Coast to Coast Lucky Zone User manual

4000 Bordentown Avenue, Suite 16 Sayreville, NJ 08872
Phone: [phone] · Toll Free 1 800 224 1717 · Fax: [phone]
www.cranemachines.com
Lucky Zone

Contents
1、Important Information ······················································· 1
2、Introduction ··································································· 1
3、Accessories···································································· 3
4、Playing introduction ························································· 4
5、arnings ······································································ 5
6、Operation instruction ························································ 6
6-1、Lottery installation instruction ····································· 6
6-2、Methods of releasing from no lottries alarm ····················· 7
6-3、Moving instruction ·················································· 7
7、Configuration ································································· 8
7-1、The Configuration for the whole equipment ····················· 8
7-2、The Configuration for components ································ 8
8、Analyse for familiar malfunction ·········································11
9、Dail Code List ······························································ 12
10、Resource allocation List ················································· 13

1
1、
、、
、Important Information.
For indoor use only.
Outer size：35X35X91H（inches）
Weight：210lbs Frequency：50HZ
Power Supply：AC110V Power：350
Player Number：1 person
Warnings
 To avoid electrical Shock, turn off and unplug the game power before servicing.
 Please read this manual carefully before operating.
2、
、、
、Introduction
LUCKY ZONE is a fast coin amusement game. It is simple to play for all ages. The

2
game is setup for coins/tokens in and tickets out.. There are two attractive bonuses which
will keep the player's interests.

3
3、
、、
、Accessories
Please check all the following accessories are ready or not before moving
Fitting
Fitting Fitting
Fitting
name
namename
name Spec
SpecSpec
Spec Qua
QuaQua
Quantity
ntityntity
ntity Sketch
SketchSketch
Sketch map
mapmap
map Remarks
RemarksRemarks
Remarks
Power
supply 1
Setting according
to customer’s
local standard.
User Manual BOOK 1 User manual
Key
ZH88 1 For coin box
ZH66
1
For coins
inserting door,
front door, back
door
Dalinton
Tube TIP122 2
ULN2803L chip
encapsulation
2
LED board ZH-090901A 2
Infrared
Photoelectric
and Optical
infrared
receiver
QPT4652B-12 2 pairs
(
((
(Table one
Table oneTable one
Table one)
))
)

4
4、
、、
、Playing introduction


 Insert a coin/token, and the coin/token will drop onto the flat through Top Funnel Part.


 The coin/token will drops into a random hole, and the corresponding LED will light up;
and corresponding values will be paid in tickets according to the hole value displayed on
the hole.


 If the coin/token drops into “?” hole, the bonus hole will be chosen randomly (you can
set the quantity of bonus hole by adjusting dip switch settings).

5
5、
、、
、Notice
 The power cord must removed and unplugged before moving this machine.
 Please comply with manufacture’s requirements during the process of moving and
transportation.
 The equipment should be setup on a even floor.
 Please do not lay any sundries on the equipment. The power supply should not be pressed
by heavy object, and the circuit should not be uncovered for a long time.
 You must check the power plug and power supply is OK or not, check the voltage is
complied with the equipment requirement or not before turning on the power.
 The power supply voltage should be at 220V～240V.
 The power cord must be removed and unplugged before maintenance and repairs begin.
 Non-professional should not repair electricity-control setting of this equipment.
 You should seize the power plug when moving the power supply, please do not seize the
power supply.
 Please do not step on the power supply cord, or contact the power supply with wet hand
to avoid electric shock..

