Clas Ohlson ADVENTURER 3 User manual

EnglishSvenskaNorskSuomiDeutsch
3D Printer
Art.no Model
38-8870 ADVENTURER 3
Ver. 20200325
English 2
Svenska 16
Norsk 30
Suomi 44
Deutsch 58

2
English
3D Printer Quickstart guide
Art.no 38-8870 Model ADVENTURER 3
Please read the entire instruction manual before using the product and then save it for
future reference. We reserve the right for any errors in text or images and any necessary changes
made to technical data. In the event of technical problems or other queries, please contact our
Customer Services (see address details on the back).
Safety
Follow the safety guidelines below. Make sure that you have read and understood all the safety
instructions and warnings in any other documents included with this product and its accessories.
• Keep the work area clean and well lit. Cluttered or dark areas invite accidents.
• Never use the product in areas where explosive gases or liquids are stored.
• Never use the product when you are tired, sick, under the influence of alcohol or medicine.
• Always unplug the mains lead when moving the product for service or maintenance.
• If extension leads are used, ensure that they are designed for the purpose for which they are
intended to be used.
• Only use earthed power points with a voltage rating which correspond to the specifications
listed on the rating plate of the product.
• Do not place the mains lead where it can be crushed or damaged by sharp edges.
• Never use the product if it or the mains lead is damaged in any way.
• Never try to open the housing or try to repair the product in any way. The product contains
no user-serviceable parts.
• Never attempt to tamper with or modify the product in any way.
• Do not place the product where it is exposed to moisture or affected by water or any other
types of liquids. Avoid exposing the product to direct sunlight, dust or extremely cold or hot
environments. The product is designed to function optimally in temperatures of 15−25 °C
(59−77 °F) and at a humidity level of 20−50 %.
• Tie back any long hair and ensure that no loose clothing or jewellery risks coming into
contact with any moving or hot parts of the product.
• Place the product on a stable, even surface and at a safe distance from all flammable
materials.
• Never store or place metal objects or any type of liquids within the printing area or on top of
the product. Doing so could lead to fire, electric shock or other personal injury.
• Only operate the product in well-ventilated areas.
• Printed models should never be exposed to any type of heat, such as that emitted by
cookers, ovens, fires and candles.
• Turn off the product and unplug it from the wall socket immediately if:
- the product begins to emits smoke or smells burnt
- the product emits unusual sounds
- metal or any types of liquid comes into contact with the product
- there is a possible risk of thunderstorms
- there is a power cut
• This product contains moving parts that can cause personal injury and parts which reach
temperatures of 200−300 °C.
Keep all parts of your body away from the printing area when the product is in operation.
Never touch the print head while printing is in progress.
• Let the product cool down completely after use before handling it.

3
English
• Never attempt to bypass any safety mechanisms that prevent user access to the printing
area and print head.
• Printed models are extremely hot after being printed. Always let the models cool before
they are handled.
• Never leave the product unattended while it is operating.
• Never let children play with the product. Never let children use the product without adult
supervision. Adult supervision is always required in order to ensure safe operation.
• Keep all models out of the hands of small children. Models pose a choking hazard.
• Printed models should never be used for food storage.
• Printed models should never be used for electrical installation purposes.
• Never print models that might break laws or regulations in the area where
the product is used.
Warning: Hot surfaces
Warning: Crush hazard
Warning: Electric shock hazard

4
English
Package contents
3D printer Filament spool Mains lead USB flash drive
Touch screen
stylus
Extra nozzle. For
best results, use
one nozzle for
PLA prints and a
different nozzle for
ABS prints.
Air filter Screwdriver
Hex key Nozzle cleaning
tool
Resealable bag for
filament reel

5
English
Unpacking
1. Place the box on a clean, firm and level
surface.
2. Open the box. 3. Remove the uppermost packaging
material which also contains loose
parts such as the mains lead and
filament.
4. Take the printer out of the box
and remove the bubble wrap.
5. Peel off the protective tape and the
packaging on the door.
6. Connect the mains lead to the
printer.
7. Connect the mains lead to a
power socket.

