Cisco PGW 2200 User manual

Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
Cisco PGW 2200 Softswitch Release 9.8
Software Installation and Configuration
Guide
February 21, 2012
Text Part Number: OL-18083-14

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display
output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in
illustrative content is unintentional and coincidental.
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
© 2012 Cisco Systems, Inc. All rights reserved.

iii
Cisco PGW 2200 Softswitch Release 9.8 Software Installation andConfiguration Guide
OL-18083-14
CONTENTS
Preface ix
Introduction ix
Document Objectives ix
Audience ix
Related Documentation x
Obtaining Documentation and Submitting a Service Request x
Document Change History xi
CHAPTER 1Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software
Installation 1-1
Introduction 1-1
Supported Platforms and Cisco Products 1-1
Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release
Preinstallation Checklists 1-2
Required Software Media 1-2
Minimum System Requirements 1-3
Required Site-Specific Information 1-3
Required Machine-Specific Information 1-3
Required Tasks 1-4
CHAPTER 2Installing the Sun Solaris 10 Operating System 2-1
Introduction 2-1
Supported Platforms 2-1
Supported Disk Drives 2-1
Before You Start 2-2
Cautions, Notes, and Tips 2-2
Loading the Sun Solaris 10 Operating System 2-3
Devices on Supported Platforms 2-3
Installingthe Sun Solaris 10 Operating System for Sparc-based Platforms 2-4
Installing the Sun Solaris 10 Operating System for Opteron-based Platforms 2-13
Installation of Solaris JS11 through ILOM 2-21
Configuring Your Host 2-30
Platform-Specific Installation Procedures 2-43
Loading the Sun Solaris 10 Operating Environment 2-53

Contents
iv
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Installing the Sparc-based Solaris 10 Patches Package (CSCOh022) 2-54
Installing the Opteron-based Solaris 10 Patches Package (CSCOh032) 2-56
Installing the Solstice DiskSuite (CSCOh023) 2-59
Rebooting from the Mirrored (Secondary) Disk on Sparc-based Platforms 2-67
Rebooting from the Mirrored (Secondary) Disk on Opteron-based Platforms 2-69
Removing the Solstice DiskSuite 2-70
Installing the Log and Spool File Systems (CSCOh024) 2-71
Uninstalling the Log and Spool File System 2-78
Installing Cisco BAMS Archive Partition (CSCOh027) 2-79
Installing the Sparc-based Communications and Alarm Software Package (CSCOh026) 2-85
Installing the Opteron-based Communications Software Package (CSCOh036) 2-99
Installing the Verification Test Suite Script Package (CSCOh021) 2-111
Using the SunVTS Test Package 2-112
Normal Unit Test 2-113
Running a Test in Brief Mode 2-117
Running a Test in Full Mode 2-118
vts_script Execution Times 2-118
Removing the VTS Package (CSCOh021) 2-118
Configuring Lights-Out Management (LOM) or the Integrated Lights Out Manager (ILOM) 2-119
Configuring LOM on Sun Fire V40z Platform 2-120
Configuring ILOM on the Sun Fire X4640 Platform 2-122
Configuring ILOM on the Sun Netra X4270 Platform 2-125
Configuring ILOM on the Sun Fire X4800 Platform 2-125
CHAPTER 3Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher 3-1
Introduction 3-1
Before You Start 3-1
Cautions, Notes, and Tips 3-2
Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases 3-3
Installing Cisco PGW 2200 Softswitch Software on a Simplex System 3-3
Installing the Cisco Security Package (CSCOh020) 3-12
Enabling Sudo 3-15
Installing the License File 3-16
Installing the License File if the Cisco PGW 2200 Softswitch is NOT Running 3-16
Installing the License File if the Cisco PGW 2200 Softswitch is Running 3-17
Installing on a Fault Tolerant System 3-17
CHAPTER 4Configuring the Cisco PGW 2200 Softswitch Software 4-1
Introduction 4-1

