Regulatory Compliance and Safety Information
for the Catalyst 8500 and LightStream 1010 Series
Read this document before installing or servicing the following Catalyst 8500 and LightStream 1010
series switches:
•Catalyst 8540 MSR
•Catalyst 8510 MSR
•Catalyst 8540 CSR
•Catalyst 8510 CSR
•LightStream 1010 ATM switch
Note Only trained and qualified service personnel (as defined in IEC 60950 and AS/NZS 3260) should install,
replace, or service the equipment. Install the system in accordance with the U.S. National Electric Code
if you are in the United States.
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents.
Note The following guidelines are applicable for products intended for use in Australia:
•Only trained and qualified service personnel should install, replace, or service the equipment, as
defined by AS/NZS 3260.
•Incorrect connection of this or connected equipment to a general purpose outlet could result in a
hazardous situation.
This document includes the following sections:
•Site Preparation, page 2
•Regulatory Standards Compliance, page 9
•Translated Safety Warnings, page 16

2
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series 78-14229-02
Site Preparation
•Related Documentation, page 26
•Obtaining Documentation, page 27
•Obtaining Technical Assistance, page 28
•Obtaining Additional Publications and Information, page 30
Site Preparation
This section describes the site requirements for installing the Catalyst 8500 MSR, Catalyst 8500 CSR,
and LightSteam 1010 series switches. To ensure normal system operation, plan your site configuration
and prepare your site before installation.
Follow these guidelines when choosing a site for installation:
•Install the system in a restricted access area, where access can be gained only by service personnel
through the use of a special tool, lock and key, or other means of security.
•Choose a site with a dry, clean, well-ventilated, and air-conditioned area.
•Choose a site that maintains an ambient temperature of 32 to 104°F (0 to 40°C).
Ensuring Overcurrent Protection
The system relies on the protective devices in the building installation for protection against
short-circuit, overcurrent, and earth (grounding) fault. Ensure that the protective devices in the building
installation are properly rated to protect the system, and that they comply with national and local codes.
Grounding the System
Follow these guidelines when grounding the system:
•Do not defeat the ground conductor on an AC plug.
•Connect AC-powered systems to grounded power outlets.
•Connect the system to earth (ground).
Creating a Safe Environment
Follow these guidelines to create a safe environment:
•Keep tools and chassis components off the floor and away from foot traffic.
•Clear the area of possible hazards, such as moist floors, ungrounded power extension cables, and
missing safety grounds.
•Keep the area around the chassis free from dust and foreign conductive material (such as metal
flakes from nearby construction activity).

3
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series
78-14229-02
Site Preparation
Rack-Mounting the System
A rack-mount kit and cable guides come with the system. The kit is not suitable for racks with
obstructions (such as a power strip) that could impair access to system components. Allow sufficient
clearance around the rack for system maintenance.
Ensuring Proper Airflow
Follow these guidelines to ensure proper airflow:
•Install the system in an open rack whenever possible. If installation in an enclosed rack is
unavoidable, ensure that the rack has adequate ventilation.
•Maintain ambient airflow to ensure normal operation. If the airflow is blocked or restricted, or if the
intake air is too warm, an overtemperature condition can occur.
•Allow at least 6 inches (15.24 cm) of clearance around the ventilation openings of the chassis.
•Avoid placing the system in an overly congested rack or directly next to another equipment rack.
Heat exhaust from other equipment can enter the inlet air vents and cause an overtemperature
condition.
•Equipment near the bottom of a rack might generate excessive heat that is drawn upward and into
the intake ports of the equipment above. The warm air can cause an overtemperature condition in
the equipment above.
•Ensure that cables from other equipment do not obstruct the airflow through the chassis or impair
access to the power supplies or cards. Route cables away from field-replaceable components to
avoid disconnecting cables unnecessarily for equipment maintenance or upgrades.
Stabilizing the System
Follow these guidelines to stabilize the system:
•Install any stabilizers that came with your equipment rack before mounting or servicing the system
in the rack.
•Load the rack from the bottom to the top, with the heaviest system at the bottom.
•Do not stack the system on top of any other equipment. If the system falls, it can cause severe bodily
injury and damage the equipment.
•Ensure that the shelf is constructed to support the weight and dimensions of the chassis if you are
using an equipment shelf. See Figure 1 and Figure 2.

