Cleveland PS130W Assembly instructions

Cleveland Ironworks a subsidiary of Enerco Group Inc.
4560 West 160th st Cleveland, Ohio 44135 1-800-251-0001
WOOD PELLET FIRE STOVE
INSTALLER: Leave this manual with the appliance. CONSUMER: Save these Instructions for future reference.
THE AUTHORITY HAVING JURISDICTION (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE
DEPARTMENT, FIRE PREVENTION BUREAU, ETC.) SHOULD BE CONSULTED BEFORE INSTALLATION
TO DETERMINE ANY NEED TO OBTAIN A PERMIT. OBSERVE ALL LOCAL BUILDING CODES.
OPERATING INSTRUCTIONS
AND OWNER’S MANUAL
Model #
PS60W
PS130W
PSBF66W
READ INSTRUCTIONS CAREFULLY: Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions could result in property damage, bodily
injury or even death. Do not allow anyone who has not read these instructions to assemble, light, adjust or
operate the stove. Place instructions in a safe place for future reference.
PS60W (F500200)
PSBF66W (F500210)
Apple Store
Google Play Store
PS130W (F500205)
66688 REV F

2Operating Instructions and Owner’s ManualCleveland Iron Works Wood Pellet Fire Stove
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS
AND INSTRUCTIONS PROVIDED WITH THIS
STOVE CAN RESULT IN DEATH, SERIOUS
BODILY INJURY AND PROPERTY LOSS OR
DAMAGE FROM HAZARDS OF FIRE, EXPLOSION,
BURN, ASPHYXIATION, CARBON MONOXIDE
POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND
FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS STOVE.
IF YOU NEED ASSISTANCE OR STOVE
INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABELS, ETC. CONTACT THE
MANUFACTURER.
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION
HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS
BUILDING MATERIALS, PAPER OR CARDBOARD,
A SAFE DISTANCE AWAY FROM THE STOVE
AS RECOMMENDED BY THE INSTRUCTIONS
NEVER USE THE STOVE IN SPACES WHICH DO
OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS
GASOLINE, SOLVENTS, PAINT THINNER, DUST
PARTICLES OR UNKNOWN CHEMICALS.
WARNING: This product can expose you to
chemicals including lead and lead compounds, which
are known to the State of California to cause cancer
and birth defects or other reproductive harm. For
more information visit www.P65Warnings.ca.gov
Contents
SPECIFICATIONS................................................................................. 3
GETTING STARTED............................................................................. 4
SAFETY PRECAUTIONS.......................................................................5
CLEARANCE TO COMBUSTIBLES........................................................6
UNPACKING & ASSEMBLY..................................................................7
INSTALLATION ................................................................................... 7
ADDITIONAL MOBILE HOME REQUIREMENTS ..................................11
OPERATION ......................................................................................13
SMART STOVE WIFI CONNECTION ....................................................15
WIFI CONTROLS............................................................................... 16
MULTI FUNCTION CONTROLS ...........................................................17
MANUAL STOVE OPERATION ........................................................... 18
MAINTENANCE................................................................................ 19
WIRING DIAGRAM........................................................................... 27
SERVICE PARTS ................................................................................ 28

3Operating Instructions and Owner’s ManualCleveland Iron Works Wood Pellet Fire Stove
SPECIFICATIONS
Model # PS60W PS130W PSBF66W
DIMENSIONS
Stove Weight
[LBS (kg)] 198 (90) 221 (100) 265 (120)
Stove Dimensions LxWxH [in (cm)] 23.5” x 21.75 “ x 33.25”
(59.7 x 55.2 x 84.5)
24.0” x 24.5 “ x 36.5”
(61.0 x 62.2 x 92.7)
26.18” x 24.53 “ x 30.39”
(66.5 x 62.3 x 77.2)
Air Inlet Pipe Diameter [in (mm)] 2” (50) 2” (50) 2” (50)
Air Outlet Pipe Diameter [in (mm)] 3” (80) 3” (80) 3” (80)
Pellet Hopper Capacity [LBS (kg)] 60 (27.2) 130 (59.0) 66 (29.9)
OPERATION SPECIFICATIONS
Fuel Wood Pellet Wood Pellet Wood Pellet
Heats approximately **
[ft2 (m2)] 1500 (139.4) 2500 (232.3) 1800 (167.2)
Carbon Monoxide Produced
(g/min)
0.59 on High
0.77 on Low
0.00 on High
0.15 on Low
0.00 on High
0.09 on Low
Pellet Consumption Rate Low [LBS/HR
(kg/HR)] 1.43 (0.65) 2.4 (1.09) 1.48 (0.67)
Pellet Consumption Rate Medium
[LBS/HR (kg/HR)] 1.81 (0.82) 2.47 (1.12) 2.16 (0.98)
Pellet Consumption Rate High [LBS/
HR (kg/HR)] 4.01 (1.82) 6.04 (2.74) 4.59 (2.08)
Stove Efficiency 81.4% 78.7% 80.8%
Heat Output Rate Low [BTU/HR (kW)] 9,739 (2.85) 16,149 (4.73) 10,151 (2.97)
Heat Output Rate Medium [BTU/HR (kW)] 12,537 (3.67) 16,644 (4.88) 14,792 (4.34)
Heat Output Rate High [BTU/HR (kW)] 28,165 (8.25) 39,460 (11.56) 31,107 (9.12)
ELECTRICAL SPECIFICATIONS
Electrical Supply Requirements
[Voltage / Frequency / Phase] 120V / 60 Hz / Single 120V / 60 Hz / Single 120V / 60 Hz / Single
Electric Current During Lighting Phase
[Amperes] 3.3 3.3 3.3
Auger Motor R.P.M. 2.4 2.4 2.4
*BTU input/output will vary, depending on the brand of fuel you use in your Stove
** Depending on climate zone. Variations in climate and location affect attributes such as stove efficiency
and CO produced.
This manual describes the installation and operation of the brand “Cleveland Iron Works” wood pellet fire stove.
This stove meets the applicable U.S. Environmental Protection Agency’s emission limits for pellet fired heaters sold
after 2020. Under specific test conditions these stoves have been shown to deliver heat at rates ranging from:
PS60W: 9,739 to 28,165 Btu/hr
PS130W: 16,149 to 39,460 Btu/hr
PSBF66W: 10,151 to 31,107 Btu/hr

