Cisco Cisco 760 Series User manual

Unpack the Router
Connect Cables to the Router
Set Up the Router
1
2
3
Quick Start Guide
CISCO 760 SERIES CABLING AND SETUP
2
Cisco 700 series router
Internet
Internet service provider/
corporate headquarters
ISDN provider/
telephone company
ISDN telephone jack
Phone #1
Power supply
Phone #2
Your computer
Your computer
Your computer

2
1Unpack the Router
Remove the router from the package and locate the clear plastic bag labeled “Open Me First.” The bag contains
all the required cables for your router. Also remove the black power supply located in the accessory kit.
1 Cisco 760 series router
1 yellow Ethernet cable
1 red ISDN U cable Cisco 762, Cisco 766 routers only.
1 orange ISDN S/T cable Cisco 761, Cisco 765 routers only.
1 RJ-45-to-RJ-11 adapter
1 blue config cable
(optional)
1 black power supply
1 black power supply cord
1 Cisco Fast Step CD-ROM
and 2 Cisco Documentation
CD-ROMs
RD
NT1
LINE
LAN
RXD
TXD
CH1 RXD TXD
CH2
RXD
TXD
PH1
PH2

3
2Connect Cables to the Router
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
NT-1
ISDN S/T
CISCO 776
10BASET
ISDN U
NODE HUB
(Cisco 766 shown)
CONFIG
ETHERNET
NODE HUB ISDN S/T
ISDN U PHONE 1 PHONE 2 Power switch
Power connector
The ports on the router and the cables are color
coded to assist you in making the proper
connections. Position the router so that the rear
panel is facing you.
The following pages contain detailed
instructions on connecting cables to your
router.

4
2Connect the Ethernet Cable to a Computer or Hub
Option 1: To connect the Ethernet cable to a computer, go to option 1 below.
Option 2: To connect the Ethernet cable to a hub, go to option 2 below.
Option 1 Connect the Ethernet Cable to a Computer
Option 2 Connect the Ethernet Cable to a Hub
1Connect the yellow Ethernet cable to the
yellow port labeled ETHERNET on the
rear panel of your router.
2Connect the other end of the cable to the
Ethernet connector on the back of your
computer.
3Set the node-hub switch to the “HUB”
position.
1Connect the yellow Ethernet cable to the
yellow port labeled ETHERNET on the
rear panel of your router.
2Connect the other end of the cable to an
available port on your Ethernet hub.
3Set the node-hub switch to the “NODE”
position.
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
ISDN S/T
CISCO 776
10BASET
NODE HUB
1
2
Ethernet hub
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
NT-1
ISDNS/T
CISCO 776
10BASET
ISDN U
NODE HUB
Ethernet
cable
13
2

5
2Connect the ISDN Line
Check the rear panel of your router to find out which model you have.
Option 1: If you have a Cisco 762 or 766, go to option 1 below.
Option 2: If you have a Cisco 761 or 765, go to option 2 below.
Option 1 Connect the ISDN Line to a Cisco 762 or Cisco 766 Router
Option 2 Connect the ISDN Line to a Cisco 761 or Cisco 765 Router
1Connect the red ISDN U cable to the red port
labeled ISDN U on the rear panel of your router.
2Connect the other end of the ISDN U cable
directly to an RJ-45 ISDN wall jack. If necessary,
use the enclosed RJ-45-to-RJ-11 adapter to
connect to an RJ-11 ISDN wall jack.
Outside North America
1Connect the orange ISDN S/T cable to the orange
port labeled ISDN S/T on the rear panel of your
router.
2Connect the other end of the ISDN S/T cable to
the ISDN wall socket.
North America Only
1Connect the orange ISDN S/T cable to the orange
port labeled ISDN S/T on the rear panel of your
router.
2Connect the other end of the orange ISDN S/T
cable to the NT1 terminal connector.
3Connect the NT1 terminal connector to the
ISDN wall jack using the ISDN S/T cable that
came with your NT1 terminal connector.
RJ-11
wall jack
2.
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
NT-1
ISDNS/T
CISCO 776
10BASET
ISDN U
NODE HUB
ISDN U
cable
1
2
RJ-45
wall jack
CONFIG
+5V---1.5A +/-5%
-30V--- 0.2A+/-25%
S
0
ISDN S/T
CISCO 776
10BASET
NODE HUB
ISDN
wall socket
ISDN S/T
cable
1
2
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
NT-1
ISDN S/T
CISCO 776
10BASET
ISDN U
NODE HUB
ISDN S/T
cable
NT1 terminal conne
c
(not included)
ISDN S/T cable
(not included)
RJ-45
wall jack
1
23

