INSTRUCTION MANUAL
FOR
DIGITAL BLOOD PRESSURE MONITOR
CHU305
1501
English
Español
* Please read all of the information in the instruction
manual before operating the monitor.
00CHU305USA.indbEng-100CHU305USA.indbEng-1 2015/01/1319:53:122015/01/1319:53:12

- Eng 2 -
English Español
Blood pressure
monitor unit
(for monitor)
4 AA-size
batteries
Instruction
Manual
Wide Range
Cuff
Contents
3 - GENERAL REMARKS
5 - PRECAUTIONS FOR USE AND MAINTENANCE
7 - FCC STATEMENT
8 - IDENTIFICATION OF PARTS
9 - LOADING THE BATTERIES
10 - REMOVING THE BATTERIES
10 - TIME ADJUSTMENT
12 - MEASURING YOUR BLOOD PRESSURE
16 - TIPS FOR OBTAINING ACCURATE MEASUREMENTS
17 - CALLING UP THE DATA STORED IN MEMORY
18 - ABOUT “BLOOD PRESSURE”
19 - BLOOD PRESSURE Q&A
20 - BEFORE REQUESTING REPAIRS OR TESTING
21 - SPECIFICATIONS
22 - 5-YEAR LIMITED WARRANTY
English
Quick Start Guide
Using YourDigital Blood Pressure Monitor
Alwaysconsult the included Guidebook for further details and instruction
Beforeapplying your blood pressure cuff, be sure you have selected
theappropriate size cuff:
WideRange Cuff fits arm circumference: 8-3/4” – 16-1/2” (22 cm – 42 cm).
A15 minute resting period is needed to stabilize
thebody prior to taking a reading.
Noeating, drinking or smoking while resting.
Removeany constrictive clothing or jewelry that may interfere with cuff placement. Wrap the cuff snugly around your left arm. Position the
cuff’sbottom edge one inch ABOVE the elbow joint. Position the air hose in the center of your arm. Youshould be able to insert one finger
betweenyour arm and cuff.
MEASUREMENTINSTRUCTIONS
•Many factors such as genetics, age, sex, altitude, physical activity,
anxiety,muscular development, certain medications or even the
timeof day can influence blood pressure.
•Blood pressure varies from moment to moment; even readings
takenafter proper rest periods can vary. Home blood pressure
readingsmay vary as much as 10-20 points from ones taken at
yourdoctor’s office.
•Variations in your individual readings should only be interpreted by
yourphysician or trained health care professional.
•We encourage you to consult with your physician to achieve the
maximumbenefit from your blood pressure monitor.
Pleaseread the Guidebook for this monitor prior to taking your first reading.
Ifyou have any questions or are experiencing difficulties, please call the toll-free
CustomerService Help Line for further assistance at 1-866-326-1313.
#93-209012/14
©2014VeridianHealthcare, LLC.
Digital Blood Pressure Monitor
Model # CHU305
• Plug the air hose connector firmly
intothe air hose socket on the
mainunit, as illustrated.
Plugthe air hose
connectorinto the main
unit.
Placethe cuff at the height of the heart.
( Seepage 16)
1
2
Airhose
socket
Airhose
connector
Pressthe “ START/STOP”switch.
3
* isdisplayed when a pulse is detected.
* Whenyou want to stop measurement,press the
“
START/STOP”switch.The cuff is deflated
andmeasurementstops.
Themeasurement results are displayed.
4
Finishingmeasurement.
• Press the “ START/STOP”switchto turn the monitor off.
5
• Once measurement is complete, the
cuffdeflates and the measurement
results(systolic/diastolic blood
pressurevalues,pulse) are displayed.
*Systolic/diastolic blood pressure
valuesand pulse are displayed
alternately.
*Provided there is no error in the
measurementresults,they are
storedautomatically.
PLEASENOTE
( Consultyour Instruction Manual for details regarding Irregular
Heartbeat(IHB)Indicator
)
AUTOMATICPOWER OFF FEATURE
• After taking the blood pressure measurement, pressing the “ START/STOP”
switchwill turn the monitor off. However,if you do not press the switch, the moni-
tor’sAutoOFF function will automatically turn the monitor off after 1 minute.
HypertensionClassificationlndicator
( Seepage15)
START/STOP
Switch
• A beep is heard and all digits displayed is an initial display, indicating that the
monitoris functioning normal.
• The cuff is pressurized automatically.
*
Ifthe unit judges that pressurizationis insufficient, it automatically repressurizes.
*The un itautomatically sets the pressurebased on the previous measurement.
* If the previous user had a high presser setting, that high pressure will
automaticallybe used for the current measurement.
* If the pressurization value exceeds 260 mmHg, if pressurization feels
abnormal,or if you want to stop the measurement process,press the
“START/STOP”switchagain. The cuff deflates, and the power turns off.
Quick Start Guide Blood Pressure Log FAQ's
Ensure that you have all the following components
00CHU305USA.indbEng-200CHU305USA.indbEng-2 2015/01/1319:53:132015/01/1319:53:13

