Clarion DXZ558RMP User manual

Service Manual
Model
-1-
(PE-2721E-A )
SPECIFICATIONS
Radio section
Tuning system: PLL synthesizer tuner
Receiving frequencies: FM 87.5 to 108MHz
(0.05MHz steps)
MW 531 to 1602kHz
(9kHz steps)
LW 153 to 279kHz
(3kHz steps)
CD player section
System: Compact disc digital audio system
Frequency response: 5Hz to 20kHz(+1/-1dB)
Signal to noise ratio: 100dB(1kHz)
Dynamic range: 95dB(1kHz)
Distortion: 0.01%
General
Output power: 25Wx4 (DIN45324, +B=14.4V)
Power supply voltage: 14.4V DC(10.8 to 15.6V allowable),
negative ground
Power consumption: Less than 15A
Speaker impedance: 4ohm(4ohm to 8ohm allowable)
Auto antenna rated current: 500mA or less
Weight: 1.3kg
Dimensions(mm):
NOTE
*Speci ications and design are subject to change without notice
for further improvement.
COMPONENTS
PE-2721E-A
Main unit 1
Mounting bracket 300-7742-00 1
DCP case 335-6035-20 1
Escutcheon(OUT-ES) 370-6150-00 1
Parts bag
Removal key 331-2497-00 2
Rubber 345-3653-20 1
A-lead 850-6681-50 1
Screw(M5x10) 716-0726-01 1
Published by Service Dept.
298-6193-00 DEC.2004P
Printed in P.R.C.
178(W)x50(H)x157(D)mm
Remote control unit
44(W)x110(H)x11(D)mm
*We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure, please repair it by
component parts base. Parts which are not mentioned in
service manual are not supplied.
*
part
Remote control unit
40g(including battery)
Remote control unit RCB-172-300 1
Battery(CR2025) 1
1
MP3 / WMA mode
MP3 Sampling rate: 11.025kHz to 48kHz
MP3 Bit rate: 8k to 320kbps/VBR
WMA Bit rate: 48k to 192kbps
Logical Format: ISO9660 level1, 2
Romeo or Joliet
*, and the Windows logo are trade-
marks, or registerd trademarks of Microsoft Corporation
in the United States and/or other countries.
*This product includes technology owned by Microsoft
Corporation and cannot be used or distributed withouta
license from MSLGP.
CD/MP3/WMA Receiver / CeNET Control
Xiamen Clarion Electrical Enterprise Co., Ltd
8/F., Xiamen Mail Processing Centre, No.275 Rujiang Road, Xiamen, China
Tel:[phone] Fax:[phone]
Clarion Co., Ltd.
50 Kamitoda , Toda-shi, Saitama 335-8511 Japan
Main unit
Main unit
f
Use only compact discs bearing the or mark.
Some CDs recorded in CD-R/CD-RW mode may not be
usable.
1.
2.
3.
4.
5.
6.
DXZ558RMP
7-1
7.
7-2
7-3
7-4

Bottom view of main unit
To engineers in charge of repair or inspe-
ction of our products.
Before repair or inspection, make sure to follow the in-
structions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk or
injury.
1. Use specified parts.
The system uses parts with special safety features against fire
and voltage. Use only parts with equivalent characteristics when
replacing them.
The use of unspecified parts shall be regarded as remodeling for
which we shall not be liable. The onus of product liability (PL) sh-
all not be our responsibility in cases where an accident or failure
is as a result of unspecified parts being used.
2. Place the parts and wiring back in their original positions after re-
placement or re-wiring.
For proper circuit construction, use of insulation tubes, bonding,
gaps to PWB, etc, is involved. The wiring connection and routing
to the PWB are specially planned using clamps to keep away
from heated and high voltage parts. Ensure that they are placed
back in their original positions after repair or inspection.
If extended damage is caused due to negligence during repair,
the legal responsibility shall be with the repairing company.
3. Check for safety after repair.
Check that the screws, parts and wires are put back securely in
their original position after repair. Ensure for safety reasons there
is no possibility of secondary problems around the repaired spots.
If extended damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
4. Caution in removal and making wiring connection to the parts for
the automobile.
Disconnect the battery terminal after turning the ignition key off.
If wrong wiring connections are made with the battery connected,
a short circuit and/or fire may occur.
If extensive damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormality is obser-
ved in their appearance. Always replace them with new ones.
(The chip parts include resistors, capacitors, diodes, transistors,
etc). The negative pole of tantalum capacitors is highly suscepti-
ble to heat, so use special care when replacing them and check
the operation afterwards.
6. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the iron tip
temperature is around 270 C. Take care not to apply the iron tip
repeatedly(more than three times) to the same patterns. Also ta-
ke care not to apply the tip with force.
7. Turn the unit OFF during disassembly and parts replacement.
Recheck all work before you apply power to the unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through the
lens of the optical pickup. When checking that the laser optical
diode lights up, keep your eyes more than 30cms away from the
lens. Prolonged viewing of the laser within 30cms may damage
your eyesight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by electr-
ostatic charge caused by your clothes and body. Make sure to
avoid electrostatic charges on your clothes or body, or discharge
static electricity before handling the optical pickup.
9-1. Laser diode
The laser diode terminals are shorted for transportation in ord-
er to prevent electrostatic damage. After replacement, open
the shorted circuit.
When removing the pickup from the mechanism, short the ter-
minals by soldering them to prevent this damage.
9-2. Actuator
The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change.
Ensure that not foreign substances enter through the ventilati-
on slots in the cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol to
lens paper and wipe the lens gently.
CAUTION
This appliance contains a laser system and is classified as a
"CLASS 1 LASER PRODUCT". In case of any trouble with this
player, please contact your nearest"authorized service station".
To prevent direct exposure to the laser beam, do not try to open
the enclosure.
DXZ558RMP
-2-

ERROR DISPLAY
If an error occurs, one of the following displays is displayed. Take the measures described below to eliminate the
problem.
Error Display Cause Measu re
A DISC is loaded upside-down inside the CD deck and
does not play.
Eject the disc then reload it properly.
ERROR 2 A CD inside the CD changer is not loaded. This is a failure of CD changer’s mechanism.
ERROR 3 A CD inside the CD changer cannot be played due to
scratches, etc.
Replace with a non-scratched, non-warped disc.
ERROR 6 A CD inside the CD changer cannot be played beca-
use it is loaded upside-down.
Eject the disc then reload it properly.
If an error display other than the ones described above appears, press the reset button.
A DISC is caught inside the CD deck and is not ejected. This is a failure of CD deck's mechanism.
ERROR 2
ERROR 3 A DISC cannot be played due to scratches, etc. Replace with a non-scratched, non-warped-disc.
CD/MP3/
WMA
CD
changer
ERROR 3 A DISC cannot be played due to scratches, etc. Retry or replace with a non-scratched, non-warped
disc.
ERROR 6 A DISC inside the DVD changer cannot be played be-
cause it is loaded upside-down.
Eject the disc then reload it properly.
ERROR P Parental level error. Set the correct Parental level.
ERROR 2 A DISC inside the DVD changer cannot be played. This is a failure of DVD mechanism.
Region code error. Eject the disc and replace correct region code
disc.
DVD
changer
ERROR R
Mode
ERROR 6
FUSE
For other vehicles For VW and Audi vehicles
(initial position)
Main unit side ISO connector
Figure 1
2. When the car stereo is installed in 1998 and later Volkswagen
models, make sure to cut the car lead wire connected the A-5
terminal.(Abreakdowncouldoccuriftheleadwireisnotcut.)
After cutting the lead wire, insulate the front end of the lead wire
with insulation tape to prevent the risk of short-circuits.
(Figure 2)
Note: Before cutting the lead wire, disconnect the car battery
- (negative) cable.
Figure 2
3. When the Main unit is also connected to an external amplifier,
connect REMOTE on the external amplifier to remote turn on
lead.
NOTES OF ISO CONNECTOR
1. For VW and Audi vehicles, change the position of fuse
installation as shown on the diagram.(Figure 1)
ISO CONNECTOR type
1. Press the [ADJ] button to switch to the adjustment selection
display.
2. Press the lever upward or downward to select the
"SYS CHK <E>".
3. Press and hold the button for 1 second or longer.
"SYSTEM CHK" appears in the display, then the unit returns
to the previous operation mode.
ANTI-THEFT INDICATOR
[]
,
[]
The red Anti-theft indicator is a function for preventing theft.
When the DCP is removed from the unit, this indicator blinks.
1. Press the [ADJ] button to switch to thead justment selection
display.
2. Press the lever upward or downward to select the
"BLINK LED".
3. Turn the [ROTARY] knob to select "ON " or "OFF ".
[]
,
Performing a system check
DXZ558RMP
-3-

Reset button
TROUBLESHOOTING
Problem
Power does not turn on.
(No sound is produced.)
Cause
Fuse is blown.
Incorrect wiring.
Measure
Replace with a fuse of the same amperage.
Read the attached "Installation/Wire connection Guide" once again
and wire properly.
No sound output when
operating the unit with
amplifiers or power
antenna attached.
Power antenna lead is shorted
to ground or excessive current
is required for remote-on the
amplifiers or power antenna.
1. Turn the unit off.
2. Remove all wires attached to the power antenna lead. Check
each wire for a possible short to ground using an ohm meter.
3.Turn the unit back on.
4. Reconnect each amplifier remote wire to the power antenna lead
one by one. If the amplifiers turn off before all wires are attached,
use an external relay to provide remote-on voltage
(excessive current required).
The microprocessor has
malfunctioned due to noise,
etc.
DCP or main unit connectors
are dirty.
Wipe the dirt off with a soft cloth moistened with cleaning alcohol.
No sound heard. The speaker protection circuit is
operating.
Turn down sound volume. Function can also be restored by turning
the power off and on again.
(Speaker volume is reduced automatically when the speaker prote-
ction circuit operates).
Sound skips or is noisy. Disc is dirty.
Turn off the power, then press the
[OPEN] button and remove the DCP.
Press the reset button for about 2 seconds
with a thin rod.
Nothing happens when
buttons are pressed.
Display is not accurate.
Clean the disc with a soft cloth.
Disc is heavily scratched or
warped.
Replace with a disc with no scratches.
Sound is cut or skipped.
Noise is generated or noise
is mixed with sound.
MP3/WMA files are not
encoded properly.
Use MP3/WMA files encoded properly.
No sound heard. MP3/WMA files are absent in
a disc.
Write MP3/WMA files onto the disc properly.
Files are not recognized as an
MP3/WMA file.
Use MP3/WMA files encoded properly.
File system is not correct. Use ISO9660 level 1,2 or Joliet or Romeo file system.
Sound is bad directly after
power is turned on.
Water droplets may form on
the internal lens when the car
is parked in a humid place.
Let dry for about 1 hour with the power on.
Wrong filename File system is not correct. Use ISO9660 level 1, 2 or JOLIET or Romeo file system.
Play list play is not
performed.
File name or extension is not
correct.
Use alphanumeric/ASCII characters for MP3/WMA file name.
Use ".M3U" for the file extension of a play list.
General
CD/MP3/WMA
DXZ558RMP
-4-