6
If you are using a Cisco 765 or Cisco 766, you can
connect telephones and facsimile machines directly
to the router.
Connect the telephone cable (provided with your
telephone or facsimile machine) to the gray port
labeled PHONE 1 or PHONE 2 on the rear panel of
your router.
If you are connecting only one device, connect it to
the port labeled PHONE 1.
2Connect Optional Telephones and Facsimile Machines
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
NT-1
ISDN S/T
CISCO 776
10BASET
ISDN U
NODEHUB
Telephone
RJ-11 telephone cable

7
2Connect Power and Turn On the Router
CONFIG
+5V ---1.5A +/-5%
-30V--- 0.2A +/-25%
S
0
ISDN S/T
CISCO 776
ETHERNET
1234
BRI
???
Power connector
14
Desktop power supply
2
3
Step 1 Connect the round end of the power
supply cable to the black circular power
connector on the rear panel of your router.
Step 2 Connect the black power supply cord to
the black power supply.
Step 3 Connect the power supply cord to an
electrical outlet.
Step 4 Turn on the router by using the on/off
switch on the rear panel.
The green RDY LED (and the NT1 LED on the
Cisco 762 and Cisco 766) on the front panel of your
router goes on. Your router is ready to be configured.
If the green RDY LED is not on, refer to the
“Troubleshooting Cisco 700 Series Routers” chapter
in the Cisco 700 Series Installation Guide, located
inside the plastic bag labeled “Open Me Only If
Needed.”

8
3Set Up the Router
If you are configuring your router using Microsoft
Windows 95 or Windows NT version 4 operating
systems, insert the CD-ROM located in the back of this
guide into the CD-ROM drive of your computer. The
Fast Step setup program should start automatically.
If the setup program does not start automatically, follow
these instructions:
Step 1 Double-click the My Computer icon.
Step 2 Double-click the CD icon.
Step 3 Double-click the Setup.exe icon.
Follow the on-screen instructions to guide you through
setting up and testing of the router.
For your convenience, information on ordering your
ISDN line is provided on page 9. A form prompting you
for setup information is on page 10.

9
Order the ISDN Line
Step 1 Contact your ISDN service provider
(usually the telephone company).
Step 2 Order a single 128-kbps ISDN BRI line
(which is equivalent to two telephone
lines).
If applicable, request the additional call
offering option that allows telephone
conversations while the router is in use.
Order other features you want—for
example, call conferencing, call waiting,
or call transferring.
Step 3 Obtain and record the following
information from your ISDN service
provider:
ISDN Information
1Switch type (check one):
NI-1 National ISDN-1
5ESS AT&T 5ESS
DMS Nortel DMS-100
INS Japan - NTT Information
Network System
VN3 France - ISDN BRI Standard
NET3 Europe - ISDN BRI Standard
1TR6 Germany - ISDN Standard
TPH Australia
2SPIDs (optional):
a. SPID1
b. SPID2
3ISDN telephone numbers (optional):
a. ISDN telephone number 1
b. ISDN telephone number 2

10
Gather Connection Information
Option 1: To connect directly to an Internet service provider, go to option 1 below.
Option 2: To connect directly to your remote corporate network, go to option 2 below.
Option 1 Internet Service Provider
Step 1 Contact your Internet service provider.
Step 2 Order Internet service for a single
128-kbps ISDN BRI line.
Step 3 Obtain and record the following
information from your Internet service
provider. Some of this information may
not be required.
4Internet service provider telephone number
5Internet service provider second telephone
number (optional)
6Your router user name
7Your Internet service provider password
8Primary DNS
9Secondary DNS
10 WAN IP address
11 WAN subnet mask
Option 2 Remote Corporate Network
Step 1 Contact your network administrator.
Step 2 Obtain and record the following
information from your network
administrator. Some of this information
may not be required.
4Remote corporate network telephone number
5Remote corporate network second telephone
number (optional)
6Your router user name
7Your remote corporate network password
To use Internet applications like Web browsers, or to
connect to Microsoft Windows NT servers using
TCP/IP, obtain the following information:
8Primary DNS
9Secondary DNS
10 WAN IP address
11 WAN subnet mask
12 Primary WINS
13 Secondary WINS
To connect to files and printers on NetWare,
Windows NT, or Windows 95 computers using the
Novell protocol, obtain the following information:
14 IPX LAN network number
15 IPX frame type (check one):
Ethernet_II 802.3 802.2 SNAP
16 IPX WAN network number
