User Manual
CLEMENTS
eVAC
Hand Operated
Suction Pump
SUC 82015
Manual No. SUC 82015 003
Issue 8

CLEMENTS
2
User Manual
eVAC Hand Operated Suction Pump
Manual Number SUC 82015 00 Issue 8
Copyright © 2016 BMDi TUTA Healthcare Pty Ltd
The information in this manual was originated by, and is the exclusive
property of BMDi TUTA Healthcare Pty Ltd. It is furnished for customer
information only, and is not an authorisation or licence to make this product
or to furnish this information to others.
Safety
Thank you for purchasing this Clements eVAC Hand Operated
Suction Pump.
For your safety it is imperative that this unit only be operated
by authorised personnel in accordance with the instructions
as described in this manual. Operated in this way, the eVAC
Hand Operated Suction Pump will provide years of service.
Due to continual improvements in product design, the eVAC
Hand Operated Suction Pump may vary in detail from the
descriptions in this manual. In the event of further questions
please contact your local distributor or BMDi TUTA Healthcare
direct.
Hangzhou Jinlin
Medical Appliance Co Ltd
M14-3-4 Hangzhou Economic &
Technological Development one
Hangzhou
310018 hejiang PRC
BMDi TUTA Healthcare Pty Ltd
Unit 4B, 128-130 Frances St
Lidcombe NSW 2141
Australia
Phone: [phone]
Website: www.medaust.com
Sponsor:

CLEMENTS
3
Contents
Classifications............................................................. 4
Specifications.............................................................. 5
Description.................................................................. 6
Directions For Use ...................................................... 7
Cleaning And Disinfecting........................................... 8
Basic Function Test .................................................... 8
Maintenance ............................................................... 8
Cleaning And Cautions ............................................... 8
Disposal and Recycling............................................... 9
Spare Parts................................................................. 9
Warranty ..................................................................... 10
Contents

CLEMENTS
4 Classifications
Classifications
GMDN Code 6776
GMDN Term Suction Unit, Manually-powered
GMDN Synonym Aspirator
Device Class Class I
Sterilisation Not supplied in sterile state
Anaesthetic
Rating
NOT Category AP
NOT Category APG
Operation Mode Continuous operation within the limits of
manual operation
Identification
SUC 82015 eVAC Hand Operated Suction Pump
Intended Use
To provide a continuous vacuum source, within the stated
operating vacuum range, for the aspiration of fluids and
particulate matter in medical procedures carried out by
clinically trained and authorized personnel.
Uninterrupted Availability
This equipment is manually powered. If patient care
requires the uninterrupted availability of a source of
continuous vacuum, the clinical facility must make
provision for either a backup power supply or standby
suction units which are battery or manually powered.

CLEMENTS
5
Warning Symbols egend
The warning symbols marked on the equipment and their
meanings are shown as follows.
Attention, consult accompanying documents
Specifications
Vacuum Range 0 to -7 kPa
[0 to –550 mmHg]
Maximum Flow Rate Peak > 20 litre/min
Collection Jar Volume 00 ml
External Diameter of Cap (Suction Port) 17 mm
External Diameter of Cannula Connection 1 mm and 6 mm
Operating Ambient Requirement -20 °C to +50 °C
Storage Ambient Requirement -40 °C to +60 °C
Unit Dimensions 198 x 74 x 169 mm
Unit Weight 247 grams
Packed Dimensions (Unit) 2 0 x 180 x 80 mm
0. 85kg
Packed Dimensions (10 Pack) 460 x 4 0 x 210mm
4.5kg
**Specifications given are achievable under test conditions and may vary during actual use. **
Specifications

CLEMENTS
6
Description
The eVAC Hand Operated Suction Pump is a light, state of the art,
high-vacuum, portable emergency device, which can be powered with
one-hand operation, leaving the other hand free for different tasks. It
was designed with a swivel which gives the operator better
accessibility whilst working in tight situations and avoids premature
engagement of the overflow mechanism. The unit has been designed
to provide efficient operation and simple maintenance.
Directions For Use
Select the appropriately sized suction cannula and connector
according to the size of the patient. Attach Connector and Suction
Cannula to the Cap Connection Port of the Collection Jar. Attach
Pump Handle to the Cap Connection Port. Ensure that the Collection
Jar is firmly attached to the Cap Connection Port.
Caution: It very important that the Collection Jar Cap is attached all
the way to the Pump Handle, and that all connections are tight and
firm.
The eVAC Hand Operated Suction Pump is operated by a simple
squeeze action of the trigger. Pull or squeeze the trigger towards the
Pump Handle to create the vacuum in the pump, and fluid will be
suctioned into the Collection jar. A one-way valve mechanism
prevents loss of suction.
Description / Directions For Use
Suction Cannula
Collection Jar
Hand Pump
Connector
Cap Connection Port

CLEMENTS
7
Once suctioning is finished, remove the tube slowly from the patient.
Unsnap the filled Collection jar and Cannula from the Pump Handle.
Place the filled Jar and tubing into a poly bag; seal bag and dispose
of appropriately.
Overflow Protection Mechanism
The eVAC Hand Operated Suction Pump is equipped with an
overflow protection mechanism which will engage once the jar is
filled. It is not possible to continue squeezing the handle once the
Collection Jar is full; extremely high resistance will be felt. When this
happens, empty the Collection Jar or replace with a back-up jar for
further suctioning. The overflow protection mechanism will ensure
that the fluid will not enter the housing of the Pump Handle
assembly once the Collection Jar is full.
When the suction port of the cap is pointed towards the floor, a
flapper valve will close to avoid spilling the aspirated contents from
the Collection Jar.
If the tip of the Suction Cannula becomes blocked, increased
resistance will be felt and the Pump handle will become difficult to
operate. Do not continue suctioning and lift the Suction Cannula
away from the occlusion. Remove the blockage from the tip of the
Cannula by disconnecting and shaking until clear, or replace with a
fresh cannula.
If the pump is turned upside down, the overflow protection
mechanism will be engaged and it will be impossible to suction. If a
sudden resistance is felt during suctioning and the Collection Jar is
not full, then the overflow protection mechanism may have become
engaged. Disconnect the Collection Jar from the Pump to release the
vacuum; shake the jar slightly to reset and reconnect. This should
disengage the overflow protection mechanism.
Note: When disconnecting the Collection Jar from the Pump, it is
important to pull apart to separate—do NOT twist. Twisting can
result in damage to the end stops.
Directions For Use