6
English
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
8. Switch the printer on. 9. Open the door.
10. PressTools. 11. Press Setting.
12. Press >and advance
to page two.
13. PressMove. 14. Press in the Z field to raise
the print bed to make it easier to
remove the packaging material
inside the printing chamber.

7
English
15. Compress the packaging material a
little and pull it out of the printer.
16. Simple as that! It is a good idea to save
the packaging material in case you
might want to repack the printer and
transport it in the future.
17. Attach the air filter under the fan.

8
English
2
3
4
5
16
7
8
9
22
23
10
13
11
12
14 15
21
16
17
18
19
20
24
25
Product description
1. Filament guide tube
2. Filament guide tube clamp
3. Extruder
4. Cooling fan
5. Removable nozzle
6. Extruder cables
7. Clips
8. LED light
9. Cooling fan air outlet
10. Door
11. Y-axis glide track
12. Build platform
13. Removable build plate
14. Touchscreen
15. USB flash drive input socket
16. [0/l] On/off switch
17. AC power input socket
18. Filament reel holder
19. Filament compartment hatch
20. Handle
21. Filament input port
22. Filament feed wheel
23. Inspection window
24. Air outlet
25. Ethernet cable connection

9
English
Network Preheat
Setting About
Status Language
Calibration Home
1/3
< <
Pre-adjusting, please wait...
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.35
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.30
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Extruder
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Completed
Calibration is stored. Extruder is
homing...
Calibration complete
Network Preheat
Setting About
Status Language
Calibration Home
1/3
< <
Pre-adjusting, please wait...
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.35
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.30
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Extruder
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Completed
Calibration is stored. Extruder is
homing...
Calibration complete
Network Preheat
Setting About
Status Language
Calibration Home
1/3
< <
Pre-adjusting, please wait...
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.35
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.30
Extruder
ok
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Extruder
Click the arrow to adjust the
nozzle so that it just touches
the platform
Z axis 0.25
Completed
Calibration is stored. Extruder is
homing...
Calibration complete
Calibration
The distance between the build plate and extruder is calibrated at the factory. If the print model
releases from the build plate during printing, or if the extruder can't print the first layer correctly, it
may mean that the distance between the build plate and the extruder needs to be recalibrated.
Do the following: Take a sheet of regular A4 sized 80 gsm paper. Place the paper between the
build plate and the extruder. The build plate and the extruder will be the correct distance apart
when the paper can be moved back and forth with just a slight resistance.
1. Press Setting 2. Press Calibration
3. Press to raise the
extruder.
4. Press to lower the
extruder.
5. Press ok when you are
happy with the gap
6. PressCompleted to exit the calibration setting

10
English
200 /235℃
Heating extruder...
Cancel
235 /235℃
Preheat completed,
Begin loading...
ok
Build
Tools
Filament
Load
Change
200 /235℃
Heating extruder...
Cancel
235 /235℃
Preheat completed,
Begin loading...
ok
Build
Tools
Filament
Load
Change
19
21
22
Loading filament
1. Press Filament 2. Press Load 3. The extruder heats up
The filament can only be loaded when the extruder has
reached the correct temperature as shown in the picture.
Remove the hatch (19) and feed the end of the filament
through the filament input port (21). Feed the filament past
the feed wheel (22) manually.
Note: The feed wheel is spring-loaded, you may need to
push the filament hard to get it past the feed wheel.

11
English
235 /235℃
OK
Press ok when new color appears
Load
Change
235 /235℃
OK
Press ok when new color appears
Load
Change
4. Note: Arrange it so that the filament is fed off the reel clockwise.
5. Press OK when the
filament has begun to exit
the extruder.
6. Press to return to the
start menu.
7. Place the filament reel
onto the holder and refit
the hatch.

12
English
...
0
h
10
min
Time Remaining
20mm_Box-PLA.gx
m
7.49
Build completed!
ok
1/3
< <
20mm_Box-
PLA.gx
20mm_Box-P...
0 h 10 min
0.70M
Build
Tools
Filament
6.67GB
No job
14.83GB
Printing
1. Press Build and select to upload the file from the USB flash drive.
2. Choose the file and press to start printing. You can also press the file symbol or the
file name to open a detailed view, then press to start printing.
3. The extruder will heat up and start to print when it reaches operating temperature.
When the print is finished, the printer will beep and a message will appear on the
display.