- Eng 3 -
Español English
General remarks on blood pressure and blood pressure
measurement
1. To deflate the cuff quickly, press the “START/STOP” switch.
2. The attached wide range cuff is suited for an arm circumstance of 8 3/4” – 16
1/2” (22 cm – 42 cm).
3. When attaching the cuff, adjust the position of the cuff so that the air hose is
located in the center of your arm and the hem of the cuff is 0.4” – 0.8” (1 cm –
2Űcm) above your elbow.
4. Self measurement is not therapy! In no event should you change the dosage of
your medication prescribed by your physician.
5. As preparation for measuring your blood pressure, you should urinate and then
remain relatively still for 10 to 15 minutes prior to measurement.
6. DO NOT place too much emphasis on the results of one measurement. Keep a
continuing record of your blood pressure variations. A complete picture can only
be obtained from a large number of readings.
To obtain correct blood pressure measurements
1. Take five or six deep breaths and then relax before measuring your blood
pressure. If you are tense when taking the measurement, you will not get a
valid reading.
2. Your blood pressure will be elevated if you are anxious or irritated, suffering
from lack of sleep or constipation, or have just taken some exercise or
eaten a meal.
3. Wrap the cuff around your arm and tighten it so that one finger can be
inserted between the cuff and arm. ( See page 12, 13)
4. DO NOT measure your blood pressure after bathing or drinking.
5. Measure your blood pressure where the room temperature is around 68°F
(20°C). DO NOT measure your blood pressure when it is too cold (below
50°F (10°C)) or too hot (above 104°F (40°C)) in the room.
6. DO NOT try to measure your blood pressure immediately after drinking coffee or
tea or after smoking.
7. Measure your blood pressure when you are relaxed and still. Keep the center of
the cuff at the level of your heart and DO NOT move your arm or talk.
8. DO NOT measure blood pressure when the cuff has been on your arm for a few
minutes or more. During this time, your arm will have built up a higher blood
pressure and you will not get valid reading.
9. If the Irregular Heartbeat (IHB) Indicator is displayed, relax and measure
your blood pressure again. If the Irregular Heartbeat (IHB) Indicator appears
frequently, you are advised to consult a doctor about your health condition.
( See page 15)
GENERAL REMARKS
00CHU305USA.indbEng-300CHU305USA.indbEng-3 2015/01/1319:53:162015/01/1319:53:16

