding bag.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
2
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR 1000 Series Route Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers

If you are returning the Cisco ASR 1000 route processor to the factory, immediately place it in a static shielding
bag.
Note
What to do next
This completes the procedure for removing an installed Cisco ASR 1000 Series route processor from the
Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Router.
Replacing the Cisco ASR 1000 Series Route Processor in the Cisco ASR 1006,
Cisco ASR 1004, and Cisco ASR 1013 Routers
To replace the Cisco ASR 1000 Series route processor (RP1 or RP2) in the Cisco ASR 1006, Cisco ASR
1004, and Cisco ASR 1013 Routers, follow this procedure:
SUMMARY STEPS
1. Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
2. Remove the new Cisco ASR 1000 series route processor from its static shielding bag.
3. Using both hands, grasp the Cisco ASR 1000 Series route processor by its metal carrier edges and orient
the it so that its printed circuit board components are upward.
4. Align the left and right edges of the Cisco ASR 1000 Series route processor printed circuit board between
the route processor slot guides.
5. Gently slide the Cisco ASR 1000 Series route processor all the way into its chassis slot until you feel the
connectors seat with the router midplane.
6. Seat the route processor in the router midplane by tightening its captive installation screws with a number
2 Phillips or a 3/16-inch flat-blade screwdriver.
DETAILED STEPS
Step 1 Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
Step 2 Remove the new Cisco ASR 1000 series route processor from its static shielding bag.
Step 3 Using both hands, grasp the Cisco ASR 1000 Series route processor by its metal carrier edges and orient the it so that its
printed circuit board components are upward.
Handle the Cisco ASR 1000 Series route processor by the carrier edges and handle only; never touch the printed
circuit board components or connector pins.
Caution
Step 4 Align the left and right edges of the Cisco ASR 1000 Series route processor printed circuit board between the route
processor slot guides.
Step 5 Gently slide the Cisco ASR 1000 Series route processor all the way into its chassis slot until you feel the connectors seat
with the router midplane.
Step 6 Seat the route processor in the router midplane by tightening its captive installation screws with a number 2 Phillips or
a 3/16-inch flat-blade screwdriver.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
3
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR 1000 Series Route Processor in the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers

What to do next
This completes the procedure for replacing the Cisco ASR 1000 Series route processor in a Cisco ASR 1006
and Cisco ASR 1004 Router.
RemovingandReplacingCiscoASR1000SeriesRouteProcessor
Internal Hard Drive
Cisco ASR 1000 Series Routers support the Cisco ASR1000-RP1 and the Cisco ASR1000-RP2 route processors.
This section contains the following topics:
Cisco ASR1000-RP1 Spare Hard Drive Accessory Kit
The Cisco ASR 1000 Series RP1 spare hard drive ships with an accessory kit.Verify that the following items
have been shipped in the accessory kit before you remove and replace a damaged Cisco ASR 1000 Series
RP1 module internal hard drive:
• Hard drive assembly
• Two cables
• Tie wrap
• One EMI wrist strap
Follow these procedures to remove and then replace the Cisco ASR1000- RP1 internal hard drive in the Cisco
ASR 1006 and Cisco ASR 1004 Router.
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
• The Cisco ASR1000-RP1 requires an OIR (shutdown).
•The reason you would be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
• If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
• To restore the backup copy from an external USB flash memory stick plugged into a USB port to the
internal hard drive, type in:
archive tar /xtract usb0:asr1000.tar harddisk
• Verify that the internal hard drive installation was successful
Removing and Replacing the Cisco ASR1000-RP1 Module Internal Hard Drive
The Cisco ASR 1000 Series route processor (RP1) contains an internal hard drive disk that provides nonvolatile
storage in the form of an internal flash disk. The Cisco ASR 1000 Series RP1 module can be configured with
either a 40 GB or a 32 GB disk. Both components are field-replaceable on the Cisco ASR 1006 Router and
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
4
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Route Processor Internal Hard Drive