EXPLA NATION OF IC:
052-3947-00 M30622MGP-178GP Main System controller
ADJUSTMENT
FM section
Item Procedure Measuring
instrument
S-meter 1.Input the 98.1MHz/30dBu/400Hz(main90%+pilot10%)signal. SG
2.Turn on the power and press the A-M button & PRESET No.6 button at the same
time for 1 second or longer.(TEST MODE)
3.Adjust the reading of LCD display to [24---- ](24+2/-2) by VR101.
4.Push the A-M button & PRESET No.6 button at the same time for 1 second or longer once
again or do power off to cancel the TEST MODE.
1.Terminal Description pin 54 : NU : IN : Not in use(GND).
pin 1 :EJECT_LED : O : Eject key illumination. pin 55 : NU : IN : Not in use(GND).
pin 2 :TIME_BASE : IN : Time base pulse input. pin 56 : NU : IN : Not in use(GND).
pin 3 : NU : IN : Not in use(GND). pin 57 : NU : IN : Not in use(GND).
pin 4 : NU : IN : Not in use(GND). pin 58 : NU : IN : Not in use(GND).
pin 5 : REMOCON : IN : Remote controller signal input terminal. pin 59 : T BASE-TEST : O : Time base confirmation pin for test mode.
pin 6 : BYTE : IN : The data length selection(8bit/16bit). pin 60 : VDD : - : Positive supply voltage.
pin 7 : CN VSS : IN : Connect to VSS. pin 61 : NU : IN : Not in use(GND).
pin 8 : JOG_CW : IN : Jog key signal input. pin 62 : GND : - : Ground
pin 9 : JOG_CCW : IN : Jog key signal input. pin 63 : NU : IN : Not in use(GND).
pin 10 : RESET : IN : Reset signal input. pin 64 : NU : IN : Not in use(GND).
pin 11 : X-OUT : O : Crystal connection. pin 65 : ST/SD : IN : At receiving the FM station, this port dete-
pin 12 : GND : - : Negative supply voltage(Ground). cts the stereo signal. At seeking or scanni-
pin 13 : X-IN : IN : Crystal connection. ng, this port detects the station detection
pin 14 : VCC : - : Positive supply voltage. signal.
pin 15 : NU : IN : Not in use. pin 66 : NOISE DCHG : O : RDS noise discharge signal output.
pin 16 : ACC_DET : IN : ACC detection signal input. pin 67 : MUTE SPD UP : O : Station detection speed up command
pin 17 : B/U_DET : IN : Backup detection signal input. output for RDS.
pin 18 : KEY_INT : IN : Key interrupting signal input. pin 68 : RDS TEST ST : O : For RDS test pin at CD play time.
pin 19 : 27pin connect : IN : Connect to 27pin. pin 69 : RDS_MUTE : O : RDS mute signal output.
pin 20 : VARI +B : O : The power supply control signal output pin 70 : RDS_DATA : IN : RDS serial data input.
for the illumination. pin 71 : NU : IN : Not in use(GND).
pin 21 : LCD +B REM : O : The power supply ON signal output for pin 72 : SOFT MUTE : O : Not in use.
the LCD driver. pin 73 : RDS CLK : IN : RDS CLK
pin 22 : NU : O : Not in use. pin 74 : E VOL CLK : O : Clock pulse output to the volume IC.
pin 23 : INT-AMP REM : O : ON signal output to the internal amplifier. pin 75 : E VOL DATA : O : The serial data output to the volume IC.
pin 24 : V COLOR G : O : PWM signal output to control the green. pin 76 : NU : IN : Not in use(GND).
pin 25 : CATS LED : O : CATS LED drive output. pin 77 : NU : IN : Not in use(GND).
pin 26 : V COLOR R : O : PWM signal output to control the red. pin 78 : AMP MUTE : O : The control signal output to internal audio
pin 27 : IE BUS RX : IN : IE Bus serial data input. power amplifier.
pin 28 : IE BUS TX : O : IE Bus serial data output. pin 79 : NU : O : Not in use.
pin 29 : EMULATOR TX : O : Emulator signal output. pin 80 :SYS MUTE : O : System muting signal output.
pin 30 :EMULATOR RX : IN : Emulator signal input. pin 81 : PHONE INT : IN : The telephone interrupt signal input.
pin 31 : FLASH MODE : IN : The flash memory mode setting input. pin 82 : ILLUMI DET : IN : Illumination ON signal input.
pin 32 : NU : O : Not in use. pin 83 : NU : IN : Not in use(GND).
pin 33 : LCD SO : O : The serial data input from the LCD driver. pin 84 : AMP REMOUT : O : ON signal output to the internal amplifier.
pin 34 : LCD SI : IN : The serial data output from the LCD driver. pin 85 : NU : O : Not in use.
pin 35 : LCD CLK : O : The clock pulse output to the LCD driver. pin 86 : 5V_REM : O : ON signal output to the 5V power supply.
pin 36 : LCD CE O : Chip select signal output to the LCD driver. pin 87 : NOISE : IN : The noise level for RDS.
pin 37 : NU : IN : Not in use. pin 88 : S_METER : IN : The input terminal of internal A/D converter
pin 38 : CTRL : O : Power supply ON signal output. to monitor the radio field strength.
pin 39 : FLASH MODE : IN : Flash mode entry signal input terminal. pin 89 : KEY_A/D : IN : The input terminal of the internal ADC for
pin 40 : MP3 SRQ : IN : MP3 request signal input. key judgment.
pin 41 : MP3 CS : O : MP3 chip selection signal output. pin 90 : NU : O : Not in use.
pin 42 : WUP : O : MP3 wakeup signal output. pin 91 :KEY ILLUMI :O: The key illumination ON signal output.
pin 43 : MP3 RESET : O : MP3 reset signal output. pin 92 :BACK LIGHT ON : O : LCD backlight control terminal.
pin 44 : FLASH MODE : IN : Flash mode entry signal input terminal. pin 93 :SYS_ACC :O: ACC detect signal output.
pin 45 : PLL SI : IN : Serial data input from the PLL IC. pin 94 :GND : - : Not in use.
pin 46 : PLL SO : O : Serial data output to the PLL IC. pin 95 :NU :IN : Not in use.
pin 47 : PLL SCK : O : The clock pulse output to the PLL IC. pin 96 :VREF :IN :The reference voltage input.
pin 48 : PLL CE : O : The chip enable signal output to the PLL IC. pin 97 :A VDD :-: Positive supply voltage for the internal an-
pin 49 : NU : IN : Not in use. alog section.
pin 50 : RDS TEST : IN : For RDS test pin at CD play time. pin 98 :MP3 SI :IN :MP3 serial data input.
pin 51 :INIT 2 :IN:The initial setting input. pin 99 :MP3 SO :O:MP3 serial data output.
pin 52 : INIT 1 : IN : The initial setting input. pin 100 :MP3 SCK :O:MP3 clock output.
pin 53 : NU : IN : Not in use(GND).
Main section
DXZ558RMP
-5-

