Technical Manual
CLP-521
Thermal Label & Barcode Printer
JM74903-00

CLP-521 5-5
CLP-521
Drawing No. 1
Parts List & Location for General Assembly
Revision Up List
Sheet No.
Rev. No. Date
1/1 0 Dec. 12, 2003

CLP-521 5-6
1
7
8
9
2
3
6
4
5
DRAWING NO. 1 General Assembly (Rev. 0)

CLP-521 5-7
PARTS LIST for CLP-521 TITLE: General Assembly Sheet No. 1/1
DrawingNo.1 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
1-1 SA, Top Cover JM56703-0 1
-2 Screw, PH, M3.0x6 E00130-06 1
-3 Cover, Motor JM56210-0 1
-4 Screw, PHT (PT), M3.0x8 E11230-08 1
-5 Cover, Connector JM56205-0 1
-6 Cover, Front JM56206-0 1
-7 Screw, PHT (PT), M3.0x14 E11230-14 4
-8 Case U JM56202-0 1
-9 Label, FCC ICES JK99902-0 1 For CA

CLP-521 5-8
Revision Up List
Sheet No. Rev. No. Date
1/2 0 Dec. 12, 2003
2/2 0 Dec. 12, 2003
CLP-521
Drawing No. 2
Parts List & Location for Base Unit

CLP-521 5-9
1
2
9
19
10
30
29
3
4
25
15
16
24
24
18 5 (1/2)
7
6
17
23
821
22
6
26
27
26
27
4
22
20
14
13
12
11
DRAWING NO. 2 Base Unit (Rev. 0)

CLP-521 5-10
PARTS LIST for CLP-521 TITLE: Base Unit Sheet No. 1/2
DrawingNo.2 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
2-1 Screw, PHT (PT), M3.0x14 E11230-14 4
-2 Unit, Mechanism JM49801-0 1
-3 SA, Centro Cable JM67725-0 1
-4 Screw, PHT (ST), M3.0x5 E11130-05 7
-5 Unit, Main PCB (With ROM)-I JM66820-0 1 For CA
-5 Unit, Main PCB (With ROM)-M JM66800-0 1 For CSE
-6 Screw, PHT (PT), M3.0x8 E11230-08 7
-7 Plate, Main PCB JM44103-0 1
-8 Unit, Centro PCB JM66825-0 1
-9 Cable, Ope-Pane JM67900-0 1
-10 Unit, Control Panel JM56801-0 1
-11 Leg, Case L F JM59902-0 2
-12 Case L JM56201-0 1
-13 Leg, Case L R JM59901-0 2
-14 Unit, Power Supply (100V) JM66810-0 1 For CA
-14 Unit, Power Supply (200V) JM66815-0 1 For CSE
-15 Sheet, Earth L JM44115-0 1
-16 Sheet, Earth R JM44114-0 1
-17 Sheet, Main PCB JM44116-0 1
-18 Plate, Earth JM54101-0 1

CLP-521 5-11
PARTS LIST for CLP-521 TITLE: Base Unit Sheet No. 2/2
DrawingNo.2 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
2-19 SA, Core JM59701-0 1
-20 SA, Power Cable JM67745-0 1
-21 Screw, BHT (ST) (N), M3.0x5 E14330-05W 2
-22 Washer, EXT. T (N), 3 E51130-00 3
-23 Lock Screw (Inch) C6390-049 2 HFS-4S-B1W
-23 Lock Screw (M2.6) C6390-050 2 HFS-2.6S-B1W
-24 Nut, M4 E40140-00 2
-25 Wire, Tie C6701-202 1 8432 L=100
-26 Screw, BH (N), M4.0x4 E02040-04 2
-27 Washer, EXT. T (N), 4 E51140-00 2
-28 Screw, BH (N), M3.0x6 E02030-06 1
-29 Cushion, Ope-pane Cable JM59903-0 1
-30 Cushion, Ope-pane Cover JM59904-0 1

CLP-521 5-12
CLP-521
Drawing No. 3
Parts List & Location for Mechanism Unit
Revision Up List
Sheet No. Rev. No. Date
1/1 0 Dec. 12, 2003

CLP-521 5-13
4
3
2
19
10
17
11
5
8
6
13
16 14
15
12
7
5
DRAWING NO. 3 Mechanism Unit (Rev. 0)

CLP-521 5-14
PARTS LIST for CLP-521 TITLE: Mechanism Unit Sheet No. 1/1
DrawingNo.3 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
3-1 Unit, Head-DT JM19801-0 1
-2 Shaft, Head Holder JM42007-0 1
-3 Screw, PH, M3.0x6 E00130-06 1
-4 Spring, Head Up JM13601-0 1
-5 SA, Platen JM22701-0 1
-6 E-Ring, 4 E60340-00 1
-7 Screw, PH (SW+PW), M4.0x16 E00940-16 1
-8 Unit, PF JM49810-0 1
-9 SA, Head Up Sensor Cable JM67715-0 1
-10 SA, Head Up Sensor PCB JM66715-0 1
-11 Screw, PH, M2.0x4 E00120-04 4
-12 Unit, Sensor U JM29701-0 1
-13 Plate, Front Guide JM24101-0 1
-14 Label 2, Caution Head AH90935-0 1
-15 Label 7, Caution Head AR99902-0 1 For CA
-15 Label 6, Caution Head AR99901-0 1 For CSE
-16 Screw, TH (N), M2.0x2 E00420-02W 2
-17 Sheet, Head Holder JM19204-0 1

