Cobra 19 MINI User manual

A1 English
Our Thanks, The CB Story,
and Customer Assistance
Thank you for purchasing the Cobra 19 MINI. Properly used, this CB
radio will give you many years of reliable service.
Citizens Band Radio History
Nothing Comes Close to a Cobra®
®
NothingComes Close to a Cobra English
For more information or to
order any of our products,
please visit our website:
www.cobra.com
Owners Manual
19 MINI AM/FM
Ultra Compact Recreational CB Radio
4W Power / 40 Channels / 12V Adapter
For more information or to order any of our products, please visit our website: www.cobra.com
English
© 2022 Cobra Electronics Corporation www.cobra.com
Cobra®, and the snake design are registered trademarks of Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™is a trademark of Cobra Electronics Corporation, USA.
Invented by Al Gross in 1945, the CB radio originally served as a method of communication for troops
during World War II. After the war, Gross worked to make two-way radios a way of communication
for personal use and the CB radio service was established by law in the U.S. in 1949. It wasn’t until
the 1970s that technology advanced and the CB market caught on as a method of communication
between drivers to report police speed traps and road hazards.
The Citizens Band Radio Service consists of 40 channel frequencies that are mostly 10 kHz apart.
Transmitter power is limited to 4 watts in the US, and range can vary depending on the terrain and
quality of the product.
Currently, the Citizens Band service does not require a license for operation, regardless of age, as
long as the rules of operation established by the Federal Communication Commission (FCC) are
followed.
Petition For FCC Part 65 Rule Changes
In 2016, Cobra petitioned the FCC to revise Part 95 rules to allow CB radios to use frequency
modulation (FM). Cobra contended that FM offers improved speech quality and lower noise
interference, which improves the standard of two-way radios and is a benefit to the customer.
Through the direct efforts of Cobra Electronics and the enthusiastic support from loyal customers and
the distribution network, the FCC granted the request and in 2021, Part 95 officially was updated to
include FM as an option for two-way radio use.
Today, thanks to Cobra Electronics’ petitions to improve the quality of the Citizens Band Radio
Service, users can enjoy the benefits of CB radio communication in a range of industries.
Customer Assistance
Should you encounter any problems with this product, not understand its features, menu
or installation, please refer to the this owner's manual. If you require further assistance,
after reading this manual, we are here to help:
For Assistance Outside the U.S.A.
Contact Your Local Dealer
Customer Assistance
Service, Orders & Product Questions
For service, orders, product questions and service hours please call 800-543-1608
or go to www.cobra.com.

Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
A3
Product Features and
FCC Regulations
A2 English
Product Features
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
AM/FM
CH9/19
Power On-Off &
Volume Control
Squelch/Auto Squelch Control
Antenna Jack
Microphone
Jack
TX Indicator
Icon
S/RF
Power Meter
LCD Channel
Display
External
Speaker Jack
Power Connection
FCC Regulations •
FCC Compliance
Any changes or modifications not expressly approved by Cobra Electronics
could void your authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Microphone Connector Detail
Menu/Lock Button
Channel Up/Down
Buttons
Push-To-Talk
(PTT)

Intro Operation Customer
Assistance
Warranty
Notice
Secondary Icons
Caution Warning
Installation Customer
Assistance
1
Contents
Introduction
Our Thanks, The CB Story and Custmer Assistance........................................................A1
Product Features..........................................................................................................A2
FCC Regulations...........................................................................................................A3
Included in the Package..................................................................................................2
Installation and Start-Up
Powering the 19 MINI AM/FM ........................................................................................3
Powering your 19 MINI AM/FM with the 12V Power Adapter ...........................................3
Mounting and Connections
To Mount and Connect Your Transceiver ........................................................................4
External Speaker...........................................................................................................5
Power...........................................................................................................................5
Fuse .............................................................................................................................5
Microphone Connector ..................................................................................................5
CB Antenna...................................................................................................................6
Antenna Installation Overview........................................................................................6
Antenna Installation (Permanent)....................................................................................7
Display .........................................................................................................................8
Turning on Your CB Radio..............................................................................................9
Volume .........................................................................................................................9
AM/FM Mode ................................................................................................................9
Channel 9/Channel 19...................................................................................................9
Squelch ........................................................................................................................9
Auto Squelch...............................................................................................................10
Operating Procedure to Receive...................................................................................10
Operationing Procedure to Transmit.............................................................................10
Selecting a Channel.....................................................................................................11
S.RF Power Meter .......................................................................................................11
TX Indicator.................................................................................................................11
Channel Frequency .....................................................................................................11
Enable/Disable VOX.....................................................................................................11
Reset to Factory Default ..............................................................................................11
