Dimplex LPC Series User manual
7211700100R02
Linear Proportional Convector Heater
LPC Series
WARNING:
WARNING: Wiring procedures and connections should be in accordance
CAUTION: Disconnect power supply before installation to prevent electric
CAUTION: Connect heaters to a branch circuit used only for permanently
installed heater and protected by over current devices rated or set at no more
CAUTION: The total connected load should not be more than 80% of the
Placement of the linear ProPortional convector
Linear Proportional Convectors may only be surface mounted on plaster, wood or
recommenDationS for locatinG DraPeS anD fUrnitUre
near heater (fiGUre 1)
furniture, the following recommendations should be observed:
Hang drapes so that, in use, they extend below the center line of the heater, but
the heater and the nearest fold of the drapes in the folded back (opened drape)
To be suitable for draperies located close to heater, material should not discolor
!NOTE: Ensure that when 2 Linear Proportional Convectors are installed near
!NOTE: If drapes are to be cut off above a heater, they should be cut off at
!NOTE:
factorY WirinG of the linear ProPortional convector
All Linear Proportional Convectors must be connected from the right side of the
inStallation With non metallic caBle tYPe nmD
Insert wire through hit-lock connector and connect to heater lead wires, as
Push cable back into wall as Linear Proportional Convector is being positioned
With Proportional Convector in position, run screws through pre-selected
Installation Instructions
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to
-
ble materials such as: furniture, pillows, bedding, papers, clothes and curtains
-
Check nameplate ratings to be sure the heater voltage is the same as the
!note: This equipment has been tested and found to comply with the limits
are designed to provide reasonable protection against harmful interference in
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Connect the equipment into an outlet on a circuit different from that to which
cause interference and (2) this device must accept any interference, including
SAVE THESE INSTRUCTIONS
min
min
min
min
min
min
min
Figure 1
Figure 2
Line / L1
Ground
Neutral / L2
Figure 3
Figure 4
Wires on LPC
Black - L1, Blue - Neutral, Yellow - L2
2
The Manufacturer warrants the Linear Proportional Convector and components of the
enclosed product against any defect in material or workmanship for a period of one year from
the date of purchase, with the exception of the elements which are warranted to be free from
The Manufacturer shall not be responsible for any transportation or shipping costs in relation
or repairs by persons other than the Manufacturer’s authorized personnel without the
This Warranty is in lieu of all other warranties or conditions whether expressed or implied
the sole remedy of the Purchaser and the sole liability of the Manufacturer in respect of the
sale of the product, whether in the nature of breach or breach of fundamental term, or of
The Manufacturer shall not be liable for any special, indirect or consequential damages or
for any damages resulting from removal or replacement of a Linear Proportional Convector
Warranty
In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice.
© 2011 Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
Maintenance
CAUTION: Before removing the front cover for cleaning, make certain the
CAUTION: Allow adequate time for the element and body casing to cool
however, essential that the Linear Proportional Convector is not operated with an
accumulation of dust or dirt on the element, as this can cause a build up of heat
WARNING:
+or -button can be pressed to
A. Setting/Temperature Display
Pressing the +or -will increase or decrease the desired temperature for the room
!NOTE: Pressing the +and -
B. Economy Setting
V
Vbutton and the icon will
disappear and the
C. Set Back Temperature Setting
Vfollowed by the +or -
D. Comfort Setting
!NOTE: Either the or icon will always be visible, dependent on the
E. Synchronized Icon
A wall mounted controller is available to control one or multiple Linear Proportional
On the Linear Proportional Convector press and hold the v button for 3
seconds, both the and
Press the -, +and then V,
!note: There is a 3 second delay between pressing the last button the wall
!note: To desynchronize a Linear Proportional Convector from the
Press and hold the V
Press the V, +and then -
F. Lock Icon
The Linear Proportional Convector Heater has a Button Lock feature, to prevent
Press and hold the V and Icons will begin
To Enable:2. +, then -, then +, then - icon
To Disable-, then +, then -, then + icon
!note:
Operation
Figure 5
B
EFGH
I
G - Decrease Button
H - Increase Button
I - Menu Button
A
C
D
inStallation With riGiD, e.m.t. conDUit or BX caBle