051-6069-08 FAN8047G3 4 channel Motor Driver
Function Table
SW45 Mute1,2_ Mute 3_ Mute 4_ 1 ch 2 ch 3 ch 4 ch
in in in in out out out out
(pin 28) (pin 9) (pin 27) (pin 20) (pin13,14) (pin11,12) (pin17,18) (pin15,16)
H H H x ON ON ON ON A
H H L x ON ON OFF ON A
H L H x OFF OFF ON OFF
H L L x OFF OFF OFF OFF
L x x H OFF OFF OFF ON B
L x x L OFF OFF OFF OFF
051-6399-00 TC94A15F CD IC
1.Terminal Description
pin 1: IPF OUT : O : IP flag output.
pin 2: SB OK O : O : Sub code Q data CRCC OK signal output.
pin 3: CLOCKIO :I/O: The clock pulse input/output for the sub
code reading.
pin 4: VDD : - : Positive supply voltage.
pin 5: VSS : - : Negative supply voltage.
pin 6: DATA : O : DATA
pin 7: SF SY O : O : Playback frame synchronous signal output.
pin 8: SB SY O : O : Sub code block synchronous signal output.
pin 9: HSO : O : The play speed flag output.
pin 10: UHSO : O : The play speed flag output.
pin 11: AR SEL IN : IN : Fix to the high level.
pin 12: AWRC : O : The control signal output for the active
wide range VCO.
pin 13: P VDD : - : PLL positive supply voltage.
pin 14: PDO : O : Phase difference signal output of EFM-
PLCK.
pin 15: TMAX S : O : T max judgment output.
pin 16: TMAX : O : T max judgment output.
pin 17: LPF N : IN : Inverted input of LPF for PLL.
pin 18: LPF OUT : O : The output terminal for the Low Pass Fil-
ter.
pin 19: P Vref : - : PLL reference voltage.
pin 20: VCO FILTER : O : Loop filter for VCO.
pin 21: VCO Ref : IN : VCO reference voltage input.
pin 22: DTC N : O : For the analog slicer.
pin 23: DTC P : O : For the analog slicer.
pin 24: PLL VSS : - : PLL ground.
pin 25: SLCO : O : Output of internal DAC for data slice level
generation.
pin 26: RF IN : IN : RF signal input.
pin 27: RF RP : IN : RF ripple input.
pin 28: RF EQ OUT : O : The output of the RF equalizer.
pin 29: A VDD : - : Positive supply voltage for the Analog sec-
tion.
pin 30: RES IN : - : For reference current setting.
pin 31: Vref OUT : O : The reference voltage output.
pin 32: VMDIR : O : The reference voltage output.
1 2 3 4 5 6 7 8 9
10
11
12 13 14
Level
Shift
Level
Shift
28 27 26 25 24 23 22 21 20 19 18 17 16 15
Level
Shift
Level
Shift
Vref 1 1ch in 2ch in Reg on(H) Reg feed Reg out Ground P Vcc 1 Mute 1,2_ Ground 2chout- 2chout+ 1chout- 1chout+
SW 45 Mute 3_ 4chinB Vref 2 4chinA 3chin SVcc PVcc Mute 4_ Ground 3chout- 3chout+ 4chout- 4chout+
Regulator
pin 34: INVSEL : IN : MDI polarity selection.
pin 35: AGCI : IN : The input terminal of RF AGC amplifier.
pin 36: RF DCI : IN : The input terminal for RF peak detection.
pin 37: RF OUT : O : RF signal output.
pin 38: PN SEL : IN : The transistor type selection input for laser
diode driver. L=NPN, H=PNP.
pin 39: EQ SET : O : The equalizer setting terminal.
pin 40: RF VDD : - : RF power supply.
pin 41: LDO : O : The laser diode drive output.
pin 42: MDI : IN : Monitor photo diode signal input.
pin 43: RF VSS : - : RF ground.
pin 44: FNI 2 : IN : Main beam signal input.
pin 45: FNI 1 : IN : Main beam signal input.
pin 46: FPI 2 : IN : Main beam signal input.
pin 47: FPI 1 : IN : Main beam signal input.
pin 48: TPI : IN : Sub beam signal input.
pin 49: TNI : IN : Sub beam signal input.
pin 50: FTEO : O : For test.
pin 51: RF ZI : IN : RF ripple zero cross signal input.
pin 52: A VSS : - : Analog ground.
pin 53: RF RP : O : RF ripple signal output.
pin 54: RF DC : O : RF peak detection signal output. (hologram
suitable)
pin 55: FEI : O : Focus error signal output.
pin 56: SBAD : O : Sub beam add signal output.
pin 57: TEI : O : Tracking error signal output.
pin 58: TE Z IN : IN : Tracking error signal inpur for zero cross.
pin 59: A VDD : - : Positive supply voltage for the Analog sec-
tion.
pin 60: FOO : O : Focus equalizer output.
pin 61: TRO : O : Tracking equalizer output.
pin 62: Vref : O : Reference voltage output.
pin 63: FMO : O : Field equalizer output / Speed error output.
pin 64: DMO : O : Disk equalizer output.
pin 65: IO2A :I/O: General input/output.
pin 66: IO3A :I/O: General input/output.
pin 67: MONIT : O : Internal DSP signal monitor.
pin 68: FG IN : IN : FG input for the spindle CAV servo.
pin 69: VSS : - : Negative supply voltage.
pin 70: VDD : - : Positive supply voltage.
pin 71: TESIN : IN : For test.
pin 72: X VSS : - : Master clock analog ground.
pin 73: X IN : IN : Crystal connection.
pin 74: X O : O : Crystal connection.
pin 75: X VDD : - : Clock power supply.
pin 76: D VSS : - : Digital ground.
pin 77: RO : O : Right channel data output for 1-bit DAC.
pin 78: D VDD : - : Positive supply voltage for the digital sec-
tion.
pin 79: D Vref : O : Digital reference voltage.
pin 80: LO : O : Left channel data output for 1-bit DAC.
pin 81: D VSS : - : Digital ground.
pin 82: Z DET O : O : 1bit DAC zero flag output.
pin 83: VSS : - : Negative supply voltage.
pin 84: BUS 0 :I/O: CD IC Data input / output.
pin 85: BUS 1 :I/O: CD IC Data input / output.
pin 86: BUS 2 :I/O: CD IC Data input / output.
pin 87: BUS 3 :I/O: CD IC Data input / output.
pin 88: BU CK IN : IN : CD IC Data clock input.
pin 89: CCEI : IN : Chip enable input.
pin 90: RSTI : IN : Reset signal input.
pin 91: VDD : - : Positive supply voltage.
pin 92: EMPHI/FAO :I/O: Emphasis input for 1-bit DAC / Flag A
output.
pin 93: BCKI/FBO :I/O: Bit clock input for 1-bit DAC / Flag B out-
put.
pin 94: AIN/FCO :I/O: Audio input for 1-bit DAC / Flag C output.
pin 95: LRCKI/FDO :I/O: LR clock input for 1-bit DAC / Flag D out-
put.
pin 96: EMPHO : O : Emphasis flag output. H=Emphasis ON.
pin 97: B CK O : O : Bit clock output.
pin 98: A OUT : O : Audio signal output.
pin 99: LR CK O : O : LR clock output.
pin100: D OUT : O : Serial data output.
CD section: 929-0301-83mechanism pin 33: TESTR : O : The compensation terminal for RFEQO off-
set.
DXZ558RMP
-6-

051-6700-00 TMS320DA140PGE160 Digital Signal Processor
1.Terminal Description
pin 1: VSS : - : Negative supply voltage.
pin 2: Memo Addrss 22: O : Control signal output for Memory IC.
pin 3: VSS : - : Negative supply voltage.
pin 4: VDD : - : Positive supply voltage.
pin 5: Memo Addrss 10: O : Address output to Memory IC.
pin 6: C RESET : O : Reset pulse output to CD IC.
pin 7: Memo Addrss 11: O : Address output to Memory IC.
pin 8: Memo Addrss 12: O : Address output to Memory IC.
pin 9: Memo Addrss 13: O : Address output to Memory IC.
pin 10: Memo Addrss 14: O : Address output to Memory IC.
pin 11: Memo Addrss 15: O : Address output to Memory IC.
pin 12: VDD : - : Positive supply voltage.
pin 13: NU : IN : Not in use.
pin 14: VSS : - : Negative supply voltage.
pin 15: VSS : - : Negative supply voltage.
pin 16: VDD : - : Positive supply voltage.
pin 17: NU : IN : Not in use.
pin 18: NU : IN : Not in use.
pin 19: READY : IN : The ready signal input.
pin 20: PS : O : Control signal output for Memory IC.
pin 21: NU : O : Not in use.
pin 22: NU : O : Not in use.
pin 23: WRITE ENBL : O : The write enable signal output.
pin 24: M STRB : O : Control signal output for Memory IC.
pin 25: NU : O : Not in use.
pin 26: NU : O : Not in use.
pin 27: LD CONT : O : The loading control signal output.
pin 28: NU : O : Not in use.
pin 29: NU : O : Not in use.
pin 30: NU : IN : Not in use.
pin 31: CS : IN : The chip select command input.
pin 32: NU : - : Not in use.
pin 33: VDD : - : Positive supply voltage.
pin 34: VSS : - : Negative supply voltage.
pin 35: V BUS WUP : IN : V BUS WUP input.
pin 36: C BUS CE/TRB :I/O: Data bus chip enable signal output to CD
IC. Or mechanism sensor signal input.
pin 37: VSS : - : Negative supply voltage.
pin 38: C BUS CK/TRA :I/O: Data bus clock pulse output to CD IC. Or
mechanism sensor signal input.
pin 39: NU : IN : Not in use.
pin 40: VSS : - : Negative supply voltage.
pin 41: C BCK : IN : Bit clock pulse input from CD IC.
pin 42: NU : O : Not in use.
pin 43: C LRCK : IN : LR clock pulse input from CD IC.
pin 44: NU : O : Not in use.
pin 45: C SD : IN : Serial data input from CD IC.
pin 46: NU : IN : Not in use.
pin 47: MS SI : IN : Serial data input from Master Computer.
pin 48: C DAC BCK : O : Bit clock output for the internal DAC of CD
IC.
pin 49: MS SCK : IN : Serial clock input from Master Computer.
pin 50: VSS : - : Negative supply voltage.
pin 51: NU : O : Not in use.
pin 52: VDD : - : Positive supply voltage.
pin 53: C DAC LRCK : O : LR clock output for the internal DAC of CD
IC.
pin 54: MS CS : IN : Chip select input from Master Computer.
pin 55: NU : O : Not in use.
pin 56: VDD : - : Positive supply voltage.
pin 57: VSS : - : Negative supply voltage.
pin 58: C BUS 0 :I/O: Data bus for CD IC.
pin 59: C DAC SD : O : Serial data output for the internal DAC of
CD IC.
pin 60: MS SO : O : Serial data output to Master Computer.
pin 61: NU : O : Not in use.
pin 62: NU : IN : Not in use.
pin 63: NU : IN : Not in use.
pin 64: WUP : IN: V BUS WUP.
pin 65: SBSY : IN : Sub code block synchronous signal detec-
tion input.
pin 66 :C BMOVF : IN : Buffer memory over flag input from CD IC.
pin 67 :SCK : IN : The clock pulse input.
pin 68 : VDD : IN : Positive supply voltage.
pin 69 : C BUS 1 : I/O: Data bus for CD IC.
pin 70 : VSS : - : Negative supply voltage.
pin 71 : LIMIT : IN : Inside limit switch signal input for the
pickup.
pin 72 : VSS : - : Negative supply voltage.
pin 73 : C PF/ CHUCK : IN : C2 correction data input from CD IC. Or
chucking signal input from the mechanism.
pin 74 : LD MUTE : IN : Muting signal output to the CD mechanism.
pin 75 : VDD : - : Positive supply voltage.
pin 76 : VSS : - : Negative supply voltage.
pin 77 : Clock Mode 1 : IN : Clock mode selection.
pin 78 : Clock Mode 2 : IN : Clock mode selection.
pin 79 : Clock Mode 3 : IN : Clock mode selection.
pin 80 : NU : IN : Not in use.
pin 81 : C BUS 2 : I/O: Data bus for CD IC.
pin 82 : NU : O : Not in use.
pin 83 : NU : IN : Not in use.
pin 84 : NU : O : Not in use.
pin 85 :
:
:
NU : O : Not in use.
pin 86 NU : IN : Not in use.
pin 87 :
:
NU : IN : Not in use.
pin 88 NU : IN : Not in use.
pin 89 : NU : IN : Not in use.
pin 90 : VSS : - : Negative supply voltage.
pin 91 : VDD : - : Positive supply voltage.
pin 92 : NU : IN : Not in use.
pin 93 : VSS : - : Negative supply voltage.
pin 94 : CLK OUT : O : Clock pulse output.
pin 95 : C BUS 3 : I/O: Data bus for CD IC.
pin 96 : NU : O : Not in use.
pin 97 :SYS CLK : IN : 16.92MHz
pin 98 : RESET : IN : Reset signal input.
pin 99 : Memo Data 0 : I/O: Parallel data input/output for Memory IC.
pin100 : Memo Data 1 : I/O: Parallel data input/output for Memory IC.
pin101 : Memo Data 2 : I/O: Parallel data input/output for Memory IC.
pin102 : Memo Data 3 : I/O: Parallel data input/output for Memory IC.
pin103 : Memo Data 4 I/O: Parallel data input/output for Memory IC.
pin104 : Memo Data 5 : I/O: Parallel data input/output for Memory IC.
pin105 :Memo Addrss 16: O : Address output to Memory IC.
pin106 : VSS : - : Negative supply voltage.
pin107 :Memo Addrss 17: O : Address output to Memory IC.
pin108 :Memo Addrss 18: O : Address output to Memory IC.
pin109 :Memo Addrss 19: O : Address output to Memory IC.
pin110 :Memo Addrss 20: O : Address output to Memory IC.
pin111 : VSS : - : Negative supply voltage.
pin112 : VDD : - : Positive supply voltage.
pin113 : Memo Data 6 : I/O: Parallel data input/output for Memory IC.
pin114 : Memo Data 7 : I/O: Parallel data input/output for Memory IC.
pin115 : Memo Data 8 : I/O: Parallel data input/output for Memory IC.
pin116 : Memo Data 9 : I/O: Parallel data input/output for Memory IC.
pin117 : Memo Data 10 : I/O: Parallel data input/output for Memory IC.
pin118 : Memo Data 11 : I/O: Parallel data input/output for Memory IC.
pin119 : Memo Data 12 : I/O: Parallel data input/output for Memory IC.
pin120 : CN VCC : IN : Connect to VCC.
pin121 :Memo Data 13 :I/O:Parallel data input/output for Memory IC.
pin122 : Memo Data 14 : I/O:Parallel data input/output for Memory IC.
pin123 : Memo Data 15 : I/O: Parallel data input/output for Memory IC.
pin124 : SRQ : O : V BUS SRQ output.
pin125 : VDD : - : Positive supply voltage.
pin126 : VSS : - : Negative supply voltage.
pin127 : NU : IN : Not in use.
pin128 : VSS : - : Negative supply voltage.
pin129 : NU : IN : Not in use.
pin130 : VDD : - : Positive supply voltage.
pin131 : Memo Addrss 0 : O : Address output to Memory IC.
pin132 : Memo Addrss 1 : O : Address output to Memory IC.
pin133 : Memo Addrss 2 : O : Address output to Memory IC.
pin134 :
:
:
:
Memo Addrss 3 : O : Address output to Memory IC.
pin135 SYS POWER : O : System power supply control signal output.
pin136 Memo Addrss 4 : O : Address output to Memory IC.
pin137 Memo Addrss 5 : O : Address output to Memory IC.
pin138 : Memo Addrss 6 : O : Address output to Memory IC.
pin139 : Memo Addrss 7 : O : Address output to Memory IC.
-7-
DXZ558RMP

