Preface
Purpose
This guide describes the Cisco ME 3800X and ME 3600X switch-specific system messages that you
might encounter. For a complete list of Cisco IOS system error messages, see the Cisco IOS Software
System Error Messages, Cisco IOS Release 12.2.
This guide does not describe how to install your switch or how to configure software features on your
switch. It also does not provide detailed information about commands that have been created or changed
for use by the switch. For hardware installation information, see the hardware installation guide and the
getting started guide shipped with your switch. For software information, see the software configuration
guide and the command reference for this release. For the latest documentation updates, see the release
notes for this release.
Conventions
This publication uses these conventions to convey instructions and information:
Command descriptions use these conventions:
• Commands and keywords are in boldface text.
• Arguments for which you supply values are in italic.
• Square brackets ([ ]) mean optional elements.
• Braces ({ }) group required choices, and vertical bars ( | ) separate the alternative elements.
• Braces and vertical bars within square brackets ([{ | }]) mean a required choice within an optional
element.
Interactive examples use these conventions:
• Terminal sessions and system displays are in screen font.
• Information you enter is in boldface screen font.
• Nonprinting characters, such as passwords or tabs, are in angle brackets (< >).
Notes use this convention and symbol:
Note Means reader take note. Notes contain helpful suggestions or references to materials not in this manual.

iv
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
Preface
Related Publications
These documents provide complete information about the switch and are available from these Cisco.com
sites:
ME 3800X switch:
http://www.cisco.com/en/US/products/ps10965/tsd_products_support_series_home.html
ME 3600X switch:
http://www.cisco.com/en/US/products/ps10956/tsd_products_support_series_home.html
Note Before installing, configuring, or upgrading the switch, see these documents:
• For initial configuration information, see the “Configuring the Switch with the CLI-Based Setup
Program” appendix in the hardware installation guide.
• For upgrading information, see the “Downloading Software” section in the release notes.
• Release Notes for the Cisco ME 3800X and ME 3600X Switch
Note See the release notes on Cisco.com for the latest information.
• Cisco ME 3800X and ME 3600X Switch Software Configuration Guide
• Cisco ME 3800X and ME 3600X Switch Command Reference
• Cisco ME 3800X and ME 3600X System Message Guide
• Cisco ME 3800X and ME 3600X Switch Hardware Installation Guide
• Cisco ME 3800X and ME 3600X Switch Getting Started Guide
• Installation Notes for the Cisco ME 3800X and ME 3600X Switch Power-Supply and Fan Modules
• Regulatory Compliance and Safety Information for the Cisco ME 3800X and ME 3600X Switches
• Cisco Small Form-Factor Pluggable Modules Installation Notes
• Cisco CWDM GBIC and CWDM SFP Installation Notes
These compatibility matrix documents are available from this Cisco.com site:
http://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_support_tables_list.html
• Cisco Gigabit Ethernet Transceiver Modules Compatibility Matrix
• Cisco 100-Megabit Ethernet SFP Modules Compatibility Matrix
• Cisco CWDM SFP Transceiver Compatibility Matrix
• Cisco Small Form-Factor Pluggable Modules Compatibility Matrix
• Compatibility Matrix for 1000BASE-T Small Form-Factor Pluggable Modules

v
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
Preface
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional
information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and
revised Cisco technical documentation:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed
and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free
service and Cisco currently supports RSS version 2.0.

vi
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
Preface

vii
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
CONTENTS
Preface iii
Purpose iii
Conventions iii
Related Publications iv
Obtaining Documentation and Submitting a Service Request v
CHAPTER 1System Message Overview 1-1
How to Read System Messages 1-1
Error Message Traceback Reports 1-5
Output Interpreter 1-5
Bug Toolkit 1-5
Contacting TAC 1-5
CHAPTER 2Messages and Recovery Procedures 2-1
ACLMGR Messages 2-3
AUTHMGR Messages 2-6
BACKUP_INTERFACE Messages 2-7
BADTRANSCEIVER Messages 2-8
BSPATCH Messages 2-8
CISL Messages 2-9
EC Messages 2-9
ENVIRONMENT Messages 2-13
EPM Messages 2-14
ETHCNTR Messages 2-14
FRNTEND_CTRLR Messages 2-15
GBIC_SECURITY Messages 2-15
GBIC_SECURITY_CRYPT Messages 2-17
GBIC_SECURITY_UNIQUE Messages 2-18
HARDWARE Messages 2-18
HCPU_PROT_MGR Messages 2-20
HLFM Messages 2-21
IDBMAN Messages 2-22

