Clemas & Co i-move 2.5B User manual

i-move 2.5B Operator Manual
Clemas & Co. Unit 16 Ashchurch Business Centre, Alexandra Way, Tewkesbury,
Gloucestershire, GL20 8NB.
Tel: [phone] Fax: [phone]
Email: [email protected] Web: www.clemas.co.uk

3
Preface
Thank you for purchasing the i-move 2.5B®. The cordless i-move 2.5B with its lightweight backpack,
gives you more freedom of movement, especially in confined areas. There is no longer a need to
worry about difficult terrain with bumps, steps, or other obstacles.
The i-move 2.5B is easy to use when you follow the instructions. Please read the user manual
carefully. Become familiar with the correct operation and maintenance procedures. Store the manual
in a safe place. The manual is an essential part of the i-move 2.5B and must be handed over to the
new owner upon resale or exchange. Each i-move 2.5B has a unique identification number that can
be found on top of the main body. Your i-team partner needs this number when you order parts.
When this manual refers to “the manufacturer” this means: Future Cleaning Technologies B.V., an
affiliate company of i-team in Eindhoven, the Netherlands. When this manual mentions “the partner”
your local i-team resell and support service partner is referred to.
Purpose of the user manual
The purpose of the user manual is to provide the user with information during the life of the
i-move 2.5B in such a way that the i-move 2.5B is used correctly, efficiently and safely, even in the
event of reasonably foreseeable misuse.
The user manual contains instructions regarding:
•personal operator safety;
•intended and non-intended use of the i-move 2.5B;
•instructions for daily use;
•maintenance instructions;
•storage conditions;
•disposal of the i-move 2.5B.
These instructions must be considered to avoid risks that could lead to physical and/or material
damage.
Target audience
This user manual is intended for operators of the i-move 2.5B and their supervisors, as well as
partners and importers.
Operators of the i-move 2.5B
The i-move 2.5B may only be operated by a person who:
•has correctly read and understood the instructions in this manual;
•is trained by an experienced operator who has read and understood the instructions in this
manual.

4
Reading guide
The following symbols and terms are used throughout this manual to alert the reader to
safety issues and important information:
Symbol
Term
Explanation
WARNING
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to injuries of the
operator or bystanders, light and/or moderate damage
to the product or the environment.
CAUTION
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to light and / or
moderate damage to the product or the environment.
BATTERIES
Indicates a battery-operated machine, batteries must
be charged according to the instructions in the separate
Class I Battery Charger user manual. Batteries must be
disposed of according to your local laws and
regulations.
ATTENTION
Indicates a liability situation, where the manufacturer
or its partners and affiliates cannot be held accountable
for damages caused by non-compliance.

5
Content
Preface .................................................................................................................................................................... 3
Purpose of the user manual.................................................................................................................................... 3
Target audience ...................................................................................................................................................... 3
Operators of the i-move 2.5B ................................................................................................................................. 3
Reading guide.......................................................................................................................................................... 4
1Introduction.................................................................................................................................................... 7
1.1 Intended use of the product.................................................................................................................. 7
1.2 Non-intended use of the product.......................................................................................................... 8
1.3 Lifespan.................................................................................................................................................. 8
1.4 Modifications......................................................................................................................................... 8
1.5 Specifications......................................................................................................................................... 9
1.6 Warranty.............................................................................................................................................. 10
1.7 Identification ....................................................................................................................................... 11
2Description ................................................................................................................................................... 12
2.1 The remote control.............................................................................................................................. 13
3Safety............................................................................................................................................................ 14
3.1 General Safety Instructions ................................................................................................................. 14
3.2 Batteries .............................................................................................................................................. 14
3.3 Risks during operation......................................................................................................................... 14
4Transport and storage.................................................................................................................................. 15
5Assembly and installation............................................................................................................................. 16
5.1 Unboxing.............................................................................................................................................. 16
5.2 Assembly.............................................................................................................................................. 17
5.3 Replacing the dust bag ........................................................................................................................ 18
6Operation ..................................................................................................................................................... 20
6.1 Before you start................................................................................................................................... 20
6.1.1 Height adjustment........................................................................................................................... 20
6.1.2 Insert the battery ............................................................................................................................ 20
6.2 Normal operation ................................................................................................................................ 21
6.2.1 After normal operation ................................................................................................................... 23
6.2.2 Remove the battery ........................................................................................................................ 23
6.3 Operation with i-brush® ...................................................................................................................... 24
6.3.1 After operation with i-brush® ......................................................................................................... 27
6.3.2 Remove the battery ........................................................................................................................ 27
7Maintenance ................................................................................................................................................ 28