Contents
v
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
Quick Guide to Configuring the Cisco PGW 2200 Softswitch Software 4-1
Before You Start 4-2
Software Directory Structure 4-3
Initial Cisco PGW 2200 Softswitch Software Configuration 4-4
Parameters Required for Initial Setup 4-8
Using the Cisco MGC Environment Configuration Tool 4-9
Configuring Groups and Users 4-12
Verifying the mgcgrp Group 4-12
Adding a User with Full MML Privileges 4-12
Adding a User with Minimal MML Privileges 4-13
Configuring SNMP Support Resources 4-14
Migrating the SNMP Configuration to a More Secure Environment (for Cisco PGW 2200 Softswitch
Release 9.3(2) or Later) 4-15
Basic Tasks 4-15
Before You Run the config-snmp Utility 4-15
Running the config-snmp Utility 4-16
Adding an SNMP Community Entry 4-18
Deleting an SNMP COMMUNITY 4-20
Adding a Trap Destination 4-21
Deleting a Trap Destination 4-23
Activating the New Settings 4-24
Verifying the SNMP Configuration Migration 4-25
Configuring the Execution Environment 4-26
Changing XECfgParm.dat File Parameters 4-27
Changing XECfgParm.dat File Parameters in a Running Fault Tolerant System 4-28
Configuring Basic System Information 4-29
Specifying IP Addresses 4-31
Configuring Geographic Separation of Active and Standby Hosts 4-33
Configuring Engine Parameters 4-37
Setting the Call Cutoff Timer 4-39
Enabling Call Screening 4-39
Configuring Call Detail Record File Output 4-40
Configuring the Clearing Location and Default Location Parameters 4-42
Configuring Switchover 4-45
Initializing the Provisioning Object Manager 4-47
Configuring SCP Queries 4-48
Before You Start 4-49
Modifying trigger.dat file parameters with provisioning commands 4-49
Configuring the trigger.dat File Attributes 4-49

Contents
vi
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Configuring the Translation Type Attribute 4-50
Sample trigger.dat File 4-51
Initializing the Call Screening Database 4-88
.odbc.ini File Information 4-89
Setting Up Replication 4-89
Network Requirements 4-90
Initializing Database Replication 4-91
Verifying Database Replication 4-92
Troubleshooting the Main Memory Database Replication 4-93
Displaying the Main Memory Database Replication Status 4-93
Verifying Database Synchronization 4-94
Synchronizing Databases 4-94
Checking for Installation Errors 4-95
Reinstalling CSCOga002 4-95
Configuring Cisco ITP-Ls 4-95
Configuring Disk Monitor During Initial Software Configuration 4-96
Configuring the Data Dumper 4-97
Configuring the Data Dumper to Support Cisco BAMS 4-98
CHAPTER 5Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 5-1
Introduction 5-1
Conditions for Migration 5-1
Cautions and Notes 5-2
Required Software 5-3
License Installation 5-4
Recording System Data 5-4
Migration Overview 5-4
Migration from Release 9.5 or 9.6 to Release 9.8 without Platform Changes 5-5
Migrating the Second Cisco PGW 2200 Softswitch Software to Release 9.8 5-5
Backing Up the Cisco PGW 2200 Softswitch Configuration Files 5-6
Installing Sun Solaris 10 5-8
Loading the Sun Solaris 10 Operating Environment Packages 5-9
Restoring Data Files 5-10
Installing and Verifying the Cisco PGW 2200 Softswitch Software 5-10
Migrating the First Cisco PGW 2200 Softswitch Software to Release 9.8 5-11
Backing Up the Cisco PGW 2200 Softswitch Configuration Files 5-12
Installing Sun Solaris 10 5-14
Loading the Sun Solaris 10 Operating Environment Packages 5-15

