Cisco RV160 User manual

Quick Start Guide
Cisco RV160 Router
Package Contents
•Cisco RV160 Router
•Power Adapter
•This Quick Start Guide
•Pointer Card/RoHS
•Technical Support Contact Card
•Ethernet Cable
•EU Directives 2014/53/EU Compliance Information (for EU SKU only)

2 Cisco RV160 Router Quick Start Guide
Welcome
Thank you for choosing the Cisco RV160 router.
The RV160 router provides reliable internet access connectivity and
includes the following features:
•Easy to use UI with multiple set-up wizards.
•Four port VPN router.
•Support for IPv6 firewall.
•Business-grade small business network in a box.
This guide describes how to install your Cisco RV160 and launch the web-
based Device Manager.
Installing the Cisco RV160
To prevent the device from overheating or being damaged:
• Ambient Temperature — Do not operate it in an area that exceeds an
ambient temperature of 104°F (40°C).
•AirFlow— Be sure that there is adequate airflow around the device. If
wall mounting the device, make sure that the heat dissipation holes are
to the side.
• Circuit Overloading — Adding the device to the power outlet must not
overload that circuit.
•MechanicalLoading— Be sure that the device is level and stable to
avoid any hazardous conditions and that it is secure to prevent it from
sliding or shifting out of position. Do not place anything on top of the
device, as excessive weight may damage it.
Desktop Mounting
For desktop mounting, place the device on a flat surface so that it sits on its
four rubber feet.
Wall Mounting
The router has two wall-mount slots on the bottom panel. To mount the
router on a wall, you will need to use the wall-mount kit screws (included).
Guidelines for Mounting the Router on a Wall
When choosing a location for mounting the router on a wall, consider cable
limitations and wall structure.
1

Cisco RV160 Router Quick Start Guide 3
•Mount the router with the front panel facing upward. Make sure to mount
the router low enough so that you can see the LEDs.
•Make sure that the power supply rests on a horizontal surface such as
the floor or a table. If the power supply is not supported, the strain on
the power adapter cable could cause it to disconnect from the router.
•Do not install the router or its power supply next to a heat source of any
kind, including heating vents.
You can mount the router on a hollow wall or a wall stud. To mount the
router, follow these steps:
STEP 1Position the router on the wall to determine where to attach the two
mounting screws. Drill two pilot holes at approximately 109 mm
apart.
STEP 2Insert a screw into each hole, leaving a gap between the surface
and the base of the screw head of 1 to 1.2 mm.
STEP 3Place the router wall-mount slots over the screws and slide the
router down until the screws fit snugly into the wall-mount slots.
WARNING Insecure mounting might damage the router or cause injury.
Cisco is not responsible for damages incurred due to insecure
wall-mounting.
WARNING For safety reasons, please ensure that the heat dissipation
holes are facing sideways.

4 Cisco RV160 Router Quick Start Guide
Cisco RV160 Features
Front Panel
PWR Power Off or in rescue mode.
Solid green when the power is on and in normal
operation.
Flashing green when the device is booting up.
VPN Off when no VPN tunnel is defined, or all defined
VPN tunnels have been disabled.
Solid green when at least one VPN tunnel is up.
Flashing green when transmitting or receiving
data over VPN tunnel.
Solid amber when no enabled VPN tunnel is up.
DIAG Off when the system is on track to bootup.
Slow blinking red (1Hz) when the firmware
upgrade is in progress.
Fast blinking red (3Hz) when the firmware
upgrade is failing.
Solid red when the system failed to boot-up with both
the active and inactive images or in rescue mode.
LINK/ACT of WAN
and LAN1-4
Off when there is no Ethernet connection.
Solid green when the GE Ethernet link is on.
Flashing green when transmitting or receiving data.
GIGABIT of WAN
and LAN1-4
Solid green when at 1000M speed.
Off when at non-1000M speed.
USB Off when the USB is not connected, or the USB
is inserted and not recognized.
Solid green when USB storage is recognized.
Flashing green when transmitting or receiving data.
Amber when the USB storage access has errors.
2

Cisco RV160 Router Quick Start Guide 5
Back Panel
RESET — The RESET button has two functions:
•To reboot the unit and retain the current configuration, press and hold
RESET for a least 3 but no more than 10 seconds, by using a paper clip
or a pen tip.
•To reboot the unit and restore the factory default configuration, press
and hold the RESET button for more than 10 seconds. Changes you
have made to the router are lost.
Console Port
— The router console port is designed for a serial cable connection
to a terminal or a computer that is running a terminal emulation program.
LAN — (1 - 4) RJ-45 device connections to link local area network devices,
such as PCs, print servers, or switches to the router.
WAN — Connecting the router to a wide area network device such as a
cable or DSL modem.
SFP Port
— A small factor-form pluggable (SFP) is a hot-swappable input/output
device that plugs into the SFP port, linking the port with the network.
POWER — Toggles power to the device on or off.
12VDC (1.5A) — Power port that connects the device to the provided
12VDC, 1.5 amp power adapter.
Side Panel
USB — Type A USB port that supports flash drives. Caution: Use only the
power supply provided with the device; using another power supply may
cause the USB dongle to fail.