CLP-521 5-15
Revision Up List
Sheet No. Rev. No. Date
1/1 0 Dec. 12, 2003
CLP-521
Drawing No. 4
Parts List & Location for Head-DT Unit

CLP-521 5-16
1
17
17
16
2
18
3
4
5
6
7
8
9
10
11 13
14
15
1
19
3
3
3
3
12
DRAWING NO. 4 Head-DT Unit (Rev. 0)

CLP-521 5-17
PARTS LIST for CLP-521 TITLE: Head-DT Unit Sheet No. 1/1
DrawingNo.4 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
4-1 Bushing, Head JM11201-0 2
-2 Bracket, Head JM14101-0 1
-3 Screw, PH, M3.0x6 E00130-06 7
-4 SA, Head Cable JM67710-0 1
-5 SA, Head JM14703-0 1
-6 Spring, Head L JM13603-0 1
-7 SA, Head Holder JM14715-0 1
-8 Screw, PHT (ST), M3.0x5 E11130-05 1
-9 Holder, Guide Sensor U JM14208-0 1
-10 Lever, Head Balance JM14203-0 1
-11 Spring, Head R JM13602-0 1
-12 SA, Head Adjust JM14720-0 1
-13 Cam, Head Balance JM19203-0 1
-14 Pivot, Head Balance Cam JM12201-0 1
-15 Guide, Head Cable JM14210-0 1
-16 Plate, Head Earth JM14105-0 1
-17 Screw, PH, M3.0x3 E00130-03 2
-18 Screw, PH, M3.0x8 E00130-08 1
-19 Guide, Head Connector JM19902-0 1

CLP-521 5-18
CLP-521
Drawing No. 5
Parts List & Location for PF Unit
Revision Up List
Sheet No. Rev. No. Date
1/2 0 Dec. 12, 2003
2/2 0 Dec. 12, 2003

CLP-521 5-19
4
26
22
2
24 1
9
10
11
5
6
12
26
26
25
25
25
3
7
10
13
14
15
16
17
18
19
20
21
3
23
12
8
27
DRAWING NO. 5 PF Unit (Rev. 0)

CLP-521 5-20
PARTS LIST for CLP-521 TITLE: PF Unit Sheet No. 1/2
DrawingNo.5 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
5-1 SA, Motor JM25701-0 1
-2 Screw, PH, M3.0x3 E00130-03 2
-3 Screw, PH, M3.0x5 E00130-05 2
-4 SA, Main Plate L JM44701-0 1
-5 Gear, PF2 JM20202-0 1
-6 Gear, PF Idle JM20203-0 1
-7 Gear, PF1 JM20201-0 1
-8 SA, Plate Peeler JM44707-0 1
-9 Frame, Main JM44101-0 1
-10 Wire Tie C6701-202 2 8432 L=100
-11 SA, Sensor Holder L JM24701-0 1
-12 Damper, Sensor L JM29902-0 2
-13 Screw, NO.0 PHT (BT#1), M2.0x3 E11920-03 1
-14 SA, Reflective Sensor PCB JM66730-0 1
-15 SA, Reflective Sensor Cable JM67720-0 1
-16 Guide, Paper Set JM44202-0 1
-17 Shaft, Sensor Guide JM42008-0 1
-18 Spring, Head Lock JM43601-0 1
-19 E-Ring, 2.5 E60325-00 1
-20 Lever, Head Lock JM44203-0 1

CLP-521 5-21
PARTS LIST for CLP-521 TITLE: PF Unit Sheet No. 2/2
DrawingNo.5 Rev.No.0
Location Part Name Part No. Q'ty/
Unit Remarks @
5-21 SA, Main Plate R JM44702-0 1
-22 Screw, NO.0 PH, M2.6x6 E01626-06 1
-23 Holder, Guide Sensor L JM44207-0 1
-24 Label 5, Caution Head AK99925-0 1
-25 Washer, EXT. T (N), 3 E51130-00 5
-26 Screw, BH (N), M3.0x6 E02030-06 5
-27 Sheet, Paper Set JM44117-0 1

CLP-521 5-22
CLP-521
Drawing No. 6
Parts List & Location for Sensor U Unit
Revision Up List
Sheet No. Rev. No. Date
1/1 0 Dec. 12, 2003

CLP-521 5-23
4
16
3
2
1
9
10 11
5
8
6
12
7
13
14
15
DRAWING NO. 6 Sensor U Unit (Rev. 0)
