Clarke CarpetMaster 100 Series Installation and user guide

Page: 1
CarpetMaster 100 Series How To
Prepare for Use
1
Loop cord then lock in
restraint clip.
2
Plug machine into an
appropriate electrical
outlet. Turn on main
power switch.
3
Step on the pedal then
tilt the vacuum handle
backwards to begin
vacuuming.
Clearing a Clog
1
Restricted airflow light
indicator comes on,
please check the
following things.
2
Check to see if bag is
full or if the tube, hose
or nozzle is blocked.
Replace bag if needed.
3
Remove the upper
hose and wand to
inspect for clogged
debris. Detach the
wand receptacle.
4
Release and remove
the brush cover by
unlocking the bearing
lock then pull brush out.
5
Inspect lower hose by
looking through the
wand receptacle to the
brush housing area.
(You should have a clear
view. If not, there is a clog)
6
Remove debris by
pushing it forward via
the brush opening (use a
long narrow object if needed) .
Reinstall brush and
brush cover. Reattach
wand receptacle.

Page: 2
CarpetMaster 100 Series How To
Maintenance
1
Disconnect power cord,
open cover latch, remove
and replace the HEPA-
filter then reinstall the
filter cover.
2
Disconnect power cord,
open dust lid
compartment and remove
the dirty pre-filter. Wash
with warm water (let dry) or
install a new pre-filter
then close the lid.
Replace deodorizer pad if
needed.
3
Replace the exhaust filter
(if necessary) then close
filter cover.
*Never operate the
machine without the
Exhaust Filter in
place.
4
Unlock the bearing block,
remove brush (clean or
replace), slide brush into
the bearing block then
lock by turning clockwise.
5
Remove dust lid. Gently
remove the bag. Insert
new (unfolded) bag in the
bag housing. Install back
cover.
6
Remove dust lid. Gently
remove the bag clip
(shake out bag contents) .
Insert cleaned/new bag.
Install back cover.
7
Wrap cord and store on
the hook. Check the
brushes and remove
debris then store the
machine in a clean, dry
place (indoors) .
•The HEPA-filter
can not be
cleaned or
washed.
•Must be replaced
when the HEPA-
filter is clogged.
•Replace 1-2
times per year
(depending on use).
•Replace the
motor pre-filter
after every fifth
dust bag change
(more often if needed)
HEPA-filter Pre-filter