the Cisco ASR 1004 Router (there is no hard disk in the Cisco ASR 1002 Router). On the front panel of the
Cisco ASR 1000 Series RP, the DISK HD LED indicates activity on the hard drive.
This section explains how to remove a hard drive assembly from the Cisco ASR1000-RP1 module and replace
it with a new internal hard drive.
Removing the Cisco ASR1000-RP1 Internal Hard Drive
To remove the Cisco ASR1000-RP1 from the Cisco ASR 1000 Series Router, follow this procedure:
SUMMARY STEPS
1. Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the screw fasteners
on the Cisco ASR 1000 Series RP1 module.
2. Using the handles on both sides of the module, with two hands gently slide the Cisco ASR1000-RP1 out
of the chassis.
3. Place the module on a flat surface free of dust and dirt.
4. Remove the internal hard drive cover:
5. Remove the internal drive cover:
6. Inspect the existing cables and replace them only if they are damaged. If you do not need to replace them,
leave the connection to the Cisco ASR 1000 Series Route Processor 1 in place and only remove the
connection to the internal hard drive.
7. Carefully disconnect the cables at the rear of the hard drive. These cables are tie-wrapped in to prevent
them from disconnecting from the Cisco ASR 1000 Series RP1 itself. If the cables are not damaged, leave
the cables connected to the Cisco ASR 1000 Series RP1 with the tie wrap in place. Remove the old hard
drive.
8. If the cables are damaged:
DETAILED STEPS
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the screw fasteners on the Cisco
ASR 1000 Series RP1 module.
Step 2 Using the handles on both sides of the module, with two hands gently slide the Cisco ASR1000-RP1 out of the chassis.
Step 3 Place the module on a flat surface free of dust and dirt.
Step 4 Remove the internal hard drive cover:
a. Unscrew the fasteners.
b. Slide the cover off.
c. Lift the cover up from the board.
The following figure shows the Cisco ASR1000RP1 module internal hard drive unit.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
5
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP1 Internal Hard Drive

Figure 1: Cisco ASR1000RP1 Module Internal Hard Drive Unit
The following figure shows the Cisco ASR1000-RP1 module with the hard drive cover removed.
Figure 2: Cisco ASR1000-RP1 Module Hard Drive Cover and Screw Fastener
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
6
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP1 Internal Hard Drive

Step 5 Remove the internal drive cover:
a) Using a # 2 Phillips screwdriver or a flat head screwdriver, loosen the screw fasteners on the cover.
b) Slide the cover off as shown in xref Figure 14-2.
c) Lift the cover up from the board.
Step 6 Inspect the existing cables and replace them only if they are damaged. If you do not need to replace them, leave the
connection to the Cisco ASR 1000 Series Route Processor 1 in place and only remove the connection to the internal hard
drive.
Step 7 Carefully disconnect the cables at the rear of the hard drive. These cables are tie-wrapped in to prevent them from
disconnecting from the Cisco ASR 1000 Series RP1 itself. If the cables are not damaged, leave the cables connected to
the Cisco ASR 1000 Series RP1 with the tie wrap in place. Remove the old hard drive.
The following figure shows the cables still connected because they do not have to be replaced.
Figure 3: Cisco ASR1000-RP1 Module With Internal Hard Drive Removed
Step 8 If the cables are damaged:
a) Remove the tie wrap around the cables.
b) Disconnect the cables from both the Cisco ASR 1000 Series Route Processor 1 connector and the internal hard drive
connector as shown in the following figure.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
7
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP1 Internal Hard Drive

Figure 4: Cisco ASR1000-RP1 Module Internal Hard Drive and Module Base
This completes the procedure for disconnecting the Cisco ASR 1000 Series RP internal hard drive.
Replacing the Cisco ASR1000-RP1 Internal Hard Drive
To replace the Cisco ASR1000-RP1 internal hard drive and insert the Cisco ASR 1000 Series Route Processor
1 into the Cisco ASR 1000 Series Router, follow these steps:
SUMMARY STEPS
1. On the Cisco ASR1000-RP1, carefully align the new hard drive unit with its screw fastener to the base
screw on the bottom of the module.
2. Reconnect the two cables to the rear of the hard drive. These are keyed for easy connection.
3. Align hard drive module to carrier base tabs, align the module fastener to base screw mate by hand, and
then tighten with screw driver.
4. Replace the cover by aligning the tabs in the slot and tightening the screw fasteners.
5. With two hands, grab the handles on the Cisco ASR1000-RP1 module and slide it back into its slot in the
Cisco ASR 1000 Series Router and tighten the captive screw.
DETAILED STEPS
Step 1 On the Cisco ASR1000-RP1, carefully align the new hard drive unit with its screw fastener to the base screw on the
bottom of the module.
Step 2 Reconnect the two cables to the rear of the hard drive. These are keyed for easy connection.
The following figure shows the Cisco ASR1000-RP1 module internal hard drive and module base.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
8
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR1000-RP1 Internal Hard Drive

