Citizen CMP-20 User manual

CMP-20 Technical Manual
Device name: CMP-20
Revision: 1.00
Created: March 14, 2014
Citizen Systems Japan, Co., Ltd.
6-1-12 Tanashi-cho, Nishi-Tokyo-Shi, Tokyo, TEL [phone]

2
Revision updates summary
Revision Date Content Notes
Rev. 1.00 3/14/2014 Published

3
Contents
Revision updates summary
............................................................................................................................... 2
Introduction
........................................................................................................................................................ 4
1. Product overview
........................................................................................................................................... 5
1.1 Overview ...................................................................................................................................................................5
1.2 Features ....................................................................................................................................................................5
1.3 Included and optional equipment ............................................................................................................................5
1.4 Equipment classification............................................................................................................................................7
2. Basic specifications
....................................................................................................................................... 8
2.1 Printing specifications................................................................................................................................................8
2.2 Character, bar-code specifications............................................................................................................................8
2.3 Paper.........................................................................................................................................................................8
2.4 Power supply specifications......................................................................................................................................9
2.5 Battery specifications ..............................................................................................................................................10
2.6 Sensors ...................................................................................................................................................................10
2.7 Equipped memory capacity.....................................................................................................................................10
2.8 Magnetic stripe reader equipped (on equipped models).........................................................................................10
2.9 Durability specifications...........................................................................................................................................11
2.10 Safety (conformity standards) ............................................................................................................................... 11
2.11 Environmental........................................................................................................................................................11
2.11.1 Printer operation and print guarantee conditions............................................................................................11
2.11.2 Storage conditions..............................................................................................................................................11
3. Exterior specifications
..................................................................................................................................12
3.1 Top side...................................................................................................................................................................12
3.2 Rear side.................................................................................................................................................................13
3.3 Operation panel.......................................................................................................................................................14
3.4 Exterior dimensions and weight..............................................................................................................................14
4. Interface specifications
................................................................................................................................15
4.1 Input buffer ..............................................................................................................................................................15
4.2 Serial interface ........................................................................................................................................................15
4.3 USB interface..........................................................................................................................................................16
4.4 Bluetooth interface (Bluetooth compatible models) ................................................................................................16
4.5 Wireless LAN interface (wireless LAN compatible model)......................................................................................17
4.6 Interface switching...................................................................................................................................................17
5. Functions
.......................................................................................................................................................18
5.1 Energy saving mode................................................................................................................................................18
5.2 Battery level detection.............................................................................................................................................18
5.3 Paper detection .......................................................................................................................................................18
5.4 Cover open detection..............................................................................................................................................18
5.5 Head temperature detection....................................................................................................................................18
5.6 Non-volatile memory for saving logos.....................................................................................................................18
5.7 Internal buzzer.........................................................................................................................................................18
5.8 Self test and HEX-DUMP mode..............................................................................................................................19
5.9 HEX-DUMP mode...................................................................................................................................................19
6. Emulation/command
.....................................................................................................................................20
7. Battery charge level warning
........................................................................................................................22

4
Introduction
・This manual contains copyrighted content, so please be cautious with its use.
Please do not copy this manual without permission.
・When using the CMP-20 please follow the usage conditions and precautions printed in this manual.
Citizen Systems Japan, Co., Ltd. is in no way liable for any damage caused by usage of the CMP-20 that
deviates from the conditions and precautions printed in this manual.
・The CMP-20 is primarily a device built for the purpose of printing for small PCs and information PDAdevices.
①When using the CMP-20 for functions in which reliability is especially important, be sure to contact the
Citizen Systems Japan Co., Ltd. sales counter in advance and take measures for device failsafe
design and appropriate redundant design processing that are the customer’s responsibility to maintain
the system and CMP-20 device’s reliability and safety.
②Please do not use for equipment demanding extremely high dependability for performance and
accuracy.
Trademark
The printed company names and product names are trademarks and registered trademarks of the respective
companies.
CITIZEN is a registered trade mark of Citizen Holdings Co., Japan
Copyright © 2006 by CITIZEN SYSTEMS JAPAN CO., LTD.

