Clarke LOGBUSTER 10 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS0815
FOOT OPERATED 1.5 TONNE LOG SPLITTER
MODEL NO: LOGBUSTER 10
PART NO: 3402046

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Foot Operated 1.5 Tonne Log Splitter.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Logbuster 10
Part Number 3402046
Weight 12.7 Kg
Dimensions (D x W x H) 866 x 258 x 468 mm
Rated Tonnage 1.5 Tonnes
Maximum Log Length 400 mm
Minimum Log Length 100 mm
Maximum Log Diameter 200 mm

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY SYMBOLS

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
WORK AREA
1. Keep the work area clean and well lit. Cluttered and dark areas invite
accidents.
2. Do not operate the log splitter in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. The log splitter may create
sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while operating the log splitter.
Distractions can cause you to lose control.
4. The surface must be perfectly level to prevent the machine from moving
during operation.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when
operating a log splitter. Do not use the log splitter while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating the log splitter may result in serious personal
injury.
2. Use safety equipment. Always wear eye protection. Safety equipment such
as non-skid safety shoes, close fitting clothing and suitable work gloves
should always be used.
3. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the log splitter in unexpected situations.
4. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
USAGE AND CARE
1. Do not force the log splitter. It will do the job better and safer at the rate for
which it was designed.
2. Store the log splitter out of the reach of children and do not allow persons
unfamiliar with the log splitter or these instructions to operate the log
splitter. Log splitters are dangerous in the hands of untrained users.
3. Maintain the log splitter. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
operation of the log splitter. If damaged, have the log splitter repaired
before use. Many accidents are caused by poorly maintained tools.
WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL
INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY.
WARNING: SAVE THESE INSTRUCTIONS.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SERVICE
1. Have your log splitter serviced by a qualified repair person using only identical
replacement parts. This will ensure that safety is maintained.
ADDITIONAL PRECAUTIONS FOR LOG SPLITTERS
• All personnel must read the manual or receive correct training before
they use the log splitter.
• Suitable personal protective equipment (PPE), including safety
footwear, close fitting clothing and suitable work gloves, eye
protection and hearing protection must be worn at all times.
• Before starting work, check for soundness of welded joints, securing
nuts & bolts.
• Make sure that the log splitter functions as expected before use.
• NEVER tamper with the log splitter.
• NEVER use the machine whilst under the influence of alcohol, drugs,
medicines, or when you are tired. A clear mind is essential for safety.
• The operator must take all necessary precautions to minimise the risk of
accidental damage or injury due to wood being ejected from the
machine.
• The log splitter is designed for one person operation only.
• Do not allow split logs to accumulate, always clean up as you work,
accumulated split logs and wood chips can create a hazardous work
environment.
• Split wood in the direction of the grain. Do not attempt to split a piece of
wood across the grain as this could seriously damage the machine.
• Please note some particular characteristics of wood when being
split. A small log can sometimes be hard to split if it has knots or
particularly tough fibres. It is important NOT to persist if the log does
not split fairly easily, you may damage your log splitter.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
BEFORE USE
SETUP
1. Place the log splitter on flat, level
ground and swing the stand into
position.
• Make sure that the log splitter is
stable.
PREPARING THE LOGS
1. Cut the logs to between 100-400 mm long to fit into the log splitter. the logs
must not exceed 200 mm in diameter.
2. Slide the pusher up with your hand
and place a log on the log guide
plate against the splitting wedge.
3. Lower the pusher against the top
of the log you want to split.
• Always split the logs in the
direction of the grain.
• Do not place the log across the
logbuster for splitting. It is
dangerous and can damage
the log splitter.
• Do not try to split two logs at
the same time. One of them
could fly up and hit you.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OPERATING THE LOG BUSTER
Before use, make sure that all nuts and bolts are tight and that the tool is in
good condition before using it.
This log buster is designed to be operated by one person only
• Keep feet and hands away from the wood, as it will fall to the floor.
• If the log moves away from the wedge, turn the log 90° and try again.
1. Press down on the foot pedal.
• The wood splitter will push down on the wood, causing the wood to start
to split. If the wood does not fully split, the pusher will lock into place as
you lift your foot up for another stroke of the foot pedal.
2. Continue pumping the foot pedal until the log is split.
• For hard logs, try to rotate the log by 90° to see if it can be split in a
different direction. If you are still not able to split the log, this means that
the wood exceeds the capacity of the log splitter and should be
discarded to protect the log splitter
3. Remove the log from the area, and repeat the operation with another
piece of log.
FREEING A JAMMED LOG
1. Slide the pusher up with your hand and tap the log away from the wedge
with a rubber mallet to release the log.
CAUTION: DO NOT PUT YOUR HANDS ANYWHERE NEAR THE SPLITTING
WEDGE DURING USE.
CAUTION: KEEP YOUR HANDS AWAY FROM SPLITS AND CRACKS WHICH
OPEN IN THE LOG; THESE CAN CLOSE SUDDENLY AND CRUSH YOUR
FINGERS.
CAUTION: KEEP CHILDREN, ANIMALS AND OBSERVERS AWAY WHEN
PRESSING DOWN ON THE FOOT PEDAL TO PREVENT INJURY CAUSED BY
POSSIBLE WOOD SPLINTERS AND/OR SPRING ACTION.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
TROUBLESHOOTING
PROBLEM CAUSE REMEDY
Fails to split logs Log is improperly positioned. Reposition the log See “Preparing
the logs” on page 6.
Wedge cutting edge is blunt. Refer to “Sharpening The Wedge”
below.
MAINTENANCE
CLEANING
• Clean the logbuster with a damp cloth to remove tree sap or dirt after
each use.
• Store it in a dry, secure location.
• Occasionally lubricate the main beam with paraffin or candle wax to
help the pusher slide freely along it. Lightly oil all other metal parts to
prevent rusting.
SHARPENING THE WEDGE
Occasionally sharpen the Splitting Wedge, using a file or sharpening stone (not
included). A sharper splitting wedge will split logs more safely and effectively
than a dull one.
WARNING: MAKE SURE THAT THE RAM ON THE LOGBUSTER IS NOT UNDER
PRESSURE WHEN YOU ARE CLEANING, MOVING OR MAKING ANY
ADJUSTMENTS.
CAUTION: KEEP THIS TOOL OUT OF REACH OF ·CHILDREN AND OTHER
UNAUTHORIZED PERSONS. PREVENT ACCIDENTS BY RESTRICTING ACCESS
TO THIS TOOL.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
EXPLODED DIAGRAM

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST
NO DESCRIPTION PART NO
1 Slidestop QMLOGB1001
2 Log Guide Plate QMLOGB1002
3 Spacer Bush QMLOGB1003
4 M8 Lock Nut QMLOGB1004
5 M8 Nut QMLOGB1005
6 Spring Gasket QMLOGB1006
7 Hexagonal Bolt QMLOGB1007
8 Support Beam QMLOGB1008
9 Wheel QMLOGB1009
10 Circlip QMLOGB1010
11 M8x40 Screw Ring QMLOGB1011
12 M8x50 Hexagonal Bolt QMLOGB1012
13 Clamp Axis QMLOGB1013
14 The Retaining Ring QMLOGB1014
15 Spring QMLOGB1015
16 Hexagonal Bolt QMLOGB1016
17 Foot Pedal QMLOGB1017
18 M10 Lock Nut QMLOGB1018
19 Outrigger QMLOGB1019
20 Fixed Handle QMLOGB1020