Figure 5: Cisco ASR1000-RP1 Module Internal Hard Drive and Module Base
Carrier mating fastener2Hard drive module fastener1
Step 3 Align hard drive module to carrier base tabs, align the module fastener to base screw mate by hand, and then tighten with
screw driver.
Step 4 Replace the cover by aligning the tabs in the slot and tightening the screw fasteners.
Step 5 With two hands, grab the handles on the Cisco ASR1000-RP1 module and slide it back into its slot in the Cisco ASR
1000 Series Router and tighten the captive screw.
Removing and Replacing the Cisco ASR1000-RP2 Module Internal Hard Drive
This section explains how to remove a hard drive assembly from the Cisco ASR 1000 Series RP2 module and
replace it with a new internal hard drive.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
9
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR1000-RP2 Module Internal Hard Drive

During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
• The form-factor internal hard drive is accessible from the front panel of the Cisco ASR1000-RP2 and
supports the online insertion and removal feature (OIR) using the following CLI commands for the
standby and active RP2:
•request platform hardware filesystem harddisk: offline (Unmounts the hard disk on the active
RP2.)
•request platform hardware filesystem harddisk: online (Mounts the hard disk on the active RP2.)
If the disk is not provisioned properly, this command will provision the disk.
•request platform hardware filesystem stby-harddisk: offline (Unmounts the hard disk on the
standby RP2.)
•requestplatformhardwarefilesystemstby-harddisk: online(Mounts the hard disk on the standby
RP2. If the disk is not provisioned properly, this command will provision the disk.)
•The reason you would be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
• If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
Removing the Cisco ASR1000-RP2 Internal Hard Drive
To remove the Cisco ASR1000-RP2 internal hard drive from the Cisco ASR 1006 Router and Cisco ASR
1004 Router, follow this procedure:
SUMMARY STEPS
1. Run the request platform hardware filesystem harddisk: offline command.
2. Slip on an ESD-preventive wrist strap.
3. From the front panel of the Cisco ASR1000-RP2, unscrew the fastener screw (see the following figure).
4. Pull the internal hard drive out as shown in the following figure.
5. Place the component in an antistatic bag if you are returning it.
6. Wait until the following console message is displayed:
DETAILED STEPS
Step 1 Run the request platform hardware filesystem harddisk: offline command.
Step 2 Slip on an ESD-preventive wrist strap.
Step 3 From the front panel of the Cisco ASR1000-RP2, unscrew the fastener screw (see the following figure).
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
10
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP2 Internal Hard Drive

Figure 6: Cisco ASR1000-RP2 Front Panel
Internal hard drive2Internal hard drive fastener screw1
Step 4 Pull the internal hard drive out as shown in the following figure.
Figure 7: Cisco ASR1000-RP2 Internal Hard Drive
Internal hard drive2Internal hard drive fastener screw location1
Step 5 Place the component in an antistatic bag if you are returning it.
Step 6 Wait until the following console message is displayed:
Example:
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
11
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP2 Internal Hard Drive

%IOSXE-0-PLATFORM: R0/0: udev: harddisk: has been removed
What to do next
You have successfully removed the Cisco ASR1000-RP2 hard drive.
Replacing the Cisco ASR1000-RP2 Internal Hard Drive
To replace the Cisco ASR1000-RP2 internal hard drive and insert the Cisco ASR1000-RP 2 into the Cisco
ASR 1000 Series Router, follow these steps:
SUMMARY STEPS
1. Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component
is keyed for easy insertion.
2. Tighten the fastener screw on the front panel.
3. Wait until the following console message is displayed:
4. Verify the disk is working by running: dir harddisk
DETAILED STEPS
Step 1 Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component is keyed for easy
insertion.
Step 2 Tighten the fastener screw on the front panel.
Step 3 Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If, after several minutes, the above message is not displayed, run:
request platform hardware filesystem harddisk: online
The only reason the system would not be able to automatically mount the new hard disk following a physical
insertion is if the disk is not partitioned correctly.
Note
Step 4 Verify the disk is working by running: dir harddisk
What to do next
You have completed the steps required to replace the Cisco ASR1000-RP2 internal hard drive.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
12
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR1000-RP2 Internal Hard Drive