4
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series 78-14229-02
Site Preparation
Figure 1 Catalyst 8540 Chassis Standard Equipment Rack Dimensions
79100
17.25 "
(45.09 cm)
19.25 "
(48.09 cm)

5
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series
78-14229-02
Site Preparation
Figure 2 Catalyst 8510 and LightStream 1010 Chassis Standard Equipment Rack Dimensions
•Ensure that the weight of the chassis does not make the rack unstable. Secure telco racks with ceiling
brackets if the rack is populated with heavy equipment.
•Bolt the rack to the floor for stability.
Lifting the System
Follow these guidelines when lifting the system:
•Disconnect all power and external cables before lifting the system.
•Ensure that your footing is solid and the weight of the system is evenly distributed between your
feet.
•Lift the system slowly, keeping your back straight. Lift with your legs, not with your back. Bend at
the knees, not at the waist.
•Do not attempt to lift the system with the handles on the power supplies or on any of the cards. These
handles are not designed to support the weight of the system.
•Depending on the weight of the system, more than one person might be required to lift it.
PS1
PS2
FAN
LINK
SLOT2
SLOT1
PCMCIA
EJECT AUX
CONSOLE
Enet
RX
TX
RESET
79099
17.25 "
(45.09 cm)
19.25 "
(48.09 cm)

6
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series 78-14229-02
Site Preparation
Figure 3 shows the number of people needed to lift the system by weight.
Figure 3 Safely Lifting the System
Power Considerations
AC and DC power supplies, and an optional redundant (second) power supply, are available for most
systems. Be careful when connecting systems to the supply circuit so that wiring is not overloaded.
Note Refer to your hardware installation guide for AC and DC power specifications and for redundant power
supply availability.
AC Power
The system is designed for connection to TN power systems. A TN power system is a power distribution
system with one point connected directly to earth (ground). The exposed conductive parts of the
installation are connected to that point by protective earth conductors.
Ensure that the plug-socket combination is accessible at all times, because it serves as the main
disconnecting device.
DC Power
Follow these guidelines for DC power supplies:
•Connect DC-input power supplies only to a DC power source that complies with the safety extra-low
voltage (SELV) requirements in the UL 1950, CSA 950, EN 60950, and IEC 60950 standards.
•Ensure that there is a readily accessible disconnect device incorporated in the building's installation
wiring.
•Ensure that power is removed from the DC circuit before installing or removing power supplies.
Tape the switch handle of the DC circuit breaker in the off position.
•Use only copper conductors to connect to a DC terminal block.
•Use approved wiring terminations, such as closed-loop or spade-type with upturned lugs, when
stranded wiring is required. These terminations should be the appropriate size for the wires and
should clamp both the insulation and the conductor.
•Ensure that no exposed portion of the DC-input power source wire extends from the terminal block
plug. An exposed wire can conduct a harmful level of electricity.
<40 lb
(<18 kg) 40 to 70 lb (18 to 32 kg) 70 to 121 lb (32 to 55 kg) >121 lb (>55 kg)
18986

7
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series
78-14229-02
Site Preparation
Using Redundant Power
If your system includes an optional redundant (second) power supply, connect each of the two power
supplies to different input power sources. Failure to do so makes the system susceptible to total power
failure in the event that one of the power supplies fails.
Preventing ESD
Electrostatic discharge (ESD) damage occurs when electronic cards or components are mishandled and
can result in complete or intermittent failures. Note the following guidelines before you install or service
the system:
•Always wear an ESD-preventive wrist or ankle strap when handling electronic components. Connect
one end of the strap to an ESD jack or an unpainted metal component on the system (such as a
captive installation screw).
•Handle cards by the faceplates and edges only; avoid touching the printed circuit board and
connector pins.
•Place any removed component on an antistatic surface or in a static shielding bag.
•Avoid contact between the cards and clothing. The wrist strap only protects the card from ESD
voltages on the body; ESD voltages on clothing can still cause damage.
Note For safety, periodically check the resistance value of the antistatic strap. The measurement should be
between 1 and 10 megohms (Mohms).
Installing and Servicing the System
Follow these guidelines when installing and servicing the system:
•Disconnect all power and external cables before installing the system.
•Install the system in compliance with your local and national electrical codes:
– United States: National Fire Protection Association (NFPA) 70; United States National
Electrical Code.
– Canada: Canadian Electrical Code, Part I, CSA C22.1.
– Other countries: If local and national electrical codes are not available, refer to IEC 364, Part 1
through Part 7.
•Do not work alone under potentially hazardous conditions.
•Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.
•Do not touch the backplane or midplane with your hand or metal tools.
•Remove all jewelry (including rings and chains) or other items that could get caught in the system
or heat up and cause serious burns.