Contents
viii
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
IFMGR Messages 2-24
IGMP_QUERIER Messages 2-25
ILET Messages 2-26
MAC_LIMIT Messages 2-26
MAC_MOVE Messages 2-27
PAGP_DUAL_ACTIVE Messages 2-27
PHY Messages 2-28
PIMSN Messages 2-30
PLATFORM Messages 2-30
PLATFORM_ENV Messages 2-31
PLATFORM_PBR Messages 2-34
PLATFORM_PM Messages 2-35
PLATFORM_UCAST Messages 2-36
PLATFORM_VLAN Messages 2-38
PM Messages 2-39
PORT_SECURITY Messages 2-45
QOSMGR Messages 2-46
REP Messages 2-55
RMON Messages 2-56
SCC Messages 2-56
SCHED Messages 2-57
SPANTREE Messages 2-57
SPANTREE_FAST Messages 2-64
SPANTREE_VLAN_SW Messages 2-64
STORM_CONTROL Messages 2-65
SUDI Messages 2-66
SUPERVISOR Messages 2-66
SUPQ Messages 2-67
SW_VLAN Messages 2-68
TCAMMGR Messages 2-73
UDLD Messages 2-74
VQPCLIENT Messages 2-75
I NDEX

CHAPTER
1-1
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
1
System Message Overview
This guide describes the Cisco ME 3800X and 3600X Ethernet Access switches system messages.
During operation, the system software sends these messages to the console (and, optionally, to a logging
server on another system). Not all system messages mean problems with your system. Some messages
are informational, and others can help diagnose problems with communications lines, internal hardware,
or the system software.
Note For information about system messages that are not Cisco ME switch platform-specific, see the Cisco
IOS Software System Messages for Cisco IOS Release 12.2S.
• How to Read System Messages, page 1-1
• Error Message Traceback Reports, page 1-5
How to Read System Messages
System log messages can contain up to 80 characters and a percent sign (%), which follows the optional
sequence number or time-stamp information, if configured. Messages appear in this format:
seq no:timestamp: %facility-severity-MNEMONIC:description
By default, a switch sends the output from system messages to a logging process.
Each system message begins with a percentsign (%) and is structured as follows:
%FACILITY-SEVERITY-MNEMONIC: Message-text
• FACILITY is two or more uppercase letters that show the facility to which the message refers. A
facility can be a hardware device, a protocol, or a module of the system software. Table 1-1 lists the
facility codes.
These messages are described in Chapter 2, “Messages and Recovery Procedures,” in alphabetical
order by facility code with the most severe (lowest number) errors described first.
Ta b l e 1-1 Facility Codes
Facility Code Description Location
ACLMGRR ACL manager “ACLMGR Messages” section on
page 2-3
AUTHMGR Authorization manager “AUTHMGR Messages” section on
page 6

1-2
Cisco ME 3400E, ME 3400, and ME 2400 Ethernet Access Switch System Message Guide
OL-23408-01
Chapter 1 System Message Overview
How to Read System Messages
BACKUP_INTERFACE Backup Interface “BACKUP_INTERFACE Messages”
section on page 2-7
BADTRANSCEIVER Bad Transceiver “BADTRANSCEIVER Messages”
section on page 2-8
BSPATCH BS Patch “BSPATCH Messages” section on
page 2-8
CISL Cisco IOS Software
Licensing
“CISL Messages” section on page 2-9
EC EtherChannel “EC Messages” section on page 2-9
ENVIRONMENT Environment “ENVIRONMENT Messages” section
on page 2-13
EPM Enforcement Policy Module “EPM Messages” section on page 14
ETHCNTR Ethernet Controller “ETHCNTR Messages” section on
page 2-14
FRNTEND_CTRLR Front-end controller “FRNTEND_CTRLR Messages”
section on page 2-15
GBIC_SECURITY Gigabit Interface Converter
(GBIC) module and small
form-factor pluggable (SFP)
module security
“GBIC_SECURITY Messages” section
on page 2-15
GBIC_SECURITY_CRYPT GBIC and SFP module
security
“GBIC_SECURITY_CRYPT
Messages” section on page 2-17
GBIC_SECURITY_UNIQUE GBIC and SFP module
security
“GBIC_SECURITY_UNIQUE
Messages” section on page 2-18
HARDWARE Hardware “HARDWARE Messages” section on
page 2-18
HCPU_PROT_MGR CPU protection manager “HCPU_PROT_MGR Messages”
section on page 2-20
HLFM Local forwarding manager “HLFM Messages” section on
page 2-21
IDBMAN Interface database
manager process
“IDBMAN Messages” section on
page 2-22
IFMGR Interface manager “IFMGR Messages” section on
page 2-24
IGMP_QUERIER Internet Group Management
Protocol (IGMP) querier
“IGMP_QUERIER Messages” section
on page 2-25
ILET Cisco IOS License
Enforcement Test messages
“ILET Messages” section on page 2-26
MAC_LIMIT MAC address table entries “MAC_LIMIT Messages” section on
page 2-26
MAC_MOVE Host activity “MAC_MOVE Messages” section on
page 2-27
Table 1-1 Facility Codes (continued)
Facility Code Description Location
