Clevemed SleepView Operating instructions

Press the ON button located on the front of SleepView
®
.
The power light should light green.
The lights for each connected sensor should be green.
Sleep in a position that is normal and comfortable for you. Try to
spend some time on your back as sleep apnea can be worse in that
position.
In the morning, press and hold OFF button (if power light is already
turned off, turn it ON and then OFF). Lights circling clockwise in green
means a good study was recorded. If the lights circle counter-clock-
wise in red, call your healthcare provider as you may need to retake
the test the next evening.
Discard cannula in trash. Return the SleepView™ Kit to your
Discard cannula in trash. Return the SleepView™ Kit to your
healthcare provider.
Adjust the sensors until the light for each connected sensor is green.
Aux Sensor:
if the Aux sensor was not provided, the light will
remain off.
The sensor lights will go off after 90 seconds, but the power light will
remain on. If you need more time to adjust the sensors, press the
ON button again to turn all of the sensor lights on for an additional 30
seconds.
Green light: A strong signal is being recorded!
Green light: A strong signal is being recorded!
Amber light: The sensor needs to be adjusted until green.
Red light: The sensor is not properly attached to SleepView®.
4
5
6
7
8
STEP
STEP
STEP
STEP
STEP
Final Instructions
How to Use
SleepView®
SleepView®
Monitor
Improper routing of leads may result in a choking hazard.
Improper routing of leads may result in a choking hazard.
Do not use in conjunction with an external defibrillator. Immediately
Do not use in conjunction with an external defibrillator. Immediately
contact your healthcare provider if you encounter any problems
contact your healthcare provider if you encounter any problems
with the SleepView
®
Monitor or accessories.
Monitor or accessories.
396-0004 Rev. M (DCO 1253)
SleepView is a registered trademark and SleepView Direct is a service mark
SleepView is a registered trademark and SleepView Direct is a service mark
of Cleveland Medical Devices Inc.
In case of a medical emergency call 911
In case of a medical emergency call 911

STEP
2
Effort Belt
Verify that both snaps on the effort belt are firmly snapped to the SleepView
®
Monitor.
Over clothing, wrap belt using Velcro tabs
to secure snugly but comfortably around
chest, not too tight to cause discomfort and
not so loose that it is falling off. The belt
may overlap and wrap around your torso.
Pull belt above your chest line so
SleepView® is positioned at the center
of your chest. Women may wear the
belt above or below your breast.
Note:
Women can wear the belt above
or below the breast, whichever position
is more comfortable.
STEP
1
Nasal Cannula
Remove the nasal cannula from its plastic packaging.
SleepView®
Monitor
STEP
2
Effort Belt
Pulse OX
Nasal
Cannula
Cleveland Medical Devices Inc.
4415 Euclid Avenue, 4th Floor,
Cleveland, Ohio 44103 USA
STEP
3
Pulse OX
Verify the Pulse OX sensor is firmly plugged into SleepView
®
. You may route the wire through the
neck of your shirt and out the sleeve. Remove any nail polish or acrylic nails before testing.
Slide your index finger from either
hand into the sensor so the icon of
a finger covers your fingernail.
Use a Steri-Strip to secure the sensor to the
back or your hand. (A Steri-Strip can also be
used to secure the sensor to your finger.)
See back for final instructions.
Hold the nasal cannula with both
hands so the nasal prongs point up
toward your nose.
Insert the nasal prongs into your nose.
Pull the tubing behind both ears. Push
the plastic slide up to tighten the cannula
tubes at your chin. Use a Steri-Strip to
secure the tube to your cheeks.
Twist the end of the cannula clockwise
onto the Cannula connector on
SleepView®until snug.
See instructional video
How to Use SleepView
®
How to Use SleepView® How to Use SleepView
at ClevemedSleepview.com
