Clarke Contractor CCM135 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC09/22
135L CEMENT MIXER
MODEL NO: CCM135
PART NO: 3400865

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Cement Mixer.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
SPECIFICATION
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended. Faulty goods should be returned to their place of purchase, no
product can be returned to us without prior permission.
This guarantee does not effect your statutory rights.
Model No CCM135
Max drum capacity 135 Litre
Max mixing capacity 100 Litre
Drum speed 25 rpm
Duty cycle classification S6 30%
Drum turning axis 360o
Weight 48 kg
Dimensions: Length x Width x Height 1180 x 713 x 1300 mm
Operating voltage & frequency 230V-50Hz
Rated input wattage 485W
Rated input ampere 2.44A
Power cable length 0.3 m
IP rating IP44D
Sound power guaranteed 91 dB LWA

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY PRECAUTIONS
1. ALWAYS keep the work area clean and well lit. Floors should always be kept
clear. Cluttered or dark areas invite accidents.
2. ALWAYS keep children and bystanders away while operating this machine.
Distractions can cause loss of control.
3. ALWAYS stay alert & do not use a machine while you are tired or under the
influence of medication or alcohol.
4. ALWAYS wear suitable protective clothing and eye protection including
industrial gloves, ear defenders & approved impact resistant safety glasses.
(Eye glasses are NOT safety glasses). Wear a dust mask if handling cement.
5. NEVER over-reach. Keep your proper footing and balance at all times to
enable better control of the machine in unexpected situations.
6. NEVER stand on the machine. Injury could occur from a fall.
7. ALWAYS store machines out of reach of children.
8. ALWAYS read and become familiar with the entire operating manual.
9. NEVER allow persons unfamiliar with this manual to operate this machine.
10. ALWAYS maintain the machine with care and keep it clean for best / safest
performance.
11. NEVER use this machine if any part is damaged. Have it inspected and
repaired by a competent technician.
12. NEVER modify this machine in any way. Use it only for the purpose for which
it is designed.
13. ALWAYS ensure the electrical cable is fully protected and there is no
danger of damage from equipment or materials. Always Inspect the cable
before use and replace if any damage is apparent.
14. ALWAYS avoid inhaling cement dust while loading the mixer. Avoid contact
with cement or any mixing additives being used. Wear gloves/face mask if
necessary.
15. ALWAYS disconnect the machine from the power supply when not in use,
and before carrying out any maintenance.
16. NEVER leave the machine running unattended or leave the machine until it
comes to a complete stop.
17. ALWAYS keep your hands well clear of the rotating drum at all times. Never
put your hands inside the drum when the machine is switched on.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
18. NEVER put any tools or other objects in or around the drum while it is
rotating.
19. NEVER wear jewellery or loose clothing that could be snagged by any part
of the rotating drum.
20. NEVER load the drum when the machine is switched off. Always switch on
and ensure the drum is rotating before loading.
21. NEVER operate this machine on a gradient. Always stand the mixer on firm,
level ground where it cannot tip over.
22. ALWAYS switch off and disconnect from the power supply before moving
the machine around the work site.
23. NEVER use the mixer if the power cable or other important parts of the
machine are damaged.
24. If an extension cable is used, the cable and plug must be of watertight
construction. Inadequate extension cables can be dangerous.
ENVIRONMENTAL RECYCLING POLICY
By purchasing this product, the customer is taking on the obligation to deal
with its safe disposal in accordance with the Waste Electrical and Electronic
Equipment (WEEE).
This means that this product must not be disposed of with general household
waste. It must be disposed of according to the laws governing Waste
Electrical and Electronic Equipment (WEEE) at a recognised disposal facility.
If disposing of this product or any damaged components, do not dispose of
with general waste. This product contains valuable raw materials. Metal
products should be taken to your local civic amenity site for recycling of metal
products.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY SYMBOLS DISPLAYED ON THE MACHINE
Read instruction
manual before use.
Wear eye protection.
Wear protective
gloves.
Wear protective
footwear.
Wear ear protection. Protect the environment
when emptying.
Do not use where the
mixer could tip over.
Keep bystanders at a
safe distance.
Do not operate on
sloping ground.
Always disconnect the
power before starting
any maintenance or
cleaning.
Do not insert anything
into the drum while the
mixer is running.
Do not remove or
tamper with any
protection or safety
device.
Do not remove drive
guard with power
connected.
Do not overload the
mixer.
Pinch point hazard. Do
not insert fingers or
other objects.
Keep hands clear of the
machine when running.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply
through an approved 13 amp BS1363 plug, or a suitably fused isolator switch.
If the plug has to be changed because it is not suitable for your socket or
because of damage, it must be removed and a replacement fitted, following
the wiring instructions shown below. The old plug must be discarded safely as
insertion into a power socket could cause an electrical hazard.
The wires in the mains lead should be
wired up in accordance with the
following colour code:
• Connect the BROWN coloured
wire to the plug terminal
marked with a letter “L”.
• Connect the BLUE coloured wire
to the plug terminal marked
with a letter “N”.
We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD). If you are not sure, consult a qualified
electrician.
DO NOT try to carry out any repairs yourself.
This symbol indicates that this is a Class II product and does not
require an earth connection.
WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS
SUPPLY.
WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
BLUE = NEUTRAL BROWN = LIVE

