Clarke Start-N-Charge BC420N Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS GC0514
HEAVY DUTY BATTERY
BOOSTERS / CHARGER
MODEL No. BC420N
HEAVY DUTY BATTERY
BOOSTERS / CHARGER

For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
or e-mail as follows:
PARTS: [email protected]
SERVICE: [e-mail]
22
22
2
SPECIFICATIONS
Supply Voltage 230
Max Charge (Amps) 60 (cont)
Max Boost (Amps) 400
Boost/Charge (Volts) 12/24
Internal Fuse Part No. EM22220012
Part No. 6225051
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.
ENVIRONMENTAL RECYCLING POLICY

Thank you for purchasing this CLARKE Battery Charger. This unit is suitable for
charging and boosting 12 or 24 Volt lead acid batteries.
Before attempting to operate the unit, please read this instruction manual
thoroughly, and follow all directions carefully. By doing so you will ensure the safety
of yourself, and others around you, and at the same time, you should look forward
to the unit giving long and trouble free service.
GUARANTEE
This product is guaranteed against faults in manufacture for 12 months from date
of purchase. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been found to have been abused in
any way, or not used for the purpose for which it was intended, or to have been
tampered with in any way. The reason for return must be clearly stated.
This guarantee does not affect your statutory rights.
CONTENTS PAGE
Specifications ...................................................................................2
Parts and Service Contacts ............................................................2
Safety Precautions ........................................................................... 4
Electrical Connections .................................................................... 5
Parts Identification ...........................................................................5
Procedure For Normal Charging .................................................. 6
Procedure For Normal Charging with Timer ................................6
Procedure For Engine Starting .......................................................7
Parts Lists & Diagrams ......................................................................12 - 13
Wiring Diagrams ...............................................................................14
33
33
3

IMPORTANT: SAFETY PRECAUTIONS
PLEASE READ BEFORE USING THIS UNIT
1.
WARNING :Some electronic equipment can be damaged by boost
charging or use of start facility. Check your vehicle handbook before using
your Start ’N’ Charge. If in doubt consult the vehicle manufacturer.
Nevertheless, you should not operate this equipment unless you are fully
conversant with vehicle electrical systems, and battery charging techniques.
2. WARNING :Because highly inflammable hydrogen gas is released in the
process of battery charging, please remember to switch OFF the charger
first, and so avoid sparking which will occur when CONNECTING OR
DISCONNECTING LIVE LEADS.
3. Black negative (-ve) lead must always be clipped to the negative, and Red
positive (+ve) lead must always be clipped to the positive.
When charging with battery installed in vehicle, or boosting, FIRST connect the
appropriate lead to the UNEARTHED battery terminal (on most modern cars this
is the positive (+ve) terminal), then connect the other lead to the chassis (or a
suitable engine bolt) away from the battery and fuel line. It is advisable to
disconnect the unearthed terminal from the battery, when charging in situ.
When disconnecting, remove the chassis lead FIRST, then the battery lead.
4. To prevent battery overheating and consequent damage, use the BOOST
facility sparingly and do not exceed our recommendations.
5. Battery acid is highly corrosive. If spillage occurs, wipe off immediately and
wash copiously with water. Particularly avoid contact with the eyes, but if this
occurs, you must seek medical advice.
6. When charging is completed, ensure that the vehicle battery leads are
secured to the proper terminals which should be clean and lightly smeared
with petroleum jelly to prevent corrosion. Finally, re-check the electrolyte level.
7. Do not expose this unit to rain.
8. Never touch together the negative and positive leads on this unit whilst the
unit is switched on.
9. Never attempt any electrical or mechanical repair. If you have a problem
with your machine contact your local dealer for service information.
10. WARNING : Certain types of sealed or maintenance-free batteries need
extra care when charging. Please consult battery manufacturers instructions
before using this unit.
11. WARNING : Since toxic fumes may be released during battery charging,
ONLY USE THIS UNIT IN A WELL VENTILATED AREA.
12. Before charging ensure the battery terminals are clean and that the cells are filled
with electrolyte to the correct level by adding distilled water where necessary.
44
44
4

ELECTRICAL CONNECTION
Connect the three core mains lead to a suitable industrial supply isolator, or heavy
duty plug. These chargers must be connected to a supply having a rated
capacity of greater than 13 Amps.
WARNING: A 13 Amp (BS1363) plug is not suitable.
The maximum input current for this unit is 48amps
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the
coloured markings identifying terminals in your plug proceed as follows:
• Connect GREEN & YELLOW coloured cord to plug terminal marked with a
letter ‘E’ or Earth symbol ‘ ’ or coloured GREEN or GREEN & YELLOW.
• Connect BROWN cord to terminal marked with a letter L or coloured RED
• Connect BLUE cord to terminal marked with a letter N or coloured BLACK
If in doubt, consult a qualified electrician.
PARTS IDENTIFICATION
A - Mains Indicator Lamp
B - Current Control Knob
C - Timer Control Knob
D - 12 V Positive Terminal
E - 24 V Positive Terminal
F - Thermal Overload
Indicator (yellow)
G - Boost Start Indicator (red)
H - Battery Charge Indicator
(green)
Fig. 1
55
55
5
BC420N

