1. INTRODUCTION
The iDP3110 is a dot-impact printer suitable for use with various data communication terminals, and measurement
terminals.
This product is extremely compact and features extensive functions suited for a wide range of applications. Please
read this manual thoroughly to understand the printer before use.
1.1 Features
1. Compact desk-top dot matrix printer
2. Light weight
3. High speed printing
4. Low power consumption
1.2 Accessories
The following attachments are included in this set aside from the printer itself. Please confirm.
Paper roll (1 roll)
Ribbon cassette (1 unit)
AC adapter (1unit)
User’s manual (1 booklet)

iDP3110 User's Manual
CITIZEN 2
2. TYPE CLASSIFICATIONS
2.1 Type
The product is categorized according to the naming plan indicated below.
iDP3110 24
40
P
R
J
F
120
230
A
B
iDP3110 24 P J 120 A
Model Name Printer cover
Number of columns A : 60mm(Dia.)
24 : 24 columns/144 dots Paper roll
40 : 40 columns/180 dots B : 80mm(Dia.)
Paper roll
Power source
120 : AC 120V
230 : AC 220-240V
Interface
P : Parallel (Centronics)
R : Serial (RS-232C) Character
J : Japanese
F : International
2.2 AC adapter
Please use the exclusive adapter indicated below.
90AD-U (AC 120V)
90AD-E (AC 220-240V)

iDP3110 User's Manual
CITIZEN 3
2.3 Specifications
Item iDP3110-24* iDP3110-40*
1 Printing method Dot matrix
2 Printing direction One-way printing
3 Character configuration (5 + 1) × 8 (4 + 0.5) × 8
(W × H)
4 Number of columns per line 24 columns: 144 dot/line 40 columns: 180 dot/line
5 Printing speed Approx. 2.5 line/sec. Approx. 1.8 lines/sec.
6 Character size (W × H) 1.6 × 2.4 mm 1.08 × 2.4 mm
7 Line pitch 3.52 mm
8 Paper Paper Roll 57.5 ± 0.5(W) × 60 (Dia) mm
57.5 ± 0.5(W) × 80 (Dia) mm
9 Interface Type P: Parallel Interface (Centronics)
Type R: Serial Interface (RS-232C)
10 Ribbon cassette Exclusive ribbon cassette
Purple print : IR-91P
Black print : IR-91B (Option)
11 Voltage DC 7V ± 1V (Printing)
Use exclusive adapter (DC 7V, 1.2A)
12 Power consumption Printing : approx. 7VA
Stand-by : approx. 0.5VA
13 Weight Approx. 400g
14 Dimension 106(W) × 180(D) × 88(H) mm (60 Dia. Paper Roll)
106(W) × 180(D) × 106(H) mm (80 Dia. Paper Roll)
15 Operating temp. 0°C to 40°C
16 Storage temp -20°C to 60°C

iDP3110 User's Manual
CITIZEN 4
3. EXTERNAL APPEARANCE AND PART DESCRIPTION
3.1 External Appearance

iDP3110 User's Manual
CITIZEN 5
3.2 Part Descriptions
1. DC Jack Insert the output plug of the AC adapter attached.
2. Power Switch When switched ON, power is supplied to the printer, starting the initializing operation.
3. Power Lamp Lighted when power is turned ON and goes out when turned OFF.
4. SEL Lamp Lighted when printer is in the selected condition (ON-LINE).
Printer becomes operational only when this lamp is on.
5. LF Switch Paper is fed when switch is pressed (de-select condition only). Used to supply paper or to
insert some space in the output.
6. SEL Switch Printer is selected (ON-LINE) by pressing this switch.
Printer is de-selected (OFF-LINE) by pressing the switch again.
7. Interface Connector Printer is connected to various hosts via cables.
Please ensure that both the printer and the host are turned off before connecting.
8. Printer Cover Opened to exchange ribbon cassette and paper roll.

iDP3110 User's Manual
CITIZEN 6
4. OPERATIONS
4.1 Connection of the AC Adapter
(1) Ensure that the power switch is OFF.
(2) Insert the output plug of the AC adapter into the DC jack of the printer.
(3) Insert the power plug of the AC adapter into a power concent supplying the designated voltage.
(Use of exclusive AC adapter is recommended. Output is DC 7V, 1.2A. Avoid using power sources not conforming to
this specification.)

iDP3110 User's Manual
CITIZEN 7
4.2 Setting of the Printer Cover
(1) Hold the protruding section at the rear of the printer cover and lift in the direction indicated.
(2) Attach the cover by pressing downward after hooking the cover to the acceptor located in the front part.

iDP3110 User's Manual
CITIZEN 8
4.3 Setting of Ribbon Cassettes
(1) Remove the printer cover after turning OFF the printer.
(2) Press down on the Ribbon cassette while inserting the ribbon between the printing head and the platen.
(3) Wind up the ribbon slack by turning the knob in the direction of the arrow.

iDP3110 User's Manual
CITIZEN 9
4.4 Setting Paper
(1) Remove the printer cover.
(2) Ensure that the end of the paper is straight or incline as indicated in the diagram.
(3) Insert the end of the paper into the slot of the printer mechanism.
(4) After turning ON the printer, press the LF switch until 5 to 6 cm of paper is fed out of the printer mechanism.
(5) Insert paper after moving aside the paper holder in the direction of the arrow. Then, secure the center of the roll
with the holder.
(6) Then, attach the printer cover so the end of the paper comes out of the opening in the cover.

