Climadiff CV52IXDZ User manual

Free-standing and under-mount service cellar
FR – MANUEL D’UTILISATION
p. 2
GB – USE INSTRUCTIONS
p. 25
D – GEBRAUCHSANWEISUNG p. 47 NL – HANDLEIDING p. 71
SP – MANUAL DE UTILIZACION
p. 95
INSTRUCTIONS FOR USE – CV52IXDZ

Before use, please read and follow the safety rules and operating instructions in this manual.
Firstly, we would like to thank you for purchasing an CLIMADIFF product and hope that this appliance
fully lives up to your expectations.
This appliance enables you to bring your bottles at room temperature or bring them to service
temperature (depending on the bottles) thanks to its wide adjustment range.
1. GENERAL SAFETY INSTRUCTIONS
Before you use your appliance for the first time, please read this
user manual carefully. Store it carefully so that you can refer to
it in the future, if necessary. To reduce the risk of fire, electrical
shock, or injury when using your appliance, follow these basic
precautions.
Generally speaking, your appliance must be maintained by a
qualified professional.
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including its
hints and warnings. To avoid unnecessary mistakes and
accidents or to avoid damage to the appliance, it is important to
make sure that all people using the appliance are thoroughly
familiar with its operation and safety features. Save these
instructions and be sure that they remain with the appliance if it
is moved or sold, so that anyone using it throughout its life will
be properly informed on its usage and safety notices. This will
ensure optimum operation of theappliance.
For the safety of life and property and to avoid any risk of injury,
keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by
omission.
This appliance is intended exclusively for domestic use and is
intended for the storage of special drink products at a storage

temperature higher than that of a storage compartment for fresh
products. Under no circumstances is it intended to keep food
products fresh.
Make sure that your electrical installation's voltage corresponds
to that on the appliance’s nameplate; the appliance must be
connected to an approved, earthed system. Incorrect repairs or
connections can cause safety hazards. Have your electrical
installation checked by a professional, if you are in any doubt.
This unit must be correctly connected to an earthed socket for
your protection. Do not cut off or remove the earth wire on the
mains cable supplied.
For safety reasons, do not use an electrical extension cable.
If your appliance is damaged (e.g. a major impact) or suffers
harm (power surge due to lightning, flood, fire), it may be
dangerous to use. Disconnect the mains plug and have the
appliance checked by an approved professional repairer.
To prevent any danger, do not replace a damaged mains cable
yourself. Contact your retailer, an approved service center or
professional repairer.
This appliance must be positioned such that the mains socket is
accessible. Do not move the appliance once it is full: you might
distort its body beyond repair. The electrical parts must not be
directly accessible.
 Keep children away from the appliance.
 Do not use this appliance outdoors.
In the event that liquid is accidentally spilled (broken bottle,

etc.) on electrical components (motor, etc.), disconnect the
mains plug immediately.
To prevent any risk of fire, electrocution or injury, do not
immerse the mains cable, plug or the appliance itself in water or
any other liquid. Do not handle the appliance with wet hands.
Keep the appliance away from any source of heat and out of
direct sunlight.
Do not allow the mains cable to hang from a table or be in
contact with sharp edges or hot surfaces.
Do not pull on the mains cable - take hold of the plug to
disconnect theappliance.
Ensure that the area where your appliance is positioned can
support its weight when loaded (a 75 cl bottle weighs
approximately 1.3 kg). Your cellar must be placed on a flat
surface. If you have to position it on a rug or carpet, place a
support underneath.
To prevent damaging the door gasket, make sure the door is
fully open when pulling shelves out of the rail compartment.
Safety of children and other vulnerable persons
 This appliance can be used by children aged from 8 years
and above, and by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
 User cleaning and servicing operations should not be carried

