Clarke EXT 10-15 User manual

Form No. 78052E 11/98 CLARKE TECHNOLOGY Printed in the U.S.A.
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your ALTO machine could
result in injury to you or to other personnel; damage to the machine or to other property could occur as
well. You must have training in the operation of this machine before using it. If your operator(s) cannot
read English, have this manual explained fully before attempting to operate this machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente antes
de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
For new books write to: ALTO U.S. Inc., 2100 Highway 265, Springdale, Arkansas 72764.
Service
Manual
EXT 10-15
Extractor
Order Parts Here:
www.ivie-ent.com/parts
Ph:[phone]

Page 16 CLARKE TECHNOLOGY Ext -10, 15 `Operator's Manual
CLARKETECHNOLOGYEXT-10,15
Main Frame Assembly Drawing 11/98
31
32
55
56
58
24 25
12
23 22
19
53
19
18
53
17
12 13
11 16
15
6
6
10
9
1
3
2
5
6
4
7
8
24 21
23
22 20
29
26 23 27
930
19
53
28 27 23 12 23 33
34
20
53
37
34
36
35
38
14
39
40
6
41
11
42
54
43
44
48
46
4547
14
14
50
49
49 51
51
54
11
43
52
652
43 54
43
44
14
46
44
43 42
40
6
44
43
60 61
59
54
39

CLARKETECHNOLOGYExt-10,15 Owner's Manual Page 17
35 66617A Plate, Q.D. Mounting 1
36 725729 Nipple, 1/8Hex 1
37 737140 Quick Disconnect 1
38 15631A Hose, Assembly, Applicator Ref
39u643418 Gasket, Vacuum Motor 2
40u44906A Motor, Vacuum120 Volt 2
44907A Motor, Vacuum 230 Volt 2
41 674112 Hose, Exhaust 1
42 954010 Wire, Assembly, Ground 2
43u980603 Washer, #10 Shakeproof 8
44u962987 Screw 10-24 x ½ Pn St. 6
45 620281 Adapter, Accessory 1
46 693473 Gasket, Vac Motor, Bottom 2
47 62605A Cover, Frame Bottom 1
48 Serial Plate 1
49 930093 Rivet, 1/8Dia., Pop 8
50 30602A Baffle Assembly, Air Intake 2
51 962109 Screw, 10-24 x 5/8Pn SS 2
52 920200 Nut, 10-24 Hex 2
53 980651 Washer 5/16 Plain 16
54 911933 Terminal 1
55 73276A Label, Spanish 1
56 73277A Label, Water 1
NI 911177 Nut, Wire (Not Shown) 4
NI 899254 Tie, Wire (Not shown) 1
58 66653A Plate, Pump, Adapter 1
59u49310A Lead Asm. (CE Machine only) 2
60u47201A Filter Asm. (CE Machine only) 1
61u69894A Bracket (CE Machine only) 1
NI 962009 Screw 4
NI 81901A Nut, Keps #10-24 4
NI 47802A Terminal, Ring 1
NI 47701A Terminal, ¼ FIFQDC 2
NI 42910A Fuse 1
NI 43004A Fuse Holder 1
NI = Not illustrated
NOTE: uindicates a change has taken place since last
publication of this manual.
1 34003B Main Frame EXT-10/15 1
2 42214A Cord, Power 120 Volt 1
42231A Cord, Power 230 Volt 1
3 38002A Strain, Relief 1
4 672011 Clamp, Strain Relief 1
5 672012 Clamp, cord 1
6 85522A Screw, 10-16 x 1 Pan Hd 19
7 215103 Label, Caution 1
8 215104 Label, Warning 1
9 35114B Hose, Pressure Gauge 1
10 35115A Hose, Vacuum 1
11 672013 Clamp, Hose 4
12 35147A Hose, Intake 4
13 49612A Harness Assembly Ref
14 962957 Screw, 10-16 x ½ PN*ST 16
15 62604A Cover, Upper Chamber 1
16 34217A Gasket, Upper Chamber 1
17 962983 Screw, ¼-20 x 5/8Pn 8
18 692473 Caster, Rear 2
19 962901 Screw, 9/32 -16 x ¾ Hx 16
20 692472 Caster, Front, Swivel 2
21 45905C Pump, 115 Volt 1
45929A Pump, 230 Volt 1
22 692870 Elbow, Swivel 3/8Hose Barb 2
23u50248A Clamp, Hose 5
24 980982 Washer, #10 Plain 10
25 962970 Screw 10-6 x 1¼ Pn Hi-Lo 4
26 69404A Hose, Discharge 1
27 170030 Coupling, ¼ MPT x 1/8MPT 1
28 729221 Tee, ¼ FPT 1
29 851144 Bushing, ¼ MPT x 1/8FPT 1
30 52401A Connector, ¼ Tube x 1/8FPT 1
31 215104 Label, Fire Warning 1
32 73275A Label, Warning, Rain 1
33 50300A Adapter, 1/8FPT to 3/8H1
34 980645 Washer 3
CLARKETECHNOLOGYEXT-10,15
Main Frame Assembly Parts List
11/98
Item # Description Qty. Part No. Item # Description Qty. Part No.