6
7.1 Cleaning ............................................................................................................................................... 28
7.1.1 Cleaning the machine...................................................................................................................... 28
7.1.2 Cleaning the hose and wand ........................................................................................................... 28
7.1.3 Cleaning the filters .......................................................................................................................... 28
7.2 Replacing the filters............................................................................................................................. 29
7.2.1 Replacing the cassette filter............................................................................................................ 29
7.2.2 Replacing the motor filter ............................................................................................................... 31
7.2.3 Replacing the fragrance cartridge ................................................................................................... 32
7.3 Brush and tool condition ..................................................................................................................... 33
7.4 Damaged or worn parts....................................................................................................................... 33
7.5 Maintenance frequency ...................................................................................................................... 33
7.6 Storage................................................................................................................................................. 33
8Trouble shooting .......................................................................................................................................... 34
9Decommissioning and disposal .................................................................................................................... 35
10 Attachments................................................................................................................................................. 36
10.1 CE Certificate ....................................................................................................................................... 36

7
1Introduction
The i-move 2.5B® is an easy and safe machine to use. This manual helps you get started and explains
the operation and maintenance procedure.
The battery must be fully charged before use. Please refer to the user manual of the i-charge® 5 for
the correct procedure.
This manual is intended for those who work with the i-move 2.5B and perform daily maintenance.
The manual must be read in full before the first actions. This manual describes the correct method of
use, safety measures, maintenance and transport.
i-team continuously improves all their products based on user experience and feedback. Any
deviations between the texts and/or images from the manual and your i-move 2.5B can therefore
arise from the difference in model or from possible changes due to continuous development and
innovation.
1.1 Intended use of the product
The i-move 2.5B is intended for indoor use for the collection of dry materials only.
Figure 1
The lightweight i-move 2.5B is specially developed to use in small spaces. For example: in hotel
rooms, classrooms, hospital rooms, shops, offices and also stairs.

8
Make sure that the i-move 2.5B® is maintained as described in section 7. Not following the
recommended maintenance may lead to hazardous situations and i-team Professional may NOT give
warranty.
Check the filters, brushes and the hose regularly for pollution or damage. Replace damaged parts.
For more information on how to order i-move 2.5B parts, please see section 7.4.
ONLY USE original i-team Professional parts! i-team Professional does NOT give warranty in case non
original parts are used.
Operation of the i-move 2.5B must be done by an adult person.
Keep the i-move 2.5B and the accessories clean.
In order to use the i-move 2.5B on different types of surfaces, besides the standard floor tool, also a
crevice tool, an upholstery tool and a round brush are available. These tools are easy to replace.
Select the right tool for each job.
1.2 Non-intended use of the product
WARNING
Non-intended use can have consequences for the safety of operators and bystanders
and will void the warranty on the product.
The i-move 2.5B is not intended to clean anything else but dry materials.
The i-move 2.5B is not suitable for the collection of:
•wet materials or water;
•hot ashes or lighted cigarette ends;
•hazardous or explosive substances;
•biological hazards;
•particulate matter;
•big pieces of glass, plastic or wood.
1.3 Lifespan
For a proper functioning and a long lifespan of the i-move 2.5B, it is important to follow the
recommended maintenance frequency mentioned in this manual.
1.4 Modifications
It is not permitted to make modifications to the design of the i-move 2.5B without consultation and
permission from the manufacturer. This affects the warranty, see section 1.6.

