Clarion TTX7502z Repair manual

Expanded TV Tuner
Syntoniseur TV étend
TV-Tunermodul
Sintonizzatore TV ingrandito
Uitgebreide TV-tuner
Sintonizador de TV ampliado
Utvidgad TV-tuner
Sintonizador de televisão alargado
TTX7502z
Owner’s Manual / Installation Manual
Manuel de l’utilisateur / Manuel d’installation
Bedienungs- & Installationsanleitung
Manuale del proprietario e manuale di installazione
Gebruiks- & Installatiehandleiding
Manual del propietario / Manual de Instalación
Bruks- och installationsanvisning
Manual do Proprietário e Manual de Instalação
Thank you for purchasing the ClarionTTX7502z.
Nous vous remercions d’avoir acheté le ClarionTTX7502z.
Vielen Dank für den Kauf des ClarionTTX7502z.
Grazie per aver acquistato il ClarionTTX7502z.
Wij danken u voor de aanschaf van de ClarionTTX7502z
Muchas gracias por la adquisición del TTX7502z Clarion.
Tack för att du köpt en ClarionTTX7502z.
Gratos pela aquisição de ClarionTTX7502z.
English
Français
Deutsch
Italiano
Nederlands
Español
Svenska
Português
Clarion Co.,Ltd.
MADE IN CHINA
286-9220-20
SERIAL No.
ZT-4610E
VHF 45.75MHz-224.25MHz
UHF 471.25MHz-855.25MHz
ISO
8mmMAX
12V GROUND
Expand TV Tuner
TTX7502z
MODEL
e13 020426
EMCTYPE 544610
TTX7502z_Top 04.8.16, 11:26 AM3

•Please read this Owner’s manual & Installa-
tion manual in its entirety before proceeding
with wire connection and installation.
•After reading this manual, be sure to keep it in
a handy place (e.g., glove compartment).
If you sell the motor vehicle, please leave the
manual in it so that the new owner can use it.
•Read the contents of the enclosed warranty
card and keep it with this manual.
■ Contents
1. PRECAUTIONS ........................................4
2. PACKAGE CONTENTS ............................4
3. SET COUNTRIES LIST ............................5
4. SPECIFICATIONS ....................................6
5. TROUBLESHOOTING ..............................7
6. INSTALLATION.........................................8
7. CAUTIONS ON WIRING ........................... 8
8. WIRING CONNECTIONS .........................9
2TTX7502z
English
English
Français
Deutsch
Italiano
Nederlands
Español
Svenska
Português
•Vor Einbau und Anschluß des Geräts
unbedingt die Einbau- und Betriebsanleitung
vollständig durchlesen.
•Bewahren Sie diese Betriebsanleitung nach
dem Durchlesen griffbereit an einem
geeigneten Ort (z.B. im Handschuhfach) auf.
Lassen Sie bitte diese Betriebsanleitung bei
einem Verkauf des Fahrzeugs für den
Nachbesitzer im Wagen.
•Lesen Sie die beiliegende Garantiekarte genau
durch und bewahren Sie sie zusammen mit
dem Handbuch auf.
■ INHALT
1. VORSICHTSMASSNAHMEN ................. 17
2. LIEFERUMFANG .................................... 17
3. VORPROGRAMMIERTE LÄNDER-SENDERLISTE .... 17
4. TECHNISCHE DATEN ............................18
5. FEHLERSUCHE .....................................19
6. EINBAU ...................................................20
7. VORSICHTSMASSNAHMEN BEIM ANSCHLIESSEN .. 21
8. KABELVERBINDUNGEN ....................... 22
Deutsch
•Veuillez lire entièrement le mode d’emploi et
le manuel d’installation avant de procéder aux
connexions et à l’installation.
•Après avoir lu ce mode d’emploi, prenez soin
de le conserver dans un endroit pratique (par
ex: la boîte à gants).
Si vous vendez votre véhicule à moteur,
laissez-y le manuel de façon que le nouveau
propriétaire puisse l’utiliser.
•Lisez le contenu de la carte de garantie com-
prise et conservez-la avec ce manuel.
■ Table des matières
1. PRECAUTIONS ......................................10
2. CONTENU DE L’EMBALLAGE .............. 10
3. LISTE DES PAYS SÉLECTIONNÉS ......11
4. SPECIFICATIONS ..................................12
5. RECHERCHE DE PANNES .................... 13
6. INSTALLATION.......................................14
7. PRECAUTIONS POUR L’INSTALLATION
DES CABLES .....................................15
8. CONNEXION DE CABLAGE .................. 16
Français
•Si raccomanda di leggere completamente il
presente Manuale d'Istruzioni e Installazione
prima di procedere con i collegamenti e
l'installazione dell'apparecchio.
•Una volta letto, il presente manuale dev'essere
tenuto a portata di mano (per esempio nel
cassetto portaoggetti).
Se vendete la vostra vettura, consegnate
anche il manuale affinché il nuovo proprietario
lo possa utilizzare.
•Leggere il contenuto della scheda di garanzia
allegata, e conservarla sempre insieme al
manuale.
■ Indice
1. PRECAUZIONI ........................................23
2. CONTENUTO DELLA CONFEZIONE.... 23
3. ELENCO DEI PAESI DA IMPOSTARE .. 24
4. SPECIFICHE ...........................................25
5. RICERCA GUASTI .................................26
6. INSTALLAZIONE .................................... 27
7. PRECAUZIONI RELATIVE AI CABLAGGI ... 27
8. COLLEGAMENTI.................................... 28
Italiano
TTX7502z_Top 04.8.16, 11:26 AM4