Page 18 CLARKE TECHNOLOGY Ext -10, 15 `Operator's Manual
CLARKETECHNOLOGYEXT-10,15
Tank Assembly Drawing
11/98
5
4
3
1
6
8
7
53 12
51
50
51
52
50
19 13
14 15
16 17 18
22
26 27
28
27 21
20
19
98
29
30
24
25
21
18
32
16
33
34
35
36
37
38
39
40
31 23
41
42
21
43
44
8
48
49
46 47

CLARKETECHNOLOGYExt-10,15 Owner's Manual Page 19
CLARKETECHNOLOGYEXT-10,15
Tank Assembly Parts List
11/98
26 692802 Elbow, 90 Street 1
27 962350 Screw, 10-32 x ½ 4
28 39303A Tube, float Shut-Off 1
29 925596 Pin, Cotter 1/8x 2" 1
30 691304 Ball-Float Shut-Off 1
31 34219A Gasket, Float Tube 1
32 690208 Adapter, Minature Hose 1
33 728535 Strainer, solution Tank 1
34 60306A Adapter, Filter 1
35 833401 Gasket, Drain 1
36 980630 Washer, ¾ ID, Plain 1
37 920264 Nut, ¾-16 x 3/8Hx Jam 1
38 170030 Coupling, ¼ P x 5/8H1
39u50248A Clamp, Hose 1
40 35147A Hose, Intake Ref
41 692701 Deflector 1
42 693406 Gasket, Swivel Coupling 1
43 690212 Adapter, Vac Hose 1
44 85522A Screw, 10-16 x 1 Pan Hd 3
45 920797 Nut, Drain Valve 1
46 733442 Gasket, Drain Valve 1
47 980422 Washer, Drain Valve 1
48 59721A Valve, Drain 1
49 53606A Elbow, 2" x 45° St 1
50 81800A Well Nut 4
51 962113 Screw, 10-32 x 1 Pn Hd 4
52 33300A Enclosure, Bottom 1
53 34238A Gasket, Plate 1
NI 962983 Screw, ¼-20 x 5/88
1 47316B Switch - On/Off 2
2
3 44400B Meter, Hour 120V 1
44401B Meter, Hour 230V 1
4 54204B Gauge, Pressure 1
5 54205B Gauge, Vac 1
6 37304C Plate, Switch & Gauge, EXT10/15 1
7 85811A Screw, 10-24 x ¾ Pn St Blk 6
8 962109 Screw 10-24 x 5/8Pn Hd SS 3
9 692409 Chain, Cover 2
10 83003A Rivet, 1/8Dia. Pop 2
11 920068 Nut, 10-24 Tinnerman 6
12 32317B Cover, Tank, EXT-10/15 1
13 49612B Harness Assembly 1
14 742880 Elbow , 1/8Pipe Thread 2
15 693303 Fitting, 1/8Hose x 1/8Pipe 1
16 52401A Connector, ¼ Tube x 1/8MPT 1
17 35114B Hose, Pressure Gauge Ref
18 694104 Hose, Vac Gauge 1
19 832322 Cover, Solution Tank 2
20 34218A Gasket, Tank Cover 1
21 920296 Nut, 10-24 Elastic-Stop 3
22u38919C Tank, Solution EXT-10 1
38920C Tank, Solution EXT-15 1
23u38916C Tank, Recovery EXT-10 1
38917C Tank, Recovery EXT-15 1
24 35115A Hose, Vac Tank to Base Ref
25 672013 Clamp, 2¾" 1
Item # Description Qty. Part No. Item # Description Qty. Part No.
NOTE:
uindicates a change has been made
since last publication of this manual
since
u
u