Contents
vii
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
Restoring Data Files 5-15
Installing and Verifying the Cisco PGW 2200 Softswitch Software 5-16
Transferring Additional Configuration Files 5-17
Migration from Release 9.7 to Release 9.8 without Platform Changes 5-21
Upgrading Lively from Sparc-based Platforms to Opteron-based Platforms 5-22
Before You Start 5-22
Live Upgrade Procedure 5-23
Falling Back Overview 5-27
Falling Back to the Cisco PGW 2200 Softswitch Software Release 9.7 without Platform Changes 5-28
Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 5-29
Falling Back to Solaris 8 If Hard Drives Were Replaced During the Upgrade 5-29
Falling Back to Solaris 8 on the Second Disk Drive 5-29
Restoring the Original Cisco PGW 2200 Softswitch Software 5-33
Falling Back to Previous Cisco PGW 2200 Softswitch Software Releases with Platform Changes 5-34
Replacing Hard Disks on an Existing Solaris 10 Platform 5-35
Backup Procedure 5-35
Hard Disk Replacement Procedure 5-36
Loading the Solaris 10 Operating System 5-36
Loading the Sun Solaris 10 Operating Environment Packages 5-37
Installing the Cisco PGW 2200 Softswitch 5-37
Restoring the System 5-37
CHAPTER 6Configuring the Local Area Network Switch 6-1
Introduction 6-1
LAN Switch Overview 6-1
Catalyst 2900 XL Series 6-2
Catalyst 5500 and 5000 Series 6-2
APPENDIX AXECfgParm.dat File Parameters A-1
Introduction A-1
Understanding the XECfgParm.dat File Format A-1
Cisco PGW 2200 Softswitch XECfgParm.dat Files A-1
Facility Names A-1
Special Parameters A-2
Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Parameter Definitions A-2
APPENDIX BClient/Server and Secure Connectivity Relationships B-1
Introduction B-1

Contents
viii
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Client/Server and Secure Connectivity Relationships B-1
Secure Connectivity Among Cisco PGW 2200 Softswitch Applications B-2
Secure Connectivity Between Cisco PGW 2200 Softswitch Application Platforms B-2
Secure Connectivity Between Cisco BAMS Application Platforms B-3
Secure Connectivity Between Cisco BAMS and Cisco PGW 2200 Softswitch Application
Platforms B-3
APPENDIX CHP OpenView Sample SNMP Configuration C-1
Configuring the Cisco PGW 2200 Softswitch to Send Alarms to HP OpenView C-1
Formatting Trap Messages C-3
APPENDIX DSample Installation Scripts D-1
Introduction D-1
Sample Output from install.sh D-1
Updated Configuration File Sample D-12
Sample Configured snmpd.cnf File D-13
Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) D-16
Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) D-27
Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) D-37
APPENDIX ESample Uninstall Scripts E-1
Introduction E-1
Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh E-1
APPENDIX FSample LAN Configurations F-1
Introduction F-1
Sample Configuration for Cisco Catalyst 5500 A F-1
Sample Configuration for Cisco Catalyst 5500 A RSM F-7
Sample Configuration for Cisco Catalyst 5500 B F-9
Sample Configuration for Cisco Catalyst 5500 B RSM F-15

ix
Cisco PGW 2200 Softswitch Release 9.8 Software Installation andConfiguration Guide
OL-18083-14
Preface
Revised: February 21, 2012, OL-18083-14
Introduction
This preface describes the objectives of this document and explains how to find additional information
on related products and services. It contains the following sections:
• Document Objectives, page ix
• Audience, page ix
• Related Documentation, page x
• Obtaining Documentation and Submitting a Service Request, page x
• Document Change History, page xi
Document Objectives
This guide describes the steps necessary to install and configure the Sun Solaris 10 operating system,
and the Cisco PGW 2200 Softswitch software Release 9.8.
Note This guide does not cover media gateway (MGW) or Cisco PGW 2200 Softswitch hardware installation.
For instructions on installing these components, see the Cisco PGW 2200 Softswitch Hardware
Installation Guide.
Audience
The audience for this document is network operators and administrators. This audience is assumed to
have experience in telecommunications networks, protocols, and equipment, and a familiarity with data
communications networks, protocols, and equipment.

x
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Preface
Related Documentation
This document contains information that is related to Cisco PGW 2200 Softswitch software installation
and configuration. For additional information on those subjects, see the documents at this URL:
http://www.cisco.com/en/US/products/hw/vcallcon/ps2027/tsd_products_support_series_home.html
You can also find the Cisco PGW 2200 Softswitch Documentation Map at the following URL:
http://www.cisco.com/en/US/products/hw/vcallcon/ps2027/products_documentation_roadmaps_list.ht
ml
Other useful reference publications include:
• Overviews of the related telephony solutions—Describe the Cisco telephony solutions with which
the Cisco PGW 2200 Softswitch node is associated
• Provisioning guides for the related telephony solutions—Describe the provisioning steps for the
Cisco telephony solutions with which the Cisco PGW 2200 Softswitch node is associated
• Solution gateway installation and configuration guides—Describe the steps for installing and
configuring the media gateway for a particular Cisco telephony solution
• Cisco IP Transfer Point - LinkExtender—Describes the Cisco IP Transfer Point - LinkExtender
(Cisco IPT-L, formerly known as the Cisco Signaling Link Terminal or Cisco SLT) and provides
configuration information
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional
information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and
revised Cisco technical documentation at
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed
and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free
service and Cisco currently supports RSS version 2.0.