13
English
Removing the finished model
Warning: The build plate and the extruder may be very hot when the model has
finished being printed. Let the parts cool before removing the model.
2. Carefully flex the build plate to release the model. You might need to use a spatula if the
model is very big or small.
1. Press down gently on the build plate and remove it from the build platform.

14
English
Heating extruder...
200
/235℃
Cancel
Load
Change
235
/235℃
OK
Pull out filament,
feed new filament, press [OK]
235
/235℃
OK
Press ok when new color appears
Build
Tools
Filament
Load
Change
Heating extruder...
200 /235℃
Cancel
Load
Change
235 /235℃
OK
Pull out filament,
feed new filament, press [OK]
235 /235℃
OK
Press ok when new color appears
Build
Tools
Filament
Load
Change
Heating extruder...
200
/235℃
Cancel
Load
Change
235
/235℃
OK
Pull out filament,
feed new filament, press [OK]
235
/235℃
OK
Press ok when new color appears
Build
Tools
Filament
Load
Change
Changing filament
1. Press Filament 2. Press Change 3. The extruder will heat up.
Once the extruder has
heated up, the filament will
automatically be feed out.
4. Remove the hatch
of the filament
compartment.
5. Remove the current
filament reel and pull the
rest of the filament from
over the feed wheel.
6. Fit the new filament and pass
it over the feed wheel.
7. PressOK.
The filament
will be fed in
automatically.
8. Press OK when
the filament has
begun to exit the
extruder.
9. Press to
return to the
start menu.
10. Place the
filament reel
onto the holder
and refit the
hatch.
If the extruder becomes clogged.
Watch the instruction video about cleaning the extruder on Youtube.
Search for the following: FLASHFORGE Adventurer 3 nozzle Unchoking

15
English
Heating extruder...
200 /235℃
Cancel
Load
Change
235 /235℃
OK
Pull out filament,
feed new filament, press [OK]
235 /235℃
OK
Press ok when new color appears
Build
Tools
Filament
Load
Change
Clip
Replacing the nozzle
1. Press Filament 2. Press Change 3. The extruder will heat up.
Once the extruder has
heated up, the filament will
automatically be feed out.
Refer to the instructions on YouTube.
Search for – Adventurer3 nozzle disassemble
4. Switch off the power to the printer and let it cool.
5. Press in both the clips and pull the
nozzle downwards. (use a pair of
pliers if you have difficulty).
6. Fit a new extruder nozzle by
pressing in the locking clips and
pushing the nozzle upwards.