Page 20 CLARKE TECHNOLOGY Ext -10, 15 `Operator's Manual
CLARKETECHNOLOGY EXT-10,15
Motor 120V (44906A) Drawing & Parts List
11/96
Item # Qty. Description
Part No.
1 51913A Clip (Optional) 2
2 54809A Housing, Vent 1
3 53905A Fan 1
4 51914A Clamp 2
5 51401A Carbon Brushes 2
6 50618A Commutator End Bracket 1
7 638313 Load Spring 1
8 53100A Disc 1
9 902679 Ball Bearing 1
10 902648 Ball Bearing 1
11 59803A Neoprene Washer 1
12 50610A Fan End Bracket 1
13 58501A Spacer 1
14 53914A Vacuum Fan 2
15 658201 Spacer 1
16 53908A Stationary Fan 1
17 57904A Fan Shell 1
18 980205 Washer 1
19 920329 Nut 1
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

CLARKETECHNOLOGYExt-10,15 Owner's Manual Page 21
CLARKETECHNOLOGYEXT-10,15
Motor 230V-#44907A 11/96
Ref # Part No. Description Qty
1 51913A Clip (Optional) 2
2 54809A Housing, Vent 1
3 53905A Fan 1
4 51914A Clamp 2
5 40813A Carbon Brushes 2
6 50618A Commutator End Bracket 1
7 638313 Load Spring 1
8 53100A Disc 1
9 902679 Ball Bearing 1
10 902648 Ball Bearing 1
11 59803A Neoprene Washer 1
12 50610A Fan End Bracket 1
13 58501A Spacer 1
14 53914A Vacuum Fan 2
15 658201 Spacer 1
16 53908A Stationary Fan 1
17 57904A Fan Shell 1
18 980205 Washer 1
19 920329 Nut 1
20 53906A Fan 1

Page 22 CLARKE TECHNOLOGY Ext -10, 15 `Operator's Manual
CLARKETECHNOLOGYEXT-10,15
Pump 45905C/44906B - 11/96
Ref # Part No. Description Qty
1 55372A Kit, Switch- Viton 80/100 psi 1
2 55374A Kit, Dual Check Valves 1
3 54881A Housing, Upper 1
4 55373A Kit, Valve 1
5 53201A Kit, Diaphragm 1
6 54882A Housing, Lower 1
7 54837A Kit, Drive assembly (45905C) 1
8 15884A Kit, Drive Assembly (45906B) 1

CLARKETECHNOLOGYExt-10,15 Owner's Manual Page 23
CLARKETECHNOLOGYEXT-10,15
Pump 45929A - 11/96
Ref # Part No. Description Qty
1 53056A Kit, Switch- Viton 80/100 psi 1
2 52908A Kit, Check Valve 1
3 54881A Housing, Upper 1
4 59783A Kit, Valve 1
5 53205A Kit, Diaphragm 1
6 54882A Housing, Lower 1
7 52907A Kit, Drive Assembly 1

Page 24 CLARKE TECHNOLOGY Ext -10, 15 `Operator's Manual
CLARKETECHNOLOGYEXT-10,15
Wiring Diagram 120V - 11/96
CLARKETECHNOLOGYEXT-10,15
Wiring Diagram 230V - 11/98