xi
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
Preface
Document Change History
Release Number Document Number Change Date Change Summary
9.8(1) OL-18083-13 June 23, 2011 Updated the XECfgParm.dat parameters.
9.8(1) OL-18083-12 March 2011 Updated information pertaining to the Sun hardware
platforms, Sun Fire X4640 and Sun Netra X4270.
9.8(1) OL-18083-11 September 7, 2010 Added a note to Chapter 5, section “Migration from
Release 9.7 to Release 9.8 without Platform Changes”
section on page 21. The note advises users of the
proper seqence for installing release 9.8(1) and a
required patch before starting the system software.
9.8(1) OL-18083-10 July 16, 2010 Added a note to describe the workaround for a known
issue of migration, in the “Migration from Release 9.7
to Release 9.8 without Platform Changes” section on
page 21.
9.8(1) OL-18083-09 May 24, 2010 Added new parameters, *.DaylightSavingsTime and
*.offset,in Table A-1, Cisco PGW 2200 Softswitch9.x
XECfgParm.dat File Configuration Parameters.
9.8(1) OL-18083-08 May 10, 2010 Added the parameters
*.AllISDNLinksFailCausesFailover,
*.AllLinksFailCausesFailover, and
replicator.reconnectInterval to Table A-1 on page A-3.
Added the section“Configuring Geographic Separation
of Active and Standby Hosts” on page 4-33.
Added the parameter *.shortdurationcallperiod to
Table A-1 on page A-20.
Addedthe parameter engine.FaultRecoveryAuditTimer
to Table A-1 on page A-30.
Added the parameter *.FaxUpspeedCodecPreference
to Table A-1 on page A-9.
Added the parameter *.analysisCapabilityLevel to
Table A-1 on page A-3.
9.8(1) OL-18083-07 February 26, 2010 Added a note that users need to download the latest
version of the mgcTTmigrate script every time before
they use it in the “Upgrading Lively from Sparc-based
Platforms to Opteron-based Platforms” section on
page 22.
9.8(1) OL-18083-06 December 21, 2009 Updated the description for the parameter,
*.GWClearChannelAlgorithm in Table A-1,
Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File
Configuration Parameters.
Added the new parameter, SIP.udp2tcp_byte_xover, in
Table A-1, Cisco PGW 2200 Softswitch 9.x
XECfgParm.dat File Configuration Parameters.

xii
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Preface
9.8(1) OL-18083-05 December 9, 2009 Added two new parameters of the XECfgParm.dat file,
*.IOI and *.ICID, in Table A-1.
Added two footnotes in Table 2-1. On the Netra X4200
M2 platform, for stability purposes, we recommend
that you use the Net 2 (e1000g0) and Net 3 (e1000g1)
interfaces, and not the nge0 and nge1 interfaces.
Removed TALI and Tekelec-related information
throughout the book.
9.8(1) OL-18083-04 October 19, 2009 Added the *.FNTBehaviourOptions and the
engine.ChangeCallIDForB2BUA parameters in
Appendix A.
Updated the section, Verifying Database Replication,
in Chapter 4.
9.8(1) OL-18083-03 September 8, 2009 Added and updated notes for patch download URLs.
Updated the download procedure for the
mgcTTmigrate script.
9.8(1) OL-18083-02 June 11, 2009 Added a procedure in Chapter 2 to check if the
Cisco PGW 2200 Softswitch software is already
installed.
9.8(1) OL-18083-02 June 11, 2009 Added Sun Fire X4600 M2 Quad-core platform
support.
9.8(1) OL-18083-01 November 26, 2008 Initial release.
Release Number Document Number Change Date Change Summary