iDP3110 User's Manual
CITIZEN 10
4.5 Self Test Printing
A self-printing function is incorporated in this product to enable the printer to check itself.
This function is triggered by the following procedure.
(1) Set paper to the printer.
(2) Ensure that the ribbon cassette is attached correctly and turn the power OFF.
(3) Turn ON the power switch while holding the LF switch down. Release the LF switch after the self-printing
operation has started.
Printing is initiated by this operation. To end self-printing, turn OFF the printer.
4.6 General Notices
(1) Never operate your printer without loading paper and ribbon cassette. Any printing without paper and ribbon
cassette may cause damage to printer head.
(2) Replace ribbon cassette before it is worn with rents.
(3) Be careful not to drop any foreign matters, such as paper clips and pin and the like into your printer.
Those can cause mechanical trouble.
(4) Nothing shall be placed on the radiation vents to the printer.
(5) Place your printer always on a stable desk which is set horizontal.
(6) No organic solvent (thinner, benzin or the lie) shall be used in sweeping clean the surface of the main body case.
(7) Make sure that the power of the printer is turned off whenever you do the following.
1) Taking out any foreign matter which was dropped into the printer.
2) Replacing the ribbon cassette.

iDP3110 User's Manual
CITIZEN 11
5. PARALLEL INTERFACE
5.1 Specifications
a) Data input system : 8 bit parallel (DATA 1-8)
b) Control signal : ACK, BUSY, STB, RESET, SELECT
c) Compatible Connector : Printer side : 57LE-40360
(AMPHENOL or equivalent)
: Cable side : 57-30360
(AMPHENOL or equivalent)
5.2 Connector Pin Assignment
PIN SIGNAL NAME PIN SIGNAL NAME
1 STB 19 TWISTED PAIR GND
2DATA1 20 ″
3″2 21 ″
4″3 22 ″
5″4 23 ″
6″5 24 ″
7″6 25 ″
8″7 26 ″
9″8 27 ″
10 ACK 28 ″
11 BUSY 29 ″
12 GND 30 GND
13 SELECT 31 RESET
14 GND 32
15 33 GND
16 GND 34
17 FRAME GND 35
18 36

iDP3110 User's Manual
CITIZEN 12
5.3 Description of Input / Output Signals
(1) Input signal
All input signals utilize type 74HC of CMOS and can be used in TTL level as the input is pulled up with 3.3 kΩ
resistance.
- DATA 8 bit parallel signal (positive logic)
- STB Strobe signal for reading out data (negative logic)
- RESET Signal for resetting the entire unit (negative logic 4ms or more)
(2) Output signal
TTL is utilized for all output signals. The output is pulled up with 3.3 kΩresistance.
- ACK Signal for requesting data. ACK is issued at the end of the BUSY signal (negative logic)
- BUSY Signal indicating the printer is busy. Input new data when the signal is in “LOW”
condition.(positive logic)
- SELECT Signal indicating the printer is set to a selected condition (on-line). “HIGH” state signifies the
printer is selected.
(3) Others
- GND The common circuit ground.
- FG Equivalent to “case ground”.
•Input
[ Printer side ] [ Host side ]
DATA : 74HC373 equivalent
STB : 74HC14 equivalent
RESET : 74HC04 equivalent

iDP3110 User's Manual
CITIZEN 13
•Output
[ Printer side ] [ Host side ]
(4) Timing chart
1) Timing for data entry and printing
T1 0.5 µs MIN
T2, T3 1 µs MIN
T4 2 µs TYPE
(5) Data receiving
Printer is capable of accepting data from the host while the BUSY signal is in the “LOW” state. Printer cannot
accept data when the signal is “HIGH”.

iDP3110 User's Manual
CITIZEN 14
6. SERIAL INTERFACE
6.1 Specifications
1) Synchronization : Asynchronous
2) Baud rate : User selection, 4,800; 9,600 Baud / sec
3) Word configuration : Start bit 1 bit
: Data bit 8 bit
: Stop bit More than 1 bit
4) Signal polarity
RS-232C
* Mark = Logic “1” (-3 to –12V)
* Space = Logic “0” (+3 to +12V)
TTL(RESET)
* H level = Logic “1” (refer to (3), section 6.3)
* L level = Logic “0”
5) Input control (DTR signal)
* Mark : Data transmission not possible
* Space : Data transmission possible

iDP3110 User's Manual
CITIZEN 15
6.2 Connector Pin Assignment
SIGNAL SIGNAL SIGNAL DIRECTION FUNCTION RS232C TTL
PIN NAME HOST-PRINTER
1 FG Frame ground
7 GND Signal ground
3RD →Received data
20 DTR ←Printer BUSY signal
23 RESET →Printer reset signal
Note: 1. Signals for RS-232C are based on EIA RS-232C level.
Applicable connector (D-Sub connector)
Printer : 17LE-13250 (Anphenol equivalent)
Cable : 17JE-23250 (Anphenol equivalent)
6.3 Description of Input / Output Signal
(1) I / O signals
1) RD
Serial input data signal. Data is ignored when framing error, overrun error, or parity error has occurred.
2) DTR
Input command or data while this signal is in ready state. Data input while the signal is BUSY will cause an
overrun error to occur and the data will be ignored. Data can be provided to the input buffer even if the printer is
printing.
Busy state may also occur when power is applied, or during test printing, on-line, or when the printer is reset.
