CJ2 Innov Athena 2424 User manual

ATHENA
by
Installation manual
You just purchased this radiant heating unit ATHENA
by CJ2 Innov and we thank you for your choice.
This unit has been studied, designed and built with
care for your complete satisfaction
.

This product
MUST
be connected to a
timer or to a
thermostat

This product
MUST
be connected to a
timer or to a
thermostat

INSTALLATION MANUAL
GENERAL INSTRUCTIONS
Before installing and using the unit, please read carefully this notice.
1. ATHENA is a heating unit made with glass, it is therefore sensitive to shock.
2. The installation must meet the standards of public safety.
3. The electric installation on which the heating unit will be connected must be
protected with a circuit-breaker
.
4. This unit is compliant with current standards (see technical sheet if required).
5. Heating solution ATHENA may be used indoor, in every room, including
bathrooms
(comply with installation areas). Do not use outdoors .
6. You may use this heating unit as described in this manual. Other uses not
recommended by the manufacturer may cause fire, electric shock or hurt
someone.
3

INSTALLATION MANUAL
PRECAUTIONS FOR USE
1. The electric connection must be done by a qualified electrician. To unplug the
heating unit, turn off the controls and power of the circuit to the main panel.
ATHENA is a radiant heater. Do not install anything less than 25 cm (10 inches)
from its emitting area.
NOTICE : Do not cover to avoid overheating. Never obstruct the top of the heater
in any way
.
2. This unit is hot while used. To avoid burn, do not touch hot surfaces with bare skin.
Keep flammable material like furniture, pillows, linen, paper, clothes, curtains, etc. at
minimum 50 cm (20 in.) in front of the unit and keep them far from each side and the
back (side and back restrictions apply for permanent electric units).
3. Note that the emitting surface can go up to 80°C (176 F). Maintain the minimum
distance between ATHENA and surrounding objects.
4. It is mandatory to connect ATHENA to a control system (Thermostat,
timer, …)
5. The emitting surface must be towards the room and object to heat.
6. ATHENA is a certified unit for its efficiency and its security. Like all heating units,
prolonged contact can cause burns.
7. If the power cable is damaged, it has to be replaced by a qualified electrician. In
any case, use a type SJOOW 14/2 cable.
8. Do not try to take the unit apart, you will lose your warranty. Do not use the unit
after a failure. Disconnect from main panel and have it inspected by a qualified
electrician before using it again.
9. To clean ATHENA, turn it off and wait until it has cooled down. Clean with a soft damp
cloth.
10. ATHENA is not designed to be used by children unless instructions and security
rules have been given and understood. A greater caution is necessary when unit is
used by or close to children and when the heating unit is working unattended.
COMPOSITION
ATHENA is made of :
Ø 2 sides Tempered glass
Ø Heating film
Ø Towel hanging rails*
* (sold separately)
4

INSTALLATION MANUAL
INSTALLATION OF ATHENA HEATING UNIT
Tools
required
for the
installation.
Accessories included
with ATHENA.
You may not
have to use
them,
depending on
the type of
walls.
MARKING AND DRILLING
Installation and activation. To facilitate the installation of your ATHENA
heater, the wall bracket will be used as the installation template
.
REMINDER OF THE DISTANCES FOR DRILLING
HORIZONTAL ORIENTATION
Horizontal
spacing ( X )
Vertical
spacing ( Y )
Athena 2424 333 mm 406 mm
Athena 1648 933 mm 206 mm
Athena 2448 933 mm 406 mm
Athena 2472 1383 mm 406 mm
VERTICAL ORIENTATION
Horizontal
spacing ( X )
Vertical
spacing ( Y )
Athena 2424 406 mm 333 mm
Athena 1648 206 mm 933 mm
Athena 2448 406 mm 933 mm
Athena 2472 406 mm 1383 mm
5

INSTALLATION MANUAL
Choosing where to install the heating unit
Position the template (wall bracket) on the wall to choose the best place for your
ATHENA heater and rely on indicated mark. Make sure you comply with the
minimal distance around the heater of 25 cm (10 in) with an obstacle or wall
angle. Adjust the position with your level. Identify the drilling marks depending
on the size of the heater. Drill the wall.
TOWEL HANGING RAILS INSTALLATION (Sold separately)
1. Insert the bars at the top
of the ATHENA heater .
2. Align the bar with the
desired fixing holes.
3. Insert washer and hex
screw and tighten
securely.
INSTALLING FOAM PADS
1. Foam pads (4x) are included to obtain support when installing ATHENA.
They are in the bag with the screws.
2. Remove protecting paper to on the side rails of the ATHENA.
Foam
pads
6

INSTALLATION MANUAL
INSTALLING FOAM PADS (CONTINUED)
3. Install them on the rails so they are centered between the mounting
opening on the side rail and the fixing holes for the towel hanging rails
.
VERTICAL INSTALLATION AND LOCK
1. 2. 3. 4.
1. Install wall supports horizontally.
2. Align the side frame openings with the hooks on the wall
brackets.
3. Place the hooks inside the side rails and make sure they
are in the correct position by pushing firmly on the
heater
.
4. Insert the locking screws.
Foam
pads
Fixing holes for
towel hanging
rails
Mounting opening
for the ATHENA
7