1. Product overview
1.1 Overview
The CMP-20 is a small-sized, feature-rich portable line thermal printer. It can be used for very diverse
applications from door-to-door sales to small and medium-sized restaurants, car rental, parking lots, field
service and in-car sales on land, sea and air transportation.
1.2 Features
・Small and sturdy
・High-speed, low-noise line thermal printing mechanism
・High reliability due to the simple construction and long-lasting print head
・Easy paper changing due to the paper drop-in construction
・Rechargeable lithium ion battery
・Battery charge level display with 3 LEDs
・Standard built-in USB and serial ports
・Built-in Bluetooth functionality (CMP-20BT)
・Automatic compatibility with both iOS Bluetooth and other OS Bluetooth (CMP-20BT) *1
・Built-in wireless LAN functionality (CMP-20WF)
・Magnetic stripe reader equipped (on equipped models)
*1 Limited to products manufactured afterAugust 2013
5

CMP-30 product specification document
6
1.3 Included and optional equipment
Included equipment
・Printer ・Battery ・Battery charger
・Dedicated serial cable ・CD-ROM ・Quick start guide
・Sample paper ・Belt clip
Optional equipment
・Charging cradle ・Car charger ・USB cable
・Leather case ・Strap

CMP-30 product specification document
7
1.4 Equipment classification
Categorized by the following naming system. (Note: There are also combinations not prepared.)

CMP-30 product specification document
8
2. Basic specifications
2.1 Printing specifications
1) Printing method: Line thermal print method (thermal)
2) Print head: Line thermal print head
3) Dot structure: 384 dots/line
4) Dot resolution: 8 dots/mm (203 dpi)
5) Print width: 48 mm
6) Print speed: Maximum 640 dot lines/second (80 mm/sec.)
7) Paper feeder: Feed pitch 0.125 mm
8) Line height: 4.25 mm (1/6 inch) user setting enabled
・The print speed may be slower depending on the combined print condition settings and commands.
2.2 Character, bar-code specifications
A) ESC/POS emulation
1) Character structure: Font A 12H x 24V dots (1.5 x 3.0 mm)
Font B 9H x 17V dots (1.17 x 2.13 mm)
Kanji 24H x 24V dots (3.0 x 3.0 mm)
2) Print character count: Maximum 32 characters (font A)
Maximum 42 characters (font B)
Maximum 16 characters (kanji)
3) Space between characters: Adjustable via commands
4) Character type: ASCII
International characters 14 types
U.S.A./France/Germany/UK/Denmark I/Sweden/Italy/Spain I/Japan
Norway/Denmark II/Spain II/Latin America/Korean
Code pages 21 types
PC437/Katakana/PC850/860/863/865/866/852/858/737/857/864/862
WPC1252/1253/1250/1254/1251/ISO8859_9/8859_2/MOZOVIA/
Kanji JIS level 1 and level 2 standard (JIS X 0208:1990 and NEC special
characters)
5) Barcode: 1-dimensional code 9 types
UPC-A/UPC-E/JAN13/JAN8/CODE93/ITF/CODABAR/CODE39/CODE
128
2-dimensional code 2 types (QR code, PDF417)
2.3 Paper
1) Paper width : 58 ± 0.5mm
2) Outer diameter : φ48 mm maximum
3) Paper thickness : 65 μm-85 μm
4) Shaft core : Outer diameter φ18.5 mm minimum
5) Recommended paper : P220VBB1 (Mitsubishi Paper Mills Ltd.)
6) Print area
80 ± 0.5 mm (paper width)
Paper feed pitch
72 mm (print width)
4mm
4mm

CMP-30 product specification document
9
2.4 Power supply specifications
1) Power consumption
While printing: Approx. 1.5 A (ASCII printing)
Peak: Approx. 4.0 A (100% printing ratio for under 10 seconds)
Standby: Bluetooth approx. 110 mA (power ON, not printing, not feeding paper)
Wireless LAN approx. 160 mA (power ON, not printing, not feeding paper)
Reference values
Continuous printing length from full charge: 236 m (approx. 76 mm/sec. printing speed)
Continuous printing time from full charge: 52 minutes (approx. 76 mm/sec. printing speed)
Period charge is held from full charge: With power OFF recharge required after approximately 14
days
2) Charger
1)
Input voltage:
AC 100V-240V, 50/60 Hz
2)
Input current:
0.2 A maximum
3)
Rated input power:
11 W
4)
Output rating:
DC 8.4 V
5)
Output current:
0.8 A
6)
Rated output power:
6.72 W
7)
Efficiency:
74.2% or higher
8)
Short circuit protection:
Short circuit cancellation returns the unit to its normal state
without breakage
or damage to parts during an output short
circuit.
9)
Safety standards:
UL, C-UL, KC, C-Tick, CE, SAA, PSE
10)
Size:
74 mm (L) x 46.6 mm (W) x 40 mm (H) not including the plug
11)
Cable:
1.5 m length/UL2464 20AWG
12)
Plug:
φ3.5 outer circumference x φ1.35 inner circumference x 8.0 mm
length
13)
Terminal polarity:
Center positive (+), outer negative (-)
14)
Mass:
Approx. 100 g
15)
Operating temperature, humidity:
-10°C-35°C, 10%-90% humidity
16)
Storage temperature, humidity:
-20°C-80°C, 10%-90% humidity
The battery pack can be recharged by plugging the charger into the printer or the charging cradle.
Charging time: Approx. 150 minutes
The charge LED meanings are as follows:
Charge LED
State
Red continuously lit
Charging
Green continuously lit
Charge complete
Red flashing
Charging error detected
If an error occurs during charging, charging will stop and the charge LED will flash red.
Re-connecting the charger commences charging and the LED will remain continuously lit red.
If you charge the printer itself you cannot tell the charge condition from the printer.

CMP-30 product specification document
10
2.5 Battery specifications
1)
Battery type:
Lithium-ion rechargeable battery pack (2S1P)
2)
Individual batteries:
BK103450AR (B&K)
3)
Battery pack model name:
LK-PB20
4)
Battery capacity:
1800 mAh
5)
Nominal voltage:
7.4 V
6)
Discharge cut-off voltage:
6.0 V
7)
Charged voltage:
8.4 V
8)
Internal resistance:
350 mΩ or less
9)
Cycle life capacity:
70% or greater (after 300 standard charges and discharges)
10)
Dimensions:
59.6 (L) x 79.2 (W) x 14 (H) mm not including the projection
11)
Weight:
200 g or less
12)
Operating temperature:
0°C-45°C (standard charge), -20°C-60°C (standard discharge)
0°C-40°C (maximum discharge)
13)
Storage temperature:
-20°C-20°C (up to 1 year), -20°C-40°C(up to 3 months)
-20°C-60°C(up to 1 month)
14)
Storage humidity:
65% RH (without condensation)
2.6 Sensors
No-paper sensor, head temperature detection, battery charge level detection
2.7 Equipped memory capacity
1) Flash memory: 16 MB
2) SRAM: 4 MB
2.8 Magnetic stripe reader equipped (on equipped models)
Compatible cards: ISO/IEC 7811/7812 (JIS I format)
Card thickness: 0.76 mm ± 0.08 mm
Supported tracks: Tracks 1 & 2
Track reading width: 1.5 mm
Card slide speed: 10 cm - 15 cm/sec
Magnetic head life: 300,000 or more passes
Power consumption: Standard 3 mA (Dual), operating 500-900 uA(Dual)
Track
ISO-1
ISO-2
Bit density
210BPI
75BPI
Storage
capacity
79 characters
(7-bit)
40 characters
(5-bit)

CMP-30 product specification document
11
2.9 Durability specifications
Print head: 50 million passes or 50 Km (at average temperature, 12.5％printing ratio, rated value
energy)
MCBF: 50 million lines (12.5％printing ratio, 65-75 um paper thickness)
Protection rating: IP42 (individual unit except for MSR model)
Individual unit drop: 1.2 m (individual unit)
2.10 Safety (conformity standards)
Acquired standard: PSE (charger)
Note: Because the battery energy density is less than 400 Wh/L it is not PSE-compliant
VccI Class B
Telec (Bluetooth model and LAN model)
2.11 Environmental
2.11.1 Printer operation and print guarantee conditions
1) Operation temperature: 5°C-40°C
2) Operation humidity: 35％-95％(without dew)
2.11.2 Storage conditions
1) Storage temperature: -10°C-50°C (not including paper)
2) Storage humidity: 10％-90％(without dew, not including paper)
0
40
Temperature °C
35
95
Humidity %
5
-10
50
Tempe
90
Humi
0
Temperature °C
90
Humidity %
0
10