out by children, unless they are more than 8 years old and
are supervised.
 Keep all packaging away from children as there is risk of
suffocation.
• Risk of child entrapment. Child entrapment and suffocation
are not problems of the past. Junked or abandoned
appliances are still dangerous, even if they will “just sit in the
garage a few days”.
 If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance as
you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
 If this appliance, featuring a magnetic door seals, is to replace
an older appliance having a spring lock (latch) on the door or
lid, be sure to make the spring lock unusable before you
discard the old appliance. This will prevent it from becoming a
death trap for a child.
 Keep the appliance and its power cable out of reach of
children less than 8 years old.
 Before you throw away your old wine cooler: take off the door.
Leave the shelves in place so that children may not easily
climb inside.
General safety
WARNING — This appliance is intended to be used in
household and similar applications suchas:
 Staff kitchen areas in shops, offices and other working
environments,
 Farm houses and by clients in hotels, motels and other
residential typeenvironments,

 Bed and breakfast typeenvironments,
 Catering and similar non-retailapplications.
WARNING — To avoid a hazard due to instability of the
appliance, it must be fixed in accordance with the instructions.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance, as
they could leak or release fluids.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid ahazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction
and ensure that air can circulate, especially if the appliance is
recessed into a wall.
WARNING — Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at an
authorized waste disposal center. Do not expose to flame.
WARNING — The refrigerant of these appliances is R600a,

flammable and explosive articles should not be put in or near
the cabinet, to avoid the fire or explodecaused.
Refrigerating fluid
The refrigerating circuit in the appliance uses refrigerating
isobutene (R600a), which is a highly inflammable natural gas
and is therefore dangerous for the environment. When
transporting or installing the appliance, ensure that no element
of the refrigerating circuit is damaged. The refrigerating fluid
(R600a) is inflammable.
Caution: risk of fire
If the refrigerant circuit should be damaged:
 Avoid opening flames and sources ofignition.
 Thoroughly ventilate the room in which the appliance is
situated. It is dangerous to alter the specifications or
modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or
electric shock.
Electrical safety
 We decline any liability in respect of incidents caused by poor
electrical installation.
 The power cord must not be lengthened. Do not use an
extension cable, or adapter, or multi-way socket.
 Make sure that the power plug is not crushed or damaged. A
crushed or damaged power plug may overheat and cause a
fire.
 Make sure that you can access the main plug of the
appliance.
 Do not pull the main cable.

 Ensure that the appliance is always electricallyearthed.
 If the power plug socket is loose, do not insert the power plug.
There is a risk of electric shock orfire.
 You must not operate the appliance without the interior
lighting lamp cover.
 Disconnect the appliance before replacing the lightingbulb.
 The cellar is only applied with power supply of single phase
alternating current of 220~240V/50Hz.
 Do not attempt to replace a damaged power cable, contact
your after-sales service.
 The power socket must be easily accessible but out of reach
of children. In case of doubt, contact your installation
technician.
Daily use
 This appliance is intended to be used exclusively for the
storage of wine.
 Do not store flammable gas or liquids in the appliance. There
is a risk of anexplosion.
 Do not operate any electrical appliances in the appliance
(electric ice cream makers, mixersetc.).
 When unplugging always pull the plug from the mains socket
and do not pull on the cable.
 Do not place hot items near the plastic components of this
appliance.
 The appliance manufactures storage recommendations
should be strictly adhered to. Refer to relevant instructions for
storage.
 Keep burning candles lamps and other items with naked
flames away from the appliance so that do not set the

appliance on fire.
 The appliance is intended for keeping beverages in normal
household as explained in this instructionbooklet.
 The appliance is heavy. Care should be taken when moving it.
If your appliance is equipped with castors, remember that
these are only designed to facilitate minor movements. Do not
move the appliance over long distances.
 Never use the base, drawers, doors etc. to stand on or as
supports.
 To avoid items falling and causing injury or damage to the
appliance, do not overload the door racks or put food in the
crisper drawers.
Caution: cleaning and servicing
 Before carrying out servicing, switch off the power supply and
disconnect the appliance.
 When cleaning the appliance, do not use metal objects,
steam systems, volatile fluids, organic solvents or abrasive
substances.
 Never clean appliance parts with flammable fluids. The fumes
can create a fire hazard orexplosion.
 Do not use sharp or pointed objects to remove ice. Use a
plastic scraper.
Important information concerning installation
 Avoid locating the unit in moistareas.
 Keep the appliance away from direct sunlight and sources of
heat (stove, heater, radiator, etc.). Direct sunlight may affect
the acrylic coating and heat sources may increase electrical
consumption. Extreme cold or hot ambient temperatures may
also cause the appliances not to perform properly.