Menu Options..............................................................................................................12
Frequency Ranges.......................................................................................................13
Specifications .............................................................................................................14
Troubleshooting & Maintainance Adjustment................................................................15
Warranty
Limited Two-Year Warranty..................................................................................................16
Customer Assistance
Need Help?..........................................................................................................................18
FCC/IC/RF Exposure .............................................................................................................19

2English 3
Installation and Start-Up
Included in the Package
Secondary Icons
CB Transceiver Microphone
CB Mounting Bracket
Microphone Bracket
Quick Start Guide
12 Volt Accessory Power Cord
Hardwire Kit
Powering the 19 MINI AM/FM
There are three power options to use and operate the 19 MINI AM/FM CB:
1. From the 12V accessory port in the vehicle,
2. Hardwired directly to the battery, or
3. Hardwired to the fuse box.
Cobra includes a 12V power adapter with the 19 MINI AM/FM CB that allows you to
power up quickly and conveniently. In addition, the 12V power accessory is a modular
design to easily connect and disconnect from the CB. This also allows you to change
power from the 12V accessory option to hardwired power as needed. This design also
allows you to use your 19 MINI AM/FM CB in multiple vehicles.
Powering Your 19 MINI AM/FM with the 12V Power Adapter:
1. Select a location to mount the CB radio.
2. Mount the CB as instructed in the "Installing the 19
MINI AM/FM" section of this QSG.
3. Connect the 12V CLA cord to the CB. Make sure the
connection is secure.
4. Plug the CLA adapter into the vehicle's 12V accessory
port.
5. Push the Power ON/OFF Volume Control to power ON
the 19 MINI AM/FM CB.
NOTE: If you do not have a 12V power output in your vehicle, you can use the
included hardwire kit for direct-to-battery or fuse box installation (see Installing
the 19 MINI AM/FM in this Guide).
Cutting the 12V adapter from the provided cord for installation is not
recommended.
Total Cord Length: 60” (5’)
Introduction
Our Thanks, The CB Story and Custmer Assistance........................................................A1
Product Features..........................................................................................................A2
FCC Regulations...........................................................................................................A3
Included in the Package..................................................................................................2
Installation and Start-Up
Powering the 19 MINI AM/FM ........................................................................................3
Powering your 19 MINI AM/FM with the 12V Power Adapter ...........................................3
Mounting and Connections
To Mount and Connect Your Transceiver ........................................................................4
External Speaker...........................................................................................................5
Power...........................................................................................................................5
Fuse .............................................................................................................................5
Microphone Connector ..................................................................................................5
CB Antenna...................................................................................................................6
Antenna Installation Overview........................................................................................6
Antenna Installation (Permanent)....................................................................................7
Display .........................................................................................................................8
Turning on Your CB Radio..............................................................................................9
Volume .........................................................................................................................9
AM/FM Mode ................................................................................................................9
Channel 9/Channel 19...................................................................................................9
Squelch ........................................................................................................................9
Auto Squelch...............................................................................................................10
Operating Procedure to Receive...................................................................................10
Operationing Procedure to Transmit.............................................................................10
Selecting a Channel.....................................................................................................11
S.RF Power Meter .......................................................................................................11
TX Indicator.................................................................................................................11
Channel Frequency .....................................................................................................11
Enable/Disable VOX.....................................................................................................11
Reset to Factory Default ..............................................................................................11
Menu Options..............................................................................................................12
Frequency Ranges.......................................................................................................13
Specifications .............................................................................................................14
Troubleshooting & Maintainance Adjustment................................................................15
Warranty
Limited Two-Year Warranty..................................................................................................16
Customer Assistance
Need Help?..........................................................................................................................18
FCC/IC/RF Exposure .............................................................................................................19

Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
5
4
Installation and Start-Up
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Microphone Connector
Allows for convenient removal of the microphone plug
when storage is required. The microphone MUST be
connected to the unit at all times, when in use, for
proper operation.