pin140 Memo Addrss 8 : O : Address output to Memory IC.
pin141 : Memo Addrss 9 : O : Address output to Memory IC.
pin14
2
: VDD : - : Positive supply voltage.
pin14
3
: Memo Addrss 21: O : Control signal output for Memory IC.
pin14
4
: VSS : - : Negative supply voltage.
Truth Table
G_ B A Y 0_ Y 1_ Y 2_ Y 3_
don't don't
H care care H H H H
LL L L H H H
051-6919-08 NJU6391PE Quarts Crystal Oscillator
051-7280-38 TC7SU04FU Single Inverter
051-7518-18 SN74LVC139APWR
Dual 2-line to 4-line Decoders/Demultiplexers
H
HH
H
H
H
H
HH
H
H
HH
LL
L
LLL
L
L
3
2
1
ON=H 5
XT
XT
CONT 4
6
7
8
VSS
OUT
N.C.
N.C.
VDD
1
2
3
5
4
VCC
OUT
NC
IN
GND
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
VCC
2G_
2A
2B
2Y0_
2Y1_
2Y2_
2Y3_
1G_
1A
1B
1Y0_
1Y1_
1Y2_
1Y3_
GND
MP3&WMA Encoded disc/CD-DA disc
(CD-ROM ISO9660)
CD Mecha.
P/U CP-51
J2 10pin J1 15pin
IC101
DRIVER
3.3V(I/O) 1.6V(Core)
FAN8047G3
IC6
DSP
TMS320DA140
(CD-ROM I/F)
Q1
3.3V
(ECC)
Transistor IC102
(MPEG audio decode)
5V 3.3V CD DSP
(WMA decode)
TC94A15F
(CD-DA ESP)
(Digital servo)
IC2 (DF/DAC)
Regulator
3.3V 1.6V
3.3V
IC10
IC1
FLASH ROM
LOGIC
MBM29DL800BA
(8Mbit)
AUDIO
D-OUT
IC3
LOGIC
SN74HCT08
V-BUS
I/F-5V
ACC8V
J3 20pin
ACC5V
DAC SN74LVC139
BLOCK DIAGRAM
--
8
CD section: 929-0301-83mechanism
DXZ558RMP

Main section
CD/MP3/WMA
MECHA
PT2579S-SN
M30622MGP-178GP
S-80821ANMP
HA17558AF
BA4916-V2
DXZ558RMP
-9-

NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 DCP-ASSY
DCP-523-700 1 1-32 382-7234-01 BUTTON 1
1-1 373-1045-01 DIAL-CVR 1 1-33 716-0872-20 PAD SCREW(M1.7X4) 1
1-2 335-7392-00 FACE PANEL(L) 1 1-34 347-7537-00 DOUBLE FACE 1
1-3 347-7507-00 DOUBLE FACE 1 1-35 347-7509-00 SHADE 2
1-4 347-7506-00 SURGE FILM 2 1-36 347-7508-00 SHADE 1
1-5 335-7401-01 LEVER CAP 1 1-37 347-7531-00 FILM 2
1-6 716-0872-01 PAD SCREW(M1.7x6) 10 1-38 347-7510-00 DOUBLE FACE 6
1-7 335-7457-00 LEVER INNER 1 1-39 347-7576-00 SPACER 2
1-8 335-7403-00 BASE LEVER 1 1-40 347-7575-00 SPACER 2
1-9 750-6794-00 SPRING(LEVER) 1 1-41 347-7159-00 CUSHION 2
1-10 331-3945-00 LEVER HOLDER 1 1-42 347-7577-00 SPACER 2
1-11 331-3944-00 ARM COVER 1 1-43 347-6988-00 DOUBLE FACE 1
1-12 335-7404-00 LEVER ARM 1 1-44 347-7540-00 REFLECTOR 2
1-13 382-7232-00 BUTTON(RELEASE) 1 1-45 347-7597-00 FILM 1
1-14 750-6720-00 SPRING (REL) 1 1-46 347-7539-00 SPACER 1
1-15 716-0872-12 PAD SCREW(M1.7x8) 4 1-47 716-0872-11 PAD SCREW(M1.7X6) 1
1-16 335-7372-00 REAR-COVER 1 1-48 331-3921-00 LCD COVER 1
1-17 335-7349-00 ILLUMI PLATE(R) 1 1-49 379-1320-41 INDICATOR(LCD) 1
1-18 370-6138-00 ESCUTCHEON 1 1-50 347-7371-00 FILM(BLACK) 1
1-19 335-7347-00 ILLUMI PLATE(L) 1 1-51 347-7372-00 FILM(LCD) 1
1-20 335-7348-00 ILLUMI PLATE(M) 1 1-52 345-5500-00 RUBBER CONNECTOR 1
1-21 382-7226-01 BUTTON 1 1-53 335-7359-00 ILLUMI PLATE 1
1-22 382-7229-01 BUTTON 1 1-54 347-7373-00 REFLECTOR 1
1-23 335-7391-00 FACE PANEL(R) 1 1-55 335-7358-00 LCD HOLDER 1
1-24 380-5608-00 KNOB 1 1-56 076-0708-02 PLUG 2
1-25 380-5609-00 KNOB CVR 1 1-57 001-7076-90 DIODE 5
1-26 345-5489-00 RUBBER RING 1 1-58 013-6312-50 SWITCH 18
1-27 382-7230-01 BUTTON 1 1-59 ----------- SWITCH PWB 1
1-28 382-7237-01 BUTTON 1 1-60 060-4017-90 IR-RECEIVER 1
1-29 382-7231-01 BUTTON 1 1-61 016-9900-85 ENCODER-SW 1
1-30 382-7227-01 BUTTON 1 1-62 076-0616-00 PLUG 1
1-31 382-7233-01 BUTTON 1
EXPLODED VIEW / PARTS LIST
DCP section
DXZ558RMP
-10-