 Plug the wine cooler into an exclusive, properly installed-
grounded wall outlet. Do not under any circumstances cut or
remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be
directed toward a certified electrician or an authorized
products service center.
 To ensure proper electrical connection, follow the
recommendations given in the presentmanual.
 Unpack the appliance and visually check that it is not
damaged. Do not connect a damaged appliance. Inform your
retailer or point of sale of any damage. In such a case, keep
the packaging.
 It is recommended that the appliance be allowed to settle for
at least 24 hours before connecting the electrical power
supply, so that the compressor fluid feed is correct.
 Proper air circulation is necessary to avoid overheating. To
ensure sufficient ventilation, observe the installation
recommendationsprovided.
 In order to avoid fire risk, wherever possible, ensure that the
appliance is not in contact with walls or with any hot element
(compressor, condenser). Observe the installation
recommendations.
 The appliance should not be placed close to radiators or
cooking hot plates or gasrings.
 Check that electrical sockets remain accessible when the
appliance is installed.
Power saving
To limit the electricity consumption of your appliance:
 Install it in an appropriate place (see “Installation
instructions”).

 Leave the doors open as little time aspossible.
 To ensure that the appliance operates properly, clean the
condenser regularly (see“Maintenance”).
 Regularly inspect the door seals and ensure that they are
still closing properly. If this is not the case, contact your
after-sales service.
Trouble shooting
• Any electrical work should be carried out by a qualified and
skilled technician.
• The appliance should be repaired by an accredited repair
centre, using only manufacturer’s original spareparts.
R600a
Safety instructions
• Caution — Do not obstruct the ventilation grills on the
appliance. Keep ventilation openings in the appliance enclosure
or in the structure for building-in clear ofobstruction.
• Caution — Do not store explosive substances, such as aerosol
cans containing an inflammable propellant, in theappliance.
• Caution — Do not damage the refrigerating circuit in the
appliance.
• Caution — The refrigerating units use isobutane (R600a), and
should not be placed close to ignition sources (for example,
electrical contacts that are exposed or open contacts that could
be closed by the refrigerating fluid in the event of a leak). The
The appliance is designed for home use only. The manufacturer
declines any liability whatsoever in the case of other use.

refrigerating fluid type is specified on the power cabinet
identification plate.
• Caution — Do not use electrical equipment in the
compartments of the appliance, unless they are of the type
recommended by themanufacturer.
This appliance meets the requirements of all applicable European directives and their
amendments, and notably complies with the following standards:
 2011/65/EU(ROHS)
 2014/35/EU on electricalsafety
 2014/30/EU on electromagneticcompatibility
 643/2009/CE relating to energylabels
2. TECHNICAL DATA
Below is an example of the nameplate:
The nameplate attached to the inside or rear of the appliance (depending on the model) includes the
entire information specific to your appliance.
We recommend that you make a note of its serial number in this booklet prior to installation, so that
you can refer to it later (technical work, request for assistance, etc.).
Once the appliance is installed and loaded, access to it is not so easy.
CAUTION: no assistance can be provided without this information.

