Cisco IR829 Manual

Cisco IR829 Industrial Integrated Services Router Hardware Installation
Guide
First Published: 2017-10-11
Last Modified: 2018-10-25
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS,
INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH
THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY,
CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version of
the UNIX operating system. All rights reserved. Copyright ©1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS.
CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS
HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network
topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional
and coincidental.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com
go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1721R)
©2017–2018 Cisco Systems, Inc. All rights reserved.

CHAPTER 1
Preface
This preface describes the objectives, audience, organization, and conventions of this guide and describes
related documents that have additional information. It contains the following sections:
•Preface, on page 1
Preface
This preface describes the objectives, audience, organization, and conventions of this guide and describes
related documents that have additional information. It contains the following sections:
Objective
This guide provides an overview and explains how to install, connect, and perform initial configuration for
the Cisco IR829. Previous versions contained additional configuration information which has now been
relocated to the Cisco IR800 Integrated Services Router Software Configuration Guide.
Audience
This guide is intended for people who have a high level of technical ability, although they may not have
experience with Cisco software.
Conventions
This section describes the conventions used in this guide.
NOTE: Means reader take note. Notes contain helpful suggestions or references to additional information
and material.
CAUTION: This symbol means reader be careful. In this situation, you might do something that could result
in equipment damage or loss of data.
TIP: Means the following information will help you solve a problem . The tip information might not be
troubleshooting or even an action, but could be useful information.
WARNING: IMPORTANT SAFETY INSTRUCTIONS Means danger. You are in a situation that
could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
1

number provided at the end of each warning to locate its translation in the translated safety warnings
that accompanied this device.
Safety Warnings
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work
on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents. Use the statement number provided at the end of each warning to locate
its translation in the translated safety warnings that accompanied this device. Statement 1071
SAVE THESE INSTRUCTIONS
Warning
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan veroorzaken.
Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij elektrische schakelingen
betrokken risico's en dient u op de hoogte te zijn van de standaard praktijken om ongelukken te voorkomen.
Gebruik het nummer van de verklaring onderaan de waarschuwing als u een vertaling van de waarschuwing
die bij het apparaat wordt geleverd, wilt raadplegen.
BEWAAR DEZE INSTRUCTIES
Waarschuwing
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin käsittelet
laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu onnettomuuksien yleisiin
ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen mukana toimitettujen käännettyjen
turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien lausuntonumeroiden avulla.
SÄILYTÄ NÄMÄ OHJEET
Varoitus
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant entraîner des
blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des dangers
liés aux circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour éviter les
accidents. Pour prendre connaissance des traductions des avertissements figurant dans les consignes de
sécurité traduites qui accompagnent cet appareil, référez-vous au numéro de l'instruction situé à la fin de
chaque avertissement.
CONSERVEZ CES INFORMATIONS
Attention
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann.
Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen
Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen
Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen
mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
Warnung
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
2
Preface
Safety Warnings

IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone.
Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai circuiti
elettrici e conoscere le procedure standard per la prevenzione di incidenti. Utilizzare il numero di istruzione
presente alla fine di ciascuna avvertenza per individuare le traduzioni delle avvertenze riportate in questo
documento.
CONSERVARE QUESTE ISTRUZIONI
Avvertenza
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du begynner
å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med elektriske kretser, og kjenne
til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten av hver advarsel for å finne
oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Advarsel
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de lesões
corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos perigos envolvidos
no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de prevenção de acidentes.
Utilize o número da instrução fornecido ao final de cada aviso para localizar sua tradução nos avisos de
segurança traduzidos que acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular cualquier
equipo, considere los riesgos de la corriente eléctrica y familiarícese con los procedimientos estándar de
prevención de accidentes. Al final de cada advertencia encontrará el número que le ayudará a encontrar el
texto traducido en el apartado de traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES
¡Advertencia!
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du
utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanliga
förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av varje varning för att hitta
dess översättning i de översatta säkerhetsvarningar som medföljer denna anordning.
SPARA DESSA ANVISNINGAR
Varning!
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
3
Preface
Safety Warnings

INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões corporais.
Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os circuitos elétricos
e familiarize-se com as práticas padrão de prevenção de acidentes. Use o número da declaração fornecido
ao final de cada aviso para localizar sua tradução nos avisos de segurança traduzidos que acompanham o
dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
VIGTIGE SIKKERHEDSANVISNINGER
Dette advarselssymbol betyder fare. Du befinder dig i en situation med risiko for legemesbeskadigelse. Før
du begynder arbejde på udstyr, skal du være opmærksom på de involverede risici, der er ved elektriske
kredsløb, og du skal sætte dig ind i standardprocedurer til undgåelse af ulykker. Brug erklæringsnummeret
efter hver advarsel for at finde oversættelsen i de oversatte advarsler, der fulgte med denne enhed.
GEM DISSE ANVISNINGER
Advarsel
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
4
Preface
Safety Warnings

Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
5
Preface
Safety Warnings

WARNING: When installing the product, please use the provided or designated connection cables/power
cables/AC adapters. Using any other cables/adapters could cause a malfunction or a fire. Electrical Appliance
and Material Safety Law prohibits the use of UL-certified cables (that have the “UL” shown on the code) for
any other electrical devices than products designated by CISCO. The use of cables that are certified by Electrical
Appliance and Material Safety Law (that have “PSE” shown on the code) is not limited to CISCO-designated
products. Statement 371
WARNING: Read the wall-mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage
to the system. Statement 378
WARNING: To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to
telephone-network voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV
circuits. Some LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables. Statement
1021
WARNING: T his equipment must be grounded. Never defeat the ground conductor or operate the equipment
in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority
or an electrician if you are uncertain that suitable grounding is available . Statement 1024
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
6
Preface
Safety Warnings

WARNING: If the symbol of suitability with an overlaid cross appears above a port, you must not connect
the port to a public network that follows the European Union standards. Connecting the port to this type of
public network can cause severe personal injury or can damage the unit. Statement 1031
WARNING: Connect the unit only to DC power source that complies with the safety extra-low voltage
(SELV) requirements in IEC 60950 based safety standards. Statement 1033
Requirements in IEC 60950 based safety standards. Statement 1033
WARNING: When installing or replacing the unit, the ground connection must always be made first and
disconnected last. Statement 1046
WARNING: Do not locate the antenna near overhead power lines or other electric light or power circuits, or
where it can come into contact with such circuits. When installing the antenna, take extreme care not to come
into contact with such circuits, because they may cause serious injury or death. For proper installation and
grounding of the antenna, please refer to national and local codes (for example, U.S.:NFPA 70, National
Electrical Code, Article 810, Canada: Canadian Electrical Code, Section 54). Statement 1052
WARNING: No user-serviceable parts inside. Do not open. Statement 1073
WARNING: Installation of the equipment must comply with local and national electrical codes. Statement
1074
WARNING: Only trained and qualified personnel should be allowed to install, replace, or service this
equipment. Statement 1030
WARNING: Read the installation instructions before connecting the system to the power source. Statement
1004
WARNING: Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040
WARNING: The covers are an integral part of the safety design of the product. Do not operate the unit without
the covers installed. Statement 1077
WARNING: Hot surface. Statement 1079
Related Documentation
•https://www.cisco.com/c/en/us/support/ios-nx-os-software/ios-15-5m-t/
tsd-products-support-series-home.html
•Cisco 800 Series Industrial Integrated Services Routers
•Cisco IR800 Integrated Services Router Software Configuration Guide.
Searching Cisco Documents
To search an HTML document using a web browser, press Ctrl-F (Windows) or Cmd-F (Apple). In most
browsers, the option to search whole words only, invoke case sensitivity, or search forward and backward is
also available.
To search a PDF document in Adobe Reader, use the basic Find toolbar (Ctrl-F) or the Full Reader Search
window (Shift-Ctrl-F). Use the Find toolbar to find words or phrases within a specific document. Use the
Full Reader Search window to search multiple PDF files simultaneously and to change case sensitivity and
other options. Adobe Reader’s online help has more information about how to search PDF documents.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
7
Preface
Related Documentation

Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information,
see the monthly What’s New in Cisco Product Documentation , which also lists all new and revised Cisco
technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed
and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free
service and Cisco currently supports RSS Version 2.0.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
8
Preface
Obtaining Documentation and Submitting a Service Request

CHAPTER 2
Product Overview
This chapter provides an overview of the features available for the Cisco IR829 Integrated Services Routers
(ISRs) and contains the following sections:
•Product Overview, on page 9
Product Overview
This chapter provides an overview of the features available for the Cisco IR829 Integrated Services Routers
(ISRs) and contains the following sections:
NOTE: For compliance and safety information, see Regulatory Compliance and Safety Information for Cisco
800 Series Routers.
General Description
The Cisco IR829 Integrated Services Router, part of the Cisco Integrated Services Routers Generation 2 (ISR
G2) Family, is designed as a next generation ruggedized fixed form factor router. It is a a small-form factor
cellular router targeting mobile/vehicle applications and includes WiFi to provide connectivity in non-carpeted
IT spaces, Industrials, Utilities, Transportation, Infrastructure, Industrial M2M application, and asset monitoring.
The IR829 comes in two models, single LTE modem and dual LTE modems.
Figure 1: Cisco IR829 Integrated Services Router, on page 10 shows the IR829.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
9

Figure 1: Cisco IR829 Integrated Services Router
Figure 2: Cisco IR829 Front Panel Single Modem, on page 10 shows the front panel details of the Cisco
IR829 Single Modem.
Figure 2: Cisco IR829 Front Panel Single Modem
Serial Ports5CELLULAR 0 AUX1
USB 2.0 type-A Port6mSATA SSD Slot2
Power Input, Battery, and
Ignition connector. Refer
to the DC Power section
for pin-outs.
7Gigabit WAN (SFP)3
WLAN ANT 0 2.4GHz8Gigabit Ethernet
LAN/PoE (RJ45)
4
Figure 3: Cisco IR829 Front Panel Dual Modem, on page 11 shows the front panel details of the Cisco IR829
Dual Modem.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
10
Product Overview
General Description

Figure 3: Cisco IR829 Front Panel Dual Modem
Serial Ports5CELLULAR 0 AUX1
USB 2.0 type-A Port6Limited Modularity Slot2
Power Input, Battery, and
Ignition connector. Refer
to the DC Power section
for pin-outs.
7Gigabit WAN (SFP)3
WLAN ANT 0 2.4/5GHz8Gigabit Ethernet
LAN/PoE (RJ45)
4
Figure 4: Cisco IR829 Back Panel Single Modem, on page 11 shows the back panels details of the Cisco
IR829 Single Modem.
Figure 4: Cisco IR829 Back Panel Single Modem
Denotes SIM card order,
SIM0 on top and SIM1 on
bottom.
5WLAN ANT 0 5GHz1
WLAN ANT 1 5GHz6WLAN ANT 1 2.4GHz2
CELLULAR 0 MAIN7Cover over SIM cards,
reset button and console
port cover, see Figure 6:
Behind the SIM Door, on
page 12
3
GPS SMA4
Figure 5: Cisco IR829 Back Panel Dual Modem, on page 12 shows the back panels details of the Cisco IR829
Dual Modem.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
11
Product Overview
General Description

Figure 5: Cisco IR829 Back Panel Dual Modem
Denotes SIM card order,
SIM0 on top and SIM1 on
bottom.
5Cellular 1 Main1
Cellular 1 AUX6WLAN ANT 1 2.4/5GHz2
CELLULAR 0 MAIN7Cover over SIM cards,
reset button and console
port cover, see Figure 6:
Behind the SIM Door, on
page 12
3
GPS SMA4
NOTE: Behind the SIM Door Assembly, there is a reset switch(1), Mini USB console port(2), and Dual SIM
slots(3). See Figure 6: Behind the SIM Door, on page 12 for details
Figure 6: Behind the SIM Door
Figure 7: Cisco IR829 Top Cover (single modem version), on page 13 shows the top of the Cisco IR829.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
12
Product Overview
General Description

Figure 7: Cisco IR829 Top Cover (single modem version)
Figure 8: Cisco IR829 LED Detail, on page 13 shows the LED detail from the Dual Modem SKU. Single
Modem SKUs will only have Cellular 0 LEDs.
Figure 8: Cisco IR829 LED Detail
The following section shows a detailed description of the LEDs.
LEDs
Table 1: LED Descriptions , on page 14 describes the LEDs for the Cisco IR829.
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
13
Product Overview
LEDs

Table 1: LED Descriptions
DescriptionActivityLED
In normal operating mode, after system
boots. (typically about 2 minutes)
Off — No power
Green Steady on — Router is reachable,
and all interfaces are up and functioning
properly
Green Flashing — Router is reachable, and
no interface is in a failed state
Amber Steady on — Router is unreachable
(An external interface of the router, that
prevents the router from being remotely
managed, is in a critical failed state)
Amber Flashing — Router is reachable,
but at least one of the interfaces is in a
non-critical failed state (functionality of
that interface is affected)
In bootup mode (during the first 60
seconds after powerup)
Green Steady on — Router is booting
Amber Steady on — Router has a system
hardware failure
In ROMMON mode:
Amber Steady on — Router is in bootup
phase or in ROM Monitor mode.
Power StatusPWR
Off — No -54V PoE power supply detected
or no PoE board installed
Green Steady on — 54V POE power
supply good and all powered port operating
normally
Amber Steady on — 54V POE power
supply good, but one or more POE ports
has a fault.
POE Power
Supply Status
POE
Off — No VPN tunnel
Steady on — At least one VPN tunnel is
up
VPNVPN
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
14
Product Overview
LEDs

DescriptionActivityLED
Off — No link
Steady on — Link is up
Flashing — Transmitting and Receiving
data
Link StatusGE0 WAN
Off — GPS not configured
On — GPS configured
Slow Flash — GPS Acquiring in
Standalone GPS
Fast Flash — GPS Acquiring in Assisted
GPS
Slow Flash is defined as the LED will be
on for 0.25 seconds and off for 0.75
seconds.Fast Flash s defined as the LED
will be on for 0.25 seconds and off for 0.25
seconds.
GPS StatusGPS
LED 0 is used for the SKUs that support
mSATA
Off - Power off or no mSATA detected
Green Steady on — mSATA detected
LED 0
LED 1 (not
used)
MOD
Off — No link
Green Steady on — Link is up
Green Flash — Transmitting and Receiving
data
Amber — POE Fault, implies no link
Link
Status/POE
Status
Ethernet LAN Switch
PortsGE1-GE4]Single LED
per Port
Off — Radio is down (no SSID configured)
Flashing Green — Bootloader, IOS
Ethernet Initialization, IOS Start Up after
system initialization.
Green to Red to Amber — Discovery/Join
process.
Rapid Flashing Green — Joined to a
controller
Steady Green — One wireless client is
associated.
2.4GHz
5GHz
WLAN
The RSSI LEDs are a 3 LED bar graph to
indicate signal strength. Their functionality
is described in the RSSI LED figure below.
RSSICELLULAR0/CELLULAR1
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
15
Product Overview
LEDs

DescriptionActivityLED
Off — Module not powered on
On — Module is powered on and
connected but not transmitting or receiving
Slow Flash — Module is powered on and
searching for connection
Fast Flash — Module is transmitting or
receiving.
ACTCELLULAR0/CELLULAR1
Off — No USIM
Green — USIM installed and active
Sim cardsSIM0/SIM1
Table 2: RSSI LED
RSSI (0)RSSI (1)RSSI (2)RSSI
Green/AmberGreenGreen
OffOffOff< -110dBm
On - AmberOffOff-110 to
-90dBm
On - GreenOffOff-90 to -75dBm
On - GreenOn -
Green
Off-75 to -60dBm
On - GreenOn -
Green
On -
Green
> -60dBm
Memory
The Cisco IR829 uses flash memory and main memory. The flash memory contains the Cisco IOS software
image and the boot flash contains the ROMMON boot code. All memory components are factory default and
not upgradeable by the end user.
Table 3: Cisco IR829 Memory, on page 16 shows the memory allocation.
Table 3: Cisco IR829 Memory
CapacityMemory
2GBDDR
16MBBoot ROM
4GBSystem
Flash
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
16
Product Overview
Memory