6
6、
、、
、Operation introduction
6-1、
、、
、Lottery-installing introduction.
A. Open the lottery door by the key
B. Put the lotteries in the lottery box with face upside.
C. Put the lottery in leading slot, and drive it below the holding wheel.
D. Press the jiggle switch in the lottery machine’s PCB by hand, until the first lottery is
sent out.
E. Lock the lottery door.
F. Notice
1.The lotteries should not be superposed when putting in the leading groove.
2.The lotteries should be set along the ticket-out direction
The eclectic wire should not be enwind or contacted with the lotteries
（
（（
（Picture One）
））
）
Operation introduction
hen inserting the lotteries, please press the jiggle switch on the PCB( or dial the
driver switch), the lotteries entry will be loosen state. Now, insert the lotteries into the
leading slot, and lead it to the holding wheel, until the first lottery is out.
常开
常开常开
常开
常闭
常闭常闭
常闭
Lottery leading slot
Gear
Lottery entry
High and low drive
high drive
Low drive
Signal feedback switch
on
off
Front
panel
Circuit
Board

7
6-2、
、、
、Methods of releasing from no lottery alarm
If there is no lottery in the box or error when outputting the lottery, the machine will
alarm automatically, and the methods of releasing from alarm are bellowing:
(一
一一
一)、
、、
、 Press the error releasing button on the code list to release from alarm.
(二
二二
二)、
、、
、 Install the lotteries, press the jiggle switch on the lottery machine to release from
alarm..
6-3、
、、
、Moving instruction.
The whole machine can be moved, and the method is very simple and rapid. The
operator just adjusts the top of the foot and wheel s under the equipment as bellowing:
（
（（
（Figure 2）
））
）
Notice：
 The machine should be at fixed state to keep even when working!
 The equipment should be power off when moving.
 Please do not move it by wheel when upstairs or downstairs.
 The operators should seize the equipment during the moving process
 Please do not lay any sundries on the equipment when moving
顶脚
顶脚顶脚
顶脚 脚轮
脚轮脚轮
脚轮
顶脚
顶脚顶脚
顶脚 脚轮
脚轮脚轮
脚轮
u
p
≈
≈≈
≈5mm
Top feet Caster
Top feet
Caster
Down
Ground
Moving state Fixed state

8
7、
、、
、Configuration
7-1、
、、
、The whole equipment configuration
（
（（
（图三
图三图三
图三）
））
）
7-2、
、、
、Components configuration
Hinge
滑币盘
（币由此落入各孔位）
Holes
Speaker
s
以文字图案显示
确定彩票数值或
币数值
Digital display
Stainless steel columns
Coins rolling plate
Coins drop from here
Determine the lotteries or
coins number by words
and picture
display
LED effect
Lotteries exit
Coins inserting machine
Top Funnel Part
Large turntable
Coins exit
Top feet

9
1、coins-inserting machine
CPU comparison coins-inserting machine：
：：
：
Advisable coins diameter：Ф22mm～Ф28mm
Advisable coins thickness:1.5mm～2.0mm
Working voltage：DC+12V±20%
orking temperature：0℃～+50℃
Operation instruction：
：：
：
(一
一一
一)、
、
、
、 Please move the test coins folder, take the test coins out, and change them for
using coins.
SW3
SW3SW3
SW3
人民币专用
S 1
S 2
wiring
N.O
N.C
100ms 长慢档
50ms 快档
25ms 短快档
Gary line
Red DC+12V
白线 Coin 讯号
码表
推荐设定
SW3
SW3SW3
SW3
For using real coins
For using sample
Accuracy
adjustment
low accuracy
High accuracy
G
ary line
Black
line
connect
to ground
hite line coin signal
Dial code
Advisable setting
100ms long and slow
50ms fast
25ms short and fast
Advisable setting
Coins folder
Sample coins
Coins inserting door
Coins inserting hole
Release from coins block
Counterfeit coins
will drop in
Coins inserting machine
lock