RemovingandReplacingtheHardDriveontheCiscoASR1002-X
Router
The Cisco ASR 1002-X Router supports an optional removable hard drive. This section explains how to
remove and replace this hard drive.
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
• The hard drive is accessible from the front panel of the router and supports the online insertion and
removal feature (OIR) using the following CLI commands:
•request platform hardware filesystem harddisk: offline (unmounts the hard disk)
•request platform hardware filesystem harddisk: online (mounts the hard disk.)
• The reason you may be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
• If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
Removing the Hard Drive from the Cisco ASR 1002-X Router
To remove the hard drive from the Cisco ASR 1002-X Router, follow this procedure:
SUMMARY STEPS
1. Run the request platform hardware filesystem harddisk: offline command.
2. Slip on an ESD-preventive wrist strap.
3. From the front panel of the router, unscrew the fastener screws by using a # 2 Phillips screwdriver or a
flat head screwdriver (see xref Figure 14-6).
4. Pull the hard drive out as shown in xref Figure 14-7.
5. Place the hard drive in an antistatic bag if you are returning it.
6. Wait until the following console message is displayed:
DETAILED STEPS
Step 1 Run the request platform hardware filesystem harddisk: offline command.
Step 2 Slip on an ESD-preventive wrist strap.
Step 3 From the front panel of the router, unscrew the fastener screws by using a # 2 Phillips screwdriver or a flat head screwdriver
(see xref Figure 14-6).
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
13
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X Router

Figure 8: Cisco ASR1002-X Router Front Panel
Internal hard drive2Internal hard drive fastener screw1
Step 4 Pull the hard drive out as shown in xref Figure 14-7.
Figure 9: Cisco ASR1002-X Router Hard Drive
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
14
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Hard Drive from the Cisco ASR 1002-X Router

Hard drive2Hard drive fastener screw location1
Step 5 Place the hard drive in an antistatic bag if you are returning it.
Step 6 Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: has been removed
What to do next
You have successfully removed the hard drive from the Cisco ASR 1002-X Router.
Replacing the Hard Drive on the Cisco ASR 1002-X Router
To insert or replace the hard drive on the Cisco ASR 1002-X Router, follow this procedure:
SUMMARY STEPS
1. Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy
insertion.
2. Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
3. Wait until the following console message is displayed:
4. Verify that the hard drive is working by running the following command:
DETAILED STEPS
Step 1 Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy insertion.
Step 2 Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
Step 3 Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If this message is not displayed after a few minutes, run the following command:
request platform hardware filesystem harddisk: online
If the new hard drive system does not get mounted automatically, the disk may not be partitioned correctly.
Note
Step 4 Verify that the hard drive is working by running the following command:
dir harddisk
What to do next
You have successfully replaced the hard drive on the Cisco ASR 1002-X Router.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
15
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Hard Drive on the Cisco ASR 1002-X Router

Removing and Replacing the Hard Drive on the Cisco ASR 1001
Router
The Cisco ASR 1001 Router supports an optional removable hard drive. This section explains how to remove
and replace this hard drive.
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
• The hard drive is accessible from the front panel of the router and supports the online insertion and
removal feature (OIR) using the following CLI commands:
•request platform hardware filesystem harddisk: offline (unmounts the hard disk)
•request platform hardware filesystem harddisk: online (mounts the hard disk.)
• The reason you may be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
• If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
Removing the Hard Drive from the Cisco ASR 1001 Router
To remove the hard drive from the Cisco ASR 1001 Router, follow this procedure:
SUMMARY STEPS
1. Run the request platform hardware filesystem harddisk: offline command.
2. Slip on an ESD-preventive wrist strap.
3. From the front panel of the router, unscrew the fastener screws by using a # 2 Phillips screwdriver or a
flat head screwdriver (see xref Figure 14-6).
4. Pull the hard drive out as shown in xref Figure 14-7.
5. Place the hard drive in an antistatic bag if you are returning it.
6. Wait until the following console message is displayed:
DETAILED STEPS
Step 1 Run the request platform hardware filesystem harddisk: offline command.
Step 2 Slip on an ESD-preventive wrist strap.
Step 3 From the front panel of the router, unscrew the fastener screws by using a # 2 Phillips screwdriver or a flat head screwdriver
(see xref Figure 14-6).
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
16
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Hard Drive on the Cisco ASR 1001 Router

Figure 10: Cisco ASR1001 Router Front Panel
Internal hard drive2Internal hard drive fastener screw1
Step 4 Pull the hard drive out as shown in xref Figure 14-7.
Figure 11: Cisco ASR1001 Router Hard Drive
Hard drive2Hard drive fastener screw location1
Step 5 Place the hard drive in an antistatic bag if you are returning it.
Step 6 Wait until the following console message is displayed:
Example:
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
17
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Hard Drive from the Cisco ASR 1001 Router