Main Section
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1346-0173-00 LEATHER SHEET 1 38 ------------ MAIN PWB 1
2335-7373-00 HOOK DCP 1 39 347-6341-00 E-SHEET 1
3750-3454-00 SPRING 1 40 345-5312-00 CUSHION 1
4341-1764-00 SHAFT 1 41 880-2090Z TUNER 1
5370-6142-00 INNER-ES 1 42 092-4000-51 ANT-RECEPT 1
6382-7255-00 BUTTON 1 43 331-3567-00 CONNECTOR HOLDER 1
7013-6312-50 SWITCH 1 44 074-1194-00 OUTLET SOCKET(13 P) 1
8716-1764-01 PAD SCREW(M1.7x5) 1 45 051-2057-00 IC 1
9074-1220-00 OUTLET SOCKET(16 P) 1 46 009-9006-70 CHOKE 1
10 074-1279-68 OUTLET SOCKET(18 P) 1 47 042-1447-00 ALUMI-ELE-C 1
11 335-7368-00 ILLUMI PLATE 1 48 331-3560-02 IC HOLDER 1
12 716-3546-01 DECORATIVE SCREW(M4.1x7) 349 331-3562-01 CONNECTOR HOLDER 1
13 331-3925-00 ARM-L 1 50 321-0969-00 CLAMP 1
14 716-1764-00 PAD SCREW(M1.7x5) 7 51 313-1867-00 HEAT SINK 1
15 750-3341-00 SPRING 1 52 855-5478-50 RCA-PIN-CORD 1
16 335-7369-00 HOOK LOCK 1 53 714-3006-81 MACHINE SCREW(M3x6) 11
17 013-7201-50 SWITCH 1 54 052-3947-00 MICOM 1
18 ------------ SUB PWB 1 55 ------------ ISO PWB 1
19 335-7370-00 DETECTOR HOOK 1 56 074-1285-00 OUTLET SOCKET(ISO) 1
20 335-7371-00 HOOK SLEEVE 1 57 060-0057-57 AUTO-FUSE(15 A) 1
21 331-3926-00 ARM-R 1 58 311-1859-02 LOWER CASE 1
22 780-2004-01 SCREW(M2x4) 1 59 286-6543-00 SETPLATE 1
23 613-0730-00 GEAR DAMPER 1 60 347-6880-01 INSULATOR 1
24 738-1722-17 PRECISION SCREW(M1.7x2.2) 361 780-2607-02 SCREW(M2.6x7) 2
25 750-6793-00 SPRING 1 62 816-2623-50 FLAT WIRE 1
26 331-3924-00 DCP-HOLDER 1 63 714-3004-81 MACHINE SCREW(M3x4) 3
27 335-7505-00 HOOK 1 64 714-2603-80 MACHINE SCREW(M2.6x3) 3
28 613-0757-00 FAN GEAR 1 65 331-3570-00 MECH-SUB-BRKT 1
29 291-0092-00 STICKER 1 66 331-3569-00 MECH-SUB-BRKT 1
30 290-8458-00 LABEL 1 67 929-0301-83 CD-MECH-MODULE 1
31 750-6783-00 SPRING 1 68 331-3427-00 MECH BRKT 1
32 001-7062-90 DIODE 2 69 731-3006-80 TAPTIGHT(M3x6) 3
33 345-5547-00 RUBBER 1 70 331-2744-00 STOPPER 1
34 051-3297-10 IC 1 71 303-0485-01 UPPER CASE 1
35 076-0648-18 PLUG(18 P) 1 72 313-1866-00 HEAT SINK 1
36 013-6103-00 TACT SWITCH 1 73 345-3799-20 RUBBER PART 6
37 074-1237-70 OUTLET SOCKET(20 P) 1
DXZ558RMP
-11-

H4
H5
G6
H6
H7
A5
A1
A2
A3
A4
G2
G3
B2
A8
A8
I1
M1
K3
K4
C1
A2
A3
G9
G8
G11
G5
G14
G6
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29 30
31
32
33
34
35
36
37
38
39
40
41
42 43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
62
61
63
64
65
66
67
68
57
42
I1
I2
D2
D1
H6
H7
K1
K2
C3
67
H5
H4
32
29
H6
B1
H1
H2
H3
G13
D1
50
D2
G12
H2
H1
H3
44
A4
A5
E2
G2
G14
G5
G1
G3
E1
G4
M1
G9
G8
G11
C5
C2
G1
I2
C1
45 45
45
45
H6
C5
C2
C3
K1
K2
K3
K4
G12
G4
A1
G13
B1
B2
66
E1
E2
72
69
3
70
73 71
74
CD
CD section: 929-0301-83mechanism
DXZ558RMP
-12-

ELECTRICAL PARTS LIST
Main PWB (B1) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT1 092-4000-51 ANT-RECEPT C28 168-1042-78 50V 0.1uF C 111 168-1042-78 50V 0.1uF
BL1 880-2090Z TUNER C31 166-1011-50 50V 100
p
FC 112 187-1063-35 16V 10uF
C1 166-2201-50 50V 22
p
FC34 168-1022-55 50V 1000
p
FC 113 178-1052-78 1uF
C3 166-2201-50 50V 22
p
FC35 166-1011-50 50V 100
p
FC 114 168-1042-78 50V 0.1uF
C4 166-2096-50 50V 2
p
FC36 187-1053-65 50V 1uF C 116 187-1053-65 50V 1uF
C7 168-1022-55 50V 1000
p
FC37 166-3311-50 50V 330
p
FC 117 187-1053-65 50V 1uF
C8 168-8222-55 50V 8200
p
FC40 168-3932-78 25V 0.039uF C 123 168-1022-55 50V 1000
p
F
C9 187-4763-35 16V 47uF C42 166-2211-50 50V 220
p
FC 124 168-1022-55 50V 1000
p
F
C10 166-1011-50 50V 100
p
FC44 187-4763-15 6.3V 47
p
FC 125 168-1022-55 50V 1000
p
F
C11 168-1032-55 50V 0.01uF C45 187-4753-55 35V 4.7
p
FC 126 168-1022-55 50V 1000
p
F
C12 168-1222-55 50V 1200
p
FC46 166-1011-50 50V 100
p
FC 127 168-1022-55 50V 1000
p
F
C13 168-2232-55 25V 0.022uF C47 168-1832-55 50V 0.018uF C 128 168-1022-55 50V 1000
p
F
C14 166-1801-50 50V 18
p
FC48 168-1832-55 50V 0.018uF C 129 168-1022-55 50V 1000
p
F
C15 166-1501-50 50V 15
p
FC55 168-1042-78 16V 0.1uF C 130 168-1022-55 50V 1000
p
F
C16 168-2232-55 25V 0.022uF C 100 187-2263-35 16V 22uF C 200 172-2231-15 50V 0.022uF
C17 168-2232-55 25V 0.022uF C 101 187-2263-35 16V 22uF C 201 042-1447-00 16V 2200uF
C21 168-2232-55 25V 0.022uF C 102 187-2263-35 16V 22uF C 203 187-1063-35 16V 10uF
C23 166-4711-50 50V 470
p
FC 103 187-2263-35 16V 22uF C 205 187-4763-35 16V 47uF
C24 187-1073-35 16V 100uF C 105 178-2242-78 25V 0.22uF C 206 187-1073-35 16V 100uF
C25 187-4763-35 16V 47uF C 106 178-2242-78 25V 0.22uF C 207 187-1063-35 16V 10uF
C26 168-1042-78 50V 0.1uF C 107 178-2242-78 25V 0.22uF C 208 187-2263-35 16V 22uF
C27 187-1053-65 50V 1uF C 108 178-2242-78 25V 0.22uF C 209 187-2263-35 16V 22uF
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1SMA-182-100 SPD-MOTOR-ASSY 1 38 621-0723-20 IDLE CASE 1
2SMA-183-100 POW-MOTOR-ASSY 1 39 621-0724-21 GEAR BASE 1
3620-1022-26 CLAMPER LINK 1 40 622-1660-20 ROLLER SHAFT 1
4966-0595-25 DRIVE-PLT-ASSY 1 41 624-0018-01 LEAD SCREW 1
5966-0638-20 SH-RACK-ASSY 1 42 629-0086-20 DAMPER F 2
6969-0065-31 PICK UP-ASSY 1 43 629-0087-20 DAMPER R 1
7345-5476-20 CUSHION RUBBER 1 44 714-2003-81 MACHINE SCREW (M2x3) 2
8620-1025-22 ID-LOCK PLATE 1 45 716-1507-00 SCREW (M2x3) 7
9620-1026-21 SPRING PLATE 1 46 716-1670-00 SCREW (M2x4) 2
10 620-1028-24 UPPER CHASSIS 1 47 716-1733-00 SCREW (M1.7x2.3) 2
11 620-1585-21 LOWER SHASSIS-W 1 48 716-3551-00 SCREW (M1.4x2.5) 2
12 621-0598-27 UPPER GUIDE 1 49 716-3469-00 SCREW (phi1.7x4) 2
13 621-0600-26 SHIFT LEVER 1 50 716-3473-00 SCREW (M2x3) 2
14 621-1735-20 RACK 1 51 750-3465-21 ROLLER SPRING L 1
15 621-0602-22 LOCK ARM L 1 52 750-3466-20 ROLLER SPRING R 1
16 621-0603-25 LOCK ARM R 1 53 750-3467-21 SHIFT SPRING 1
17 621-0605-22 GEAR COVER 1 54 750-3468-20 RACK SPRING 1
18 621-0608-21 SECOND GEAR 1 55 750-3469-20 CLAMPER SPRING 1
19 621-0609-20 BASE GEAR 1 56 750-3470-20 ID-LOCK SPRING 1
20 621-0610-20 IDLE GEAR A 1 57 750-3472-21 DR-SPRING F 2
21 621-0611-20 IDLE GEAR B 1 58 750-3473-20 DR-SPRING RA 1
22 621-0612-21 ROLLER GEAR A 1 59 750-3474-20 DR-SPRING RB 1
23 621-0616-20 POWER GEAR A 1 60 750-3475-21 DR-SPRING C 1
24 621-0617-20 POWER GEAR B 1 61 803-4906-60 VINYL-COAT-WIRE(ORANGE) 1
25 621-0618-20 POWER GEAR C 1 62 816-2590-00 EXTENSION LEAD(GREEN) 1
26 621-0619-20 POWER GEAR D 1 63 816-2591-00 EXTENSION LEAD(YELLOW) 1
27 621-0620-20 THREAD GEAR A 1 64 816-2592-00 EXTENSION LEAD(BLUE) 1
28 621-0621-20 THREAD GEAR B 1 65 816-2593-00 EXTENSION LEAD(PURPLE) 1
29 621-0622-21 ROLLER SLEEVE 2 66 816-2624-50 FLAT WIRE 1
30 621-0623-23 LS-HOLDER 1 67 --------------- LED PWB 1
31 621-0624-22 GUIDE RAIL 1 68 --------------- CD PWB 1
32 621-0629-20 LOADING ROLLER 2 69 620-1023-23 CLAMPER PLATE 1
33 621-0709-20 SH-BASE 1 70 620-1721-20 SENSOR ARM 1
34 621-0718-21 ROLLER GUIDE 1 71 621-0626-21 STOPPER LINK 1
35 621-0719-20 ROLLER GEAR 1 72 621-0627-21 DISC STOPPER 1
36 621-0720-20 ROLLER GEAR C 1 73 621-0708-20 CLAMPER RING 1
37 621-0721-20 ROLLER GEAR D 1 74 750-3471-20 SENSOR SPRING 1
DXZ558RMP
-13-
Note) Several different parts of the same reference number are alternative parts.
Oneofthosepartsisusedintheset.