3. INSTALLATION INSTRUCTIONS
Before using this appliance
 Remove the exterior and interiorpacking.
 Before connecting the appliance to the power source, let it stand upright for approximately 24
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
 Clean the interior surface with lukewarm water using a soft cloth.
 When disposing your appliance, please choose an authorized disposal site.
 Place your wine cooler on a floor that is strong enough to support it when it is fully loaded. To level
your Wine cooler, adjust the front leveling leg at the bottom of the winecooler.
 Adequate ventilation is required, do not block the front air outlet.
 Not designed for placement in adage orbasement.
 The appliance is for indoor useonly.
 This wine cellar is designed for free-standing or built-under installation.
 Connect the cellar to a single socket, leaving a 30-mm gap between the back of the cellar and the
wall. Be careful to support it, so that your wine cellar is perfectly level (use of a spirit level is
recommended). This will prevent any movement due to instability, causing noise and vibration, and
will ensure that the door seals perfectly.
 This appliance is intended to be used exclusively for the storage of wine.
 This appliance is using flammability refrigerant. So never damage the cooling pipe work during the
transportation.
Attention
 Store wine in sealedbottles.
 Do not overload thecabinet.
 Do not open the door unless necessary.
 Do not cover shelves with aluminum foil or any other shelf material which may prevent air
circulation.
 Should the wine cooler be left empty for long periods it is suggested that the appliance is
unplugged, and after careful cleaning, leave the door ajar to allow air to circulate inside the cabinet
in order to avoid possible condensation, mold or odors forming.
CAUTION: please keep the appliance away from substance, which can cause ignition.
Ambient room temperature limits
This appliance is designed to operate in ambient temperatures specified by its temperature class
marked on the rating plate.
CLASS SYMBOL
AMBIENT TEMPERATURES RANGE (°C)
Extended temperate
SN
From +10 to +32
Temperate
N
From +16 to +32
Subtropical
ST
From +16 to +38
Tropical
T
From +16 to +43

Built-in installation drawings
Reversing the door
The door can be changed from left and right side. No special requirement, all the door is opened from
left side. If required to open from right side please refer to the following direction.
1. Remove the aeration grille (1) by undoing the screws(2).
2. Use a Phillips screwdriver to remove the top hinge. Lift the door and set it downcarefully.
3. Unscrew the bottom hinge.
4. Remove the plastic cap located on the opposite side.
5. Screw the hinge back into the opposite side of the door bottom.
6. Marry up the holies in the two hinges with the cabinet holes, then screw the hinges in (figureE).
7. Reposition the plastic caps on the other side of the cellar so as to plug the holes which are now
visible.

8. Reinstall the grille and screw it in (figureA).
4. OPERATING INSTRUCTIONS
It is recommended that you installed your appliance in a place where the ambient temperature is
between 16-32°C (N class marked on the rating plate). If the ambient temperature is above or below
recommended temperatures, the performance of the unit may be affected and it may not be possible
to obtain temperature between5-10°C/10-18°C.
• “RUN”
Power indicator
• “Power”
On/Off switch (press and hold for 3s)
• “Light”
Lighting control button
• “UpperChamber”
Upper chamber electronic display
• “Lower Chamber”
Lower chamber electronic display
• “Set Upper” button
Upper chamber temperature setting button
• “Set Lower” button
Lower chamber temperature setting button
Press “Set Upper” to adjust the upper chamber temperature. The relevant chamber display will start
to flash and each press on the button will alter the temperature by 1°C. Once the lowest set
temperature of 5°C is reached, the display automatically changes to the highest set temperature of
10°C. Once selected, the display will flash for approximately 5s before showing the current internal
temperature of the cellar. The set temperature can be viewed at any time by pressing and holding the
temperature select buttons.
Press “Set Lower” to set the upper chamber temperature.. The relevant chamber display will start to
flash and each press on the button will alter the temperature by 1°C. Once the lowest set temperature
of 10°C is reached, the display automatically changes to the highest set temperature of 18°C. Once
selected, the display will flash for approximately 5s before showing the current internal temperature of
the cellar. The set temperature can be viewed at any time by pressing and holding the temperature
select buttons.
In the event of a power cut, all previously selected temperature settings will be deleted and each
chamber will re-initialize to the factory-preset temperature of 6°C for the upper chamber and 12°C for
the lower chamber.