CMP-30 product specification document
12
3. Exterior specifications
3.1 Top side
(1) Paper cover
Open and close when loading paper.
(2) Manual cutter
To separate the printed paper, angle the paper to have full contact with the manual cutter and
slowly pull on the end of the paper.
(3) Power button
Press the power button for approximately 3 seconds to turn on the printer.
Press the power button until it beeps to turn off the printer.
(4) Cover open button (blue)
Press this button to open the paper cover.
(5) Feed button
The paper feeds while this button is pressed.
(6) Operation panel
Refer to operation panel mentioned later.
(7) DC jack
Connect the charger to charge the batteries.
(8) MSR slot (optional)
Slide the magnetic stripe.
(9) IC card slot (optional)
This option is currently not available.

CMP-30 product specification document
13
3.2 Rear side
(10) Battery
Removable battery pack
(11) Belt clip screw holes
Holes for attaching the belt clip in order to hang the printer from a belt
(12) USB port (mini B connector)
Connector for connecting to a host PC with a USB cable
(13) Serial port
Connector for connecting to a host with a serial cable

CMP-30 product specification document
14
3.3 Operation panel
Name
Function
Power
button
Power LED
(green)
This button turns the printer power ON/OFF.
When the printer is OFF, press this button for approximately 3 seconds to
turn it ON.
When the printer is ON, press this button for approximately 3 seconds to turn
it OFF.
A beep occurs when turning ON/OFF. When the power is ON the power LED
is illuminated.
Feed button
The paper feeds while this button is pressed.
This button is also used to perform the self test.
Battery
status LEDs
(Blue x 3)
1. The number of illuminated LEDs changes corresponding to the battery
charge level.
If 3 LEDs are illuminated the battery is in full charge state.
2. If no LEDs are illuminated and a beep is heard, immediate charging is
required.
3. If the battery charge level is extremely low power will cut off automatically.
4. The lights do not illuminate in power save mode.
Error LED
(red)
A red LED means that the paper is out or the cover is open.
3.4 Exterior dimensions and weight
Exterior dimensions: 93.07 (W) x 138.75 (D) x 62.2 (H) mm
Weight: Approx. 0.45 kg (including the battery, without the belt clip, without paper)

CMP-30 product specification document
15
4. Interface specifications
4.1 Input buffer
Buffer size: 4K bytes
4.2 Serial interface
(Bold letters signify the default setting)
Interface: 2-way serial communication
Signal level: RS-232C
Baud rate: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps (switch via command)
Data length: 7 or 8 bit
Start bit: 1bit
Stop bit: Greater than 1bit
Parity: None, even number, odd number
Flow control: DTR/DSR, Xon/Xoff
Connector: Printer side mini-DIN 8-pin female connector
PC side (dedicated cable) D-SUB 9-pin
Connector pin arrangement
No.
Signal
name
Signal
direction
Explanation
Dedicated cable connector (PC
side)
1 RXD Input Receives data Number 3 pin (RXD)
2 TXD Output Sends data Number 2 pin (TXD)
3 DTR Output Printer busy signal Number 6 & 8 pins (DSR, CTS)
5 GND －Ground Number 5 pin (GND)
[Terminal name explanations]
・TXD (Transmit Data)
Line for sending serial data from the printer to the host
When there is data flow control via x-ON/x-OFF: If the buffer reaches 8000 bytes
remaining while receiving data then DC3 (13H: Data receive disable signal) is output.
If the buffer reaches 8192 bytes remaining while receiving data then DC1 (11H: Data
receive enable signal) is output.
・RXD (Receive Data)
Line for sending serial data from the host to the printer. Framing error, overrun
When an error occurs the characters are distorted.
・DTR (Data Terminal Ready)
This is enabled when DTR/DSR flow control is selected.
When this signal is ready, data and commands can be written to the input buffer.
When this signal is busy, writing data causes an overrun error and the data is ignored.
The input buffer can be written to while printing. Busy may occur during self printing
when the power is turned on.
・GND (Signal Ground)
Signal line GND