- Eng 4 -
English Español
10. The figure below shows the blood pressure classifications under the WHO
standards.
Remarks:
The graph is not exact, but
may be used as a guide in
understanding non-invasive
blood pressure measurements.
The device is only intended for
use by adults.
Definitions and Classifications of Blood Pressure Levels
* This unit is equipped an indicator which visually indicates the blood pressure
classification (Optimal/Normal/High-Normal/Grade 1 Hypertension/Grade 2
Hypertension/Grade 3 Hypertension) of the result after each measurement.
11. Intended Use
• This device is noninvasive blood pressure monitor by oscillometric method.
This device can measure the systolic blood pressure (SYS), the diastolic blood
pressure (DIA) and the pulse rate automatically.
• This device is intended to be used for checking personal health condition at
home under the direction of a physician and is not intended to be a diagnostic
device.
• This device is not intended for use with neonates or infant, and not intended
for automatic cycling measurement.
Measure your blood pressure at the same time each day.
* Your blood pressure changes all the time. This means that data gathered over
a long period has far more significance than data from just one measurement.
For this reason, you must measure your blood pressure on a daily basis. Ideally,
you should measure your blood pressure at the same time each day, wherever
possible.
00CHU305USA.indbEng-400CHU305USA.indbEng-4 2015/01/1319:53:162015/01/1319:53:16

- Eng 5 -
Español English
Precautions for use
1. If you suffer from heart disease, high blood pressure or other circulatory disease,
consult your physician before using the monitor.
2. Inflating to a higher pressure may result in bruising where the cuff is applied.
If the cuff pressure feels abnormal or you experience any other irregularity while
using the cuff, reduce the pressure immediately by pressing the “START/STOP”
switch, detach the cuff or unplug the air hose connector from the monitor and
then consult the sales outlet where you purchased the monitor.
3. If you think the measurement is abnormal or if measurement makes you feel
unwell, discontinue use and consult your physician.
4. Blood pressure measurement may not be possible for anyone with a weak pulse
or arrhythmia.
5. Repeated blood pressure measurement and prolonged overinflation may cause
problems such as congestion or swelling in some people.
6. Frequently repeated blood pressure measurements will not give accurate
results. Allow an interval of about 1 minute between measurements.
7. If you suffer from a severe problem with blood circulation in your arms, consult
your physician before using the monitor. Failure to do so could be hazardous to
your health.
8. Measurement may not be possible for anyone with insufficient blood flow to the
area where measurements will be taken or who suffers from a frequent irregular
heartbeat. Consult your physician for advice on whether to use the monitor.
9. DO NOT wrap the cuff around an injured arm.
10. DO NOT wrap the cuff around an arm in which a drip (intravenous infusion)
is inserted or which is being used for blood transfusion as part of medical
treatment. Doing so could result in an injury or a serious accident.
11. Do not share the cuff with other infective person to avoid cross-infection.
12. If you have any doubt about the application of the cuff on the arm on the side of
a mastectomy, consult your physician.
13. DO NOT use the monitor in the vicinity of flammable gases such as those used
for anaesthesia. Doing so could ignite the gases and cause an explosion.
14. DO NOT use the monitor in enriched oxygen environments such as a hospital’s
hyperbaric chamber or oxygen tent. Doing so could ignite the oxygen and
cause a fire.
15.
DO NOT use mobile phones near the monitor as this could result in a malfunction.
16. If you use a cardiac pacemaker, consult your physician before using the monitor.
17. Be sure to use this unit only for measuring blood pressure. DO NOT use it for
any other purpose.
18. Be sure to use only our authorized parts and accessories. Parts and
accessories not approved for use with the device may damage the unit.
19. DO NOT use this unit on infants.
20. Blood pressure measurement may not be possible for anyone with common
arrhythmias such as atrial or ventricular premature beats or atrial fibrillation.
PRECAUTIONS FOR USE AND MAINTENANCE
00CHU305USA.indbEng-500CHU305USA.indbEng-5 2015/01/1319:53:162015/01/1319:53:16