4Operating Instructions and Owner’s ManualCleveland Iron Works Wood Pellet Fire Stove
GETTING STARTED
ACCESSORY KIT
WHAT YOU’LL NEED (NOT SUPPLIED)
TOOLS REQUIRED
• Tape Measure
• Phillips Screwdriver or Comparable Electric Screw
Driver & Drill Bit.
• Stud Finder
• Plumb Bob
• Reciprocating Saw
• High Temperature Silicone or High Temperature
Sealant or High Temparture Flue Tape
• Floor Protection (see “FLOORING SPACE” and
“FLOORING MATERIAL” on page 6)
• Manufactured venting of 3” (80mm) in diameter
of type “L” or “PL” which is listed to UL 641, ULC
S609 (Standard for 650°C Factory-Built Chimneys), or
ULC/ORD C441. Install per chimney manufacturer’s
instructions (see page 9)
SAFETY EQUIPMENT (RECOMMENDED)
• Safety Glasses
• Gloves
• Closed-toed Shoes
• A friend (the stove is heavy, do not attempt to move
the stove without assistance)
Display Panel Firepot Main Power Cord Allen Wrenches (x2)
Cleaning ToolHose Clamp
Termination Cap and
Screws (x4)
Flex Hose

5Operating Instructions and Owner’s ManualCleveland Iron Works Wood Pellet Fire Stove
SAFETY PRECAUTIONS
HAVE AN ESTABLISHED PLAN FOR WHAT
TO DO IN THE EVENT OF A FIRE. CONTACT
YOUR LOCAL FIRE AUTHORITY TO ACQUIRE
INFORMATION AND A PLAN FOR WHAT TO DO
IN THE EVENT OF A CHIMNEY FIRE.
WARNING: DO NOT INSTALL IN SLEEPING
ROOM.
CAUTION: HANDLE STOVE WITH CARE.
AVOID STRIKING, SCRATCHING OR
SLAMMING GLASS ASSEMBLIES. DO NOT
OPERATE WITH CRACKED, BROKEN OR
SCRATCHED GLASS.
WARNING: HOT WHILE IN OPERATION. KEEP
CHILDREN, CLOTHING AND FURNITURE
AWAY. CONTACT MAY CAUSE SKIN BURNS.
WARNING: NEVER LEAVE CHILDREN NEAR
THE STOVE UNATTENDED WHILE THE STOVE
IS OPERATING.
WARNING: DO NOT OVERFIRE. OVERFIRING
THE APPLIANCE MAY CAUSE A FIRE. IF THE
UNIT OR CHIMNEY CONNECTOR GLOWS,
YOU ARE OVERFIRING.
WARNING: THIS WOOD HEATER HAS A
MANUFACTURER-SET MINIMUM LOW
BURN RATE THAT MUST NOT BE ALTERED.
IT IS AGAINST FEDERAL REGULATIONS
TO ALTER THIS SETTING OR OTHERWISE
OPERATE THIS WOOD HEATER IN A
MANNER INCONSISTENT WITH OPERATING
INSTRUCTIONS IN THIS MANUAL.
CARBON MONOXIDE
WARNING:
WHEN USED WITHOUT ADEQUATE
COMBUSTION AND VENTILATION AIR, THIS
STOVE MAY GIVE OFF EXCESSIVE CARBON
MONOXIDE, AN ODORLESS, POISONOUS
GAS.
WARNING:
EARLY SIGNS OF CARBON MONOXIDE
POISONING RESEMBLE THE FLU, WITH
HEADACHE, DIZZINESS AND/OR NAUSEA. IF
YOU HAVE THESE SIGNS, STOVE MAY NOT
BE WORKING PROPERLY. GET FRESH AIR AT
ONCE! HAVE STOVE SERVICED.
SOME PEOPLE - PREGNANT WOMEN,
PERSONS WITH HEART OR LUNG DISEASE,
ANEMIA, THOSE UNDER THE INFLUENCE OF
ALCOHOL, THOSE AT HIGH ALTITUDES - ARE
MORE AFFECTED BY CARBON MONOXIDE
THAN OTHERS.
Regardless of how safe this stove is, every fuel burning
appliance creates Carbon Monoxide. It is always a
good plan to reduce risk to you and your loved ones
as much as possible by installing a Carbon Monoxide
detector. It is recommended to install monitors in
areas that are expected to generate carbon monoxide
such as heater fueling areas, pellet fuel bulk storage
areas, or sheds containing hydronic heaters. Follow
the installation, operation, & maintenance instructions
provided by the manufacturer of your detector.
SMOKE DETECTORS
Have at least 1 smoke detector on each floor of
your building. Follow the installation, operation, &
maintenance instructions provided by the manufacturer
of your detector. Avoid false alarms by placing the
detector outside the immediate vicinity of the stove.
Typically a good installation location for smoke
detectors is near bedrooms.
FOR MORE SAFETY INFORMATION
For auxiliary information regarding pellet stove safety
and operation information contact the National Fire
Protection Association (NFPA) by mail at:
NFPA, Batterymarch Park, Quincy, MA 02269
or visit the NFPA website:
https://www.nfpa.org/