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
UNPACKING & ASSEMBLY
Remove all components from the packing case and lay them out so that they
can be identified and checked for any possible damage during transit. Should
any component be found to be damaged or missing, please contact your
CLARKE dealer immediately. Check the components against the following list.
1. Mixing blades 5. Stand Legs
2. Drum assembly c/w mixing blades 6. Stand Connector
3. Wheels 7. Fixings Kit (bolts/nuts/washers/pins
R-clips/cotter pins
4. Handlebars

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY
1. Bolt the handles to the main
frame using the nuts & bolts
supplied.
2. Tip the assembly over and slide
the wheels onto each of the axles
securing them with the large
washers and cotter pins suppled.
3. Bolt the mixing blades to the
mixing drum using the short bolts,
nuts and washers supplied.
4. Assemble the stand by sliding the
four legs into the stand connector.
Fasten in place with the pins and
R-clips provided.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. Lift and locate the cement mixer onto
the stand.
• The assistance of another person
will be required to do this.
OPERATION
1. Switch the mixer on by pressing
the green (I) switch on the motor.
Stop by pressing the red (O)
switch.
2. Introduce water first, to prevent
the mixer from clogging.
3. Add cement as required.
4. Add aggregate to suit.
• Do not load the drum when the
machine is switched off. Always set the machine running before
filling.
• Avoid stopping and starting the mixer while there is a heavy weight
of material inside the drum as the extra strain could be harmful to
the motor.
• Keep the drum rotating while emptying the mixture.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. When emptying, remove the
locking pin and tilt the mixer
forward while gripping both
handles tightly.
• Only discharge the mixer when
a suitable receptacle for the
cement mix is in position.
• Do not operate this machine
on a steep gradient. Always
stand the mixer on firm, level
ground where it cannot tip over.
• Always keep water away from the motor and other electrical
components as far as possible.
It is essential that the mixer is kept clean. Dried cement inside the drum will be
very difficult to remove. For the mixer to perform at its best it must be
thoroughly cleaned after every use.
CARE AND MAINTENANCE
BEFORE STARTING WORK
Inspect the power cable and ensure it is free from damage and is not in
danger of being damaged by vehicles, equipment or other operations taking
place on the work site.
AFTER USE
At the end of the working shift it is essential that the machine is hosed down
thoroughly with clean water, being sure to remove all traces of the cement
mix especially from around the mixing blades. The drum may be scoured for a
couple of minutes running using course gravel and water which is then
discharged and the drum finally hosed clean.
Never allow cement residue to harden inside the drum and thereafter be
tempted to beat on the drum with hand tools to dislodge such accumulations
of dried cement.
WARNING: REMEMBER THAT THE CENTRE OF GRAVITY OF THE LOADED
MIXER MAY PRESENT A HAZARD WHEN OPERATING ON UNEVEN GROUND.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
The machine is constructed to IP44D ingress protection which enables the
drum and any other areas to be hosed down safety. However, the motor and
plug should not be hosed directly under pressure.
STORAGE
The mixer can be better stored with the support
stand folded away.
Remove and lower the mixer to the floor with the
help of an assistant. Loosely re-fit the pins and R-
clips into their respective holes for safe keeping.
Leave the mixer with the drum partially inverted to
exclude water or debris and always store the mixer
in a dry place out of reach of children.
OCCASIONALLY
After extensive use, inspect the paint and remove
any rust that may be apparent before touching up
where necessary with a rust resistant paint.
MAINTENANCE FREE ITEMS
The bearings in the machine are sealed for life and require no maintenance.
The drive belt is under constant tension and therefore no adjustment is
required.
CAUTION: OWING TO THE WEIGHT AND BULK OF THE MIXER, TWO
PEOPLE WILL BE REQUIRED TO LOWER THE MIXER AND RE-FIT THE BOLTS.

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
COMPONENT PARTS

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
COMPONENT PARTS LIST
ID DESCRIPTION ID DESCRIPTION
1 Drum 34 Bearing 6206-2RS
2 Nut M10 35 Drum rotating shaft
3 Spring washer M10 36 Circlip 62
4 Washer 10 37 Circlip 15
5 Leather washer 10mm 38 O-ring
6 Screw M10 x 25 39 Drive pinion
7 Mixing blade 40 Pin 6 x 25
8 Nut M6 41 Drive
9 Spring washer 6 42 Bearing 6202-2RS
10 Washer 6 43 Cotter pin 5 x 40
11 Leather washer 6 44 Flat washer
12 Gearwheel 45 Wheel
13 Bolt M6 x 25 46 Frame
14 Bolt M6 x 20 47 R-clip
15 Plastic rotator disc 48 Leg connecting bracket
16 Locknut M8 49 Support leg
17 Washer 8 50 Pin
18 Spring washer 8 51 Wire snap ring
19 Bolt M8 x 25 52 Circlip
20 Handle 53 Bearing 61906-2RS
21 Handle grip 32 dia 54 Drive pulley
22 Washer 55 Nut
23 Spring washer 12 56 Bolt
24 Bolt M12 x 30 57 Locknut
25 ST screw 58 Power cable & plug
26 Motor end plate 59 ST screw
27 Motor seat 60 Switch
28 Bolt M8 x 30 61 Switch seal
29 Drive belt 6PJ-L540 62 Motor cover
30 Motor 63 Decorative cover
31 Adjusting washer 64 ST screw
32 Bearing 6305-2RS 65 Tilt locating pin
33 Circlip 30 66 Pin securing chain

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATIONS OF CONFORMITY-UK

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATIONS OF CONFORMITY-EU