%IOSXE-0-PLATFORM: R0/0: udev: harddisk: has been removed
What to do next
You have successfully removed the hard drive from the Cisco ASR 1001 Router.
Replacing the Hard Drive on the Cisco ASR 1001 Router
To insert or replace the hard drive on the Cisco ASR 1001 Router, follow this procedure:
SUMMARY STEPS
1. Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy
insertion.
2. Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
3. Wait until the following console message is displayed:
4. Verify that the hard drive is working by running the following command:
DETAILED STEPS
Step 1 Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy insertion.
Step 2 Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
Step 3 Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If this message is not displayed after a few minutes, run the following command:
request platform hardware filesystem harddisk: online
If the new hard drive system does not get mounted automatically, the disk may not be partitioned correctly.
Note
Step 4 Verify that the hard drive is working by running the following command:
dir harddisk
What to do next
You have successfully replaced the hard drive on the Cisco ASR 1001 Router.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
18
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Hard Drive on the Cisco ASR 1001 Router

Removing and Replacing the Cisco ASR 1000 Series DIMM
Memory Modules
Cisco ASR 1000 Series Routers support the Cisco ASR1000-RP1 and the Cisco ASR1000-RP2 route processor
DIMM memory modules for system DRAM. This section describes how to replace the DIMMs on the Cisco
ASR1000-RP1, the Cisco ASR1000-RP2 route processors, the Cisco ASR 1001, and the Cisco ASR 1002-X
routers.
The following table shows the Cisco ASR1000-RP1 and Cisco ASR1000-RP2 memory design.
Table 1: Cisco ASR 1000 Series Route Processor Memory Support
Cisco ASR1000-RP2Cisco ASR1000-RP1
Supports up to 16 GB memorySupports up to 4 GB memory
• 4 GB dual rank VLP DIMMs• 1 GB (2 GB)
miniDIMMs
• Up to 4 DIMMs with up to two DIMMs per
channel
• DDR-533
• Allowable memory options of 4 GB, 8 GB, or 16
GB
—
• DDR-667—
You might need to upgrade the DIMM for the following reasons:
• You have upgraded to a new Cisco IOS feature set or release that requires more memory.
• You are using very large routing tables or many protocols.
This section contains the following topics:
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006
Router and the Cisco ASR 1013 Router
The Cisco ASR 1006 Router and the Cisco ASR 1013 Router have redundant RPs. The following is an
overview of the steps to remove and replace the DIMM memory modules on these routers:
SUMMARY STEPS
1. Remove the standby RP by performing the procedure described in the xref “Removing the Cisco ASR
1000 Series Route Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers”
section.
2. Remove the DIMM memory module from the standby RP by performing one of the following procedures:
• Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules
Removing the Cisco ASR1000-RP2 DIMMs
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
19
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR 1000 Series DIMM Memory Modules

3. Insert the new DIMM memory module on the standby RP by performing one of the following procedures:
• Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules
Removing the Cisco ASR1000-RP2 DIMMs
4. Insert the standby RP by performing the procedure described in the xref “Removing the Cisco ASR 1000
Series Route Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers” section.
5. Verify the memory upgrade on the standby RP by running the following commands:
6. Use the redundancy force-switchover command to switch the upgraded standby RP to the active state.
The RP that was in the active state moves to the standby state.
7. Repeat Step 1 through Step 5 on the standby RP.
DETAILED STEPS
Step 1 Remove the standby RP by performing the procedure described in the xref “Removing the Cisco ASR 1000 Series Route
Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers” section.
Step 2 Remove the DIMM memory module from the standby RP by performing one of the following procedures:
• Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules
Removing the Cisco ASR1000-RP2 DIMMs
Step 3 Insert the new DIMM memory module on the standby RP by performing one of the following procedures:
• Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules
Removing the Cisco ASR1000-RP2 DIMMs
Step 4 Insert the standby RP by performing the procedure described in the xref “Removing the Cisco ASR 1000 Series Route
Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers” section.
Step 5 Verify the memory upgrade on the standby RP by running the following commands:
Example:
Router# configure terminal
Router(config-red)# redundancy
Router(config-r-mc)# main-cpu
Router(config-r-mc)# standby console enable
Router(config-r-mc)# end
Router-stby# show version
Cisco IOS Software, IOS-XE Software (PPC_LINUX_IOSD-ADVENTERPRISEK9-M), Experimental Version
15.2(20111220:221816) [v152_2_s_xe36_throttle-tozhang-xe36_ios 114]
.
.
.
cisco ASR1006 (RP1) processor with 1689519K/6147K bytes of memory.
Processor board ID FOX1224G4VX
20 Gigabit Ethernet interfaces
32768K bytes of non-volatile configuration memory.
4194304K bytes of physical memory.
955063K bytes of eUSB flash at bootflash:.
39004543K bytes of SATA hard disk at harddisk:.
.
.
.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
20
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006 Router and the Cisco ASR 1013 Router
