Coaster 300171QB1 User manual

Fine Furniture for every stage of life
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
PAGE 1 OF 5 COASTERFURNITURE.COM
300171QB1/B2
Metal Queen Size Bed
REVISION 0 : 05/16/2019
REVISION 2 : 07/12/2022
REVISION 3 : 11/25/2022

ASSEMBLY INSTRUCTIONS
ASSEMBLY TIME
PARTS IDENTIFICATION
30 MINUTES
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
AFRAME 2PCS
ITEM:300171QB1/B2
PAGE 2 OF 5 COASTERFURNITURE.COM
B1PC
C1PC
D1PC
E1PC
F8PCS
G4PCS
POST FOR HEAD
BOARD (LEFT)
POST FOR HEAD
BOARD (RIGHT)
POST FOR FOOL
BOARD(LEFT)
POST FOR FOOL
BOARD(RIGHT)
BALL
FOOT PAD

HARDWARE IDENTIFICATION
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
116PCS
28PCS
38PCS
LONG BOLT
(Φ1/4"x2-1/4")
ITEM: 300171QB1/B2
PAGE 3 OF 5 COASTERFURNITURE.COM
41PC
SHORT BOLT
(Φ1/4"x3/4")
FLAT WASHER
(Φ16.0xΦ6.5x1.5)
FLAT WASHER
(Φ16.0xΦ6.5x1.5)
ALLEN KEY
(4mm)

ITEM: 300171QB1/B2
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
PAGE 4 OF 5 COASTERFURNITURE.COM
F
B
A
C
1
4
1
1
E
4
1
A
3
2
G
D

ITEM: 300171QB1/B2
PAGE 5 OF 5 COASTERFURNITURE.COM
Product size:1956WX1333DX953H(mm)
Product size:77"WX52-1/2"DX37-1/2"H
57.2"
25.6"
19.5"
54.85"
51.3"
39.25"
36.3"
11.75"
25.5"
2"2"
15.4"
