English
Digital Picture Frame
Art.no. 18-8114 Model PF-7AW-103-UK
38-3426 PF-7AW-103
Please read the entire instruction manual before using the product and save it for
future reference. We reserve the right for any errors in text or images and any neces-
sary changes made to technical data. If you have any questions regarding technical
problems please contact Customer Services.
Contents
1. Safety 4
2. Product description 4
3. Buttons and functions 5
4. Getting started 6
5. Operation 7
6. Settings 9
7. Care and maintenance 10
8. Troubleshooting guide 10
9. Disposal 10
10. Specifications 10

4
English
1. Safety
Caution: Do not open the casing! Certain components within the product’s casing
contain dangerous currents. Contact with these may give you an electric shock.
- The product should only be repaired by qualified service technicians.
- The product should not be taken apart or modified.
- Do not place the product where it can fall into water or other liquids. Do not place
any objects which contain liquid on top of product, e.g. flower vases or drinks.
- Do not cover the ventilation holes. Do not place the product close to heat
sources such as on top of the radiator, TV, or on e.g. the sofa where the
ventilation holes risk being blocked.
- Always unplug the adaptor from the electrical outlet if the product is not be used
for an extended period.
- The product is designed for 8 – 10 hours of continuous operation. Avoid any
prolonged use. Let the product sit for a while before re-using.
- The product is intended for indoor use only.
- Do not expose the product to direct sunlight for extended periods of time.
- Do not use the product in damp, dusty, or dirty environments.
- Only use a lightly moistened soft cloth with a little washing up liquid to clean
the screen.
- Handle the screen carefully to avoid scratching it.
- Do not disconnect the adaptor while the frame is in use. The attached memory
may be damaged. Neither should the connected memory be removed when the
frame is in use.
2. Product description
- 7˝Widescreen Digital Photo Frame.
- Displays your digital photos without the need for OF computer.
- USB memory and memory card slots (SD/MMC/MS)
- Power adaptor.

5
English
4
1
2
3
5 6 7 8
9 10
3. Buttons and functions
Button/
Connection
Function
1. SD/MMC/MS Memory card slot
2. USB HOST Connection for USB memory, MP3 players, etc. (USB 2.0)
3. DC Adaptor connection (5 V DC, 1 A)
4. <Goes to the next image.
5. ►[Play/Pause/Confirm. Depress and hold to reach
the main menu.
6. ΛUp arrow. Goes to the preview menu (miniature).
7. >Goes to the previous image.
8. vDown arrow Rotates image when pressed.
9. ON/OFF Power switch.
10. Support stand Adjustable Can be adjusted to lie in both landscape and
portrait modes.

6
English
ON OFF
A B
C D
4. Getting started
4.1 Assembling the table stand
4.2 Power supply
1. Connect the adaptor’s DC plug to the DC connection on the photo frame.
2. Plug the adaptor into a wall socket.
3. Set the On/Off switch (9) to ON to turn it on or OFF to turn it off.

7
English
A
B
4.3 Inserting a memory card or a USB memory
Memory cards
The following memory cards are compatible:
- Secure Digital (SD)
- Multimedia Card (MMC)
- Memory Stick (MS)
If your digital camera uses any of the above mentioned memory cards you can
connect the camera’s memory card directly to the photo frame.
1. Insert the memory card into the
slot marked SD/MMC/MS (A).
Be careful when inserting.
2. Remove the card by pulling it
straight out.
USB memory
USB equipment such as a USB flash memory or MP3 players with a USB connection
can be connected directly to the USB HOST (B) connection.
5. Operation
5.1 Main menu key
Depress and hold ►to reach the main menu.
Buttons for devices, setup and Now Playing (current slideshow) are displayed.
USB Highlighted when a USB memory
is selected.
Card Highlighted when a SD/MMC/MS
card is selected.
Setup Picture frame settings.
Now Playing Plays current slideshow.
Use [ Λ ]and [ v ] to navigate the main menu. Press ►to confirm and to enter
the submenus. In the upper right hand corner of the display you will see a button
indicator that mirrors the actual button you are pushing on back of the picture frame.
If you insert a USB or memory card when you are in main menu mode the slideshow
will start immediately.