16
Svenska
3D-skrivare Quickstart-guide
Art.nr 38-8870 Modell ADVENTURER 3
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska problem
eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
Följ alla säkerhetsanvisningar i nedanstående text. Försäkra dig om att du har läst och förstått alla
säkerhetsföreskrifter och varningar som kan förekomma i andra dokument som medföljer produkten
eller dess tillbehör.
• Håll arbetsutrymmet rent och väl upplyst. Belamrade och mörka utrymmen inbjuder till olyckor.
• Använd aldrig produkten i utrymmen där brännbara gaser eller vätskor förvaras.
• Använd aldrig produkten om du är trött, sjuk, påverkad av alkohol eller medicin.
• Dra alltid ut nätkabeln ur vägguttaget innan produkten flyttas och vid service eller underhåll.
• Om du använder skarvkabel för att ansluta produkten till elnätet, försäkra dig om att kabeln
är lämplig för ändamålet innan den används.
• Produkten får endast anslutas till ett jordat vägguttag vars spänning överensstämmer med
den som anges på produktens märkskylt.
• Placera nätkabeln så att den inte kläms eller skadas av vassa kanter.
• Använd aldrig produkten om den eller nätkabeln på något sätt är skadade.
• Försök aldrig öppna höljet eller reparera produkten på något sätt. Den innehåller inga delar
som kan repareras av användaren.
• Försök aldrig modifiera eller förändra produkten på något sätt.
• Placera inte produkten så att den utsätts för fukt eller påverkas av vatten eller annan
vätska. Undvik ihållande solljus, dammiga, mycket kalla eller mycket varma miljöer. Produkten
är konstruerad för att fungera optimalt i temperaturer mellan 15−25 °C (59−77 °F) och i en
luftfuktighet mellan 20−50 %.
• Sätt upp långt hår och se till att inte löst hängande smycken eller kläder kan komma i kontakt
med produktens rörliga eller varma delar.
• Placera produkten på en stabil, plan yta på avstånd från brandfarligt material.
• Förvara eller placera aldrig metallföremål eller vätska av något slag i utskriftsområdet eller på
produkten. Detta kan leda till brand, elektrisk stöt eller annan personskada.
• Produkten får endast användas i välventilerade utrymmen.
• Utskrivna modeller får inte utsättas för någon form av värme t.ex. från spisar, ugnar, öppen eld,
levande ljus.
• Slå omedelbart av produkten och dra ut nätkabeln ur vägguttaget om:
- produkten avger rök eller luktar bränt
- avger onormala ljud
- metalldelar eller någon form av vätska kommer i kontakt med produkten
- risk för åska föreligger
- vid strömavbrott
• Produkten innehåller rörliga delar som kan orsaka kroppsskada och delar som når tempera-
turer på 200−300 °C.
Håll alla kroppsdelar på avstånd från utskriftsområdet när produkten arbetar. Rör aldrig skri-
varhuvudet när utskrift pågår.
• Låt produkten svalna helt innan den hanteras efter användning.
• Försök aldrig forcera ev. säkerhetssystem som förhindrar att användaren kommer i kontakt
med utskriftsområdet och skrivarhuvudet.

17
Svenska
• Utskrivna modeller är mycket varma när de färdigställts. Låt alltid modellerna svalna innan
de hanteras.
• Lämna aldrig produkten oövervakad när den arbetar.
• Låt aldrig barn leka med produkten. Låt aldrig barn använda produkten utan vuxens närvaro.
Vuxens närvaro krävs för att produkten ska kunna användas på ett säkert sätt.
• Håll utskrivna modeller på avstånd från små barn. Modellerna utgör en kvävningsrisk.
• Utskrivna modeller får inte användas för förvaring av matvaror.
• Utskrivna modeller får aldrig användas i elektriska installationer.
• Skriv inte ut modeller som kan strida mot lagar och förordningar i det område där
produkten används.
Varning! Heta ytor
Varning! Klämrisk
Varning! Risk för elektrisk stöt I förpackningen

18
Svenska
I förpackningen
3D-skrivare Filamentspole Nätkabel USB-minne
Pekpenna (stylus
pen) för touch-
skärmen.
Extra skrivar-
munstycke. För
bästa resultat,
använd ett huvud
till PLA-utskrifter
och ett annat
huvud för ABS-
utskrifter.
Luftfilter Skruvmejsel
Insexnyckel Rengöringsverktyg
för skrivarhuvud.
Återförslutningsbar
påse för förvaring
av filamentrulle.

19
Svenska
Uppackning
1. Placera förpackningen på en plan,
ren och stabil yta
2. Öppna kartongen. 3. Ta bort förpackningsmaterialet som
ligger överst, där finns tillbehör som
nätkabel, filamentrulle m.m.
4. Lyft ut skrivaren ur kartongen
och ta bort bubbelplasten.
5. Dra bort skyddstejpen och dörrens
emballage.
6. Anslut nätkabeln till skrivaren. 7. Anslut nätkabeln till ett vägguttag.

20
Svenska
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
Build
Tools
Filament
Network Preheat
Setting About
Move Camera
FilamentCheck Led
<
2/3
<
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
1/3
< <
8. Slå på skrivaren. 9. Öppna dörren.
10. Tryck Tools. 11. Tryck Setting.
12. Tryck >och bläddra
till sidan två.
13. Tryck Move. 14. Tryck i fältet Z för att höja
bädden så det blir lättare att ta
bort förpackningsmaterialet som
ligger inne i skrivaren.