4TTX7502z
English
INFORMATION FOR USERS:
CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BYTHE MANUFACTURER
WILL VOID THE WARRANTY.
1. PRECAUTIONS
•This equipment uses DC 12 V only. Do not
use this equipment on 24 V vehicles such
as large trucks.
•When driving, keep the TV tuner volume
down to a level where you can hear sounds
from outside the vehicle.
•If a problem occurs such as entry of a
foreign object, water gets into the tuner, or
it produces smoke or strange smells, stop
using the tuner immediately, and consult
your dealer.
■Tuner Handling
•Disconnecting the cables while the system is
operating may cause a system breakdown.
Always turn off the power (ACC-OFF) before
you disconnect the cables.
•If the power supply to the system is stopped
due to battery replacement, etc., the details
you have entered into the microcomputer
memory may be erased and the settings may
return to the default settings. If this occurs,
enter your settings again.
■Reception
•If your vehicle is outside the broadcast
transmission range, the radio waves will
become weak and reception will deteriorate.
UHF stations and regional broadcast stations
output a comparatively weak radio
transmission, so the reception conditions may
get worse while driving over a distance of only
a few kilometers.
•The screen image may be disturbed and output
noise due to train lines, high voltage power
lines and traffic signal lights.
•This equipment does not have a display
function, so the screen will be black during
driving.
2. PACKAGE CONTENTS
1. TV tuner unit (TTX7502z)
2. User’s Manual / Installation Manual .................................................................................................. 1
3. CeNET cable (2.5 m) ......................................................................................................................... 1
4. Picture RCA cable (2.5 m) ................................................................................................................. 1
5. Accessories Bag ................................................................................................................................ 1
6. PKG connection cable ....................................................................................................................... 1
TTX7502z_Eng 04.8.16, 11:24 AM4

TTX7502z 5
English
3. SET COUNTRIES LIST
The TV AREA function can be used to set the following country areas.
No. Set Countries Display Title
0ALBANIA
1AUSTRIA
2BELGIUM
3BOSNIA I H
4CZECH
5DENMARK
6FINLAND
7GERMANY
8HUNGARY
9ICELAND
10 IRELAND
11 ITALY
12 NETHERLNDS
13 NORWAY
14 PORTUGAL
15 RUMANIA
16 SLOVAKIA
17 SLOVENIA
18 SPAIN
19 SWEDEN
20 SWITZERLND
21 TURKEY
22 UK
23 AFGHAN.
24 ALGERIA
25 ANGOLA
26 AUSTRALIA
27 BAHRAIN
No. Set Countries Display Title
28 CHINA
29 N.KOREA
30 GHANA
31 HONGKONG
32 INDIA
33 INDONESIA
34 ISRAEL
35 JORDAN
36 KENYA
37 KUWAIT
38 LIBERIA
39 MALAYSIA
40 MOLDIVES
41 N.ZEALAND
42 NIGERIA
43 OMAN
44 PAKISTAN
45 QATAR
46 SINGAPORE
47 S.AFRICA
48 SRILANKA
49 SUDAN
50 THAILAND
51 U.ARABE.
52 UGANDA
53 YEMEN
54 ZAMBIA
TTX7502z_Eng 04.8.16, 11:24 AM5

6TTX7502z
English
4. SPECIFICATIONS
Reception channels: VHF CCIR 2 to 12ch
UHF CCIR 21 to 69ch
Antenna input: 75 Ωunbalanced
voltage: 14.4 V
Grounding: Negative terminal grounding
Power consumption: 0.4 A or less
External dimensions: 7" (Width) ✕1" (Height) ✕4.9" (Depth)
[178 mm (Width) ✕25 mm (Height) ✕125 mm(Depth)]
Weight: 1.1 lb. (0.5 kg)
*The specifications and design may be subject to change without prior notice due to improvements.
7" (178mm)
0.26" (6.6mm)
4.9" (125mm)
1" (25mm)
TTX7502z_Eng 04.8.16, 11:24 AM6