External Speaker
The speaker jack on the rear panel is used for an External Speaker.
The external speaker should have an 8-Ohm impedance and be rated
to handle at least 4 watts. When the external speaker is plugged
in, the internal speaker is automatically disconnected.
Microphone Connector
External Speaker Jack
Installation
Power Cable
Installation
Power
These wires supply power to the CB radio. This cable is permanently
attached to the radio and terminates in a connector for a quick installation
of the included 12V vehicle power adapter or to connect to the hardwire
kit provided.
Fuse
The DC power wires and the 12V vehicle adapter includes a fuse (in the
tip) of the following type: include an inline fuse holder that contains the
following fuse type: F2AL 125V - UL rated.
NOTE: Cobra external speakers are rated at 15 watts.
WARNING:
The 19 MINI AM/FM external speaker output is a
Bridge Tied Load (BTL) design. Do not short the speaker wires to
ground as it may damage the speaker amplifier.
Notice
Select a location for the CB radio and microphone bracket that is convenient for operation.
In automobiles, the CB is usually mounted underneath the dash panel, with the microphone bracket
beside it. Avoid areas near airbags and mount to an area that is secure enough to hold it in place.
One (1) universal mounting bracket is supplied along with one (1)
microphone bracket, four (4) self-tapping screws and star washers.
The CB is held in the universal mounting bracket by two (2) thumb
screws, permitting adjustment to the most convenient angle.
To Mount and Connect Your Transceiver:
1. Hold the radio with mounting bracket in the exact location desired.
Remove the radio and use the mounting bracket as a template to
mark the location for the mounting screws.
2. Drill necessary holes and secure the mounting bracket in location.
3. Connect the antenna cable plug to the receptacle on the back
the unit.
4. Connect the red lead of the DC power cord to an accessory
12 volt fuse.
5. Connect the negative or black lead to the the frame of the vehicle.
NOTE: The battery is bonded to the vehicle frame most commonly
called the "chassis." Sometimes this requires removing paint to
get to a location with good electrical contact. Installation
requirements can vary depending on the vehicle.
6. Connect the CB and hardwire connectors.
7. Mount the microphone bracket in a convenient location that does
not interfere with vehicle operation using the two supplied screws.
8. Connect the microphone plug to the RJ-45 front panel jack.
9. Power the CB ON to use.
WARNING: Do not operate the CB without an antenna. This may
damage the transmitter.
Secondary Icons
CB Radio Bracket
Fuse Connection
Antenna Connector
Main Icons
Microphone Connector
Main Icons
NOTE: For improved CB radio performance, connect the radio power leads directly to the
vehicle battery. This helps to ensure:
1. Reduces conducted power line noise into radio by taking advantage of the mechanical filtering
properties of the vehicle battery;
2. By using the correct wire gauge between the battery and radio, voltage drops to the radio transmitter
section are minimized and transmitter RF output power is maximized.
Questions or Need Help? Please call Cobra Customer Care at 800-543-1608.
Mounting and Connections
CB Radio BracketMicrophone Bracket Mounting Hardware
Installation and Start-Up
Hardwire Kit Total Cord Length 60” (5’)

66
Installation and Start-Up Installation and Start-Up
NOTE : This product requires a CB antenna for use.
Cobra offers a line of CB radio antennas that can be used with your 19 Series CB Radio.
Visit cobra.com for antennas and antenna mounting options..
