Clean Air Optima CA-506 User manual

1
Clean Air Optima HEPA UV ionizer air purifier
CA-506
Manual
Read these instructions carefull before ou start using the air purifier and
keep the manual for later usage.
© Copyright : Clean Air Optima

2
Introduction
Clean Air Optima wishes to thank ou for purchasing this unique air purifier with
high qualit technolog . We live in times where air pollution, viruses and particulate
matter seem to be an unavoidable threat for our wellbeing. Clean Air Optima offers an air
purifier that represents an affordable and efficient answer to this threat.
n your new air purifier, several technologies have been combined in order to filter
small dust particulates and biological particulates out of the air. The device eliminates
unicellular organisms, as well as viruses and bacteria floating in the air by means of UV-C
light and it purifies the air from unwanted and harmful particulates.

3
Technical diagram and components of the CA-506

4
Before use
Features
The Clean Air Optima CA-506 includes 6 filter technologies and is 100% ozone free.
Activated carbon pre-filter
The pre-filter catches big particulates like: lint, hair and dander from pets.
Activated carbon neutralises smoke, chemicals, gases and smells, it prevents the development of
bacteria, viruses and mold. The activated carbon pre-filter extends the durability of the TRUE HEPA
filter.
Filter combination
Original True HEPA + Pet Pure Treatment: True HEPA catches 99.97% of all floating particulates
and allergens like dander of pets, dust mites, pollen, bacteria and viruses >0,3 micron. The Pet Pure
Treatment (PPT) is a filter coating to which an antimicrobial substance was added to prevent the
development of mold, mildew, bacteria causing smells on the surface of the filter.
UV-C light combined with titanium dioxide
UV-C light technology works in combination with titanium dioxide (TiO²) to eliminate bacteria and
viruses floating in the air. TiO² is activated by the UV-C light to neutralize smell molecules caused by
smoking, cooking and pets.
Ionizer
This powerful ionizer produces more than 6.000.000 negative ions/cm³ (known as “vitamins of the
air”) to purify and refresh indoor air. t purifies air from dust, cigarette smoke, pollen, mold and
harmful gases.

5
Warning
Take the following steps to minimize the risk of personal injury caused by for example electric shocks
or fire.
1. Only for indoor use.
2. Pull the plug when you do not use the device or when you clean internal or external parts of it.
3. Use, maintain and clean the device as described in this manual.
4. Do not use the device when there is visible damage on the electrical cord, the UV lamp or on the
device itself. Do not repair the device yourself in case of damage.
5. Make sure that the air outlets are always free, clean up dust, hair and other obstruction for the
airflow and at the air outlets.
6. Keep your hair, clothes, jewels or fingers away from the air outlets.
7. Do not stick sharp objects through the grid as it can result in failures or electric shocks.
8. Do not use the device in rooms where inflammable liquids or gases are stored, close to heat
sources or in particularly humid rooms like the bathroom.
9. Touch the device only with dry hands.
10. Pay attention to damages on the electrical cord. Never pull the device by its cord.
11. Bring discarded devices to the appropriate collecting points. Prevent children from opening the
device. The device is not a toy. Children may only use the device under the surveillance of an
adult.
12. The UV-C lamp in the device produces UV-C radiation which can be harmful for skin and eyes
during direct contact. Never look directly into the UV-C lamp and never put your face close to the
grid at front side or the backside. Never use the lamp for other purposes.