8
English
[ ►] Play/OSD menu [ ] Preview [ ] Previous
(Hold ) [ ►]: Main Menu [ ] Rotate [ ] Next
I◄ ► ►I


5.2 Slideshow
Starting a slideshow:
1. Connect a USB memory or a memory card containing JPG/JPEG image files.
2. Highlight USB, CARD or Now Playing in the main menu and then press ►
to confirm.
3. The slideshow should now begin.
When the slideshow starts the display menu will appear at the bottom portion of the
display. Quickly pressing ►during a slideshow playback will also bring up the
display menu.
Controls (used during slideshow playback):
ΛPreview (miniatures)
</> Selects the previous or next image.
vRotates the image.
Quickly pressing ►Pauses the slideshow.
Depressing and holding ►Brings up the main menu.
5.3 Display Menu commands
You may also use the display menu to display pictures one at a time. During slide-
show playback quickly press ►to bring up the display menu. The slideshow should
now pause.
Use <and >to advance through the commands.
 To start a slideshow, highlight ► and then press the ►-button on back of the
picture frame.
 Highlight I◄ or ►I to select the next or previous image and then press the
►-button on back of the picture frame.
 To rotate an image, highlight

and then press the ►-button on back of the
picture frame.
 To preview an image, highlight

and then press the ►-button on back of the
picture frame.
 To zoom in on an image, highlight and then press the ►-button the desired
number of times to enlarge the image.

9
English
5.4 Preview mode
During slideshow playback press
Λ to reach preview mode. Navi-
gate between the images using
Λ, v, >and <.
Depress and hold ►to reach
the main menu.
6. Settings
1. Highlight Setup in the main menu and press ►to confirm. The setup menu will
be shown.
2. Use [ Λ ] and [ v ] to navigate
the menu and press ►to
select the chosen setting.
3. Use the [ Λ ] and [ v ] to select
a value. Press ►to confirm.
4. Depress and hold ►to return
to the main menu.
6.1 Setup options
Settings Description
Language Sets the menu language.
Slideshow Time Sets the duration of each image. (3 sec, 5 sec, 15 sec,
1 min, 15 min or 1 hour.)
Slideshow shuffle Displays images randomly or in predetermined order.
Transition Effect Selects transition effects.
Now Playing Displays slideshow immediately.
Brightness Light – dark.
Contrast Sharp – diffuse.
Saturation Colour intensity.
Hint Time Sets the duration of the on-screen button command during
slideshow playback.
Photo Mode Sets the aspect ratio to full-screen or normal mode.
Default Settings Resets the device to factory settings.

10
English
7. Care and maintenance
Use a soft damp cloth to clean the product. Never use solvents or strong detergents.
8. Troubleshooting
Problem Solution
The device does not start/no
photo is shown.
Check that the adaptor is correctly connected.
The device automatically
switches to standby mode.
Disconnect the adaptor and re-connect.
Cannot read the memory card. Make sure that the files on the memory card are
supported by the device. See Specifications.
Some photos are uploaded
quicker than others.
Photos with high resolution take longer to
upload. Use photos with lower resolution for
quicker display.
9. Disposal
Follow local ordinances when disposing of this product. If you are unsure of how
to dispose of this product, please contact your municipality.
10. Specifications
Display 7˝colour analogue LCD, 16:9
Resolution 480 (h) x 234 (v)
Operating voltage 5 V DC, 1 A via the supplied mains adaptor
(100-240 V AC, 50/60 Hz)
USB port 2.0 (support for USB memory)
Memory card slot SD (Secure Digital), MMC (Multimedia Card),
MS (Memory Stick)
Picture format JPEG (Max. resolution 8000 x 8000 pixels)
Storage temperature: - 20 °C ~ 60 °C
Operating temperature 0 °C ~ 45 °C
Size 219 x 152 x 29 mm
Weight 380 g
