BISSELL SC100
SPOT CARPET EXTRACTOR
Clemas & Co. Unit 5 Ashchurch Business Centre, Alexandra Way, Tewkesbury,
Gloucestershire, GL20 8NB.
Tel: [phone] Fax: [phone]
Email: in[email protected] Web: www.clemas.co.uk

2global.BISSELL.com
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
»Connect to a properly grounded outlet only. See grounding
»instructions. Do not modify the 3-prong grounded plug.
»Do not leave appliance when it is plugged in. Unplug from
outlet when not in use and before servicing.
»Do not expose to rain. Store indoors.
»Do not allow to be used as a toy. Close attention is necessary
when used by or near children.
»Do not use for any purpose other than described in this user
guide. Use only manufacturer’s recommended attachments.
»Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, have it repaired at an
authorized service center.
»Always install float before any wet pick-up operation.
»Do not pull or carry by cord, use cord as a handle, close a
door on cord, or pull cord around sharp edges or corners. Do
not run appliance over cord. Keep cord away from heated
surfaces.
»Do not unplug by pulling on cord. To unplug, grasp the plug,
not the cord.
»Do not handle plug or appliance with wet hands.
»Do not put any object into openings. Do not use with any
opening blocked; keep openings free of dust, lint, hair, and
anything that may reduce air flow.
»Keep hair, loose clothing, fingers, and all parts of body away
from openings and moving parts.
»Turn OFF all controls before plugging or unplugging
appliance.
»Use extra care when cleaning on stairs.
»Do not use to pick up flammable or combustible materials
(lighter fluid, gasoline, kerosine, etc.) or use in areas where
they may be present.
»Do not use appliance in an enclosed space filled with vapors
given off by oil-based paint, paint thinner, some moth-
proofing substances, flammable dust, or other explosive or
toxic vapors.
»Do not use to pick up toxic material (chlorine bleach,
ammonia, drain cleaner, etc.).
»Do not pick up anything that is burning or smoking, such as
cigarettes, matches or hot ashes.
»Use only BISSELL® Commercial cleaning products intended
for use with this appliance to prevent internal component
damage. See the Cleaning Formula section of this guide.
»Keep appliance on a level surface.
»Do not carry the appliance while in use.
»Operators shall be adequately instructed on the use of these
machines.
»This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
»This appliance is suitable for commercial use, for example in
hotels, schools, hospitals, factories, shops, offices and rental
businesses
»Wet filters and the interior part of the liquid container shall be
dried before storage.
»WARNING Do not allow the supply cord to come into contact
with the rotating brushes.
»This appliance is not suitable for picking up hazardous dust.
»If foam or liquid escapes from the machine, switch off
immediately.
»Clean the water level limiting device regularly and examine it
for signs of damage.
»Do not immerse. Use only on surfaces moistened by the
cleaning process.
»Inspect machine before each use to make sure it is free of
damage.
SAVE THESE INSTRUCTIONS
THIS MODEL IS FOR COMMERCIAL USE.
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
WARNING
Improper connection of the equipment-grounding conductor
can result in a risk of electrical shock. Check with a qualified
electrician or service person if you aren’t sure if the outlet is
properly grounded. DO NOT MODIFY THE PLUG. If it will not
fit the outlet, have a proper outlet installed by a qualified
electrician. This appliance is designed for use on a nominal
120-volt circuit, and has a grounding attachment plug that
looks like the plug in the illustration. Make certain that
the appliance is connected to an outlet having the same
configuration as the plug. No plug adapter should be used
with this appliance.
GROUNDING INSTRUCTIONS
This appliance must be connected to
a grounded wiring system. If it should
malfunction or break down, grounding
provides a safe path of least resistance
for electrical current, reducing the risk
of electrical shock. The cord for this
appliance has an equipment-grounding conductor and a
grounding plug. It must only be plugged into an outlet that is
properly installed and grounded in accordance with all local
codes and ordinances.
Grounded
Outlets
Grounding
Pin

global.BISSELL.com 3
Body Tools
What’s in the Box?
Standard accessories may vary by model.To identify what should be included with your purchase,
please refer to the “Carton Contents” list located on the carton top flap.
1. Power Switch
2. Power Cord
3. Quick Release™ Cord Wrap
4. Dirty Water Tank
5. Dirty Water Tank Carry Handle
6. Clean Water Tank Carry Handle
7. Clean Water Tank
8. Hose Grip
9. Spray Trigger
10. Hose Secure Latch
11. Flex Hose
1
2
3
4
5
7
8
9
11
10
6
Product View
For additional support videos and information about your vacuum, visit support.BISSELL.com.