TTX7502z 7
English
5. TROUBLESHOOTING
The following symptoms may not be the result of a breakdown, so perform the remedy suggested
below before contacting your Dealer for repairs.
Check the wiring method in the manual again,
then connect the wiring properly.
Check that the parking brake is engaged
completely.
Check the connection method in the manual
again, then connect the wiring properly.
The transmission may not be reaching you
properly because you are in a valley or the
shadow of a building. Check again at a location
where the transmission can reach you properly.
The image may be affected by transmission
reflected from
mountains or buildings. Change your location or
the reception
direction.
Reception may be affected by radio interference
from another
vehicle, a train, high voltage or neon signs.
Check your
reception again at another location.
No power
No image
Unclear image from
rear seat monitor
Image is unclear
Double or triple image
Image is spotty or
striped
Wiring is incomplete.
Parking brake is not engaged.
Image output for front and
rear is connected in reverse.
Poor reception
Poor reception
Electrical interference
Symptom Cause Remedy
TTX7502z_Eng 04.8.16, 11:24 AM7

8TTX7502z
English
6. INSTALLATION
■Installation Using Screws
1. When using the installation holes at the sides
of the unit, use M4 ✕8 screws. Using screws
other than the specified screws may cause a
malfunction.
2. If you are going to drill holes in the dashboard,
make sure beforehand that there are no
harnesses behind the dashboard at that
position or nearby.
Max. 5/16" (8mm)
Chassis
■Installation Using Velcro Tape
1. Apply Velcro tape to the bottom surface of the
unit.
2. Attach the unit to the floor carpet beneath the
seat.
ClarionCo.,Ltd.
MADEIN CHINA
286-9220-20
SERIALNo.
ZT-4610E
VHF45.75MHz-224.25MHz
UHF471.25MHz-855.25MHz
ISO
8mmMAX
12VGROUND
ExpandTVTuner
TTX7502z
MODEL
e
13 020426
EMCTYPE 544610
7. CAUTIONS ON WIRING
Pay particular attention to the following points when laying out the cords.
•Keep the unit’s cables as far away as possible from the vehicle’s wiring bundles.
•Keep the unit’s RCA pin cord and the power cord separated as far as possible.
CAUTION
•Disconnect the battery negative cable before connecting the wiring.
•If you are making holes in the vehicle body in order to install the unit, first confirm the
position of pipes, tanks and electrical wiring to avoid contact and interference.
•When installing the wiring for connection cords on a vehicle equipped with airbags, do
not install the wiring where it may affect the airbag system.
•Do not cover the ventilation holes and heat-radiating parts of the tuner.
CAUTION
•When you have finished connecting the cords, secure them with clamps and insulating
tape for protection.
•Make sure that the connection cables will not get caught on burrs and edges of the metal
parts under the seat. It could damage the cables and cause noise from the unit.
•To assist safe driving, connect the parking brake connection terminal to the lead wire on
the lamp side of the parking brake lamp switch.
TTX7502z_Eng 04.8.16, 11:24 AM8

TTX7502z 9
English
8. WIRING CONNECTIONS
Connect the unit as follows.
Notes:
*1 Connect the cable to the terminal of equipment (center unit) that is connected by connection cables
(CeNET cable) with the L-shaped terminals.
*2 Connection requires a CCA-389 conversion cord (RCA3P →mini DIN8P) which is sold separately.
*3 If you are connecting an antenna other than a 4 system diversity antenna, connect it to the MAIN
terminal on the far right.
*4 Connect the terminal to the lead wire on the lamp side of the parking brake lamp switch. After
connection, apply the parking brake, then check that the TV displays an image.
• If the PKG cable is not connected to the side brake, some units may not operate.
CENTER UNIT(VRX6570z)
SOURCE UNIT (TTX7502z)
For connection of the Clarion CD changer (sold separately) for CeNET use.
For connection of the rear seat monitor (sold separately).
For connection of the monitor (such as the Clarion VMA8582, sold separately).
Supplied image RCA cable (∗ 1)
For connection of a video appliance (∗ 2) such as a handy camera (sold separately).
For connection of a Clarion security camera (sold separately).
Antenna MAIN terminal
Terminal (∗ 4) for connection
to parking brake.
Supplied PKG cable
To parking brake
NAVI/CCD terminal.
Supplied CeNET cable (∗ 1)
For connection (∗ 3) of a Clarion
antenna such as ZCA407 (sold
separately).
*For connection of VRX6570z, connect the CCD camera to the
NAVI/CCD terminal of VRX6570z.
TTX7502z_Eng 04.8.16, 11:24 AM9