9
1.5 Specifications
Figure 2
Body size excluding harness (W x T x H):
224 x 240 x 480 mm
Weight (excl. hose and wand, incl. batteries):
5.28 kg
Battery weight (1 battery):
0.70 kg
Hose length (retracted/stretched out):
50 cm/200 cm
Capacity:
2.5 L
Sound level (1 m distance and 1 m distance on 1.5
m height):
77.5 dB(A)/ 72.7 dB(A)
Vibration (main body/handle):
Amplitude: 0.004/0.004 mm
Velocity: 0.3/0.7 m/s
Acceleration: 1.5/0.8 m/s²
Diameter of tools:
32 mm
Suction (200 gr. salt, full charging, area surface
1.5 x 1 m, test time 2 min.):
Net weight of suction (gr.): 189/159/184
Suction rate (%): 94.5/79.5/92
Motor:
250 W/28 V/9.6 Ah
Air flow (max.):
1.75 m³/sec
Application:
Indoor, dry
Power source:
i-power 8.7 battery
Battery spec i-power x:
14.4 V 8.7 Ah
Run time:
≈56 minutes
Charger type:
External
Material outer shell:
ABS
Material hose:
ESD

10
1.6 Warranty
The i-move 2.5B® should only be operated with the materials supplied. Using alternative supplies
may cause damage to the i-move 2.5B and may cause a risk to the operator. The use of alternative
supplies voids manufacturer's warranty. The warranty period is 1 year.

11
1.7 Identification
Each i-move 2.5B® has a unique serial number that can be found on the bottom of the main body.
Your i-team partner needs this number when you order parts.
Explanation type plate:
Product type: i-move 2.5B
Serial number:
Current: 28V/power 240 W
Distributer:
i-team Professional
Hoppenkuil 27 b
NL-5626 DD Eindhoven
Figure 3

12
2Description
The unique carrying system of the i-move 2.5B® ensures ultimate comfort during lengthy working
times. You can turn the i-move 2.5B on and off with the remote control. The i-move 2.5B uses a HEPA
H11 filter and also includes a fragrance cassette for pleasant smelling air. Combine the i-move 2.5B
with our i-brush® if you need extra suction power.
The i-move 2.5B consists of:
Figure 4
Legend
1.
A hose.
6.
A harness.
2.
An i-brush connector.
7.
A remote control.
3.
An hour meter.
8.
A wand.
4.
A hatch for the dust bag.
9.
A hose connector.
5.
Two battery holders.

13
2.1 The remote control
1. Battery power status display
(Figure 5, pos 1). The blue battery power
status LEDs are on during normal use. When
the battery is full all blue LEDs are on, when
the batteries get empty the blue LEDs will go
off one by one.
2. ON/OFF button (Figure 5, pos 2).
Figure 5

14
3Safety
Safety comes first, therefore please take time to read and understand these safety instructions.
Improper use can cause harm or void the manufacturer’s warranty.
3.1 General Safety Instructions
3.2 Batteries
BATTERY
During normal operation the 14.4 V batteries cause no safety hazard on their own.
Please keep in mind the following safety instructions:
•do not crush, pierce or damage in any way;
•do not heat or incinerate;
•do not short-circuit;
•do not dismantle;
•keep the battery dry;
•only charge between 5 °C ~ 40 °C/41 °F ~ 104 °F;
•only use between 5 °C ~ 45 °C/41 °F ~ 113 °F.
3.3 Risks during operation
WARNING
STOP OPERATION IMMEDIATELY if the i-move 2.5B® does not perform properly or
makes an unusual noise. Service the i-move 2.5B before you continue the operation.
WARNING
DO NOT use the i-move 2.5B on damp or wet surfaces. This will cause damage to the i-
move 2.5B and is dangerous to the user. The damage caused by the use on a wet
surface is not covered under the warranty.
WARNING
DO NOT operate the i-move 2.5B without a filter dust bag.