10
(二
二二
二)、
、
、
、 Choose to use real coins or sample cost, please adjust SW3
(三
三三
三)、
、、
、 Please adjust SW2 to choose the inserting signal speed.
(四
四四
四)、
、、
、 Please adjust the sensitivity of filtering coins, please spin the accuracy adjustment
to adjust；
2、Code list
The coins quantity and lotteries quantity is accurately counted by dial code list.
3、Power filter
（
（（
（Picture Five
Picture FivePicture Five
Picture Five）
））
）
ON
ONON
ON
OFF
OFFOFF
OFF
If the power cord is connected, and
power supply is on, but the
machine is still no power, please
check the fuse, or change it.
Coin counter Tickets counter
Error rel
easing button
power
Test button
Volume
adjustment
Connect
to the
power
Fitting the fuse Power switch

11
8、
、、
、Analyses for familiar error
Malfunction
description Causes
CausesCauses
Causes Resolution
ResolutionResolution
Resolution
Do not work
1、Power is off or fuse is broken
2、Switch power supply box is broken
3、CPU board is broken
4、Main PCB is broken.
1、Turn on the power,；change the
fuse
2、Change switch power supply box
3、change CPU board
4、change main PCB
No sound
1、Speaker is broken or circuit blocks.
2、Sound deposit chip is wrong inserted in or
broken.
3、Main PCB amplifier is broken.
1、Get through the circuit ,change
the speaker.
2、Re-insert in or change the Sound
deposit chip
3、Resolve the malfunction by hand
Coins block 1、Coins
CoinsCoins
Coins block
blockblock
block
2、Coins machine is broken or too precise
1、Resolve the malfunction by hand
2、Change the Coins machine or
adjust the precision
Lottery out
malfunction
1、Lottery machine is broken
2、Lottery machine is blocked
3、Circuit is block
4、The state of code-dialing switch is not
right
1、Change the lottery machine
2、Resolve the malfunction by hand
3、Check the circuit and get it
through
4、Affirm the state of dial code
switch(Reference to List 3)
Coins
CoinsCoins
Coins-
--
-out
out out
out
malfunction
malfunctionmalfunction
malfunction
1、Coins
CoinsCoins
Coins block
blockblock
block
2、Coins counter is broken or malfunctioned.
3、Photoelectric scores counting board is
broken and no scores or counting is not
correct.
1. Resolve the malfunction by
hand
2. Repair the coin counter or
change it.
3. Change the photoelectric
scores counting board.
Turntable is not
Turntable is not Turntable is not
Turntable is not
work
work work
work
1、The turntable motor is broken or
malfunction.
2、SCR（BTA12）is broken
1、Repair or change the turntable
motor.
2、Change the SCR(BTA12)
Turntable LED is
Turntable LED is Turntable LED is
Turntable LED is
not on.
not on.not on.
not on.
1、PCB ZH-090907A is broken.
2、Conductive ring is poor contact.
1、Repair PCB ZH-090907A
2、Resolve the malfunction by hand
Leakage of the
Leakage of the Leakage of the
Leakage of the
coins
coinscoins
coins-
--
-counting
countingcounting
counting
1、Two coins are overlapped when going into
the test hole.
2、Test hole blocks the coin.
1. It’s ok, if the coins are
overlapped, the coins will be
considered as one coin.
2. Open the back down door to
resolve it by hand.

12
（
（（
（Table 2）
））
）
9、
、、
、Dial Code
8
7 6 5 4 3 2 1 Usage
SW1
SW1SW1
SW1
ON Lottery out（Please dial the code on
KN 3.6
）（For lottery mode）
OFF No lottery out（Please dial the code
on KNW3.6）（For lottery mode）
ON Clear electric protect parameter
（Please dial the code on KNW3.6）
OFF
No action! （Please dial the code on
KNW3.6）
ON Coins out（Please dial the code on
KN 3.6
）（For coins mode）
OFF No coins out（Please dial the code on
KNW3.6）（For coins mode）
ON Unify the mode for coins or lotteries.
OFF
No action!（The face value of the
bonus hole is what, the same coins
or lotteries will be come out）
ON Unify the mode for lotteries.
OFF Unify the mode for coins.
SW2
SW2SW2
SW2
ON ON ON 1 coin=50 tickets(Could be mutual
converted)
ON ON OFF
1 coin=100 tickets(Could be mutual
converted)
ON
OFF
ON
1 coin=150 tickets(Could be mutual
converted)
ON
OFF OFF
1 coin=200 tickets(Could be mutual
converted)
OFF
ON ON 1 coin=250 tickets(Could be mutual
converted)
OFF
ON OFF
1 coin=300 tickets(Could be mutual
converted)
OFF
OFF ON 1 coin=400 tickets(Could be mutual
converted)
OFF
OFF OFF
1 coin=500 tickets(Could be mutual
converted)
ON
ON
0 light win when Winning “?”bonus
（Can be adjusted by dial code on
small PCB）
No
Usage
Setting
Code
group

