Clearaudio Emotion CMB Upgrade Kit User manual

User manual
Bedienungsanleitung
© clearaudio electronic GmbH, 2020-02 Made in Germany
Emotion CMB
Upgrade Kit - Nachrüstsatz

User manual / Bedienungsanleitung
2 © clearaudio electronic GmbH, 2020-02
User manual ...............................................2 - 9
Bedienungsanleitung..................................10 - 17
Dear Clearaudio customer,
Congratulation’s to your choice of the Emotion-CMB upgrade Kit.
The Emotion CMB-bearing is based on a clearaudio patent, with it’s high polished ceramic shaft,
CMB-magnet rings and as well an integrated shield against magnetic elds. There is no bearing ball
needed anymore. The CMB-bearing lets the turntable platter oating like on a cushion of air and
gives a huge improvement to the Emotion turntable.
Please read this instructions carefully, to avoid any damages or loss of warranty.
These instructions will help you with an easy set-up and guarantee the highest pleasure for a long
time.
We wish you a lot of musical enjoyment with your new clearaudio Emotion-CMB turntable.
clearaudio electronic GmbH
CE-MARKIERUNG

User manual / Bedienungsanleitung
Made in Germany 3
Contents
1. Packing contents......................................................................4
2. Installation of the Emotion - CMB............................................5
3. Service .....................................................................................9
4. Special directions .....................................................................9
Warranty information...................................................................18 - 19

User manual / Bedienungsanleitung
4 © clearaudio electronic GmbH, 2020-02
1. Packing contents
Your CMB upgrade kit comes in a secure packing to avoid during the transportation any damages.
Please store this original packing, in case you need to ship the CMB.
1. Upper part of the CMB-bearing
2. Magnetic ring (lower part)
3. Tool to remove the bearing ball
12 3

User manual / Bedienungsanleitung
Made in Germany 5
2. Installation of the Emotion - CMB
The installation of the Emotion CMB upgrade kit is easy and done in a few minutes.
Please follow the steps to install your Emotion CMB upgrade kit:
Picture 1: Taking o the belt
Picture 3: Taking o the standard bearing
Picture 2: Taking o the platter
Step 1
Step 2
Step 3

User manual / Bedienungsanleitung
6 © clearaudio electronic GmbH, 2020-02
Step 4 Bearing ball removal tool
Picture 4: Removing the bearing ball. Please use the tool to remove the bearing ball.
Picture 5: Remove the bearing ball by pushing the tool into the
bearing.
Step 5
Step 6
Picture 6: Pull the tool out of the bearing. The bearing ball is now removed.

User manual / Bedienungsanleitung
Made in Germany 7
Picture 5: Remove the bearing ball by pushing the tool into the
bearing.
Step 7 !
Picture 7: IMPORTANT: Please remove the protection foil from the magnetic ring before applying the ring on
the turntable chassis.
Step 8
Picture 8: The side of the magnet ring with glue must face to the turntable chassis.
Place the magnet ring onto the bearing shaft.
Step 9
Picture 9: Synthetic bearing oil for the turntable bearing (2 – 3 drops).

User manual / Bedienungsanleitung
8 © clearaudio electronic GmbH, 2020-02
Step 10
Picture 10: Place the upper part of the CMB into the bearing shaft.
Step 11
Picture 11: Setting up the platter and allocate the belt
IMPORTANT: Use only genty pressure during this step!
The Emotion – CMB upgrade is now nished.
We wish you a lot of pleasure with your new Emotion-CMB upgrade.
Your clearaudio-team

User manual / Bedienungsanleitung
Made in Germany 9
3. Service
In case of any necessary service for all clearaudio products should be done by authorized personal
only.
In case of any repair, the clearaudio Emotion-CMB needs to be send to your nearest authorized
dealer or directly to the clearaudio factory:
clearaudio electronic GmbH
Spardorfer Str. 150
91054 Erlangen
Germany
Tel/Phone: [phone]
www.clearaudio.de
www.analogshop.de
[e-mail]
Send / ship the Emotion-CMB always and only in the original packing!
Please pack the CMB-bearing very carefully to provide any damages of the axis!
Only in the original packing clearaudio can provide the warranty.
4. Special directions
Only if the product is returned in it’s original packing clearaudio can provide the warranty of 3
years.
Transportation advice: If any transportation of the Emotion-CMB should be necessary, please always
be carefull to avoid any damages to the axis.
Please use the original packing!
About two years you can lubricate (but only if you recognize speed variations) the bearing of the
turntable with the clearaudio full synthetic bearing oil (Art. Nr. AC068). In this case it is enough to
put 2 or 3 drops of the oil into bearing.
Important:
Avoid any contact with cardiac pacemaker!
Avoid any contact with any credit cards!

User manual / Bedienungsanleitung
10 © clearaudio electronic GmbH, 2020-02
Sehr verehrte clearaudio – Kundin, sehr verehrter clearaudio - Kunde,
Der Emotion CMB Nachrüstsatz besteht aus einer Präzisionsscheibe mit einem eingelassenen
Magneten und einem Lageroberteil in dem ebenfalls ein CMB – Magnetring eingearbeitet ist.
Die Präzisionsscheibe wird über die bereits im Laufwerkschassis montierte Lagerbuchse zentriert
und mittels angebrachter Klebefolie am Laufwerkschassis befestigt.
Das Lageroberteil verfügt über eine Keramikachse mit polierter Oberäche und einer abgeschirmten
Magnetanordnung.
Das Emotion CMB Lager Nachrüstsatz macht eine Lagerkugel überüssig und lässt den Plattenteller
durch die patentierte Magnetanordnung wie auf einem Luftkissen schweben.
Um die volle Qualität des Emotion - CMB Upgrade nutzen zu können, lesen Sie bitte diese
Bedienungsanleitung aufmerksam durch. Alle Hinweise dienen dazu, Ihnen viele Jahre ungetrübten
Musikgenuss zu bereiten und Fehlbedienungen zu verhindern.
Wir bedanken uns bei Ihnen für Ihr Vertrauen und wünschen Ihnen viel Freude mit Ihrem neuen
clearaudio Emotion-CMB Upgrade.
clearaudio electronic GmbH