CB Antenna
Only a properly matched Antenna system will allow maximum power output. In mobile
installations (cars, trucks, boats, etc.), an antenna system that is nondirectional should be used.
When installed in a boat, the transceiver will not operate at maximum efficiency without a ground
plane unless the vessel has a steel hull. Before installing the transceiver in a boat, consult your
dealer for information regarding an adequate grounding system.
Antenna Installation Overview
A CB radio is only as good as the antenna it is
connected to. You can choose from two types of mobile
CB antennas, either a full-length whip antenna or a
loaded whip antenna. There are several different
mounting options depending your antenna and your
vehicle's specific requirements.
• There are two main methods for installing your CB
antenna. Temporary installation or permanent
installation.
1. Temporary installations typically utilize an antenna
with a magnetic base for easy installation anywhere
on the roof or hood of your vehicle. The Cobra HG
A1500 42-inch magnetic mount antenna is a good
example of such an antenna.
2. For permanent installations, the CB antenna is used
in conjunction with a more purpose-built metal base
that attaches to a specific part of a vehicle, whether
that be to the mirror, hood, trunk, etc.
Antenna Installation (Permanent)
As previously stated, permanent antenna installations
typically use a metal mounting piece in conjunction
with the CB antenna to securely mount to a specific
location on your vehicle. Each vehicle and CB user will
have different mounting requirements, so make sure
to determine the location that best suits your needs
before mounting your antenna.
1. When installing a mobile antenna, it must be fixed
to the vehicle where there is a maximum of metallic
surface (ground plane). A poor ground plane will
result in reduced transmission effectiveness from
your CB radio.
2. For an antenna that is attached by drilling into the
vehicle metallic body, ensure a good electrical
ground between the coax shield and the vehicle
body. Use proper protection for this electrical
connection to guard against exposure to moisture.
3. When mounting of the antenna is complete,
connect your coaxial cable running from your
antenna to the antenna jack on the back of your CB
radio. Be careful not to pinch the cable as this can
also reduce your radio’s transmission effectiveness.
4. Once your antenna is installed and connected to
your CB radio you can adjust its SWR if it is an
adjustable antenna. Consult your owner’s manual
for specific SWR adjustment instructions.

VOL
AM/FM
Signal Strength Meter
The Signal Strength Meter indicates the received signal strength
from the antenna. The meter segments shown on the LCD increase
with signal strength.
TX Indicator
The TX Indicator appears when in transmit mode. In this mode,
the meter shows all bars at full output power.
Channel Frequency
Displays the current channel frequency.
Enable/Disable VOX
1. Push and hold the Push-To-Talk switch on the microphone, then
2. Push and release the MENU button.
3. This will both enable and disable the VOX function.
Reset to Factory Default
1. Press and hold the MENU button to enter the menu list.
2. Turn the POWER button or press the microphone UP or DN button to
choose the RESET setting.
3.
Press and release the POWER button to select. RESET will blink in
the display.
4. Press and hold the POWER button until RESET stops blinking.
5. Release the POWER button and the radio will automatically
reset to factory default settings.
AM/FM, Channel 9/19 Button
Turning Your CB Radio ON/OFF
The main control of the CB is the channel knob (the largest button
on the radio). Push and release the channel knob to power the CB
radio ON or OFF.
On-Off/Volume Knob
Volume
Rotate the channel knob left or right to adjust the volume.
On-Off/Volume Knob
Notice
A. TX Icon
B. AM or FM Icon
C. Auto Squelch Icon
D. Channel
E. Key Tone Icon
AB C D
E
F. S/RF Meter
G. Channel Lock Icon
H. Channel Frequency
I. VOX Icon
FGHI
AM/FM Selection
Your 19 Series CB allows you change transmitter modulation and communi-
cate over AM or FM modes. Use the AM/FM mode select button to change
modes.
Changing AM/FM modes:
1. Press and release the AM/FM button to choose AM.
2. Press and release the AM/FM button again to choose FM.
Emergency Channel 9/19
Set CH 9 to obtain access to the emergency channel. Set CH 19 to obtain
instant access to the information and calling channel.