The set temperature can be viewed at any time by pressing and holding the temperature select
buttons for 5s.
Internal light
In order to reduce energy consumption, this wine cabinet will automatically switch off the LED lights
after 10 minutes.
If you want the LED light to remain on continuously, this is possible. Please press and hold the “Light”
button for 5 seconds, the display will show "LP". After 4 seconds the display will revert back to normal,
and the light will remain on until manually switchedoff.
If you want to revert back and conserve energy (recommended), please press and hold the “Light”
button for 5 seconds, the display will show "LF". After 4 seconds the display will revert back to normal,
and the light will automatically switch off after 10 minutes.
5. EQUIPMENT
The climate control system
According to advice from specialists, the ideal temperature for storing wine is around 12°C, within a
bracket of 10 to 14°C. Do not confuse this with service temperature, which varies between 5 and 18°C,
depending on the specific nature of thewine.
It is especially important to avoid sudden changes in temperature. Designed by specialists for
oenophiles, this appliance, unlike a simple refrigerator, takes into account the sensitivity of grand cru
wines to sudden variations in temperature by ensuring the close control of a constant average
temperature.
The anti-vibration system
The refrigeration compressor is equipped with special dampers (silent-blocks) and the inner space is
insulated from the body by a thick layer of polyurethane foam. These characteristics prevent the
transmission of vibration to your wines.
The humidification system
This appliance is fitted with a tray that maintains the correct level of humidity. If the humidity is too low,
top up the level in the reservoir to three quarters of its capacity. Check the level from time to time and
add water if necessary. Ensure that the tray always contains water.
Designed by specialists for oenophiles, Climadiff brand has taken into account the sensitivity of corks
to too low a level of ambient humidity. This is why the tray should be placed on the shelf below the fan
situated in the bottom, to provide minimum humidity. Be sure to check the water level, if you are
storing wines over a long period and you are not using the appliance solely for bringing wines to
service temperature (with a quick rotation of bottles).
The anti-UV system
Light accelerates the ageing of wine. In our solid door cellars, your wines are naturally protected, on
condition, of course, that the door is not opened too often. This glass-door model has been specially
treated and filters out harmful ultraviolet rays, thus ensuring your wines are perfectly shielded.
Defrosting
Your appliance is equipped with an automatic defrost cycle. When a cooling cycle finishes, the
appliance’s refrigerated surfaces are defrosted automatically. The defrost water is channeled into a
condensates evaporation tray which is located in the back of the appliance near the compressor. The

Front
heat produced by the compressor then evaporates the condensates collected in the tray.
The winter system
The winter kit is a frost protection system which enables the cellar to operate in an environment where
the temperature is between 0 and 32°C. A sensor located outside the appliance triggers a low power
electrical element when the ambient temperature in the room falls to around 8°C in case. This is a low
power element to avoid sudden rises in the temperature of the wine and so avoid thermal shocks that
are damaging to the preservation of the wine. The kit is intended to raise the cellar’s internal
temperature even before there is a thermal exchange with the bottles.
Shelves
 To prevent damage to the door seal, ensure that the door is fully open before pulling out the
shelves to add or remove bottles.
 For easier access to the contents of the shelves, slide the shelf out approximately one third of the
way. The shelves are, however, fitted with a stop to prevent the bottles fallingout.
 To remove or reposition the shelves, incline the shelf as indicated in the diagram, then push or pull
as required.
Foot sliders
Two foot sliders are provided with your appliance, allowing you to move it easily when your feet are
adjusted to maximum height. The foot sliders have to be installed in parallel under the feet in
accordance with the location for the front and for the back.
Back
Enhanced safety
Since this range of appliances is intended for storing items of value, we have been careful to select
quality components and to design suitable manufacturing techniques to ensure optimum safety in
operation.