INSTALLATION MANUAL
HORIZONTAL INSTALLATION AND LOCK
1. 2. 3. 4.
1. Install wall supports vertically.
2. Align the side frame openings with the hooks on the wall
brackets.
3. Place the hooks inside the side rails and make sure they
are in the correct position by pushing firmly on the
heater
.
4. Insert the locking screws.
ELECTRIC CONNECTION AND FUNCTION
Direct connection to the
line
Protect the line with
a breaker
Switch on
BEFORE SWITCHING ON - IMPORTANT
Once the installation is complete, turn the switch located under the electrical box of the
heater to
position I.
wall
Electrical
box
Power
cord
Front
Radiant
Surface
8

INSTALLATION MANUAL
SAFETY INFORMATION
• Use ATHENA unit only for recommended applications.
• For effective guarantees, ATHENA heater should always be mounted with
elements provided (bars, control, …
).
• The electrical connection must meet the electrical standards.
• The electrical installation on which will be connected ATHENA must
necessarily be protected by an RCD (25 or 30 mA).
• The heater ATHENA should always be connected to the mains (240V AV
50/60 Hz) by a circuit protected by a 15A circuit breaker overcurrent
placed in an electrical distribution. The entire system must be protected
by a circuit breaker.
• The electrical connection must be performed by a qualified electrician.
• ATHENA heating solution is suitable for indoor use, in every room, even the
bathroom (comply with installation area),
• Do not install ATHENA if the product is damaged or shows signs of impacts.
• ATHENA must be connected to a control system (Thermostat, timer, …)
• The top of the ATHENA should never be obstructed in any way.
SPECIFIC INSTRUCTIONS
1. ATHENA must be connected to a control system (Thermostat, timer, …).
2. Towels need to be hanged correctly and NEVER obstruct the top of the heater in
any way.
9

INSTALLATION MANUAL
TECHNICAL SPECIFICATIONS
ATHENA HEATER
Voltage 120 / 240 V
Maximum current 10A
Class II
IP Protection IP 44
Power 400W / 500W / 750W / 1100W
Indicative Power for a ceiling
height of 2,5 meters 54W / m3
ATHENA RANGE
See brochure for the complete list
of products
POWER
(Watt)
WIDTH
(mm)
HEIGHT
(mm)
Range 400 / 500 / 750 / 1100 400 / 600 600 / 1200
/ 1800
Standard Colors White / Black
Pantone Colors Upon request
REPAIR
In case of damage during the warranty period and after, contact your dealer or
manufacturer below :
MANUFACTURER :
CJ
2
INNOV INC.
[e-mail]
www.cj2innov.com
10

INSTALLATION MANUAL
WARRANTY
• 5 years for ATHENA heater.
• The warranty period starts from the date of purchase shown on the
invoice or receipt
.
• The warranty applies in addition to any statutory rights .
OUR COMMITMENT
THE FIRST 5 YEARS :
• If a defect covered by this warranty is found, CJ²INNOV will replace the
product with a new one for free.
• This warranty is limited to the repair or the replacement of the product. The
product repaired, with the written authorization of CJ2INNOV within the
warranty period, will be guaranteed for the remaining period of the warranty.
This warranty will not be valid and CJ2INNOV could refuse a claim if the
product has been modified in any way without written consent by CJ2INNOV
or if the numbers shown on the label have been removed or modified. This
warranty does not cover scratches, bumps, corrosion or discoloration caused
by excessive heat, chemical cleaning products or abrasive agent.
Furthermore, it does not cover damages or breakage during transportation.
• NB : Our commitment is limited to providing a new product. Installation costs and
other expenses in connection with such work are not covered.
11

WARRANTY
WARRANTY CONDITIONS
Any request under the guarantee is subject to the terms and
conditions set out below:
• The warranty is only valid in the context of interior use.
• The warranty covers defects arising during the manufacture of the equipment.
It does not cover damage caused by third parties (damages during
transportation or installation).
• No warranty is offered for damages arising from misuse, abuse, accidents or
natural disasters, or for damages resulting from other unusual circumstances
under residential applications.
• The guaranty does not apply if the products are not installed according to the
recommendations of CJ²INNOV.
• Damage resulting from maintenance or improper cleaning, overloading,
damage due to the influence of moisture are also excluded from
coverage under this warranty.
• The warranty is void if the products are installed despite visible
defects.
• CJ2INNOV reserves the right to inspect the damage on site after
agreeing a reasonable inspection date to verify the conformity of the
situation in the terms and conditions of warranty.
• This warranty supersedes all other warranties. The warranty coverage
is subject to the version of the warranty in effect at the time of the
purchase.
• Please note: our commitment is limited to providing a new
ATHENA. Installation costs and other direct or indirect, incidental
or consequential costs related to this work are not covered and CJ²
INNOV disclaims any liability related thereto.
• Damage resulting from improper maintenance and cleaning, overloading,
inadequate structure or damage due to the influence of mechanical stress is
also excluded from coverage under this warranty.
• No agent or representative or distributor has the authority to modify this
warranty.
• Please fill the information card « Warranty Certificate » and return it to us
without delay by email at [e-mail] or by phone at
819 960-
3357 to take advantage of your warranty.
12

WARRANTY
WARRANTY CERTIFICATE
To preserve your rights, please fill in and return the certificate to the
manufacturer at [e-mail]
DISTRIBUTOR
WARRANTY CERTIFICATE
Product :
Serial number :
Name :
Street :
City :
Province :
Postal Code :
Country :
Phone :
Email :
Date of purchase :
Installer :
Installation date :
Problems
encountered :
CAUTION
Risk of electric
shock. Do not open.
No user-serviceable
parts inside.

By:
