CNC4PC C36S User manual

USER’S
MANUAL
VER.1
C36S –QUAD RELAY BOARD
Rev. 1
MARCH 2018

User’s Manual Page i
USER'S MANUAL
TABLE OF CONTENTS
Contents Page #
1.0 OVERVIEW.....................................................................................................................1
2.0 FEATURES.....................................................................................................................1
3.0 BOARD DESCRIPTION..................................................................................................2
4.0 SPECIFICATIONS ..........................................................................................................2
4.1 Power Requirements.................................................................................................2
5.0 POWER BOARD.............................................................................................................3
4.1 Terminal Power.............................................................................................................3
4.2 Connector RJ45............................................................................................................3
6.0 RELAY SPECIFICATION................................................................................................4
7.0 RJ45 PINOUT.................................................................................................................4
8.0 WIRING SAMPLE...........................................................................................................4
9.0 DIMENSIONS..................................................................................................................5

User’s Manual Page 1
1.0 OVERVIEW
This board provides 4 electromechanical relays with NO (Normally Open) and NC
(Normally Closed) connections.
2.0 FEATURES
•4 Electromechanical relays with NO and NC positions.
•RJ45 connectors for Inputs.
You only have to use standard networks cable to make all your connections.
•Screw-On connections for all terminals.
•Status LEDs on all relays connections. No more guessing. You can SEE
all your signals.
•All TTL +5VDC or +3.3VDC Signals. Interface directly with parallel port interface
products and other cnc4pc.com cards.
•Din Rail Mountable. *NEW*.

User’s Manual Page 2
3.0 BOARD DESCRIPTION
4.0 SPECIFICATIONS
4.1 Power Requirements
It requires a +5VDC@200mA or +7-24V@200mA external power supply or voltage
supplied by the RJ45 to operate.
WARNING
Check the polarity and voltage of the external power source and connect the 5V and
GND. Overvoltage or reverse-polarity power applied to these terminals can cause
damage to the board, and/or the power source.

User’s Manual Page 3
5.0 POWER BOARD
5.1 Terminal Power
If used the terminal of power, set jumper as sample in the image
5.2 Connector RJ45
If used the connector RJ45 to power the board, set jumper as sample in the image.

User’s Manual Page 4
6.0 RELAY SPECIFICATION
ELECTROMECHANICAL RELAYS SPECIFICACTIONS
Maximun Current (AC)
7A@240VAC; 10A@125VAC
Maximum Current (DC)
15A@24VDC; 10A@28VDC
7.0 RJ45 PINOUT
8.0 WIRING SAMPLE
Note: This wiring is just to illustrate a sample product application. Specific wiring may
vary from system to system. It is the user’s responsibility to implement it correctly
RJ45 PIN
FUNCTION
1
GND
2
RELAY 4
3
RELAY 3
4
RELAY 2
5
RELAY 1
6
NOT USED
7
+5VDC
8
NOT USED

User’s Manual Page 5
9.0 DIMENSIONS
All dimensions are in Millimeters.
Fixing holes (3.8mm).
Disclaimer:
Use caution. CNC machines can be dangerous machines. Neither DUNCAN USA, LLC
nor Arturo Duncan are liable for any accidents resulting from the improper use of these
devices. This product is not a fail-safe device and it should not be used in life support
systems or in other devices where its failure or possible erratic operation could cause
property damage, bodily injury or loss of life.
