Coaster 460056K User manual

PAGE 1 OF 7COASTERFURNITURE.COM
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
460056K
Full/Full Bunk Bed
REVISION 0 : 05
REVISION 1 : 0 /10/6 /2019
/2016
/06

ITEM:460056K
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME
COASTERFURNITURE.COM
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
PARTS IDENTIFICATION
30 MINUTES
PAGE 2 OF 7
AV BED END
(WITH LABEL A)
BV BED END
(WITH LABEL B)
CV TOP PLATFORM
DV BOTTOM PLATFORM
EV GUARDRAIL
1PC
1PC
1
PC
2PCS
1
PC
COASTER
FINE
FURNITURE
A

ITEM:460056K
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
HARDWARE IDENTIFICATION
COASTERFURNITURE.COM
PAGE 3 OF 7
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
1
2
4
4PCS
12PCS
4PCS
3
4PCS
5
1PC
LONG BOLT
(1/4"x65mm
- BLK
)
SHORT
BOLT
(1/4"
x
20
mm - BLK)
MEDIUM BOLT
(1/4"
x
5 5mm - BLK)
FLAT WASHER
(
Φ
6 x16
mm - BLK)
ALLE
N WRENCH
(4MM - BKL)
COASTER
FINE
FURNITURE

COASTERFURNITURE.COM
PAGE 4 OF 7
ITEM:460056K
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
5
1
5
2
5
2
2
5
4
3
AV
WITH LABEL A
EV
DV
CV BV
WITH LABEL B

COASTERFURNITURE.COM
PAGE 5OF 7
ASSEMBLY INSTRUCTIONS
ITEM:460056K
STEP 3
COMPLETE

ITEM:460056K
ASSEMBLY INSTRUCTIONS
The length and width of the bunk mattress are as follow:
Upper bunk 52 1/2"- 53 1/2" 6" Maximum
Lower bunk 52 1/2"- 53 1/2" 6" Maximum
1.
2.
3. Surface of mattress must be at least 5 in. (127 mm) below the upper edge of guardrails.
4. Do not allow children under 6 years of age to use the upper bunk.
5. Prohibit more than one person on upper bunk.
6.
7. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
8.
Always use the ladder for entering and leaving the upper bunk.
9. Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
10. Use of a night light may provide added safety precaution for a child using upper bunk.
11.
12. The use of water or sleep flotation mattress is prohibited.
13. Keep these instructions for future reference.
STRANGULATION HAZARD:
14.
REPLACEMENT PARTS:
Always use the recommended size mattress or mattress support or both to help prevent
the likelihood of entrapment or falls.
Periodically check and ensure that the guardrail, ladder, and other components are in
their proper position, free from damage, and that all connectors are tight.
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and wall.
Never attach or hang items to any part of the bunk bed that are not designed for use with
the bed for example, but not limited to hooks, belts, and jump ropes.
Replacement parts, including additional guardrails may be obtained from any COASTER
Furniture Dealer.
PAGE 6 OF 7COASTERFURNITURE.COM
74" -75"
Ensure thickness of mattress does not exceed 6” and there must be at least 5” from mattress
sleeping surface to top edge of guardrail.
SAFETY WARNING
Follow the information on the warnings appearing on the upper bunk end structure and on
the carton. Do not remove the warning label from bed.
Width
SIZE OF MATTRESS
Length
74" -75" Thickness
COASTER
FINE
FURNITURE
AA

ITEM: 460056K
ASSEMBLY INSTRUCTIONS
1.
2.
3.
4.
5.
Any misuse or unauthorized use of the ladder could result in serious or fatal injury.
Failure to follow the above WARNING, and/or failure to follow assembly instructions
completely, will void any and all liability of COASTER COMPANY OF AMERICA for
damages and injury to persons and property.
PAGE 7 OF 7 COASTERFURNITURE.COM
When using beds as bunk beds, the ladder MUST be securely attached to the upper bunk
rail at all times.
When using the beds as two (2) separate floor-standing beds, the ladder MUST be stored
in a separate location where children cannot use the ladder in any manner.
DO NOT use, nor permit children to use, the ladder in any manner whatsoever, other than
to access the top unit when used as bunk beds, and only if the ladder is securely attached
to the top bunk rail, as set forth in the instructions.
WARNING
TO PREVENT SERIOUS OR FATAL INJURY
Coasterfurniture.com | 877-COASTER (262-7837)
COASTER
®
FINE
FURNITURE

460056K
COASTERFURNITURE.COM
ITEM:
Dimension tolerance ±5%
Note :
59"
78.5"
56.75"
3.07"
11.81"
11.42"
15.75"
11.02"
32.68"
INNER SIZE: 53.94" X 75.39"
"
1
3
.
0
3