6 Cisco RV160 Router Quick Start Guide
Kensington Lock Slot — Lock slot on the right side to secure the device
physically, using the Kensington lock-down equipment.
Connecting the Equipment
Connect a configuration terminal (PC) to the device by using a LAN port.
The terminal must be in the same wired subnetwork as the device to
perform the initial configuration. As part of the initial configuration, the
device can be configured to allow remote management.
To connect a computer to the device:
STEP 1Power off all equipment, including the cable or DSL modem, the
computer, and this device.
STEP 2Use an Ethernet cable to connect your cable or DSL modem to the
WAN port on this device.
STEP 3Connect another Ethernet cable from one of the LAN (Ethernet)
ports to the Ethernet port on the computer.
STEP 4Power on the WAN device and wait until the connection is active.
STEP 5Connect the power adapter to the 12VDC port of this device.
CAUTION Use only the power adapter that is supplied with the device.
Using a different power adapter could damage the device or
cause the USB dongles to fail.
The power switch is on by default. The power light on the front
panel is solid green when the power adapter is connected
properly and the device is finished booting.
STEP 6Plug the other end of the adapter into an electrical outlet. Use the
plug (supplied) specific to your country.
STEP 7Continue with the instructions in the Using the Setup Wizard to
configure the device.
Using the Setup Wizard
The Setup Wizard and Device Manager are supported on Microsoft
Internet Explorer, Mozilla Firefox, Apple Safari, and Google Chrome.
3
444

Cisco RV160 Router Quick Start Guide 7
To configure the device using the Setup Wizard, follow these steps:
STEP 1 Power on the PC that you connected to the LAN1 port in Step 3 of the
Connecting Equipment section. Your PC becomes a DHCP client of the
device and receives an IP address in the 192.168.1.xxx range.
STEP 2Launch a web browser.
STEP 3 In the address bar, enter the default IP address of the device, https://
192.168.1.1
. A site security certificate message is displayed. The Cisco
RV160 uses a self-signed security certificate. This message appears
because the device is not known to your computer.
STEP 4 Click Continue to this website to continue. The sign-in page appears.
STEP 5Enter the username and password. The default username is cisco.
The default password is cisco. Passwords are case-sensitive.
STEP 6Click Log In. The Router Setup Wizard is launched.
STEP 7Follow the on-screen instructions to set up your device. The Router
Setup Wizard should detect and configure your connection. If it is
unable to do so, it asks you for information about your Internet
connection. Contact your ISP for this information.
STEP 8Change the password as instructed by the Router Setup Wizard or
follow the instructions in the Changing the Administrator Username
and Password section. Log in to the device with the new username
and password.
NOTE We recommend that you change the password. You are
required to change the password before enabling features such as
remote management.
The Device Manager Getting Started page appears. It displays the
most common configuration tasks.
STEP 9 Click one of the tasks listed in the navigation bar to complete the
configuration.
STEP10 Save any additional configuration changes and log out of the
device manager.
Changing the Administrator Username and Password
To change the Administrator username and password on the device:
STEP 1From the Getting Started page, select Change Administrator
Password or select System Configuration > User Accounts from
the navigation bar.
STEP 2 Check a username from the Local User Membership list and click Edit.

8 Cisco RV160 Router Quick Start Guide
STEP 3Enter the Username.
STEP 4Enter the old Password.
STEP 5Enter the new Password.
STEP 6Confirm the new Password.
STEP 7Select the group (admin, guest) from the drop-down list in the
Password Strength Meter.
STEP 8Click Save.
Troubleshoot Your Connection
If you cannot access your device by using the Setup Wizard, the device
may not be reachable from your computer. You can test network
connections by using ping on a computer running Windows:
STEP 1Open a command window by using Start > Run and enter cmd.
STEP 2At the Command window prompt, enter ping and the device IP
address. For example, ping 192.168.1.1 (the default static IP
address of the device).
If you can reach the device, you should get a reply similar to the
following:
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1: bytes=32 time<1ms TTL=128
If you cannot reach the device, you should get a reply similar to the
following:
Pinging 192.168.1.1 with 32 bytes of data:
Request timed out.
Possible Causes and Resolutions
Bad Ethernet connection:
Check the LEDs for the proper indications. Check the connectors of the
Ethernet cable to ensure that they are firmly plugged into the device
and your computer.
Wrong or conflicting IP address:
Verify that you are using the correct IP address of the device.
Verify that no other device is using the same IP address as this device.
No IP route:

Cisco RV160 Router Quick Start Guide 9
If the device and your computer are in different IP subnetworks,
remote access must be enabled and you need at least one router on
the network to route the packets between the two subnetworks.
Unusually long access time:
Adding new connections may take 30–60 seconds for the affected
interfaces and LAN to become operational.
Where to Go From Here
For EU Lot 26 related test results, see www.cisco.com/go/eu-lot26-results
Support
Cisco Support
Community
https://community.cisco.com/t5/small-
business-support-community/ct-p/5541-
small-business-support
Cisco Firmware
Downloads
https://software.cisco.com/download/home
Select a link to download firmware for Cisco
products. No login is required.
Cisco Partner Central
(Partner Login Required)
http://www.cisco.com/c/en/us/
partners.html
Product Documentation
Cisco RV160 https://www.cisco.com/c/en/us/support/
routers/rv160-vpn-router/model.html
5

Americas Headquarters
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates
in the U.S. and other countries. To view a list of Ciscotrademarks, go to this URL:
www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their
respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (1110R)
© 2018 Cisco Systems, Inc. All rights reserved.
78-100991-01