-14 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 210 187-3363-25 10V 33uF D 112 001-4301-41 HZU7.5B2 Q 207 125-2041-93 RT1N241M
C 213 187-1073-35 16V 100uF D 201 001-0592-61 1N5404 Q 207 125-2027-92 DTC124EUA
C 214 187-1073-15 6.3V 100uF D 202 001-1310-00 KDS160 Q 208 125-0034-92 RT1P141M
C 215 187-1063-35 16V 10uF D 203 001-0466-60 1A2 Q 213 125-2041-93 RT1N241M
C 216 042-1631-50 10V 100uF D 204 001-1310-00 KDS160 Q 213 125-2027-92 DTC124EUA
C 219 166-1011-50 50V 100
p
FD 205 001-1310-00 KDS160 Q 214 190-1602-00 2SA1602
A
C 220 168-1042-78 50V 0.1uF D 206 001-4301-26 HZU4.7B2 Q 215 125-2041-93 RT1N241M
C 222 166-1011-50 50V 100
p
FD 207 001-1310-00 KDS160 Q 215 125-2027-92 DTC124EUA
C 223 166-1011-50 50V 100
p
FD 208 001-0347-32 MA4056M Q 216 125-2041-93 RT1N241M
C 300 168-4722-55 50V 4700
p
FD 210 001-0466-61 1A4 Q 216 125-2027-92 DTC124EUA
C 301 168-4722-55 50V 4700
p
FD 211 001-0466-61 1A4 Q 217 125-3005-90 KTA1273
C 302 187-2253-65 50V 2.2uF D 212 001-0466-61 1A4 Q 220 190-1602-00 2SA1602
A
C 303 187-2253-65 50V 2.2uF D 216 001-1310-00 KDS160 Q 221 125-2041-93 RT1N241M
C 306 187-2253-65 50V 2.2uF D 501 001-1310-00 KDS160 Q 221 125-2027-92 DTC124EUA
C 307 187-2253-65 50V 2.2uF D 502 001-1310-00 KDS160 Q 222 190-1365-50 2SA1365
C 308 187-1063-35 16V 10uF D 504 001-4301-43 HZU8.2B2 Q 222 191-1197-50 2SB1197
K
C 309 187-1063-35 16V 10uF D 505 001-4301-23 HZU4.3B2 Q 454 125-4012-90 KTD1304
C 310 187-1063-35 16V 10uF D 600 001-1310-00 KDS160 Q 455 125-4012-90 KTD1304
C 311 187-1063-35 16V 10uF D 601 001-1310-00 KDS160 Q 456 125-4012-90 KTD1304
C 312 168-4732-78 25V 0.047uF D 602 001-7062-90 RBR1111C Q 457 125-4012-90 KTD1304
C 313 168-4732-78 25V 0.047uF D 801 001-1310-00 KDS160 Q 502 192-4155-49 2SC4155
A
C 314 187-1053-65 50V 1uF D 802 001-1310-00 KDS160 Q 503 125-2041-96 RT1N436M
C 454 187-2263-35 16V 22uF IC 1 051-6201-90 LC72146M Q 503 125-2027-95 DTC143ZUA
C 455 187-2263-35 16V 22uF IC 101 051-2057-00 TB2906HQ Q 505 125-0034-96 RT1P436M
C 456 187-2263-35 16V 22uF IC 200 051-3297-10 BA4916-V2 Q 506 125-0034-96 RT1P436M
C 457 187-2263-35 16V 22uF IC 302 051-3049-90 HA17558AF Q 514 125-2041-96 RT1N436M
C 462 168-5612-55 25V 560
p
FIC 501 051-5030-90 M61523FP Q 514 125-2027-95 DTC143ZUA
C 463 168-5612-55 25V 560
p
FIC 600 052-3947-00 M30622MGP- Q 601 125-2041-93 RT1N241M
C 464 168-5612-55 25V 560
p
F 178GP Q 601 125-2027-92 DTC124EUA
C 465 168-5612-55 25V 560
p
FIC 601 051-5437-08 S-80821ANMP Q 602 125-2041-93 RT1N241M
C 500 187-2253-65 50V 2.2uF IC 602 051-6600-58 HA12187FP Q 602 125-2027-92 DTC124EUA
C 501 187-2253-65 50V 2.2uF IC 603 051-5443-08 BD4850G Q 603 190-1602-00 2SA1602
A
C 502 187-2253-65 50V 2.2uF IC 801 051-0350-93 NJM4558M R5 119-4721-15 1/16W4.7k ohm
C 505 187-2253-65 50V 2.2uF IC 802 051-4616-90 PT2579S-SN R6 116-3311-15 1/4W 330 ohm
C 506 187-2253-65 50V 2.2uF J 600 074-1194-00 13P R7 119-1231-15 1/16W 12k ohm
C 507 187-2253-65 50V 2.2uF J 601 076-0648-18 18P R8 119-2711-15 1/16W 270 ohm
C 508 187-1063-35 16V 10uF J 900 074-1237-70 20P R10 119-2221-15 1/16W 2.2k ohm
C 509 187-1073-35 16V 100uF L1 010-2003-04 30uH(Variable) R11 119-2221-15 1/16W 2.2k ohm
C 510 168-1042-78 50V 0.1uF L3 010-6026-50 220uH R12 119-1021-15 1/16W 1k ohm
C 512 166-2201-50 50V 22
p
FCH L6 010-6026-50 220uH R13 119-1031-15 1/16W 10k ohm
C 516 166-2201-50 50V 22
p
FCH L 200 010-2230-64 2.2uH R15 119-1021-15 1/16W 1k ohm
C 518 166-2201-50 50V 22
p
FCH L 507 010-3105-62 1k ohm 100MHz R16 119-5621-15 1/16W 5.6k ohm
C 519 166-2201-50 50V 22
p
FCH L 508 010-3105-62 1k ohm 100MHz R17 119-5631-15 1/16W 56k ohm
C 525 166-1011-50 50V 100
p
FL 509 010-3105-62 1k ohm 100MHz R18 119-1021-15 1/16W 1K ohm
C 533 168-1022-55 50V 1000
p
FL 510 010-3105-62 1k ohm 100MHz R19 119-1021-15 1/16W 1K ohm
C 537 187-2263-35 16V 22uF L 601 010-3100-66 2.2uH R20 119-1021-15 1/16W 1K ohm
C 600 168-1032-55 50V 0.01F L 602 010-3100-66 2.2uH R21 119-8201-15 1/16W 82 ohm
C 601 042-0650-00 5.5V 0.1uF L 603 010-3100-66 2.2uH R22 119-1041-15 1/16W 100k ohm
C 603 168-1032-55 50V 0.01uF L 605 010-3100-66 2.2uH R23 119-3311-15 1/16W 330 ohm
C 605 042-1577-00 6.3V 100uF L 606 010-3100-66 2.2uH R24 119-5631-15 1/16W 56k ohm
C 606 168-1022-55 50V 1000
p
FL 607 010-3100-66 2.2uH R29 119-1021-15 1/16W 1k ohm
C 607 168-1032-55 50V 0.01uF L 610 010-3105-62 1k ohm 100MHz R32 119-1521-15 1/4WS 1.5k ohm
C 608 168-1032-55 50V 0.01uF L 611 010-3105-62 1k ohm 100MHz R33 119-1031-15 1/16W 10k ohm
C 609 168-4732-78 25V 0.047uF Q3 198-0669-00 2SK669 R34 119-1031-15 1/16W 10k ohm
C 612 187-1063-35 16V 10uF Q4 125-2041-93 RT1N241M R36 119-1031-15 1/16W 10k ohm
C 619 168-1022-55 50V 1000
p
FQ4 125-2027-92 DTC124EUA R37 119-1521-15 1/4WS 1.5k ohm
C 620 168-1022-55 50V 1001
p
FQ5 192-3440-50 2SC3440 R40 119-1031-15 1/16W 10k ohm
C 622 168-1022-55 50V 1002
p
FQ6 125-0034-93 RT1P241M R 100 119-1031-15 1/16W 10k ohm
C 801 168-2232-55 25V 0.022uF Q7 190-1602-00 2SA1602
A
R 101 119-0000-05 1/16W 0 ohm JW
C 802 166-8211-50 50V 820
p
FQ8 190-1602-00 2SA1602
A
R 102 119-0000-05 1/16W 0 ohm JW
C 803 166-6811-50 50V 680
p
FQ9 125-2041-92 RT1N141M R 103 119-1221-15 1/16W 1.2k ohm
C 804 166-5611-50 50V 560
p
FQ9 125-2027-91 DTC114EUA R 106 119-4731-15 1/16W 47k ohm
C 805 166-3311-50 50V 330
p
FQ10 192-4155-49 2SC4155
A
R 501 119-1021-15 1/16W 1k ohm
C 806 187-2253-65 50V 2.2uF Q 200 125-4011-90 KTD863 R 110 119-4721-15 1/16W 4.7k ohm
C 808 168-2232-55 25V 0.022uF Q 201 125-2041-96 RT1N436M R 111 119-4721-15 1/16W 4.7k ohm
C 809 168-1032-55 50V 0.01uF Q 201 125-2027-95 DTC143ZUA R 112 119-4721-15 1/16W 4.7k ohm
C 810 166-4701-50 50V 47
p
FQ 202 190-1602-00 2SA1602
A
R 113 119-4721-15 1/16W 4.7k ohm
C 811 166-5601-50 50V 56
p
FQ 203 192-4155-49 2SC4155
A
R 200 119-1231-15 1/16W 12k ohm
C 812 166-1007-50 50V 10
p
FQ 204 190-1602-00 2SA1602
A
R 201 119-1541-15 1/16W 150k ohm
C 813 187-4763-15 6.3V 47
p
FQ 205 193-1858-50 2SD1858 Q
,
RR 202 119-3321-15 1/16W 3.3k ohm
D 111 001-4301-41 HZU7.5B2 Q 206 193-1858-50 2SD1858 Q
,
RR 203 119-3311-15 1/16W 330 ohm
DXZ558RMP