15
4Transport and storage
•do not store the i-move 2.5B® outdoors;
•store the i-move 2.5B in a dry place;
•in case the i-move 2.5B is stored for a longer period, remove the battery. See section 6.3.2;
•before you transport the i-move 2.5B , remove the battery. See section 6.3.2;
•before you use the i-move 2.5B again, make sure the battery is loaded, see the User Manual of
the i-charge® 5.

16
5Assembly and installation
The i-move 2.5B® does not require much assembly, the harness is already attached to the
i-move 2.5B. A battery and a battery charger can be ordered separately.
5.1 Unboxing
The i-move 2.5B is packed in 1 box. It includes the i-move 2.5B itself and a starter package of tools.
Figure 6
Legend
1.
1x crevice tool
6.
1x i-move 2.5B
2.
1x round brush
7.
1x harness
3.
1x upholstery tool
8.
1x remote control
4.
1x telescopic wand
9.
1x ESD hose
5.
1x standard floor tool
10.
1x this user manual

17
5.2 Assembly
1. Insert the hose (Figure 7, pos 1) into the body of the i-move 2.5B® (Figure 7, pos 4) and into the
wand (Figure 7, pos 2).
2. Attach the desired tool (Figure 7, pos 3) onto the narrow end of the wand.
Figure 7

18
5.3 Replacing the dust bag
ATTENTION
•Only use original i-team dust bags.
1. Place the i-move 2.5B® on a level surface.
2. Push the yellow button (Figure 8, pos 1) to
unlock the hatch.
3. Remove the hatch (Figure 8, pos 2).
4. Push the yellow button (Figure 9, pos 1) to
release the dust bag.
5. Pull the cardboard handle (Figure 9, pos 2) to
remove the dust bag (Figure 9, pos 4).
6. Pull the cardboard tag (Figure 9, pos 3) to
seal the dust bag.
Figure 8
Figure 9

19
7. Place the yellow holder (Figure 10, pos 1) in
its top position. Push the yellow button
(Figure 10, pos 2) and it will click into its
locked position.
8. Insert the cardboard collar of the new dust
bag (Figure 10, pos 3) fully into the yellow
bag holder.
9. Replace the hatch (Figure 8, pos 2), press in
firmly until it clicks.
Figure 10

20
6Operation
6.1 Before you start
1. Check the i-move 2.5B® for damage or defects.
2. Make sure that the dust bag is placed in the i-move 2.5B.
3. Make sure you have the correct tool for the intended purpose.
4. Check the brush from the tool for wear and tear.
5. Check the motor filter. See section 7.2.2.
6.1.1 Height adjustment
Pull the collar (Figure 11, pos 1) on the wand up
to unlock it, adjust the length of the wand and
release collar to lock it.
Figure 11
6.1.2 Insert the battery
1. Insert the battery (Figure 12, pos 1) in the
slot (Figure 12, pos 2), until you hear a
"click". The battery is now fixated. Repeat
this for the second battery.
Figure 12

21
2. Check the batteries by pressing the red
button (Figure 13, pos 1) on each individual
battery. See also 2.1.
3. Press the ON/OFF switch on the remote
control (Figure 13, pos 2) to turn off the
i-move 2.5B®.
Figure 13
6.2 Normal operation
CAUTION
Make sure that the harness is well adjusted, so it fits comfortably on your body.
Otherwise it can cause physical discomfort.
1. Place the i-move 2.5B on a table or similar
(Figure 14, pos 4).
2. Open the waistband (Figure 14, pos 3).
3. Loosen the buckle at the front
(Figure 14, pos 2).
4. Loosen the 2 buckles (Figure 14, pos 1).
Figure 14