CMP-30 product specification document
16
4.3 USB interface
Format: USB 2.0 Full Speed
Connector: USB mini B connector
Pin
number Signal Details
1 +5V +5V
2 DATA- Receives data
3 DATA+ Receives data
4 GND Ground
Vendor ID: 0x0525
Product ID: 0xA702
Serial Number: 0x00
4.4 Bluetooth interface (Bluetooth compatible models)
Interface: Bluetooth standard 2.0 conformant
Frequency: 2402-2480 MHz
Channel spacing: 1 MHz
Number of channels: 79
Output class: Class 2
Modulation method: FH method (frequency hopping spectrum method)
Transmission distance: Approx. 10 m
Max. transmission speed: 115200 bps (Bluetooth and printer unit transmission speed)
Transmission ability: +4 dBm or less (Class 2)
Password: None
Support profiles: SPP and iAP (*1)
Passkey: Default value 0000 (multi-pairing compatible)
Local name: Default value “Mobile Printer”
With serial or USB connection, the passkey and discover blue mode can be changed via Utilities.
*1: The iAP profile requires firmware version 2.01A or later as well as hardware manufactured after
August 2013. The local name can also be changed under these same conditions.
SPP and iAP are automatically selected based on the connection.
Compared with SPP, the iAP signal speed is significantly slower.

CMP-30 product specification document
17
4.5 Wireless LAN interface (wireless LAN compatible model)
Standard: IEEE802.11b / 802.11g
Transmission speed: Max. 54 Mbps, average 50 kbps
Transmission distance: 100 m (inside with no obstructions) depending on environmental factors
Protocols: ARP, RARP, IP, ICMP, TCP, UDP
Printing method: 9100 port, LPR/LPD
With a serial or USB connection wireless LAN settings can be made via Utilities (Ver. 1.61).
(Settings can also be made using wireless LAN, but there are limitations.)
The following settings can be made.
SSID, Netmask, Gateway, DNS
IP address: Fixed, DHCP
Mode: Infastructure, Adhoc
Channel: 1-14
WEP protection: Open System, Shared Key (WEP Key ID:1-4)
Security: WEP 64/128, WPA-PSK-TKIP, WPA2-PSK-AES (WPA keys are 8-64 characters)
Security protocol
Encryption protocol
Encryption algorithm
1
WEP 64/128 bits
-
RC4
2
WPA-PSK
TKIP (802.11i)
RC4
3
WPA2-PSK
CCMP (802.11i)
AES
When DHCP is enabled and the power is ON, an IP address is obtained from the DHCP server when the
cover is closed and the received information is printed. If there is an error obtaining the IP address a beep is
heard.
4.6 Interface switching
・The first interface to transmit becomes enabled.
・When transmission by that interface finishes, transmission from other interfaces becomes possible.

CMP-30 product specification document
18
5. Functions
5.1 Energy saving mode
Standard: As long as the power is not shut off with the power button, the power remains ON.
Power OFF mode: If there is no operation for a set time period, power automatically turns OFF. To
resume using, turn back ON as usual.
Power save mode: If there is no operation for a set time period, power save mode is automatically
entered into and the battery LED turns off. If the power ON button is pressed or 2
bytes of data are received (except via USB connection) the device returns to
print-ready status.
Even if there is no paper and the cover is open the device enters power OFF and power save modes.
Mode and time (1-99 min) settings can be made via Utilities.
Reference values: Standby enabled times in power save mode from full charge
Standby: 16 hours 20 minuites (Bluetooth)
10 hours (Wireless LAN)
5.2 Battery level detection
・The printer’s 3 LEDs display 4 steps of battery level.
・3 LEDs: Approx. 7.8 V or higher
・2 LEDs: Approx. 7.5 V or higher
・1 LED: Approx. 7.2 V or higher
・1 LED flashing (and beeping) low battery state:
Approx. 6.1 V or higher
・Power OFF: Less than approx. 6.1 V
5.3 Paper detection
・If there is no paper, the Error LED turns red and beeps intermittently.
・If paper running out is detected while printing, printing will stop. (Certain conditions excluded)
・If paper is replaced and the cover is closed, the Error LED turns off and stops beeping.
5.4 Cover open detection
・If the cover is opened, the Error LED turns red and beeps intermittently.
・If the cover is opened during printing, printing will stop.
・If the cover is closed, the Error LED turns off and stops beeping.
5.5 Head temperature detection
・If the head temperature reaches 65°C the head hot alarm stops printing and turns off the Power LED.
・If the head temperature falls below 60°C printing will automatically resume and the head hot alarm will be
released.
5.6 Non-volatile memory for saving logos
32 KB capacity (can be saved and erased via the dedicated utility)
5.7 Internal buzzer
The internal buzzer beeps in the following cases. Each type of beeping differs.
When power is turned ON
When power is turned OFF (including auto power OFF)
When the cover is open, there is no paper or an error is detected
When low battery is detected
When DHCP is enabled with wireless LAN and there is an error obtaining an IP address