SUB PWB (B2) section
ISO PWB (B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D 800 001-7062-90 EJECT S 801 013-6312-50 EJECT
J 701 074-1279-68 18P SW800 013-7201-50 DCP DET
J 703 074-1220-00 16P PWB 039-2634-00 PWB
(
WITHOUT
R 621 119-1521-15 1/16W 1.5k ohm COMPONENT
)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
J 201 074-1285-00 ISO PWB 039-1400-30 PWB
(
WITHOUT
FUSE 060-0057-57 AUTO FUSE(15A) COMPONENT
)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 702 168-4732-78 25V 0.047uF D 728 001-4301-41 HZU7.5B2 R 720 119-3311-15 1/16W 330 ohm
C 703 168-4732-78 25V 0.047uF D 729 001-4301-41 HZU7.5B2 R 721 119-1031-15 1/16W 10k ohm
C 704 042-0423-97 16V 10uF D 730 001-4301-41 HZU7.5B2 R 722 119-3311-15 1/16W 330 ohm
C 705 042-0423-97 16V 10uF IC 701 051-6066-00 NJU6535 R 723 119-1031-15 1/16W 10k ohm
C 706 168-4732-78 25V 0.047uF IR 701 060-4017-90 RS-671 R 725 119-1031-15 1/16W 10k ohm
D 706 001-7076-90 DIODE LCD702 379-1320-41 INDICATOR(LCD) R 726 119-1031-15 1/16W 10k ohm
D 708 001-7076-90 DIODE P 701 076-0616-00 PLUG R 727 119-1031-15 1/16W 10k ohm
D 709 001-7076-90 DIODE Q 703 192-3440-50 2SC3440 R 728 119-1031-15 1/16W 10k ohm
D 713 001-4301-41 HZU7.5B2 Q 704 192-3440-50 2SC3440 R 752 119-4711-15 1/16W 470 ohm
D 714 001-4301-41 HZU7.5B2 Q 705 190-1602-00 2SA1602
A
R 753 119-5611-15 1/16W 560 ohm
D 715 001-4301-41 HZU7.5B2 Q 706 192-4155-49 2SC4155
A
R 754 119-5611-15 1/16W 560 ohm
D 716 001-4301-41 HZU7.5B2 Q 710 190-1365-50 2SA1365 R 756 119-8211-15 1/16W 820 ohm
D 717 001-4301-41 HZU7.5B2 Q 710 191-1197-50 2SB1197
K
R 758 119-8211-15 1/16W 820 ohm
D 720 001-7076-90 DIODE Q 711 192-4155-49 2SC4155
A
R 759 119-8211-15 1/16W 820 ohm
D 721 001-7076-90 DIODE R 701 119-1031-15 1/16W 10k ohm R 760 119-3311-15 1/16W 330 ohm
D 722 001-4301-41 HZU7.5B2 R 702 119-1011-15 1/16W 100 ohm R 761 119-3311-15 1/16W 330 ohm
D 723 001-4301-41 HZU7.5B2 R 703 119-1021-15 1/16W 1k ohm R 762 119-1031-15 1/16W 10k ohm
D 724 001-4301-41 HZU7.5B2 R 704 119-1011-15 1/16W 100 ohm R 763 119-1021-15 1/16W 1k ohm
D 725 001-4301-41 HZU7.5B2 R 705 119-1241-15 1/16W 120k ohm R 764 119-1031-15 1/16W 10k ohm
D 726 001-4301-41 HZU7.5B2 R 706 119-2221-15 1/16W 2.2k ohm R 765 119-6811-15 1/16W 680 ohm
D 727 001-4301-41 HZU7.5B2 R 708 119-1011-15 1/16W 100 ohm R 768 119-4711-15 1/16W 470 ohm
Switch PWB (B4) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R 204 119-1831-15 1/16W 18k ohm R 320 119-8221-15 1/16W 8.2k ohm R 620 119-1841-15 1/16W 180k ohm
R 205 119-1031-15 1/16W 10k ohm R 454 119-2231-15 1/16W 22k ohm R 622 119-2231-15 1/16W 22k ohm
R 206 119-1031-15 1/16W 10k ohm R 455 119-2231-15 1/16W 22k ohm R 624 119-3311-15 1/16W 330 ohm
R 207 119-1021-15 1/16W 1k ohm R 456 119-2231-15 1/16W 22k ohm R 625 119-1521-15 1/16W 1.5k ohm
R 208 119-4731-15 1/16W 47k ohm R 457 119-2231-15 1/16W 22k ohm R 626 119-1011-15 1/16W 100 ohm
R 209 119-1531-15 1/16W 15k ohm R 462 119-3311-15 1/16W 330 ohm R 627 119-1811-15 1/16W 180 ohm
R 210 119-1031-15 1/16W 10k ohm R 463 119-3311-15 1/16W 330 ohm R 628 119-1811-15 1/16W 180 ohm
R 211 119-4731-15 1/16W 47k ohm R 464 119-3311-15 1/16W 330 ohm R 629 119-1811-15 1/16W 180 ohm
R 213 116-2291-15 1/4WS 2.2 ohm R 465 119-3311-15 1/16W 330 ohm R 630 119-1811-15 1/16W 180 ohm
R 214 116-2291-15 1/4WS 2.2 ohm R 468 119-1021-15 1/16W 1k ohm R 631 119-2711-15 1/16W 270 ohm
R 215 116-1511-15 1/4WS 150 ohm R 469 119-1021-15 1/16W 1k ohm R 633 119-2221-15 1/16W 2.2k ohm
R 220 119-1221-15 1/4WS 1.2k ohm R 500 119-1021-15 1/16W 1k ohm R 634 119-2221-15 1/16W 2.2k ohm
R 221 119-1031-15 1/16W 10k ohm R 501 119-1021-15 1/16W 1k ohm R 635 119-1041-15 1/16W 100k ohm
R 222 119-2221-15 1/16W 2.2k ohm R 502 119-1021-15 1/16W 1k ohm R 637 119-4721-15 1/16W 4.7k ohm
R 223 119-2221-15 1/16W 2.2k ohm R 503 119-1021-15 1/16W 1k ohm R 638 119-4731-15 1/16W 47k ohm
R 225 119-1031-15 1/16W 10k ohm R 504 119-4721-15 1/16W 4.7k ohm R 639 119-4731-15 1/16W 47k ohm
R 226 116-1221-15 1/4WS 1.2k ohm R 505 119-4721-15 1/16W 4.7k ohm R 641 119-1021-15 1/16W 1k ohm
R 229 116-1521-15 1/4WS 1.5k ohm R 522 119-1021-15 1/16W 1k ohm R 642 119-1021-15 1/16W 1k ohm
R 230 119-1031-15 1/16W 10k ohm R 523 119-8221-15 1/16W 8.2k ohm R 643 119-2711-15 1/16W 270 ohm
R 231 119-3321-15 1/16W 3.3k ohm R 524 119-2231-15 1/16W 22k ohm R 801 119-1231-15 1/16W 12k ohm
R 232 119-1031-15 1/16W 10k ohm R 526 119-1021-15 1/16W 1k ohm R 802 119-1031-15 1/16W 10k ohm
R 233 119-1021-15 1/16W 1k ohm R 532 119-1021-15 1/16W 1k ohm R 803 119-3321-15 1/16W 3.3k ohm
R 308 032-0140-64 1/10W 43k ohm R 544 119-3311-15 1/16W 330 ohm R 804 119-3331-15 1/16W 33k ohm
R 309 032-0140-64 1/10W 43k ohm R 600 119-3321-15 1/16W 3.3k ohm R 805 119-1041-15 1/16W 100k ohm
R 310 032-0140-64 1/10W 43k ohm R 601 119-4731-15 1/16W 47k ohm R 806 119-2211-15 1/16W 220 ohm
R 311 032-0140-64 1/10W 43k ohm R 602 119-4721-15 1/16W 4.7k ohm S 600 013-6103-00 RESET
R 312 032-0140-89 1/10W 47k ohm R 603 116-6801-15 1/4WS 68 ohm SUP1 060-0122-91 DSP-141N-S00B
R 313 032-0140-89 1/10W 47k ohm R 604 119-1031-15 1/16W 10k ohm T 201 009-9006-70 CHOKE
R 314 032-0140-89 1/10W 47k ohm R 605 119-1031-15 1/16W 10k ohm VR101 012-4431-13 470K
R 315 032-0140-89 1/10W 47k ohm R 606 119-5621-15 1/16W 5.6k ohm X2 061-9013-00 7.2MHz
R 316 119-1041-15 1/16W 100k ohm R 615 119-4721-15 1/16W 4.7k ohm X 601 060-1533-90 10MHz
R 317 119-1021-15 1/16W 1k ohm R 616 119-4721-15 1/16W 4.7k ohm X 801 061-9011-00 4.332MHZ
R 318 119-1021-15 1/16W 1k ohm R 617 119-1041-15 1/16W 100k ohm PWB 039-2632-00 PWB
(
WITHOUT
R 319 119-1041-15 1/16W 100k ohm R 619 119-1031-15 1/16W 10k ohm COMPONENT
)
DXZ558RMP
-15-