4global.BISSELL.com
1. Remove tank from the back
of the machine by lifting the
clean water tank carry handle.
2. Unscrew the black cap and
remove bottle insert.
3. Fill tank with warm tap
water (140° F/60° C MAX) to
the water fill line.
4. Add cleaning formula up to
the “CLEANING FORMULA” fill
line (60 mL/2 oz).
5. Place bottle insert back into
tank and tighten the black cap.
6. Place the tank back onto
the machine.
Always use genuine BISSELL formulas in your machine. Other formulas may harm the machine.
Ultimate Stain Destroyer
30-second stain removal.
Ultimate + OXY
Removes deep down dirt, stains, & odours
Pretreat
Pretreat spots and stains to improve
carpet cleaning performance.
Carpet Cleaning Formula
Keep plenty of BISSELL® Commercial formulas on hand
so you can clean whenever it fits your schedule.
WARNING To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL
Commercial cleaning formulas intended for use with the carpet cleaning device.
Filling the Clean Water Tank
View our full lineup of powerful carpet cleaning formulas
at BISSELL-commercial.co.uk.

global.BISSELL.com 5
Using Your Machine
To purchase additional tools or formulas, visit BISSELL-commercial.co.uk.
1. Release the hose by twisting
the secure latch. Attach your
desired tool.
2. Twist the Quick Release™
Cord Wrap and unwind the
cord to plug into outlet.
3. Press the power button to
turn the machine ON.
4. Attach the 8cm or 15cm tool
to the hose grip until you hear
a “click”.
5. Point the tool approximately
1 inch above the spot or stain
and press the spray trigger.
6. Release spray trigger and
gently scrub the stain.
1. Vacuum to remove loose dirt from area to be cleaned.
2. Spray any BISSELL® Commercial stain pretreat formula to soiled areas or stains.
3. Allow to sit for at least 3 minutes.
4. Clean following instructions below.

6global.BISSELL.com
1. When the dirty water tank
reaches the “FULL” line it is
time to empty.
2. Remove dirty water tank
and carry to disposal area.
3. Unlock by rotating the
handle up and over the back of
the tank.
4. Remove lid and pour out
dirty water. Rinse out tank to
remove any debris.
5. Replace the tank lid and
rotate the handle forward to
lock back into place.
6. Before placing tank back
into the machine, remove any
debris from the red filter.
7. Remove and rinse the tools
under clean, running water.
Allow tools to dry.
8. It is recommended that you
suction clean water from a bowl
(or bucket) to rinse out the hose.
Lift end of hose and stretch out
to ensure all water is cleared.
9. Wrap and secure the flex
hose and power cord.
NOTICETo reduce the risk of a leaking condition, do not store where freezing may occur. Damage to internal
components may result.
After-Cleaning Care
Storing Your Machine
Store machine in protected, dry area at room temperature (40° F - 110° F).
WARNING To reduce the risk of electric shock, turn power OFF and disconnect from electrical outlet before
performing maintenance or troubleshooting.

global.BISSELL.com 7
Problem Possible Cause Remedies
Reduced/
no spray
Clean water tank may be
empty.
Refill tank.
Clean water tank may not be
completely seated.
Turn power OFF. Remove and reseat tank.
Pump may have lost prime. Hold end of hose below water level in tank
to prime.
Loss of
suction power
Tanks may not be completely
seated.
Turn power OFF. Remove and reseat both tanks.
Dirty water tank is full. Empty tank.
Troubleshooting
Below are some of the issues you may run into. If you don’t see the
issue you’re experiencing below, visit BISSELL-commercial.co.uk.
WARNING To reduce the risk of electric shock, turn power OFF and disconnect from electrical outlet before
performing maintenance or troubleshooting.
Warranty
Service
This warranty gives you specific legal rights,
and you may also have other rights which may
vary from state to state. If you need additional
instruction regarding this warranty or have
questions regarding what it may cover, please
contact BISSELL® Commercial Consumer Care by
e-mail or telephone asdescribed below.
Limited One-Year Commercial Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS
identified below, upon receipt of the product
BISSELL Commercial will repair or replace (with
new, refurbished, lightly used, or remanufactured
components or products), at BISSELL
Commercial’s option, free of charge from the date
of purchase by the original purchaser, for one
year, any defective or malfunctioning part. See
information below. This warranty does notapply
tofans orroutine maintenance components such
as filters, belts, or brushes. Damage or
malfunction caused bynegligence, abuse,
neglect, unauthorized repair, oranyother use
not in accordance with the user guide is not
covered.
BISSELL Commercial isnotliable for incidental
or consequential damages of any nature
associated with the use of this product. BISSELL
Commercial’s liability will not exceed the
purchase price of the product. Some countries do
not allow the exclusion or limitation of incidental
or consequential damages, so the above
limitation or exclusion may not apply to you.
*Exceptions and Exclusions From the
Terms of the Limited Warranty
This warranty is exclusive and in lieu of any
other warranties, either oral or written. Any
implied warranties which may arise by operation
of law, including the implied warranties of
merchantability and fitness for a particular
purpose, are limited to the one-year duration from
the date of purchase as described above. Some
countries do not allow limitations on how long an
implied warranty lasts so the above limitation may
not apply to you.
Note: Please keep your original sales receipt. It
provides proof of date of purchase in the event
of a warranty claim.
If your BISSELL Commercial product should require a service, for information about repairs and
replacement parts, or for questions about your warranty, please contact the distributor where the
product was purchased.
If your query remains unresolved, please visit BISSELL-commercial.co.uk.