PROCEDURE FOR NORMAL CHARGING
NOTE: All references in brackets refer to Fig. 1
1) Before charging or boosting, ensure that the cells are filled with electrolyte to the
correct level by adding distilled water where necessary.
2) Where appropriate we recommend that the non-earthed lead on the battery is
disconnected prior to charging. It is possible that damage may occur to any
electronically controlled system fitted to the vehicle such as engine management,
anti-theft alarm, alternator etc.
3) Check that the mains supply is OFF and the Current Control Knob (B) is in the ‘O’ OFF
position.
4) Connect the appropriate lead to the unearthed battery terminal (on most modern
cars this is positive (+ve) terminal), then connect the other lead to the chassis (or a
suitable engine bolt) away from the battery and fuel line.
NOTE: Ensure the lead is plugged into the 12V or 24V receptacle, depending upon the
voltage of the battery to be charged
5) Remove the battery filler caps during charging in order to prevent the build up of
dangerous gases within the battery.
6) Switch ON the mains supply
7) Turn the Current Control Knob (B) to the position necessary to obtain the required
charge rate, as indicated on the ammeter.
8) Keep the battery on charge until the Ammeter reads zero (or 0-2 amps) or has
stopped moving down, then turn the Current Control Knob (B) to the OFF position.
10) When disconnecting the charger, disconnect 1. supply, 2. chassis conductor
and 3. battery conductor, IN THAT ORDER.
Important:
If the fixed positive lead and the fixed negative lead are connected to the wrong
terminals, then a flash will occur when the 2nd Clamp is attached. Damage to the
charging unit and the battery will be avoided as your START’N CHARGE is fitted with
a polarity protection feature. It will however be necessary to replace the internal
fuse. Remove the black plastic cover on the back panel (marked ‘fuse’) and replace
the burnt fuse with an exact replacement. See ‘Specifications’ for replacement fuses.
CHARGING WITH TIMER
1. Follow the same instructions as for NORMAL CHARGING UP TO AND INCLUDING PARA. 6
2. Turn the timer control knob (C) clockwise to the desired charging time setting.
3. Switch ON the mains supply.
4. Turn the Current Control Knob (B) clockwise to position 5 or 6, to obtain the desired
charging rate as indicated on the ammeter.
66
66
6

77
77
7
Notes on charging procedure.
* A complete charge is best done slowly in order to protect your battery We ecommend
the charging ratebe no more than 10% of the battery capacity rating (AH). eg. a
typical battery has a rating of 40 Ampere Hours, therefore the charging rate should be
4 amps , and a complete charge will take 10 hours.
** If a low current reading (2 amps or less) is seen on the gauge, this may indicate that the
battery is either (a) already fully charged or (b) at the end of its useful life and in need
of replacement. Do not charge the battery for longer than is necessary.
Check the SG of the battery with a hydrometer
PROCEDURE FOR ENGINE STARTING
Note: We recommend that where possible, and before attempting to boost start, you charge
the battery for 10-15 minutes. This will improve the chance of a first time start, particularly
with bigger engines. When the battery is completely flat however, you must charge the
battery for 10-15 minutes before attempting to start, otherwise you may cause damage to
the vehicle electronic systems.
a) Check to ensure the mains supply switch is OFF and the Current Control Switch is in the
OFF (O) position.
b) Connect the cables as for normal charging.
c) Switch ON the mains supply - the green lamp will illuminate.
d) Turn the Current Control Knob to the ‘START’ position.
d) Turn the key in the vehicles ignition to ‘start’.
This equipment is provided with an automatic boost start function. The current required to
start an engine will be detected by the systems’ electronics and supplied to the starter
motor. As the load reduces, the system will compensate accordingly.
Once the engine has started, the system will automatically shut down the boost start function.
At this point, switch the Current Control Knob to the OFF (O) position, and disconnect the
leads from the battery in the same manner as that for normal charging.
NOTE: If the Start and Charge unit is overloaded at any time, a thermal cut out will
automatically come into operation, rendering it inoperative. These models are equipped
with a thermal overload indicator (yellow indicator light) which will illuminate. Allow
approximately 5-10 minutes, or wait for the indicator light to go out before using the unit
again.

PARTS DIAGRAM
88
88
8

99
99
9
PARTS LIST
01 Knob D.38 1 21690318
02 Switch 12A 1 22205133
03 Timer 16A 250V 1 22215001
04 Timer Knob 1 21690034
05 Green Pilot-lamp 220V L=600 1 22610008
06 Ammeter 60A 1 22600018
07 Contactor 220V 10A 1 22225006
08 Upper Control Panel 1 33710272
09 Front Frame 1 21690322
10 Complete Thermostat 1001+ Support 1 04600113
11 Rectifier PMS 20/2/2 CB 1 22400011
12 PVC Input Cable 3x2,5 M.2,5 1 20220020
13 Transformer 1 44105075
14 Thermostat Vebe 1301 1 04600276
15 Lower Panel 1 33700028
16 Black Cable 25sqmm W/Clamp 120 1 43200025
17 Red Cable 25sqmm 2,5M 1 43200024
18 Dinse Plug 25sqmm Cx20 1 22100001
19 Clamps 120A Red-black 1 04600067
20 Wheels-axle D.20 L=488 1 55200001
21 Wheel D.175 Rubber. Hole D.20 2 21625009
22 Handle 1 33725080
23 Fuse Box Cover Dim.60x175 1 21690110
24 Fuse 300A 1 22220011
25 C.P.S. Control P.C.B. 1 22700015
26 Female Dinse Plug 25sqmm 2 22100002
27 Cable Clamp D.10 + Screw 2 04600234
28 Front Panel 1 33700722
29 Cover Panel 1 33705346
No. Description Qty Part No.

WIRING DIAGRAMS
1010
1010
10