- Eng 6 -
English Español
Maintenance Precautions
1. DO NOT store the blood pressure monitor in locations exposed to direct
sunlight, high temperatures (over 131°F (55°C)), low temperatures (below -4°F
(-20°C)), high relative humidity (over 90%) or excessive amounts of dust.
Make sure to store the blood pressure monitor, where children, pets and or
pests are not there.
2.
DO NOT drop the blood pressure monitor or subject it to other shocks or vibration.
3. Remove the batteries if the monitor will be left unused for a long period.
4. DO NOT attempt to disassemble the monitor. Ask the service center which is
designated by manufacturer.
5. DO NOT bend the cuff or the air hose excessively.
6. If the monitor and the cuff are very dirty, wipe them clean with a cloth moistened
with sterilizing alcohol or a neutral detergent. Then wipe them with a dry cloth. If
needed in hospital, the cuff should be disinfected 2 times every week.
7. NEVER clean the blood pressure monitor with thinners or benzene, as this could
damage the monitor.
8. To clean the cuff, wipe it with a moist cloth. Avoid hard rubbing, as this will
cause air leakages. Take care also not to get water into the air hose.
9. Clean the cuff after the usage of every 200 times is recommended.
Calibration:
The blood pressure measuring device is generally recommended to have the
monitor inspected every two years to ensure correct functioning and accuracy.
Please contact a distributor.
Warning
No modification of this device is allowed.
Symbols Explanation
: Type BF applied part (The cuff is type BF applied part.)
: Keep dry
: Warning
: Refer to instruction manual before use (The sign background color:
blue. The sign graphical symbol: white.)
:
Symbol for “ENVIRONMENT POROTECTION – Waste electrical products
should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local Authority or retailer for recycling advice”
Warning
The device has been tested and homologated in accordance with
EN60601-1-2 for EMC. This does not guarantee in any way that
the device will not be affected by electromagnetic interference.
Avoid using the device in high electromagnetic environment.
Toll-Free Customer Care Help Line
866-326-1313 Mon-Fri 8:30 am – 4:30 pm CST
Exclusively Distributed in USA by:
©2014 Veridian Healthcare, LLC.
1175 Lakeside Drive
Gurnee, IL 60031 USA
Made in China
#93-1271 11/14
00CHU305USA.indbEng-600CHU305USA.indbEng-6 2015/01/1319:53:162015/01/1319:53:16

- Eng 7 -
Español English
NOTE:
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)
This product has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. The product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If the
product does cause harmful interference to radio or television reception, which can
be determined by turning the product on and off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for Canada only)
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the interference-causing equipment
standard entitled “Digital Apparatus”, ICES-003 of the Canadian Department of
Communications.
Cet appareil numérique respecte les limites de bruits radioeléctriques applicables aux
appareils numériques de Clase B prescrites dans la norme sur le materiel brouilleur:
“Appareils Numériques”, ICES-003 édictée par le minister des communications.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC STATEMENT
00CHU305USA.indbEng-700CHU305USA.indbEng-7 2015/01/1319:53:162015/01/1319:53:16

- Eng 8 -
English Español
<Main Unit>
Component names
IDENTIFICATION OF PARTS
Air hose
connector
Air hose
<Cuff>
Metal hoop
Display
MEMORY
Switch
Air hose socket
START/STOP Switch
Stand-by
* See page 9 for the Battery compartment
* See page 15 for the Irregular Heartbeat (IHB) Indicator.
<Display>
Systolic blood
pressure display
Ready to inflate
indicator
Battery icon
Memory icon
Hypertensinon
Classification
Indicator
Irregular Heartbeat
(IHB) Indicator* Date/Time display
Diastolic blood
pressure/Pulse
display
00CHU305USA.indbEng-800CHU305USA.indbEng-8 2015/01/1319:53:172015/01/1319:53:17

- Eng 9 -
Español English
(Batteries supplied with the unit should be loaded in compartment before you use
the blood pressure monitor.)
LOADING THE BATTERIES
1Open the cover of battery compartment.
Pressing the upper part of the battery cover, pull the cover toward you to open.
2Place batteries in the compartment.
Put the batteries paying attention to the
positive and negative terminal symbols
and .
* If the Blood pressure monitor is left unused for an extended period of
time, the batteries should be removed from the compartment.
Battery cover
Battery compartment
4 “AA” batteries
3Close the battery cover.
00CHU305USA.indbEng-900CHU305USA.indbEng-9 2015/01/1319:53:172015/01/1319:53:17