CLEMENTS
8
Cleaning And Disinfecting
If the suction pump was contaminated, disinfect the pump and
handle (by scouring with warm soapy water, mild detergent, bleach
solution, etc) before placing into storage.
Caution: Do NOT immerse the pump unit in liquid.
Basic Functional Test
It is important to check the pump function before returning it for
use. Mount a Collection Jar , occlude the Connection Port with your
thumb or palm and squeeze the handle to check the vacuum.
Maintenance
Apart from the cleaning and testing procedures referred to above the
eVAC Hand Operated Suction Pump requires no special maintenance
or storage conditions.
Cautions
Read directions prior to use. The eVAC Hand Operated Suction Pump
should be used by persons with training in suction techniques. The
use of the suction device may require that appropriate infectious
disease precautions be taken during use, cleaning of the device, and
disposal of the tubing and the Collection Jar (as per local protocol).
Maintenance

CLEMENTS
9
Spare Parts
Spares Parts
Catalogue
SUC 82015 eVAC Hand Operated Suction Pump with
Collection Jar and Cannula Kit
SUC 82015 001 00ml Collection Jar and Cap for eVAC
Hand Operated Suction Pump
SUC 82015 002 Cannula Kit for eVAC Hand Operated
Suction Pump with 1 x Large Cannula,
1 x Small Cannula
SUC 82015 00 User Manual for eVAC Hand Operated
Suction Pump
Disposal and Recycling
Waste Materials
The contents of the collection jar, cannulae, may contain
biohazard wastes. Handle using safe handling procedures,
which may include the use of rubber gloves and eye protection,
and dispose of according to local protocols for biohazard
materials.
Recycling
At the end of their service life, the pump and accessories should
be dismantled if necessary, and disposed of according to local
requirements.

CLEMENTS
10 Warranty
Warranty
BMDi TUTA Healthcare Pty Ltd warrants that this product is free from
defects in workmanship and materials for a period of 12 months (
months for batteries) from the date of shipment by BMDi TUTA
Healthcare Pty Ltd or its authorised agent to the purchaser. Subject to
the conditions of this warranty, if the product fails to operate for any
reason within the warranty period and the product is returned to the
place of purchase at the purchaser's expense, Medical Australia Limited
will repair or replace the product free of charge.
If a valid warranty claim is made within 0 days from the date of
shipment, then BMDi TUTA Healthcare Pty Ltd will also reimburse the
purchaser for reasonable freight costs in returning the product to the
place of purchase.
Conditions of Warranty
1. The product must be returned to the place of purchase with proof of
purchase.
2. This warranty is only available to the original purchaser of the product.
. The product must not have had its serial number removed, defaced or
changed, its casing opened, its power supply altered or have been
tampered with in any other way.
4. This warranty does not cover :
• inadequate or incorrect site preparation;
• improper installation;
• connection to the wrong voltage;
• failure of the product due to misuse;
• the use or operation of the product outside of the physical, electrical
or environmental specifications of the product;
• use in a manner or environment in which the product is not designed
to be used;
• improper adjustment, calibration or operation by the purchaser;

CLEMENTS
11
Warranty
• the use of accessories including consumables, hardware or software
which were not manufactured or approved in writing by BMDi TUTA
Healthcare Pty Ltd ;
• any modifications of the product which were not authorised in writing
by Medical Australia Limited;
• any contamination or leakages caused or induced by the purchaser;
and
• inadequate or improper maintenance of the product.
5. This warranty does not cover normal wear and tear.
6. BMDi TUTA Healthcare Pty Ltd will not be responsible for damage or
loss caused during shipping.
7. In Australia, apart from any warranties implied by the Trade Practices
Act 1974 all other warranties expressed or implied and whether arising
by virtue of statute or otherwise are hereby excluded.
8. Outside Australia, all other warranties expressed or implied and
whether arising by virtue of statute or otherwise (including any
warranties implied by the Vienna Convention) are hereby excluded.
9. BMDi TUTA Healthcare Pty Ltd obligations under this warranty are
limited to the repair or replacement of the product, within the terms of
this warranty and the total liability of BMDi TUTA Healthcare Pty Ltd for
loss or damage of every kind whether arising pursuant to the terms of
the sale of the product or otherwise in connection with the product is
limited to the amount paid by the purchaser to BMDi TUTA Healthcare
Pty Ltd for the product.
10. Apart from any liability imposed by Part VA of the Trade Practices Act,
BMDi TUTA Healthcare Pty Ltd accepts no other liability for any loss or
damage occasioned (including consequential loss or damages) in any
way as a result of the use of the product.
11. The warranty does not extend to cover damage to the following parts as
they are inherently prone to wear :
• motor brushes
12. This warranty does not extend to cover corrosion due to any cause nor
to any damage to painted or anodised surfaces.
1 . BMDi TUTA Healthcare Pty Ltd will give the purchaser the benefit of any
manufacturer's warranty in respect of any components in the product
which were not manufactured by BMDi TUTA Healthcare Pty Ltd , if
such a manufacturer's warranty is available.