CHAPTER
1-1
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
1
Preparing for Sun Solaris Operating System and
Cisco PGW 2200 Softswitch Software
Installation
Revised: February 21, 2012, OL-18083-14
Introduction
This chapter provides checklists describing the required and optional components, software media, and
information you must have on hand before installing the Sun Solaris operating system and the
Cisco PGW 2200 Softswitch software:
• Cisco PGW 2200 Softswitch Release 9.8 and up, which requires the Sun Solaris Operating System
10
Note The entire installation procedure takes approximately 2 hours to complete.
Supported Platforms and Cisco Products
The following Cisco products are supported by this software:
• Cisco PGW 2200 Softswitch
• Cisco Billing and Measurements Server (BAMS)
• Cisco H.323 Signaling Interface (HSI)
The platforms that are supported for these products are identified in the Cisco PGW 2200 Softswitch
Hardware Installation Guide (Release 7 & 9).

1-2
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Chapter 1 Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software Installation
Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release Preinstallation Checklists
Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8
and Higher Software Release Preinstallation Checklists
Table 1-1 through Table 1-4 list the required and optional tasks, information, and software media for
installing the Solaris 10 operating system and the Cisco PGW 2200 Softswitch software Release 9.8 and
higher.
Before installing the Sun Solaris operating system, Solaris patches, and alarm card software, ensure that
you collect the information and complete tasks listed in the following tables.
Note The target machine must have a terminal connected to the console port by means of a serial cable.
Required Software Media
Gather all of the appropriate software media listed in Table 1-1. For more information, see the
appropriate Sun documentation that shipped with your system.
Table 1-1 Solaris 10 Required Media Checklist
Media Version
The following CD-ROM disks are ordered from Cisco:
• Cisco Solaris 10 Operating System Jumpstart Disk
This disk installs the Sun Solaris 10 Operating System,
configured specifically to support the
Cisco PGW 2200 Softswitch software. There are two versions of
this disk, one for each of the supported platform types:
– Cisco Solaris 10 Operating System Jumpstart Disk for
Sparc-based platforms
– Cisco Solaris 10 Operating System Jumpstart Disk for
Opteron-based platforms
06/06
01/06
10/081
• Cisco Solaris 10 Operating Environment CD
This disk contains the following packages:
– CSCOh020 (MGC Security package)
– CSCOh021 (Verification Test Suite scripts)
– CSCOh022 (Solaris 10 patches for Sparc-based platforms)
– CSCOh023 (DiskSuite installation scripts)
– CSCOh024 (Log/Spool installation for Sparc-based
platforms)
– CSCOh026 (Xterm, ftp, ntp, and alarm software installation
for Sparc-based platforms)
– CSCOh032 (Solaris 10 patches for Opteron-based platforms)
– CSCOh036 (Xterm, ftp, and ntp installation for
Opteron-based platforms)
3.0(6)

1-3
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
Chapter 1 Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software Installation
Solaris 10,Cisco PGW 2200 SoftswitchSoftwareRelease9.8 and Higher Software Release Preinstallation Checklists
Minimum System Requirements
Refer to the Cisco PGW 2200 Softswitch Hardware Installation Guide (Release 7 & 9) for the host
minimum hardware requirements. Before using the minimum hardware configuration, consult your
Cisco representative to determine the hardware that gives you the best performance results based on your
network configuration, proposed traffic, and desired processing power.
Required Site-Specific Information
Your system site administrator can provide the required site-specific information in Table 1-2. Use the
Notes column in this table to record the information. Several steps in the installation procedure in
Chapter 2, “Installing the Sun Solaris 10 Operating System” require you to provide this information.
Required Machine-Specific Information
Your system site administrator can provide the information called for in Table 1-3 as it applies to your
target Sun Netra machine. Use the Notes column in this table to record the information. Several steps in
the installation procedure require you to provide this information.
1. There are two versions of the Cisco Solaris 10 Operating System Jumpstart Disk for Opteron-based platforms. If you are
installing the Sun Solaris 10 Operating System on an X4640 Quad-core platform, use the 10/08 version (the latest version).
If you are installing the Sun Solaris 10 Operating System on other Opteron-based platforms, use either the 10/08 version or
the 01/06 version.
Table 1-2 Site-Specific Information
Required Information Notes
Subnet Mask
(Example: 255.255.255.0)
Default router
(Example: 111.11.xxx.1)
DNS server
NTP server IP address
Time zone
(Example: United States (Eastern))
Root password
(Assigned by your system site
administrator)
Table 1-3 Machine-Specific Checklist
Information Notes
Host name of target machine
IP address of target machine
Default router IP address
Additional Ethernet IP address