- Eng 10 -
English Español
REMOVING THE BATTERIES
• When the icon is displayed or nothing appears in the display, replace the old
batteries with four new ones. All four batteries should be changed at once.
• Adjust the clock after changing the batteries.
• The data stored in the memory is not deleted by changing the batteries.
• Do not use rechargeable batteries.
• Do not use alkaline (LR6) and manganese (R6P) batteries together.
• Batteries included are for demonstration purposes only. Battery life may be
shorter than specified.
• When disposing of used batteries, comply with governmental regulations or
environmental public institution’s rules that apply in your country/area.
TIME ADJUSTMENT
Setting the clock enables measurements to be accurately recorded.
The monitor can record the date and time of measurement as well as the
measurement results. Be sure to set the clock after inserting the batteries.
1When you install the batteries for the first time,
the monitor will display time and date by turns.
2Press and hold both the “ START/STOP” switch
and the “ MEMORY” switch for approximately
two seconds, a beep is heard and the “month”
indicator blinks at first.
3 P re ss the “ MEMORY” switch to adjust the
“month”.
Press the “ MEMORY” switch to increase
the number by one. Press the “ START/STOP”
switch to confirm the setting. The “month” is set and
the “day” indicator blinks.
* You can fast-forward the numbers in display by
pressing and holding the MEMORY switch.
00CHU305USA.indbEng-1000CHU305USA.indbEng-10 2015/01/1319:53:172015/01/1319:53:17

- Eng 11 -
Español English
4Press the “ MEMORY” switch to adjust the
“day”. Press the “ MEMORY” switch to increase
the number by one. Press the “ START/STOP”
switch to confirm the setting. The “day” is set and the
“hour” indicator blinks.
5 P ress the “ MEMORY” switch to adjust the
“hour”.
Press the “ MEMORY” switch to increase
the number by one. Press the “ START/STOP”
switch to confirm the setting. The “hour” is set and the
“minutes” indicator blinks.
6Press t he “ MEMORY” switch to adjust the
“minutes”.
Press the “ MEMORY” switch to
increase the number by one. Press the “ START/
STOP” switch to confirm the setting.
* Press the “ START/STOP” with the time signal on the
radio, etc. to complete clock adjustment.
00CHU305USA.indbEng-1100CHU305USA.indbEng-11 2015/01/1319:53:182015/01/1319:53:18

- Eng 12 -
English Español
2 ATTACHING THE CUFF
Before applying your blood pressure cuff, be sure you have selected the
appropriate size cuff:
Wide Range Cuff fits arm circumference: 8 3/4” – 16 1/2” (22 cm – 42 cm).
• Plug the air hose connector firmly into the air hose socket on the main unit,
as illustrated.
• Do not bend the air hose
during measurement, which
may cause inflation error,
or harmful injury due to
continuous cuff pressure.
1 Plug the air hose connector into the main unit.
Air hose
socket
Air hose
connector
MEASURING YOUR BLOOD PRESSURE
2Put the cuff around your arm so that the air
hose comes to the palm side.
Metal hoop
1Unroll the cuff and thread the end through the
metal hoop so that the side with the hook-
and-loop fastener is on the outside.
: The position of
the artery.
00CHU305USA.indbEng-1200CHU305USA.indbEng-12 2015/01/1319:53:192015/01/1319:53:19