13
ON
OFF
1 light win when Winning “?”bonus
（Can be adjusted by dial code on
small PCB）
OFF
ON
2 lights win when Winning “?”bonus
（Can be adjusted by dial code on
small PCB）
OFF
OFF
3 lights win when Winning “?”bonus
（Can be adjusted by dial code on
small PCB）
（
（（
（Table Three）
））
）
Remarks：
：：
：Please replace or power off then to restart the machine, the setting can be in effect if you
have reset the dial code
Hardware test process
Hardware test processHardware test process
Hardware test process：
：：
：
1、Lotteries machine test 2、Coins counter machine test 3、LED besides the door test
4、Turntable motor test 5、Digital tube and LED around test 6、Sound test（Total 16）
Please press hardware test button for next functional test each after you
finished a test.
10、
、、
、Resource allocation
allocationallocation
allocation List
ListList
List
Subdivision
Subdivision Subdivision
Subdivision
Port No:
Port No:Port No:
Port No: Port No:
Port No:Port No:
Port No:
Programmer
ProgrammerProgrammer
Programmer
resource
resourceresource
resource
Direction
DirectionDirection
Direction Usage instruction
Usage instructionUsage instruction
Usage instruction
IN0
JP1
JP1JP1
JP1
I Coins inserting signal
IN1 I Coin counter feed backing signal
IN2 I
IN3 I
IN4 I
IN5 I
IN6 I
IN7 I
IN8
JP2
JP2JP2
JP2
I Connect to H-090907A board 032
IN9 I Connect to H-090907A board 033
IN10 I Connect to H-090907A board 034
IN11 I Connect to H-090907A board 035
IN12 I Connect to H-090907A board 036
IN13 I
IN14 I
IN15 I
IN16
JP3
JP3JP3
JP3
I
IN17 I
IN18 I
IN19 I
IN20 I
IN21 I
IN22 I
IN23 I

14
IN24
JP4
JP4JP4
JP4
I
IN25 I
IN26 I
IN27 I
IN28 I
IN29 I
IN30 I Hardware Test button
IN31 I Replenish switch for No lottery alarm(if
error happens, press this button to go on)
+5V
JP13
JP13JP13
JP13
5V Power supply positive port
GND
Power supply negative port
GND Power supply negative port
+12V
12V Power supply positive port
1
JP11
JP11JP11
JP11 Sound
output
O
Left CH positive port
2-3 P Sound
4 O Right CH positive port
（
（（
（Followings continued）
））
）
Subdivision
Subdivision Subdivision
Subdivision
Port No:
Port No:Port No:
Port No: Port No:
Port No:Port No:
Port No:
Programmer
ProgrammerProgrammer
Programmer
resource
resourceresource
resource Direction
DirectionDirection
Direction Usage instruction
Usage instructionUsage instruction
Usage instruction
1
JP21
JP21JP21
JP21 Volume
adjustment VR
Right CH input
2 Right CH output
3 Sound
4 Left CH input
5 Left CH output
Ｏ0
JP
JPJP
JP5
55
5
ULN2803
ULN2803ULN2803
ULN2803
Ｏ Coins out code list drive
Ｏ1 Ｏ Lotteries counter code list drive
Ｏ2 Ｏ Coins inserting code list drive
Ｏ3 Ｏ
Ｏ4 Ｏ
Ｏ5 Ｏ
Ｏ6 Ｏ
Ｏ7 Ｏ
Ｏ8
JP6
JP6JP6
JP6
ULN2803
ULN2803ULN2803
ULN2803
Ｏ
Connect to H-090907A board P1.3（
（（
（to
judge whether start the demonstration or
not ）
））
）
Ｏ9 Ｏ
Ｏ10 Ｏ
Ｏ11 Ｏ
Ｏ12 Ｏ
Ｏ13 Ｏ
Ｏ14 Ｏ
Ｏ15 Ｏ
Ｏ16
JP7
JP7JP7
JP7
ULN2803
ULN2803ULN2803
ULN2803
Ｏ
Ｏ17 Ｏ
Ｏ18 Ｏ
Ｏ19 Ｏ