1-4
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Chapter 1 Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software Installation
Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release Preinstallation Checklists
Required Tasks
Before you begin installing the Solaris 10 operating system, perform the tasks listed in Table 1-4.
Subnet address for each additional Ethernet IP address
Netmask address for each additional Ethernet IP address
Table 1-3 Machine-Specific Checklist
Information Notes
Table 1-4 Tasks Checklist
Check Tasks
Make sure that the target machine is connected to a terminal by a serial cable inserted into
the console port.
Have your company's internal support and Cisco support contact information readily
available so you can get help with the installation if needed. If you have questions or need
assistance, see the “Obtaining Documentation and Submitting a Service Request” section
on page x.

CHAPTER
2-1
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
2
Installing the Sun Solaris 10 Operating System
Revised: February 21, 2012, OL-18083-14
Introduction
This chapter provides instructions for installing the packages that create the Sun Solaris 10 operating
system and its operating environment on the Sun Netra and Sun Fire platforms. The following sections
contain these instructions.
Note In the following procedures, your responses to prompts sometimes depend on the disk drive size or other
particulars of your system. These are pointed out as you follow the procedures.
• Supported Platforms, page 2-1
• Supported Disk Drives, page 2-1
• Before You Start, page 2-2
• Loading the Sun Solaris 10 Operating System, page 2-3
• Loading the Sun Solaris 10 Operating Environment, page 2-53
Note For procedures on migrating to Solaris 10 and Cisco PGW 2200 Softswitch software Release 9.8, see
Chapter 5, “Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8.”
Supported Platforms
This document describes the specific steps necessary for installing the Sun Solaris 10 operating system
and the operating environment on the Sun Netra and Sun Fire platforms. Two platform types are used:
Sparc-based and Opteron-based. The platforms that are supported for these products are identified in the
Cisco PGW 2200 Softswitch Hardware Installation Guide (Release 7 & 9).
Supported Disk Drives
The following disk drives are supported:

2-2
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Chapter 2 Installing the Sun Solaris 10 Operating System
Before You Start
• 73 GB
• 146 GB
Before You Start
Be sure to read the following cautions, notes, and tips before installing the Sun Solaris 10 operating
system and the operating environment.
If you purchased the Sun hardware platform from Cisco, the Sun Solaris 10 operating system, the
operating environment, and the base Cisco PGW 2200 Softswitch software may already be installed.
You can skip the installation of the software. You must install all of the Cisco PGW 2200 Softswitch
software patches.
There are two methods to verify if the software was already installed:
• Check if the two files, /opt/jumpstart_log* and /.core_finished, exist on your hardware platform. If
the two files exist, the software was already installed.
• Enter man and press Enter. If the system returns the message below, the software was already
installed.
<machine name>% man
man: Command not found
Cautions, Notes, and Tips
Note The procedures in this chapter require a working knowledge of the system administration procedures for
the Sun Solaris (UNIX) operating system.
Note Be sure to have the required information listed in Chapter 1, “Preparing for Sun Solaris Operating
System and Cisco PGW 2200 Softswitch Software Installation,” before you begin the installation
process.
Note Allow at least 2 hours downtime for the installation of the Cisco PGW 2200 Softswitch software
environment.
Note The text in the screens displayed throughout this document might differ slightly from the text displayed
on your console. The screen displays are for reference only and should be treated as examples.
Note Most of the steps in the installation process ask you to press F2 to continue. However, F2 does not apply
to all console types. If it does not apply on your system, you should press Esc-2 instead.