- Eng 13 -
Español English
4Pull the end of the cuff
outwards so that the cuff is
snug around your arm and
then secure the end to the
hook-and-loop fastener.
5Place your arm on a table or the
like, so that the center of the cuff
comes to the height of your heart.
* Carefully place the cuff on
your arm, taking care to use
the correct tightness. The
tightness is correct if you can
readily slide a finger between
the cuff and your arm.
6Relax your arm and lightly open your hand, with the palm upward.
3 Place the cuff at the height of the heart.
( See page 16)
3Adjust the position of the cuff so that the air hose is located in the
center of your arm and the hem of the cuff is 0.4” – 0.8” (1 cm – 2 cm)
above your elbow.
* The cuff should be put on the bare arm
or over a light-weight underwear.
* If you wear a heavy-weight top, please
remove it.
0.4” – 0.8” (1 cm – 2 cm)
00CHU305USA.indbEng-1300CHU305USA.indbEng-13 2015/01/1319:53:192015/01/1319:53:19

- Eng 14 -
English Español
4 Press the “ START/STOP” switch.
* If the previous user had a high pressuer setting, that high pressure will
automatically be used for the current measurement.
* If the pressurization value exceeds 260 mmHg, if pressurization feels
abnormal, or if you want to stop the measurement process, press the
“START/STOP” switch again. The cuff deflates, and the power turns off.
• A beep is heard and all digits displayed is an initial display, indicating that the
monitor is functioning normal.
• The cuff is pressurized automatically.
*
If the unit judges that pressurization is insufficient, it automatically repressurizes.
* The un it automatically sets the pressure based on the previous measurement.
* is displayed when a pulse is detected.
* When you want to stop measurement, press the “ START/STOP” switch.
The cuff is deflated and measurement stops.
5 The measurement results are displayed.
• Once measurement is complete,
the cuff deflates and the
measurement results (systolic/
diastolic blood pressure values,
pulse) are displayed.
* Systolic/diastolic blood
pressure values and pulse are
displayed alternately.
* Provided there is no error in
the measurement results, they
are stored automatically.
6 Finishing measurement.
START/STOP
Switch
Hypertension Classification lndicator
( See page 15)
• Press the “ START/STOP”
switch to turn the monitor off.
00CHU305USA.indbEng-1400CHU305USA.indbEng-14 2015/01/1319:53:202015/01/1319:53:20

- Eng 15 -
Español English
Irregular Heartbeat Indicator
If an irregular heartbeat is detected during measurement, the Irregular
Heartbeat (IHB) Indicator is displayed after measurement is completed.
There are 2 conditions under which the signal of IHB will be displayed:
1) The coefficient of variation (CV) of pulse period > 25%
2) The difference of adjacent pulse period 0.14s, and the number of such
pulse takes more than 53 percentage of the total number of pulse.
• Measurement may not be correct if your heartbeat fluctuates greatly during
measurement. If the Irregular Heartbeat (IHB) Indicator is displayed, measure your blood
pressure again.
Caution If the Irregular Heartbeat (IHB) Indicator appears frequently,
you are advised to consult a doctor about your health
condition.
Hypertension Classification Indicator
The measured blood pressure value is displayed according to the WHO standards.
( See page 4)
Normal
Optimal
High-Normal
Grade 1 Hypertension (mild)
Grade 2 Hypertension (moderate)
Grade 3 Hypertension (severe)
SYSTOLIC
(mmHg)
DIASTOLIC
(mmHg)
180
160
140
130
120
80 85 90 100 110
Technical Alarm Description
The monitor will show ‘HI’ or ‘Lo’ as technical alarm on LCD with no delay if the
determined blood pressure (systolic or diastolic) is outside the rated range specified
in part SPECIFICACIONS. In this case, you should consult a physician or check if
your operation violated the instructions.
The technical alarm condition (outside the rated range) is preset in the factory and
cannot be adjusted or inactivated. This alarm condition is assigned as low priority
according to IEC 60601-1-8. The technical alarm is non-latching and need no reset.
The signal displayed on LCD will disappear automatically after about 8 seconds.
00CHU305USA.indbEng-1500CHU305USA.indbEng-15 2015/01/1319:53:202015/01/1319:53:20