6
Usage
Placement
1. Get the air purifier and the filter out of the package and place the filter into the device. Attention:
pay attention to the arrow on the filter in order to place the filter correctly.
2. Position the device on a solid, flat and straight base.
3. The device needs to be positioned at least 30 cm from the walls and furniture to obtain good air
flow.
4. Make sure that the front air outlet of the device is positioned away from the closest wall or piece
of furniture. Make sure that the air in-and outlets are not blocked.
5. nsert the plug into the socket.
6. Never pull up the device by its loose parts.
Operation
1. Make sure that the filters are placed correctly and that all components are snapped.
2. Use the ON/OFF button on top of the device to switch it on and off.
3. Use the MODE button to install the level of purification 1 to 5. 1 = low, 5 = high. LED lights will
lighten up and display which level you selected.
Choose the right setting depending on the size of the room and the level of air pollution. f you place
the air purifier in a smaller room, for example the bedroom, level 1 is sufficient.
4. Press on the TIMER button to set the timer to “switch of automatically” in a range between 1, 2,
3, 4, 5, 6, 7 and 8 hours. The number of hours selected can be read on the display of the timer.
5. Press on the UV button to switch the UV lamp on and off.
Tested technolog
UV sterilization technology is accepted for more than fifty years and it has been proven that it can
considerably reduce the number of bacteria and polluting substances in the air safely.
Longevit
The extremely efficient UV lamp only needs to be replaced after 8.000 working hours. f you use the
UV lamp 24 hours a day, you can use it for 12 months. The UV lamp can easily be replaced.

7
Cleaning and maintenance
Cleaning the outside of the device
1. Switch off the device and pull the plug.
2. Use a soft and humid piece of cloth to clean the device from dust and dirt.
3. Make sure that no water gets into the device.
Replacement of filters
The Clean Air Optima air purifier CA-506 is equipped with a filter monitor that shows when the filters
need to be replaced. When the moment of replacement has come, the air purifier will make a 30
seconds long sound after which the HEPA RESET lamp will lighten up. Replace the filters according
to the instructions below. Restart the air purifier by resetting: after the replacement of the filters,
insert the top of a pen into the HEPA RESET area on the control panel to restart the system.
1. Switch out the device and pull the plug.
2. Press on the release button and remove the rear cover.
3. Remove the used activated carbon pre-filter.
4. Remove the used HEPA filter from the device.
5. Unpack the new filters.
6. Position the HEPA filter into the purifier (pay attention to the arrow on the filter for the correct
direction).
7. Position the activated carbon filter into the back part of the device.
8. Position the rear cover and press until it snaps.

8
Depending on the use, the HEPA filter has a lifespan of 6-8 months and the activated carbon
pre-filter can be used during around 12 months. Filter cleaning: the best effect is reached by
cleaning the filters once a month. f indoor air is extremely polluted, more cleaning can be required.
Clean the activated carbon pre-filter and the HEPA filter with a brush or your vacuum cleaner.
That way bigger dust particles like lint, hair and dander of pets can be removed from the filter.
Signs for used up filters: increased sound, reduced air flow, congested filters, rising presence of
smells. The filter needs to be replaced by a new one when the HEPA filter changes its color from
white to grey or black. f the HEPA filter remains white, there is NO need to replace the filter.
Warning Do never wet or rinse the HEPA filter with water.
How to order filters:
Contact Clean Air Optima Customer Service tel. + 31(0) 742670145 or visit our webshop:
https://www.cleanairoptima.com

9
Replace the UV-C lamp

10
Problem resolution
Specifications
• deal for rooms from up to 60m² / 150m³ (645ft²)
• AHAM certified for rooms up to 20,4m² (220ft²)
Maximum CADR: 131cfm (Dust)
• 6-fold filter technolog , 100% ozone free
• True HEPA filter capacity: > 99.97% of all particulate matter of 3 micron or bigger
• True HEPA filter surface: 0.75m² (8.07ft²)
• True HEPA filter provided with PTT (Pet Pure Treatment) coating
• UVC wavelength 254nm
• UVC spectrum >12 µW/cm² (on 1 meter distance)
• Fan capacity ca.220 m³/h
• Silent fan ca. 38 dB(A) (Low), 60 dB(A) (H )
• 5 speed levels
• 8 hours timer
• Voltage AC 220V-240V/50Hz
• Maximum power consumption 48 watt
• Purifies, enriches and refreshes indoor air with 6.000.000 negative ions/cm³
• Digital control panel
• Dimensions 25,6 x 17,0 x 55cm
• Colours dark grey / silver grey
• Weight 4kg
Problem Solution
The device does not work Make sure the device is plugged in
The device switches itself off Make sure the device is plugged in and the socket works
Check whether the HE A filter is well positioned in the device
Check whether the rear cover is snapped
No air circulation Unplug the device. Check whether the activated carbon pre-filter
and the HE A f
ilter are clean
.
Replace them if necessary
Intensified noise Make sure that the filters are clean. Replace them if necessary.
Long beeping It is time to replace the filters, see chapter "Cleaning and maintenance"