Channel 9/19 access:
1. Press and hold the AM/FM button for 2 seconds to select Channel 9.
2. Press and hold the AM/FM button for 2 seconds to select Channel 19.
3. Repeat step 1 to select Channel 9.
To squelch your radio:
1. Push and release the SQ/ASQ button.
2. Rotate the Channel knob to set the desired squelch level
(level selection is 1 - 34).
3. Push and release the SQ/ASQ button to save the setting.
Adjust Squelch
Display •
Squelch
This control is used to cut off or eliminate receiver background noise in the
absence of an incoming signal when properly adjusted.
Installation and Start-Up Operation
89
Channel Selection
1. Push and release the Channel knob.
2. Rotate the channel knob left or right to select the channel.
3. Push and release the channel knob to save the setting.
Selecting a Channel

11
10 English
OperationOperation
Intro Operation Customer
Assistance
Warranty
Notice
Secondary Icons
Caution Warning
Installation Customer
Assistance
Signal Strength Meter
The Signal Strength Meter indicates the received signal strength
from the antenna. The meter segments shown on the LCD increase
with signal strength.
TX Indicator
The TX Indicator appears when in transmit mode. In this mode,
the meter shows all bars at full output power.
Channel Frequency
Displays the current channel frequency.
Enable/Disable VOX
1. Push and hold the Push-To-Talk switch on the microphone, then
2. Push and release the MENU button.
3. This will both enable and disable the VOX function.
Reset to Factory Default
1. Press and hold the MENU button to enter the menu list.
2. Turn the POWER button or press the microphone UP or DN button to
choose the RESET setting.
3.
Press and release the POWER button to select. RESET will blink in
the display.
4. Press and hold the POWER button until RESET stops blinking.
5. Release the POWER button and the radio will automatically
reset to factory default settings.
S/RF Power Meter
TX Indicator
Main Icons
Channel Frequency
To auto squelch your radio:
1. Push and hold the SQ/ASQ button until "AQ" shows on the LCD
display. The ASQ level set will also show in the lower left side
of the display.
2. Rotate the Channel knob to set the desired ASQ level (level
selection is 1-9).
3. Push and release the SQ/ASQ button to save the setting.
Adjust Squelch
Auto Squelch
The Auto Squelch (ASQ) feature can help to improve the receiver
performance experience when enabled for communicating with
nearby stations. For weaker or more distant stations consider using
the SQ (traditional squelch) system or disable squelch for continuous
receiver audio.
Operating Procedure to Receive
Be sure the power cord, antenna and microphone are connected to
the proper connectors before proceeding further (see pages 4 and 5).
To receive:
1. Turn ON the radio.
2. Select the desired channel.
3. Set squelch to OFF (audio noise heard from speaker).
4. Set the receiver volume to a comfortable listen level.
5. Reset the squelch level for the intended listening requirements.
On-Off/Volume Knob
Squelch/ASQ Button
Press-to-Talk Switch
Main Icons
VOX
Operating Procedure to Transmit
Be sure the antenna is properly connected to the radio before
transmitting. Prolonged transmitting without an antenna, or with a
poorly matched antenna, could cause damage to the transmitter.
To transmit:
1. Select the desired channel.
2. The receiver and transmitter are controlled by
the Push-to-Talk switch on the microphone.
Press the switch and the transmitter is activated; release
switch to receive. When transmitting
(on a clear channel), hold the microphone
two inches from the mouth and speak clearly
in a normal voice.
Selecting the Menu
Intro Operation

13
12 English
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Operation
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
LCD Display Function Setting
KEY BP Beep on (default): turn on beep
oF: turn off beep
ROG BP
Roger Beep Sound oF, Tone settings 01 - 06
(End of transmission sound) oF: (default) turn off
roger beep
VOX L
VOX Level (Sensitivity) Level: 01 - 09
Default: 03
VOX T VOX Delay Time Level: 01 - 09
Default: 01
RF.GAIN RF Gain Control Levels
: 03, 06, 09 - 48
oF (default) RF gain off
TOTSET Time Out Timer oF, 01 - 10 minutes
Default: 05
PWRAUTO
Automatic Power On on (default): Auto power on
oF: Manual power on
FW VER Firmware Version Displays 2-digit
Firmware Version
RESET See Reset to Factory
Default Section (page 8)
Menu Options
1. Push and release the MENU button to access the menu
(see menu options in the Table below).