- Eng 16 -
English Español
■Measurement in a reclining posture
1Lie down, facing the celling.
2Lightly open your hand with palm up and straighten your arm.
3Relax your body, arm and fingers.
4Do not move your body or talk during measurement.
* Relax yourself to avoid placing
pressure on the cuff.
■You may use your right arm to measure your blood pressure.
Blood pressure value is likely to differ by as much as 10mmHg when measured on
the right arm instead of the left (or vice-versa). Measure your blood pressure on the
same arm each day.
TIPS FOR OBTAINING ACCURATE MEASUREMENTS
Your blood pressure varies according to your posture, the time of day and a range of
other factors. Ideally, you should measure your blood pressure in the same posture
at the same time every day.
■Taking measurements while sitting
* Be seated comfortably with your feet flat on the floor, and don't cross your legs.
1Place your arm on a table or similar
surface with your forearm extended.
2It is important to have the cuff level with
your heart.
3Open your hand slightly on the table
so that your palm is facing up and your
fingers are relaxed.
4Do not move your body or talk while
taking the measurement.
AUTOMATIC POWER OFF FEATURE
• After taking the blood pressure measurement, pressing the “ START/STOP”
switch will turn the monitor off. However, if you do not press the switch, the
monitor’s Auto OFF function will automatically turn the monitor off after 1 minute.
00CHU305USA.indbEng-1600CHU305USA.indbEng-16 2015/01/1319:53:202015/01/1319:53:20

- Eng 17 -
Español English
99 measurement results can be stored in
Memory.
The average value is calculated
automatically to help you manage your daily
health.
2If you press the Memory switch again, past measurement data are
displayed.
Each time you press the switch, the measurement data are displayed in order from the
most recent to the oldest.
* Example of display when the Memory switch is pressed.
CALLING UP THE DATA STORED IN MEMORY
Memory switch
The data number is
displayed before the
measurement results.
1Press the Memory switch once.
* Example of display when the Memory switch is pressed.
Now the LCD displays the amount of the results in the current bank and
indicating the average value appears at the bottom of the display. Then the
average value, based on the last three measurements, is displayed.
• The value stored in memory is numbered in the order of measurements. For
example, when 99 sets of data are stored in memory, the data number 1
represents the latest data.
Data number: 1, 2, 3, ... ... 98, 99

The latest data

The earliest data
00CHU305USA.indbEng-1700CHU305USA.indbEng-17 2015/01/1319:53:212015/01/1319:53:21

- Eng 18 -
English Español
HOW TO DELETE THE DATA
1When any result (except average reading of the last three
measurements) is displaying, press and hold the Memory switch for
more than 3 seconds.
All data stored in Memory will be deleted.
ABOUT “BLOOD PRESSURE”
What is blood pressure?
The heart is a pump that
circulates blood throughout your
body. Blood is pumped from the
heart at a constant pressure into
arteries. This pressure is called
the arterial blood pressure and
represents, in general terms,
your blood pressure. Blood
pressure is indicated by several
kinds of pressures, including
the systolic pressure that occurs when the heart pumps blood, and the diastolic
pressure that occurs when blood returns to the heart.
Your blood pressure changes all the time.
Your blood pressure differs according to your age, gender and a range of other
factors. It is likely to be affected by your biorhythm during the day and by your
posture, physical activities, mental activities, level of stress and even by the air
temperature. The blood pressure of a healthy person generally varies within a day.
[Example of blood pressure variations within a day]
Blood pressure value (mmHg)
160
140
120
100
80
60
40
Time of day
12 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 6 7 8 9 10 11
Systolic blood
pressure
Diastolic blood
pressure
Sleeping
(Blood pressure values
measured at five-minute
intervals through the day)
●Bevan AT, Honour AJ, Stott
FH. Clin Sci 1969;36:329–
44.
(Systolic) (Diastolic)
Artery Artery
Left atrium
Left
ventricle
Left atrium
Left
ventricle
Dilation
The artery wall expands.
Contraction
Normal state is restored
to the artery wall.
Press and hold
for 3 seconds
Deleted
A message saying all
the data have been
deleted from the
memory is displayed.
00CHU305USA.indbEng-1800CHU305USA.indbEng-18 2015/01/1319:53:212015/01/1319:53:21