8
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series 78-14229-02
Site Preparation
Disconnecting Power
Follow these guidelines when disconnecting power:
•Locate the emergency power-off switch for the room before working with the system.
•Turn off the power and disconnect the power from the circuit when working with components that
are not hot-swappable or when working near the system backplane or midplane. If the system does
not have an on/off switch, unplug the power cord.
•De-energize the system completely by disconnecting the power connection to all power supplies.
•For DC power supplies, locate the circuit breaker on the panel board that services the DC circuit,
switch the circuit breaker to the off position, and tape the switch handle of the circuit breaker in the
off position.
•Do not touch the power supply when the power cord is connected. Line voltages are present within
the power supply even when the power switch is off and the power cord is connected.
Working with Lasers
The following laser safety standards classify the Catalyst 8500 MSR, Catalyst 8500 CSR, and
LightSteam 1010 series switches:
•Class 1 LASER PRODUCT (IEC 60825-1 2001-01)
•Class I LASER PRODUCT (21CFR 1040.10 and 1040.11)
Caution Use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
Invisible laser radiation may be emitted from one end of the fiber or connector. Do not stare into the beam
or view directly with optical instruments.
Preventing EMI
When you run wires for any significant distance in an electromagnetic field, electromagnetic interference
(EMI) can occur between the field and the signals on the wires. Be aware of the following:
•Bad plant wiring can result in RFI (radio frequency interference).
•Strong EMI, especially when it is caused by lightning or radio transmitters, can destroy the signal
drivers and receivers in the system, and can even create an electrical hazard by conducting power
surges through lines and into the system.
To predict and remedy strong EMI, consult RFI experts.
Covering Empty Slots
Ensure that all cards, faceplates, and covers are in place. Filler motherboards and filler modules and
cover panels are used to:
•Prevent exposure to hazardous voltages and currents inside the chassis
•Help contain EMI (electromagnetic interference) that might disrupt other equipment

9
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series
78-14229-02
Regulatory Standards Compliance
•Direct the flow of cooling air through the chassis
•Protect the backplane from dust
Disposing of the System
Dispose of the system and its components (including batteries) as specified by all national laws and
regulations.
Regulatory Standards Compliance
This section includes the regulatory compliance, safety, and EMC standards. It also lists the warnings
applicable to different countries.
Table 1 lists the regulatory standards compliance specifications.
Table 1 Regulatory Standards Compliance
Specification Description
Regulatory Compliance Products bearing a CE Mark indicate compliance with the
89/336/EEC and 73/23/EEC directives, which include the
following safety and EMC standards in this table.
Safety UL 1950
CAN/CSA-C22.2 No. 950
EN 60950
IEC 60950
TS 001
AS/NZS 3260
IEC 60825-1
IEC 60825-2
EN 60825-1
EN 60825-2
21CFR 1040
EMC FCC Part 15 (CFR 47) Class A
ICES-003 Class A
EN 55022 Class A with UTP cable
CISPR22 Class A with UTP cable
AS/NZS 3548 Class A with UTP cable
VCCI Class A with UTP cable
EN 55022 Class B with FTP cable
CISPR22 Class B with FTP cable
AS/NZS 3548 Class B with FTP cable
VCCI Class B with FTP cable
EN 55024
ETS 300 386
EN 50082-1
EN 61000-3-2
EN 61000-3-3

10
Regulatory Compliance and Safety Information for the Catalyst 8500 and LightStream 1010 Series 78-14229-02
Regulatory Standards Compliance
Table 2 lists the NEBS and ETSI specifications that the Catalyst 8500 MSR, Catalyst 8500 CSR, and
LightSteam 1010 series switches are designed to meet.
FCC Part 68 Notice
The T1 IMA (Model C85MS-8T1-IMA) and CES T1 (Model WAI-T1C-4RJ48) interface modules used
in the ATM switch router comply with Part 68 of the FCC rules. On the bottom of this equipment is a
label that contains, among other information, the FCC registration number. If requested, this information
must be provided to the telephone company.
This equipment cannot be used on telephone company-provided coin services. Connection to the Party
Line Service is subject to state tariffs.
If this equipment causes harm to the telephone network, the telephone company notifies you in advance
that temporary discontinuance of service might be required. If advance notice is not practical, the
telephone company notifies you as soon as possible. Also, you are advised of your right to file a
complaint with the FCC if you believe it is necessary.
The telephone company can make changes in its facilities, equipment, operations, or procedures that
might affect the operation of the equipment. If this happens, the telephone company provides advance
notice so you can make the necessary modifications to maintain uninterrupted service.
If you experience trouble with this equipment, please contact us for repair and warranty information. If
the trouble is causing harm to the telephone network, the telephone company can request that you
remove the equipment from the network until the problem is resolved.
We recommend that the customer install an AC surge arrestor in the AC outlet to which this device is
connected. This is to avoid equipment damage caused by local lightning strikes and other electrical
surges.
This equipment uses Uniform Service Order Code (USOC) jacks as listed in Table 3.
Table 2 NEBS and ETSI Specifications
Specification Description
NEBS1
1. NEBS = Network Equipment Building Systems
GR-63-Core NEBS Level 3 Requirements
GR-1089-Core NEBS Level 3 Requirements
ETSI2
2. ETSI = European Telecommunication Standards Institute
ETS 300 019 Storage Class 1.1
ETS 300 019 Transportation Class 2.3
ETS 300 019 Stationary Use Class 3.1
Table 3 USOC Jacks for CES Port Adapters
Model No. Facility Interface Code Service Order Code Jack Type
C85MS-8T1-IMA 04DU9-BN 6.0N RJ48c
C85MS-8T1-IMA 04DU9-DN 6.0N RJ48c
C85MS-8T1-IMA 04DU9-IKN 6.0N RJ48c
C85MS-8T1-IMA 04DU9-ISN 6.0N RJ48c