Installing the handle
Your appliance has a stainless-steel handle. To fit it, simply screw it onto the door with the screws
supplied as per the diagram below, having first removed the seal.
6. LOADING
The maximum recommended loading quantities for bottles are given as guidelines and are indicative
only; they provide a quick estimate of the size of the appliance (similar to the capacity of a refrigerator
expressed in liters).
They correspond to tests conducted with a standard bottle: the standard “75 cl light Bordeaux” bottle -
standards apply the geographical origin of each bottle shape (Bordeaux, Burgundy, Provence, etc.)
and a type (traditional, heavy, light, flute, etc.), each with its own diameter and height.
In reality and in extreme cases, you could store more bottles by stacking the same type of bottle
without using shelves, but a varied cellar comprises a wide variety of bottles and the practical aspect
of everyday cellar management limits its capacity. You will therefore probably load the appliance a
little less than the recommended maximum.
Types of bottle:
We see here 4 kinds of 75 cl wine bottles: Burgundy and Bordeaux wine bottles of different
dimensions. There are many others of all shapes and sizes. You will note the storage differences
depending on bottle heights, diameters and alternating position method.
For example, if a wine cellar is loaded only with Burgundy wine bottles, there will be approximately
30% fewer bottles than the initial quantity calculated for Bordeaux bottles.
Front
Back

Criss-crossing types
Top-to-bottom neck-to-neck:
Note the difference in depth!
Top-to-bottom neck between bottle bodies:
Increased loading.
Examples of serving temperatures
Opinions vary, and the ambient temperature too, but many people agree on the following:
Prestigious Bordeaux wines – Reds 16 – 17°C
Prestigious Burgundy wines – Reds 15 – 16°C
Prestigious dry white vintages 14 – 16°C
Light, young, fruity reds 11 – 12°C
Provence rosés, primeur wines 10 – 12°C
Dry whites and vin de pays reds 10 – 12°C
Vin de pays whites 8 – 10°C
Champagnes 7 – 8°C
Sweet wines 6°C
7. CARE AND MAINTENANCE
Before cleaning your appliance (something that should be done regularly), disconnect it by removing
the plug or by pulling the fuse on the circuit.
Before using your appliance for the first time and regularly after that, we recommend that you clean
the inside and outside (front, side and top) with warm mixed with a gentle cleaning product. Rinse with
clean water and allow drying before reconnecting. Do not use solvents or abrasives.
When the appliance is switched on for the first time, there may be a residual odor. In that case, runt
the appliance empty for a few hours at the coldest possible temperature. The cold will kill any odors.
In case of a power cut
Most power cuts are resolved within a short time. A power cut of 1 or 2 hours will not affect the
temperature in your cabinet. To protect your wines during a power cut, avoid opening the door as
much as possible. During very long power cuts, take the necessary measures to protect your wine.
 If the appliance is disconnected or if there is a power cut, you must wait three to five minutes
before re- starting. If you try to re-start before this time, the compressor will only re-start after 3 to 5
minutes (if the temperaturerequires).
 When switching on for the first time or following a prolonged shutdown, it is possible that when re-
starting, the temperatures selected and those displayed are not the same. This is normal. It will
take a few hours before theystabilize.

Vacation time
• Short vacations: leave the wine cooler operating during vacations of less than three weeks.
• Long vacations: if the appliance will not be used for several months, remove all items and turn off
the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the
door open slightly: blocking it open ifnecessary.
Moving your wine cooler
• Remove all items.
• Securely tape down all loose items (shelves) inside your appliance.
• Turn the adjustable leg up to the base to avoiddamage.
• Tape the door shut.
• Be sure the appliance stays secure in the upright position during transportation. Also protect
outside of appliance with a blanket, or similaritem.
8. IN THE EVENT OF A BREAKDOWN
Despite the care we take during production, a breakdown can never be totally ruled out. Before contacting
your retailer’s after-sales department, please check that:
• The appliance is properly pluggedin
• There is not a power cut inprogress
• The breakdown is not one of those described in the table at the end of this manual
IMPORTANT: if the power cable supplied is damaged, it must be replaced by the manufacturer, a
service centre approved by the brand or the retailer. In all events, it must be replaced by qualified
personnel in order to avoid any risk of injury.
IF THESE CHECKS REVEAL NOTHING, THEN CONTACT YOUR RETAILER’S AFTER-SALES DEPARTMENT.
CAUTION!
Unplug the appliance before carrying out any maintenance or
repair work.