- Eng 19 -
Español English
QWhy is the blood pressure measured at home different from that measured by the
physician or at a hospital?
A Your blood pressure may vary due to exercise, the ambient temperature or your mental
state. When you have a physician or nurse measure your blood pressure, the pressure
value is likely to be 10 to 20 mmHg higher than usual due to anxiety and/or stress.
Knowing what affects your blood pressure helps you to better monitor your health.
QWhy does the blood pressure obtained vary with measurement?
AOur blood pressure is adjusted by automatic nerve function. Blood pressure differs
with every heart beat. We are likely to think that our blood pressure is constant, but
it varies if you take measurements in repetition. Blood pressure is susceptible to the
time of day, such as morning and afternoon, season and atmospheric temperature.
In addition, blood pressure is easily affected by mental stress or emotional ups and
downs. It tends to increase when you feel tension or decrease when you are relaxed.
QWhat is the benefit of measuring my blood pressure at home?
A Blood pressure measurements taken at home give reliable data as they can be taken
when you are in a stable and relaxed condition. Physicians place considerable importance
on blood pressure measurements taken at home. You should measure your blood
pressure at the same time each day and record the variations in your blood pressure.
Always consult your physician for an interpretation of your blood pressure
readings and to determine the proper treatment.
BLOOD PRESSURE Q&A
00CHU305USA.indbEng-1900CHU305USA.indbEng-19 2015/01/1319:53:212015/01/1319:53:21

- Eng 20 -
English Español
Make sure to check the following before sending your blood pressure monitor away
to be tested or repaired.
Troubleshooting (1)
Problem Possible Cause Solution
LCD Display
shows abnormal
result
The cuff position was not correct or
it was not properly tightened
Apply the cuff correctly and
try again.
Body posture was not correct
during testing
Review the “BODY POSTURE
DURING MEASUREMENT”
sections of the instructions and
re-test.
Speaking, arm or body
movement, angry, excited or
nervous during testing
Re-test when calm and without
speaking or moving during
the test.
Irregular heartbeat
(arrhythmia)
It is inappropriate for people
with serious arrhythmia
to use this Electronic
Sphygmomanometer.
Troubleshooting (2)
Problem Possible Cause Solution
LCD shows low
battery symbol Low Battery Change the batteries.
LCD shows “Er 0” Pressure system is unstable
before measurement Don’t move and try again.
LCD shows “Er 1” Fail to detect systolic pressure
LCD shows “Er 2” Fail to detect diastolic pressure
LCD shows “Er 3” Pneumatic system blocked or
cuff is too tight during inflation Apply the cuff correctly and
try again.
LCD shows “Er 4” Pneumatic system leakage or
cuff is too loose during inflation
LCD shows “Er 5” Cuff pressure above
300 mmHg
Measure again after five
minutes. If the monitor is still
abnormal, please contact the
local distributor or the factory.
LCD shows “Er 6” More than 3 minutes with cuff
pressure above 15 mmHg
LCD shows “Er 7” EEPROM accessing error
LCD shows “Er 8”
Device parameter checking error
LCD shows “Er A” Pressure sensor parameter
error
No response when
you press button
or load battery.
Incorrect operation or strong
electromagnetic interference
Take out batteries for five
minutes, and then reinstall all
batteries.
* If you want to dispose this product, do not mix with general household waste. There is a
separate collection systems for used electronics products in accordance with legislation.
BEFORE REQUESTING REPAIRS OR TESTING
00CHU305USA.indbEng-2000CHU305USA.indbEng-20 2015/01/1319:53:222015/01/1319:53:22