11
Filter spectrum
Dust / dust mite / particulates / bird dust, bacteria, germs / viruses, pollen and other allergens,
mildew, mold spores, cigarette smoke, chemicals and volatile organic compounds (VOCs), as well as
smells.
What does HEPA mean?
HEPA signifies High Efficiency Particulate Air. HEPA filters are the most effective filters that can be
found on the market. Clean Air Optima true HEPA filters catch 99.97% of all particulate matter with
the size of 3 microns or bigger passing through the filter.
What does CADR mean?
CADR or Clean Air Delivery Rate describes the amount of purified air (measured in cubic feet per
minute or CFM) that an air purifier can deliver to a room. A high CADR shows a high capacity to
deliver purified and clean air to the room.
CADR: 112 (cigarette smoke) – CADR: 131 (dust) – CADR: 123 (pollen)
What is AHAM
AHAM (Association of Home Appliance Manufacturers) is an independent organisation that checks the
test results of household appliances like air purifiers. AHAM is located in the US and certifies to the
client that the Clean Air Delivery Rate (CADR) has been verified independently and is conform to
ANS /AHAM -1 “Method for measuring the performance of portable air purifiers”.
Ask your retailer or your municipality for updated information regarding the disposal of the packaging
and of the device.

12
Service
WARRANTY CERT F CATE FOR THE Clean Air Optima CA-506
HEPA UV Ionizer Air Purifier
Date of purchase: …………………………………………………………………………………………
Customers name: …………………………………………………………………………………………
Address: …………………………………………………………………………………………………….
Telephone: ………………………………………………………………………………………………….
Email: ………………………………………………………………………………………………………..
Seller’s name: ……………………………………………………………………………………………...
Address: …………………………………………………………………………………………………….
1. Please fill in completely this Warranty Certificate. Send it with the invoice and the unit, postage
pre-paid and using the original packing box, to your distributor. Make sure to include the
appropriate return postage for the package.
2. Please enclose a short description of the damage, fault or malfunction, and the circumstances
under which these problems arose.
The Clean Air Optima CA-506 is subjected to strict testing procedures before leaving the factory.
f within one year from the date of purchase the product does not perform according to the
specifications, because of factory defects, the purchaser is entitled to free repairs or replacement of
parts upon presentation of this warranty (provided that the malfunction or damage to the device
and/or parts occurred under normal operating conditions). What is covered: All parts defective in
material and workmanship. For how long: one year from purchase date. What we will do: Repair or
replace any defective parts. Exclusions: Regular replacement filters and UV-C Lamp.
Other Conditions
The provisions of this warranty are in lieu of any other written warranty whether express or implied,
written or oral, including any warranty of merchantability or fitness for a particular purpose. The
manufacturer’s maximum liability shall not exceed the actual purchase price paid by you for the
product. n no event shall the manufacturer be liable for special, incidental, consequential, or indirect
damages. This warranty does not cover a defect that has resulted from improper or unreasonable use
or maintenance, faulty assembly, accident, natural catastrophes,
improper packing, or unauthorized tampering, alteration, or modification as determined solely by us.
This warranty is void if the label bearing the serial number has been removed or defaced.

13