2. Turn the POWER button or press the microphone UP or DN
buttons to choose the desired function.
3. Push and release the POWER button on the selected option,
then rotate the knob to the desired setting and the POWER
button again to save the setting.
Selecting the Menu
Selecting the Menu
Intro Operation
Frequency Ranges
This unit features advanced Phase Lock Loop (PLL) circuitry providing
complete coverage of all 40 CB channels.
NOTE
All 40 channels support AM and FM operating modes.
CB
Channel
Channel Frequency
in MHz
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
CB
Channel
Channel Frequency
in MHz
21 27.215
22 27.225
23 27.255
24 27.235
25 27.245
26 27.265
27 27.275
28 27.285
29 27.295
30 27.305
31 27.315
32 27.325
33 27.335
34 27.345
35 27.355
36 27.365
37 27.375
38 27.385
39 27.395
40 27.405
Mode
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
Mode
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM

15
14 English
Intro Operation Customer
Assistance
Warranty
Notice
Secondary Icons
Caution Warning
Installation Customer
Assistance
Troubleshooting &
Maintenance/Adjustment
Specifications
•
Your Cobra CB transceiver is specifically designed for the environment encountered in
mobile installations. The use of all solid state circuitry and its light weight result
in high reliability. Should a failure occur, however, review the following, then if necessary,
replace parts with identical parts. Substitution is not recommended. If you have questions,
please call Cobra Customer Care at 800-543-1608 (hours are listed on the Cobra.com website).
Check Power Source
Check Fuses in DC Power Cord
1. Check connections to the source of power and make sure it
is the 13.8 VDC required to operate your radio.
2. Check the fuses in the DC power cord and in the 12V accessory
power plug.The main power lead (red) has a 2 Amp fuse -
type F2AL 125V - UL rated in its holder. Use only the above
specified type and size fuse for maximum protection.
Failure to do so will void the warranty.
3. Make certain the microphone is properly
plugged in.
4. Make certain the antenna is properly assembled and connected.
If you are unable to correct the problem, please contact Cobra
customer service.
Maintenance/Adjustment
English
Check Microphone Connection
Check Antenna Connection
Notice
y Icons
Caution
Notice
Secondary Icons
Caution
General
Channels CB - 40 CH AM and FM
Frequency Range CB – 26.965 to 27.405 MHZ
Frequency Tolerance 0.005 %
Frequency Control PLL (Phase Lock Loop) Synthesizer
Operating Temperature Range -30° C TO + 65° C
Microphone Plug-in Condenser
Input Voltage 13.8VDC nom. (negative ground)
Current Drain Transmit: AM / FM mod., 1.4A (Maximum)
Receive: Squelched, 0.9 A;
full audio output, 1.2A (nominal)
Size .98"H x 4.37"W x 4.09"D
Weight .66 lbs. (1.37 lbs. in package)
Antenna Connector UHF; SO-239
Fuse DC power cord inline fuse holder contains the
following fuse type: F2AL 125V - UL rated.
12V accessory charging cord contains the following
fuse type: F2AL 125V - UL rated.
Transmitter
Power Output 4 watts
Modulation AM (Amplitude Modulation)
FM (Frequency Modulation)
Frequency Response 300 to 3000 Hz
Output Impedance 50 ohms, unbalanced
Receiver
Sensitivity AM - Less than 1uV for 10dB (S+N)
FM - -120dBm @ 12 dB SINAD)
Selectivity 6 dB @ 7 KHz, 60 dB @ 10KHz
Image Rejection 60 dB, typical
Adjacent-Channel Rejection 50 dB, typical
Automatic Noise Limiter Built-in

NOTES
Need Help?
