Clear One Chat 50 User manual

CHAT
™50 Personal Speaker Phone
QUICK START GUIDE

CHAT
™50 Personal Speakerphone
1
INSTALLING THE CHAT 50 SOFTWARE (WINDOWS)
1. Insert the Chat 50 CD into your computer’s CD-ROM/DVD drive.
>Note: This procedure shows Windows XP screenshots. The
installation instruction apply to both Windows XP and Windows
Vista. For instructions on installing this software on a Mac, please
refer to the Chat 50 User Manual.
2. Follow the instructions in the Setup Wizard to complete
installation of the Chat 50 software.

CHAT
™50 Personal Speakerphone
CONFIGURING AND TESTING YOUR CHAT 50
1. Using the included USB 2.0 cable, connect the Chat 50 to your PC
(Figure 1.0).
FIGURE 1.0 Connecting Chat 50 to a PC
2

CHAT
™50 Personal Speakerphone
3
2. Start the Chat 50 configuration software by
double-clicking the Clearone Chat icon on your desktop.
3. Click the Device Setup button.
ClearOne Chat desktop icon
Chat 50 Device Setup button

CHAT
™50 Personal Speakerphone
4
4. Click the type of device you are using with your Chat 50 (Figure 2.0).
CHAT
™50 Personal Speakerphone
FIGURE 2.0 Chat 50 Device Setup: Select 1st column

CHAT
™50 Personal Speakerphone
5
5. Click the manufacturer of your device; click Other or All, if not listed
(Figure 3.0).
FIGURE 3.0 Chat 50 Device Setup: Select 2nd column

CHAT
™50 Personal Speakerphone
6
6. Click the model of your device; click Other or All, if not listed (Figure
4.0).
FIGURE 4.0 Chat 50 Device Setup: Select 2nd column
CHAT
™50 Personal Speakerphone

CHAT
™50 Personal Speakerphone
7
7. Click the Apply to Chat button to
apply these audio settings to your Chat 50.
8. Connect your Chat 50 to the device you just configured (see the
specific connection picture in the following paragraphs for the
connection).
>NOTE: When connecting to an analog device, you can leave the
Chat 50 connected to your PC if you wish. (If you do, then you
do not need to connect the power supply because the Chat 50
is being powered through the USB 2.0 cable.)
Chat 50 Apply to Chat button

CHAT
™50 Personal Speakerphone
8
9. To ensure optimal sound quality, you need to customize the Chat 50’s
audio setting for every application and device you will use. Refer to
the tuning procedures in the Optimizing Sound Quality section in the
user manual.
10. If you wish to further adjust the Chat 50 audio settings for this
device, refer to the Chat 50 User’s Manual for more information.

CHAT
™50 Personal Speakerphone
9
CONNECTING YOUR CHAT 50
The following paragraphs show how to connect your Chat 50 to a
number of different devices:
CONNECTING CHAT 50 TO A TELEPHONE
1. Using the included power supply (USB Plus only), connect the Chat
50 to a power outlet (Figure 5.0).
2. Using a ClearOne telephone connection cable (available separately),
connect the Chat 50 to your telephone’s headset jack (or 2.5mm jack)
(Figure 5.0).

CHAT
™50 Personal Speakerphone
10
CHAT
™50 Personal Speakerphone
DO NOT plug the cable into the telephone’s line jack as
damage to the telephone and/or Chat 50 might occur.
(Custom cable
not included)
FIGURE 5.0 Connecting Chat 50 to a telephone

CHAT
™50 Personal Speakerphone
11
CONNECTING CHAT 50 TO A CELLPHONE
1. Using the included power supply (USB Plus only), connect the Chat
50 to a power outlet (Figure 6.0).
2. Using the included 2.5mm-3.5mm cellphone connection cable,
connect the Chat 50 to your cellphone’s headset jack (or 2.5mm jack)
(Figure 6.0).
3.5mm
2.5mm
FIGURE 6.0 Connecting Chat 50 to a Cell Phone

CHAT
™50 Personal Speakerphone
12
CONNECTING CHAT 50 TO AN MP3 PLAYER
1. Using the included power supply (USB Plus only), connect the Chat
50 to a power outlet (Figure 7.0).
2. Using a ClearOne MP3 connection cable (available separately),
connect the Chat 50 to your MP3 player’s headset jack (or 2.5mm
jack) (Figure 7.0).
MP3
(Custom cable
not included)
FIGURE 7.0 Connecting Chat 50 to an MP3 player

CHAT
™50 Personal Speakerphone
13
CHAT
™50 Personal Speakerphone
CONNECTING CHAT 50 TO A DESKTOP VIDEO CONFERENCING DEVICE
1. Using the included power supply, connect the Chat 50 to a power
outlet (Figure 8.0).
2. Using a ClearOne desktop video conferencing device connection
cable (available separately), connect the Chat 50 to your desktop
video conferencing device’s headset jack (or 2.5mm jack)(Figure 8.0).
(Custom cable
not included)
FIGURE 8.0 Connecting Chat 50 to a desktop video conferencing device

CHAT
™50 Personal Speakerphone
14
USING THE CHAT 50
POWER LED INDICATOR
The power LED indicator lights blue when the Chat 50 is connected to a
PC via the USB 2.0 cable or when the power supply is plugged in. The
indicator lights red when the Chat 50 microphone mute function is active.
VOLUME UP/DOWN & MUTE BUTTONS
Use the Volume Up/Down buttons to adjust the volume level of the Chat
50. Use the Mute button to mute the Chat 50’s microphone until the Mute
button is pressed again. If you are using the Chat 50 with a PC, you can
also use the Volume Control in Windows to make these adjustments.

TELEPHONE [phone]
1.801.974.3760
FAX [phone]
EMAIL [email protected]
TECHNICAL SUPPORT
Caution: Read the Safety Information
in the user manual