15
Ｏ20 Ｏ
Ｏ21 Ｏ
Ｏ22 Ｏ
Ｏ23 Ｏ
Ｏ24
JP8
JP8JP8
JP8
TIP122
TIP122TIP122
TIP122
Ｏ
Effect LED 1 besides the door（See from
front of the machine, from up to down,
with both sides paralleled）
Ｏ25 Ｏ
Effect LED 2 besides the door（See from
front of the machine, from up to down, with
both sides paralleled）
Ｏ26 Ｏ
Effect LED 3 besides the door（See from
front of the machine, from up to down, with
both sides paralleled）
Ｏ27 Ｏ Coins counting drive signal
Ｏ28 Ｏ Turntable motor drive signal.
Ｏ29 Ｏ Coins receiver funnel LED drive
Ｏ30 Ｏ
1
JP15
JP15JP15
JP15
UART0
UART0UART0
UART0
RS232
Comminication
+5V
2 I
3 Ｏ
4 GND
1 JP20
JP20JP20
JP20
External
Reset
GND
2 RST
（
（（
（Connected to above）
））
）
Subdivision
Subdivision Subdivision
Subdivision
Port No:
Port No:Port No:
Port No: Port No:
Port No:Port No:
Port No:
Programmer
ProgrammerProgrammer
Programmer
resource
resourceresource
resource Direction
DirectionDirection
Direction Usage instruction
Usage instructionUsage instruction
Usage instruction
P32I
JP17
JP17JP17
JP17
I feedback of lottery machine
+12V P
GND P
P32O Ｏ Lottery Machine Drive
（
（（
（Table four）
））
）
ZH-090907A Board wiring list
Subdivision
Subdivision Subdivision
Subdivision
Port No:
Port No:Port No:
Port No: Port No:
Port No:Port No:
Port No:
Programmer
ProgrammerProgrammer
Programmer
resource
resourceresource
resource
Direction
DirectionDirection
Direction Usage instruction
Usage instructionUsage instruction
Usage instruction
IN0
INPUT1
INPUT1INPUT1
INPUT1
I 30 lotteries refraction Test
IN1 I 10 lotteries refraction Test
IN2 I 15 lotteries refraction Test
IN3 I 20 lotteries refraction Test
IN4 I 40 lotteries refraction Test
IN5 I 13 lotteries refraction Test
IN6 I 10 coins refraction Test
IN7 I 5 lotteries refraction Test
IN8
INPUT2
INPUT2INPUT2
INPUT2
I 12 lotteries refraction Test 30
IN9 I 100 lotteries refraction Test 12
IN10 I 12 lotteries refraction Test 25