CD PWB (B5) section: 929-0301-83
LED PWB (B6) section: 929-0301-83
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R 773 119-8211-15 1/16W 820 ohm S 707 013-6312-50 SWITCH S 716 013-6312-50 SWITCH
R 790 119-4711-15 1/16W 470 ohm S 708 013-6312-50 SWITCH S 717 013-6312-50 SWITCH
R 791 119-5611-15 1/16W 560 ohm S 709 013-6312-50 SWITCH S 718 013-6312-50 SWITCH
S 701 013-6312-50 SWITCH S 711 013-6312-50 SWITCH S 720 013-6312-50 SWITCH
S 702 013-6312-50 SWITCH S 712 013-6312-50 SWITCH S 721 013-6312-50 SWITCH
S 704 013-6312-50 SWITCH S 713 013-6312-50 SWITCH VR720 016-9900-85 ENCODER-SW
S 705 013-6312-50 SWITCH S 714 013-6312-50 SWITCH PWB 039-2633-00 PWB
(
WITHOUT
S 706 013-6312-50 SWITCH S 715 013-6312-50 SWITCH COMPONENT
)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 1 168-1042-78 16V 0.1uF C 134 168-1042-78 16V 0.1uF R 6 033-3911-15 1/10W 390 ohm
C4 168-1042-78 16V 0.1uF C 135 045-6801-50 50V 68
p
FR 7 033-4731-15 1/10W 47k ohm
C5 046-1032-78 0.01uF C 136 178-1052-78 1uF R 8 033-1051-15 1/10W 1M ohm
C9 046-4722-58 4700
p
FC 138 168-1042-78 16V 0.1uF R 9 033-3311-15 1/10W 330 ohm
C10 045-1011-50 100
p
FC 139 168-1042-78 16V 0.1uF R 12 033-4731-15 1/10W 47k ohm
C13 168-1042-78 16V 0.1uF C 140 046-6812-58 680
p
FR 13 033-1041-15 1/10W 100k ohm
C16 168-1042-78 16V 0.1uF C 142 178-1052-78 1uF R 14 033-4721-15 1/10W 4.7k ohm
C17 046-1032-78 0.01uF C 144 042-0560-85 6.3V 100uF R 15 033-4721-15 1/10W 4.7k ohm
C18 178-1052-78 1uF C 145 168-1042-78 16V 0.1uF R 16 033-1021-15 1/10W 1k ohm
C19 046-1032-78 0.01uF C 146 168-1042-78 16V 0.1uF R 17 033-1021-15 1/10W 1k ohm
C20 168-1042-78 16V 0.1uF C 147 178-1052-78 1uF R 19 033-4731-15 1/10W 47k ohm
C21 042-0595-53 4V 220uF C 148 042-0595-53 4V 220uF R 20 033-4731-15 1/10W 47k ohm
C22 168-1042-78 16V 0.1uF C 149 163-1073-35 16V100uF R 23 033-2211-15 1/10W 220 ohm
C23 168-1042-78 16V 0.1uF C 150 168-1042-78 16V 0.1uF R 24 033-4731-15 1/10W 47k ohm
C24 046-1032-78 0.01uF C 151 178-1052-78 1uF R 28 033-6841-15 1/10W 680k ohm
C25 045-8097-50 8
p
FC 200 178-1052-78 1uF R 29 033-6841-15 1/10W 680k ohm
C26 045-8097-50 8
p
FCCT 1 050-0145-54 1/16W 47kohm x4 R 30 033-1041-15 1/10W 100k ohm
C27 042-0416-52 10V 10uF TAN CCT 2 050-0145-58 2.2k ohm x 4 R 31 033-1031-15 1/10W 10k ohm
C28 046-1032-78 0.01uF CCT 3 050-0140-63 1/32W 47kohm x4J R 32 033-1031-15 1/10W 10k ohm
C29 168-1042-78 16V 0.1uF CCT101 050-0140-68 1/32W 3.3kohm x4J R 33 033-1031-15 1/10W 10k ohm
C30 045-1201-50 12
p
FD 1 001-2610-90 RB480KTL R 34 033-6831-15 1/10W 68k ohm
C31 168-1042-78 16V 0.1uF D 2 001-2610-90 RB480KTL R 35 033-6831-15 1/10W 68k ohm
C32 046-1032-78 0.01uF D 3 001-2610-90 RB480KTL R 36 033-3311-15 1/10W 330 ohm
C33 046-1032-78 0.01uF D 4 001-2610-90 RB480KTL R 43 033-4731-15 1/10W 47k ohm
C34 046-1032-78 0.01uF D 5 001-2610-90 RB480KTL R 44 033-4731-15 1/10W 47k ohm
C35 046-1022-58 1000
p
FD 6 001-2610-90 RB480KTL R 45 033-4731-15 1/10W 47k ohm
C 102 163-1073-35 16V100uF D 101 001-0367-91 1SS226 R 101 033-1231-15 1/10W 12k ohm
C 103 046-4722-58 4700
p
FIC 1 051-7518-18 SN74LVC139APWR R 102 033-3321-15 1/10W 3.3k ohm
C 104 046-1032-78 0.01uF IC 2 051-3315-90 TPS76316DBVR R 103 033-3331-15 1/10W 33k ohm
C 105 168-1042-78 16V 0.1uF IC 3 051-7239-38 SN74AHCT08PWR R 104 033-4731-15 1/10W 47k ohm
C 106 168-1042-78 16V 0.1uF IC 5 051-5441-08 BD4828G-TR R 105 033-4731-15 1/10W 47k ohm
C 107 042-0416-52 10V10uF TAN IC 6 051-6700-00 TMS320DA140 R 106 033-2211-15 1/10W 220 ohm
C 108 168-1042-78 16V 0.1uF IC 10 052-5055-33 MBM29DL800B- R 107 033-2211-15 1/10W 220 ohm
C 109 168-1042-78 16V 0.1uF A90PFTN R 108 033-1021-15 1/10W 1k ohm
C 110 168-1042-78 16V 0.1uF IC 11 051-6919-08 NJU6391PE R 109 033-1021-15 1/10W 1k ohm
C 111 168-1042-78 16V 0.1uF IC 12 051-7221-58 SN74AHC1G04- R 110 033-4731-15 1/10W 47k ohm
C 112 168-4732-78 0.047uF HDCKR R 115 033-0000-05 1/10W 0 ohm
C 113 168-4732-78 0.047uF IC 13 051-7280-38 TC7SU04FU-TE85L R 116 033-5621-15 1/10W 5.6k ohm
C 114 168-1042-78 16V 0.1uF IC 14 051-7280-38 TC7SU04FU-TE85L R 117 033-4731-15 1/10W 47k ohm
C 115 045-4701-50 47
p
FIC 101 051-6069-08 FAN8047G3 R 118 033-3341-15 1/10W 330k ohm
C 116 046-4712-58 470
p
FIC 102 051-6399-00 TC94A15F R 119 033-2231-15 1/10W 22k ohm
C 117 046-4712-58 470
p
FJ 1 074-1138-65 15P R 120 033-2231-15 1/10W 22k ohm
C 118 168-1042-78 16V 0.1uF J 2 074-1138-60 10P R 121 117-1001-15 1/10W 10 ohm
C 119 168-1042-78 16V 0.1uF J 3 074-1237-70 20P R 122 033-2211-15 1/10W 220 ohm
C 120 046-1532-78 0.015uF Q 1 131-1188-50 2SB1188PQR R 123 117-6811-15 1/10W 680 ohm
C 121 046-6822-58 6800
p
FQ 2 125-2004-92 RN1402 R 124 032-0162-50 1/10W 0.51 ohm
C 122 168-1042-78 16V 0.1uF Q 101 131-1188-50 2SB1188PQR R 126 033-1021-15 1/10W 1k ohm
C 123 046-1032-78 0.01uF Q 102 131-1188-50 2SB1188PQR R 127 033-1021-15 1/10W 1k ohm
C 126 046-3332-78 0.033uF R 1 033-4721-15 1/10W 4.7k ohm R 130 033-1051-15 1/10W 1M ohm
C 127 046-4722-58 4700
p
FR 2 033-1041-15 1/10W 100k ohm TM101 073-0768-90 TERMINAL
C 130 168-1042-78 16V 0.1uF R 3 033-1041-15 1/10W 100k ohm X 1 061-3534-90 16.92MHz
C 131 046-1522-58 1500
p
FR 4 033-1031-15 1/10W 10k ohm PWB 039-2429-21 PWB
(
WITHOUT
C 132 168-1042-78 16V 0.1uF R 5 033-2231-15 1/10W 22k ohm COMPONENT
)
C 133 046-1532-78 0.015uF
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D 11 001-7058-90 AN1105W-RR Q 11 060-4015-90 PS1192H S 2 013-7413-50 LIMIT
D 12 001-7058-90 AN1105W-RR Q 12 060-4015-90 PS1192H PWB 039-1944-21 PWB
(
WITHOUT
J 4 074-1138-60 10P S 1 013-7414-50 CHUCKING COMPONENT
)
-16-
DXZ558RMP

Caution: COMPONENT SIDE: Parts on the component side seen
from the component side are indicated.
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.
COMPONENT SIDE
PRINTED WIRING BOARD 1/4
Switch PWB(B4) section
DXZ558RMP
-17-
SOLDER SIDE
TO J703 OF SUB PWB (B2) PAGE 20
1
2
15
16
1
17
33
49

PRINTED WIRING BOARD 2/4
CD PWB(B5) / LED PWB(B6) section
-18-
DXZ558RMP
LED PWB-B(B6)
LED PWB-A(B6)
SPD-MOTOR-ASSY
SMA-182-100
POW-MOTOR-ASSY
SMA-183-100
PICK UP-ASSY
FLAT WIRE
816-2624-50
CD PWB(B5)
Caution:
COMPONENT SIDE: Parts on the component side seen
from the component side are indicated.
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.
COMPONENT SIDE
SOLDER SIDE
SOLDER SIDE
TO J900 OF Main PWB(B1) PAGE 19
GRN
ORG
BLK
RED
BLU
PUR
YEL

1
2
3
4
5
6
7
8
9
10
11
12
13
1
224
25
23 18 10 1
1
1
3
4
5
26
51 14
5
8
75
100
12
1
218
17
1
120
112
13
24
1
4
58
13
4
5
1
12 13 24
1
4
58
1
8
916
TO J3 OF CD PWB (B5)
PAGE 18
ICQ
15
5
1
BRN
RED
ORG
YEL
J201
A1
A4A6
A5
A8
A7
B1
B2
B3
B4
B5
B6
B7
B8
ILLUMI
BACK UP
PHONE
---
---
B1 B3 B5 B7
B2 B4 B6 B8
A1 A3 A5 A7
A2 A4 A6 A8
A8
A7
A6
A5
A4
REMOTE
A3
A2
A1
ACC
GND B8
B7
B6
B5
B4
B3
B2
B1
FL-
FR-
RR+
FL+
RL+
RL-
RR-
FR+
J201
A
B
AB
1
2
3
4
5
6
7
8
9
10
11
12
13
GND
BUS 14V
L-CH (+)
BUS (+)
R-CH (+)
R-CH (-)
SYS-ACC
BUS (-)
L-CH (-)
ILLUMI
WHT
RED
RED
WHT
RED
WHT
BLK
GRY
RED
855-5478-50
LEFT
RIGHT
LEFT
RIGHT
LEFT
RIGHT
FRONT
REAR
AUX-IN
FR
FL
GND
RR
RL
R-GND
AUX-R
L-GND
AUX-L
LINE OUT
AUX-IN
GND
-19-
PRINTED WIRING BOARD 3/4
Main PWB(B1) section1/2
Sub PWB(B2) section1/2
ISO PWB(B3) section
DXZ558RMP
MAIN PWB(B1)
SUB PWB(B2)
COMPONENT SIDE
SOLDER SIDE
218
17
1
Caution:
COMPONENT SIDE: Parts on the component side seen
from the component side are indicated.
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.

12
3456
78910
11 12
13
1
2
24
25
23 18 10 1
1
12
2
18
17 1
1
20
218
17
1
PRINTED WIRING BOARD 4/4
Main PWB(B1) section 2/2Sub PWB(B2) section 2/2
-20-
SUB PWB(B2)
Main PWB(B1)
SOLDER SIDE
TO P701 OF SW PWB (B4) PAGE 17
COMPONENT SIDE
Caution:
COMPONENT SIDE: Parts on the component side seen
from the component side are indicated.
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.
DXZ558RMP