SKU Information
Table 4: Supported SKUs for Cisco IR829s, on page 17 lists the different SKUs available for the Cisco ISRs.
All SKUs support external antenna.
Table 4: Supported SKUs for Cisco IR829s
AvailabilitymSATA SSDPoEDual LTELTESKU
US - VerizonNoOptionalNoYesIR829GW-LTE-VZ-AK9
US (AT&T) and
Canada
NoOptionalNoYesIR829GW-LTE-NA-AK9
EuropeNoOptionalNoYesIR829GW-LTE-GA-*K9
LATAM and APJCNoOptionalNoYesIR829GW-LTE-LA-*K9
North America and
Europe
NoNoNoYesIR829B-LTE-EA-*K9
North America and
Europe
YesYesNoYesIR829M-LTE-EA-*K9
North America and
Europe
YesYesYesYesIR829M-2LTE-EA-*K9
Australia, New
Zealand and Brazil
YesYesNoYesIR829M-LTE-LA-ZK9
North America and
Europe
NoOptionalYesYesIR829-2LTE-EA-*K9
For detailed product information, see the Cisco 829 Industrial Integrated Services Routers Data Sheet .
Hardware Features
This section provides an overview of the following hardware features for the Cisco IR829.
Platform Features for Cisco IR829
The following lists the hardware platform features for the Cisco IR829.
• Intel Atom Dual-Core Rangeley CPU, 1250 MHz
• 2GB DDR3 memory capacity
• 16MB SPI BIOS NOR flash
• 8GB (4GB usable) “eMMC” bulk storage flash
• 4-port GE LAN switch, optional PoE 802.3at (30W max) for Cisco devices only.
NOTE: The software does not support PoE negotiation over LLDP, only CDP. Therefore, PoE will only
power up Cisco devices,
• WAN 1 GE SFP
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
17
Product Overview
SKU Information

• WWAN /WLAN
• 2 internal mini PCIe slots for 3G/4G/LTE modems, dual SIM — 2 external SIM card slots
• Single 802.11 a/b/g/n WiFi radio with MIMO support.
• Optional Limited Modularity (BYOI) slot
• One RJ45 RS232 DTE serial port
• One RJ45 RS232 DCE/RS485 serial port
• One USB 2.0 Type A external port
• One mini USB type B connector for console
• Lithium Ion battery backed-up RTC
• External Reset/Recovery Push Button
• External Power
• Direct-wire 12/24VDC vehicle charging system input (9 — 32VDC)
• 4-pin locking power connector
• External GPS SMA Connector
•Six External TNC/RP-TNC connectors (depends on the configuration) for connection to WWAN /WLAN
internal modules
• Class A EMC compliance
• RoHS6 compliance
• Mechanical
• Fanless operation
• Form-factor with no cable cover = 11.00” x 7.70” x 1.73” (WDH)
• Horizontal, Vertical, wall, floor, cabinet-mount and shelf-mount
Wi-Fi
Table 5: Wi-Fi domains, on page 18 shows the different Wi-Fi domains associated with the SKUs.
Table 5: Wi-Fi domains
Cellular CarrierWi-Fi
Domain
CountrySKU
NTT, DoCoMo, Softbank, KDDIQJapanIR829GWR-LTE-LA-QK9
N/ADIndiaIR829GW-LTE-LA-DK9
Telstra, SparkZAustralia, New ZealandIR829GW-LTE-LA-ZK9
N/AKKoreaIR829GW-LTE-LA-KK9
N/AHChinaIR829GW-LTE-LA-HK9
N/ALMalaysiaIR829GW-LTE-LA-LK9
N/ASHong KongIR829GW-LTE-LA-SK9
N/ANPanamaIR829GW-LTE-LA-NK9
Cisco IR829 Industrial Integrated Services Router Hardware Installation Guide
18
Product Overview
Wi-Fi