CMP-30 product specification document
19
5.8 Self test and HEX-DUMP mode
1) Press the power button for approximately 3 seconds to turn off the printer.
2) While pressing the feed button, press the power button and hold both until the beep sounds.
3) Printing will commence.
Print sample
ＳＥＬＦ－ＴＥＳＴ
**********************************
Printer is as follows
Firmware Version Ver.1.16c
**********************************
Flash Memory : 2MByte
Board Version : Newer
PRINT DENSITY : [ 0 ]
**********************************
Serial Interface
Baud rate : 115200
Data bits : 8 bits
Parity : none
Stop bits : 1 bit
Handshaking : DTR/DSR
Receive error: ignore
**********************************
Bluetooth mode : spp + iap
LOCAL Name : Mobile Printer
BD_ADDR :00:13:7B:52:D6:F4
**********************************
MSR : Option
Read Mode : Auto TRACK1/2
**********************************
Emulation : ESC/POS
PrintDensity : Normal
Characters : 32 Char/Line
**********************************
Please press FEED button...
Important note:
If the FEED button is pressed within 30 seconds, it will print additional ASCII printing patterns.
Self-test completes automatically after printing ASCII printing patterns.
Self-test completes automatically if the FEED button is not pressed within 30 seconds.
5.9 HEX-DUMP mode
Within 30 seconds after the printing completes, briefly press the FEED button once more to switch to
HEX-DUMP print mode.
If the FEED button is not pressed within 3 seconds, it will switch to standard mode.
In HEX-DUMP print mode, data received will be printed in HEX format.
To exit HEX-DUMP print mode, turn off the power.

CMP-30 product specification document
20
6. Emulation/command
1) Emulation ESC/POS command standard (partially proprietary specifications)
2) ESC/POS command
Command
Function
CMP-20
HT(0x09)
Horizontal tabulation ○
LF(0x0A)
Print new line
○
CR(0x0D)
Print return ○
FF
Page mode printing and standard mode carriage return ○
CAN(0x18)
Print data cancel in page mode ○
DLE(0x10) EOT
Real time status transmission
○
DLE ENQ
Real time status request ○
ESC FF(0x0C)
Page mode data print ○
ESC SP(0x20)
Character right space setting ○
ESC 2
Initial new line quantity setting
○
ESC 3
Minimum feed pitch unit new line quantity setting ○
ESC -
Enable & cancel underline ○
ESC !
Print mode batch specification ○
ESC $
Select absolute position
○
ESC %
Select & cancel downloaded characters ○
ESC &
Define downloaded characters ○
ESC *
Select bit image mode ○
ESC ?
Delete downloaded characters
○
ESC @
Initialize printer ○
ESC {
Select & cancel vertical printing ○
ESC ¥
Select relative position ○
ESC a
Justification ○
ESC D
Set horizontal tab position ○
ESC d
Print &
n
line feed ○
ESC E
Select & cancel bold printing ○
ESC J
Print % feed minimum pitch unit
○
ESC L
Select page mode ○
ESC M
Select character font ○
ESC R
Select international characters ○
ESC S
Select standard mode
○
ESC T
Select character print direction in page mode ○
ESC t
Select character code table ○
ESC V
Select & cancel 90-degree character rotation ○
ESC W
Select print area in page mode ○
GS !
Select character size ○
GS $
Specify character absolute longitudinal position in page
mode
○
GS *
Download bit image definition ○
GS /
Download bit image print ○
GS :
Open & close macro definition ○
GS ^
Execute macro ○
GS ¥
Specify character relative longitudinal position in page
mode
○
GS a
Enable & disable automatic status transmission ○
GS B
Select & cancel inverted black & white printing in page
mode
○