16
IN11 I 35 lotteries refraction Test
IN12 I 25 lotteries refraction Test 12
IN13 I 8 lotteries refraction Test
IN14 I 5 coins refraction Test
IN15 I 7 lotteries refraction Test
IN16
INPUT3
INPUT3INPUT3
INPUT3
I 50 lotteries refraction Test
IN17 I 20 lotteries refraction Test
IN18 I 18 lotteries refraction Test
IN19 I 16 lotteries refraction Test
IN20 I 40 lotteries refraction Test
IN21 I lucky refraction Test
IN22 I 2 coins refraction Test
IN23 I 13 lotteries refraction Test
P1.1
P1
P1P1
P1 口
口口
口
I/O
P1.2 I/O
P1.3 I/O
Connect to KNW ZH V3.6 board’s input
port Ｏ8（to judge whether start the
demonstration or not）
P1.4 I/O
P1.5 I/O
P1.6 I/O
P1.7 I/O
P1.8 I/O
（
（（
（Followings continued）
））
）
Subdivision
Subdivision Subdivision
Subdivision
Port No:
Port No:Port No:
Port No: Por
PorPor
Port No:
t No:t No:
t No:
Programmer
ProgrammerProgrammer
Programmer
resource
resourceresource
resource Direction
DirectionDirection
Direction Usage instruction
Usage instructionUsage instruction
Usage instruction
Ｏ0
0UT1
0UT10UT1
0UT1
Ｏ 30 lotteries LED drive signal
Ｏ1 Ｏ 10 lotteries LED drive signal
Ｏ2 Ｏ 15 lotteries LED drive signal
Ｏ3 Ｏ 20 lotteries LED drive signal
Ｏ4 Ｏ 40 lotteries LED drive signal
Ｏ5 Ｏ 13 lotteries LED drive signal
Ｏ6 Ｏ 10 coins LED drive signal
Ｏ7 Ｏ 5 lotteries LED drive signal
Ｏ8
0UT2
0UT20UT2
0UT2
Ｏ 12 lotteries LED drive signal 30
Ｏ9 Ｏ 100 lotteries LED drive signal 12
Ｏ10 Ｏ 12 lotteries LED drive signal 25
Ｏ11 Ｏ 35 lotteries LED drive signal
Ｏ12 Ｏ 25 lotteries LED drive signal 12
Ｏ13 Ｏ 8 lotteries LED drive signal
Ｏ14 Ｏ 5 coins LED drive signal
Ｏ15 Ｏ 7 lotteries LED drive signal
Ｏ16
0UT3
0UT30UT3
0UT3
Ｏ 50 lotteries LED drive signal
Ｏ17 Ｏ 20 lotteries LED drive signal
Ｏ18 Ｏ 18 lotteries LED drive signal
Ｏ19 Ｏ 16 lotteries LED drive signal

17
Ｏ20 Ｏ 40 lotteries LED drive signal
Ｏ21 Ｏ Lucky LED drive signal
Ｏ22 Ｏ 2 coins LED drive signal
Ｏ23 Ｏ 13 coins LED drive signal
Ｏ24
0UT4
0UT40UT4
0UT4
Ｏ
Ｏ25 Ｏ
Ｏ26 Ｏ
Ｏ27 Ｏ
Ｏ28 Ｏ
Ｏ29 Ｏ
Ｏ30 Ｏ
Ｏ31 Ｏ
Ｏ32
0UT5
0UT50UT5
0UT5
Ｏ Connect to KNW ZH V3.6 board’s input port
IN8（To judge which port will go into）
Ｏ33 Ｏ Connect to KNW ZH V3.6 board’s input port
IN9（To judge which port will go into）
Ｏ34 Ｏ Connect to KNW ZH V3.6 board’s input port
IN10（To judge which port will go into）
Ｏ35 Ｏ Connect to KNW ZH V3.6 board’s input port
IN11（To judge which port will go into）
Ｏ36 Ｏ Connect to KNW ZH V3.6 board’s input port
IN12（To judge which port will go into）
Ｏ37 Ｏ
Ｏ38 Ｏ
Ｏ39 Ｏ
（
（（
（Table Five）
））
）
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