2-3
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide
OL-18083-14
Chapter 2 Installing the Sun Solaris 10 Operating System Loading the Sun Solaris 10 Operating System
Tip During the installation process, monitor system output frequently for error messages and correct any
error conditions before continuing with the installation.
Loading the Sun Solaris 10 Operating System
This section provides the following instructions for loading the Sun Solaris 10 operating system:
• Devices on Supported Platforms, page 2-3
• Installing the Sun Solaris 10 Operating System for Sparc-based Platforms, page 2-4
• Installing the Sun Solaris 10 Operating System for Opteron-based Platforms, page 2-13
• Configuring Your Host, page 2-30
• Platform-Specific Installation Procedures, page 2-43
• Installing the Sparc-based Solaris 10 Patches Package (CSCOh022), page 2-54
• Installing the Opteron-based Solaris 10 Patches Package (CSCOh032), page 2-56
• Installing the Solstice DiskSuite (CSCOh023), page 2-59
• Installing the Log and Spool File Systems (CSCOh024), page 2-71
• Installing Cisco BAMS Archive Partition (CSCOh027), page 2-79
• Installing the Sparc-based Communications and Alarm Software Package (CSCOh026), page 2-85
• Installing the Opteron-based Communications Software Package (CSCOh036), page 2-99
• Installing the Verification Test Suite Script Package (CSCOh021), page 2-111
Devices on Supported Platforms
Table 2-1 shows the Ethernet and disk drive device names for each platform type. This table is referenced
throughout this chapter.
Table 2-1 Device Names on the Supported Host Platforms
Platform Type Ethernet Interfaces Disk Drives
First Second Third Fourth First Second Third Fourth
Sun Fire V210 /
Netra 210 bge0 bge1 bge2 bge3 c1t0d0 c1t1d0 — —
Netra 240 bge0 bge1 bge21
1. This device is not used currently.
bge31c1t0d0 c1t1d0 — —
Sun Fire V40z bge0 bge1 ce0 c1t0d0 c1t1d0 — —
Sun Fire X4640 e1000g0 e1000g1 e1000g2 e1000g3 c3t0d0 c3t1d0 — —
Netra 440 ce0 ce1 — — c1t0d0 c1t1d0 c1t2d01c1t3d01
Sun Netra X4270 igb0 igb1 igb2 igb3 c3t0d0 c3t1d0 — —

2-4
Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14
Chapter 2 Installing the Sun Solaris 10 Operating System
Loading the Sun Solaris 10 Operating System
Note If your platform has multiple disk drives, install the Solaris 10 Operating System on the first disk drive
only.
Installing the Sun Solaris 10 Operating System for Sparc-based Platforms
The instructions in this section were written to correspond with the instructions in the Cisco Solaris 10
Operating System Jumpstart Disk for Sparc-based Platforms. Other Solaris installations are similar, with
slight variations. These instructions willnote the differences between the sets of installationinstructions.
Step 1 Choose one of the following options to connect the Cisco PGW 2200 Softswitch:
• Connect to the Cisco PGW 2200 Softswitch through a console port.
• Connect a keyboard and monitor to the Cisco PGW 2200 Softswitch.
Step 2 This step is optional—if you decide to skip this step, go to Step 3.
a. Place the system in single-user mode by shutting down the standby machine.
b. When the machine prompts for a password, type either ^ -d to proceed with normal startup, or the
root password for system maintenance.
Step 3 Load the appropriate version of the CD-ROM labeled Cisco Solaris 10 Operating System Jumpstart Disk
for Sparc-based Platforms into the CD-ROM drive.
Step 4 If the system is currently running, log in as root.
Step 5 Bring the system to the ok prompt by entering the following command:
# init 0
Note If you are prompted to select a language before booting from the CD, go to the ok prompt by
sending a break on the console port. On Sun Sparc-based platforms, the key sequence <cr>#.
gets you to the system controller prompt.
From the system controller prompt, use the break -y command to break out of the operating
system and console -f command to return to the console display. You should see the ok prompt.
Step 6 Boot the system from the CD-ROM drive by entering the appropriate command:
ok boot cdrom - install
Information similar to the following is displayed:
ok boot cdrom - install
SC Alert: Host System has Reset
Probing system devices
Probing memory
Probing I/O buses
Sun Fire V210, No Keyboard
Copyright 2005 Sun Microsystems, Inc. All rights reserved.
OpenBoot 4.18.5, 2048 MB memory installed, Serial #52030991.
Ethernet address 0:3:ba:19:ee:f, Host ID: 8319ee0f.
