CMD Rotasoc User manual

Isolate power then pull
up the fuse carrier with
the tabs on either side
of it.
Remove the fuse.
Replace with fuse type
ceramic IEC 60127-2
(10A max).
Push down the fuse
carrier until closed.
Isolate power and with
a suitable tool turn anti-
clockwise to release the
fuse carrier.
Isolate power then 1/4
turn the fuse carrier
anti-clockwise with a
suitable tool.
Open the spring loaded
cover to access RCD.
Support the cover as it
opens.
Remove fuse carrier and
fuse. Replace with fuse
type BS1362. (13A max).
Lift carrier and remove
fuse. Replace with fuse
type ceramic IEC 60127-
2 (5A max).
Push trip to ‘off’ position
then to ‘on’ to reset
RCD.
Re insert the carrier and
lock in place by turning
clockwise.
Re insert the carrier and
lock in place with a 1/4
clockwise turn using the
screw driver.
Close the spring loaded
cover to protect the
RCD.
Flip up the rubber screw
covers with a suitable
tool.
The power sockets can be freely rotated by hand in both clockwise and anti-
clockwise directions.
Insert a No.8 pozi-pan
screw or M4 bolt of the
required length into the
hole and tighten.
Once the module is
secured to the surface
push down the rubber
screw caps to nish.
On the rear face, release
the lever with a small
screw driver.
When connecting modules together, ensure that the coloured busbar shields
are colour matched and correctly aligned. Do not connect modules if shields
are of different colours.
Connect the male and
female ends together.
Both ends must be
colour matched.
Once connected, push
back the lever so it sits
ush with the surface to
lock modules together.
Connecting modules
Coloured busbar shields
Mounting to a surface
Rotating the sockets
Replacing fuse - circuit protection module
Replacing fuse - fused socket
Resetting the RCD/RCBO (if applicable)
1/4
turn
1/4
turn
Replacing fuse - infeed
Rotasoc Installation, user and care guide
Standard Earth
White White WhiteRed Red Red
Clean Earth Dual Circuit
TEST
16A infeed and UK sockets shown for illustration purposes.
Part No: 134264 Issue No: 001

CMD Ltd, Rotherham, S65 1EN, UK
T: 01709 829 511 E: [email protected]
Feed the wires into the
module and ex them
round to the opposite
terminals.
With the xing plate in
place, pull the cable in
towards the terminals.
Insert the conductors
into the correct
terminals and tighten to
a max torque of 0.8Nm.
Insert the conductors
into the correct
terminals and tighten to
a max torque of 2Nm.
Replace the terminal
cover then re insert and
tighten the M4 xing
screw to secure in place.
Replace the terminal
cover then re insert and
tighten the 2x screws to
secure in place.
Loosen M4 xing screw
on the underside of
module and remove the
terminal cover.
Remove the M4
xing screw from the
underside of the infeed
module.
Remove 2x nuts from
conduit xing plate and
put to one side. Leave
contact washer in place.
Loosen the 2x screws on
the top face and remove
the terminal cover as
shown.
Lift out the terminal
blanking plug in front of
the relevant terminals.
Insert the M4 ring
termimal into the screw
recess as shown.
Fit a ring terminated
earth wire and the 2x
nuts back on the xing
plate.
Prepare the wires as
shown with a suitable
wire stripping tool.
Prepare the wires as
shown with a suitable
wire stripping tool (3
core x 1.5mm² only).
Re insert and tighten
the M4 xing screw to
secure in place.
Ensure the nuts are fully
tightened.
Fix a suitable gland for
cable/conduit to the
xing plate and feed the
cable through.
Wiring the 16A infeed
Earthing the 16A infeed (Standard Earth and Dual Circuit) Earthing the 32A infeed
Wiring the 32A infeed
Additional information
• Installation is to be carried out in accordance with relevant Health & Safety regulations and only to be carried out by a skilled or competent person.
• The product should be installed to comply with the relevant national standards and be inspected and tested prior to being put into service (in the UK BS
7671 Wiring Regulations or BS 6396 Ofce and Educational Systems Best Practice).
• Isolate the supply before installation or repositioning. Any locking mechanisms must be used and fully engaged.
• Incorrect use could lead to risk of electrocution.
• Connectors must not be engaged or disengaged when under load or live.
• Product to be used only for the intended purpose of distributing power and data in ofce and commercial environments.
• Do not misuse, dismantle or re-congure the product because doing so will invalidate the warranty.
• If a product incorporates RCD protection, the RCD should be regularly tested in-line with current standards.
Safety
• Refer to the Declaration of Conformity.
Standards
• Fuse replacement only to be carried out by a skilled or competent person.
• Should the supply cable need replacing, contact CMD.
Further guidance
• Clean using a dry cloth. No abrasives or solvents to be used on the product.
• Do not drop or expose to moisture.
Product care
25mm *
* +5mm for Earth wire
Replace blanking plug in
unused hole rst
Hold the terminal cover
in place when removing
screw
Keep wires clear
of the xing
hole
* +5mm for Earth wire
55mm *6mm 10mm