17
16 English
If you have any questions about operation or installing your new Cobra product,
PLEASE CONTACT COBRA FIRST…do not return this product to any retail store.
The contact information for Cobra will vary depending on the country in which you purchased
and utilize the product. For the latest contact information, please go to www.cobra.com/support
For products purchased in the U.S.A. you may call 800-543-1608.
For products purchased in the U.S.A., if your product should require factory service, please
please go to www.cobra.com/support and follow the instructions for returning your product
to the Cobra Factory Service Department for service.
Should there be any problems with this product or further information is needed on its features
please visit www.cobra.com for support, frequently asked questions, Declarations of Conformity,
and full manuals.
For Products Purchased Outside the U.S.A. or Canada
Please contact your local dealer for product service information.
For Products Used in Canada
Industry Canada Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
excempts de licence. L;exploitation est autorisée aux deux condtions suivantes:
(1) l’appariel ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
•
•
Limited Two-Year Warranty
Warranty Terms:
Cobra warrants your product against all defects in materials and workmanship for a period of two
(2) years from the date of original purchase.
Cobra, at our sole discretion, will repair or replace your product (with the same or comparable
product) free of charge.
Cobra will not pay shipping charges that you incur for sending your product to us. Products
received COD will be refused.
To make a warranty claim, we will require proof or purchase in the form of an invoice or receipt.
No proof of purchase is required for factory direct purchases.
Warranty Exclusions: Warranty does not apply to your product under any of the following
conditions: 1. The serial number has been removed or modified. 2. Your product has been
subjected to misuse or damage (including water damage, physical abuse, and/or improper
installation). 3. Your product has been modified in any way. 4. Your receipt or proof-of-purchase is
from a non-authorized dealer or internet auction site including E-bay, U-bid, or other non-autho-
rized resellers.
LIMITATION OF WARRANTY: EXCEPT AS EXPRESSLY PROVIDED HEREIN, YOU ARE ACQUIRING
THE PRODUCT "AS IS" AND "WHERE IS", WITHOUT REPRESENTATION OR WARRANTY. COBRA
SPECIFICALLY DISCLAIMS ANY REPRESENTATION OR WARRANTY INCLUDING, BUT NOT
LIMITED TO THOSE CONCERNING THE MERCHANTABILITY AND SUITABILITY OF THE PRODUCT
FOR A PARTICULAR PURPOSE. COBRA SHALL NOT BE LIABLE FOR CONSEQUENTIAL, SPECIAL
OR INCIDENTAL DAMAGES INCLUDING, WITHOUT LIMITATION, DAMAGES ARISING OUT OF
THE USE, MISUSE OR MOUNTING OF THE PRODUCT.
The above limitations or exclusions shall be limited to the extent they violate the laws of any
particular state. Cobra is not responsible for products lost in shipment between the owner and our
service center.
General Warranty Information
Each product we manufacture is covered by our factory warranty. While each product may have
unique components and policy, the general guideline below will apply to most Cobra products.
All Cobra products purchased factory-direct or from our Authorized Resellers will come with a full
one to three (1-3) year warranty from the date of the original retail purchase (see policy statement
above for full warranty details and exclusions).
Standard accessories packaged with each model will have a one-year factory warranty.
Accessory items have a one-year factory warranty.
Shipping to our facility is not covered in our warranty. Return shipping is included within the US.
This warranty is non-transferrable.
For the sake of clarity, ‘repair or replace the Product or its defective part’ does not include removal
or installation work, costs or expenses which include but are not limited to labor costs or expenses.
Cobra will not be responsible for lost packages.

19
18 English
Intro Operation Customer
Assistance
Warranty
Notice
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
FCC/IC/RF Exposure Statement
FCC Part 15.19 Warning Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
FCC Part 15.21 Warning Statement-
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
FCC Part 15.105(b) Warning Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
IC RSS-GEN, Sec 8.3 Warning Statement
ENGLISH: This radio transmitter (identify the device by certification number, or model number
if Category II) has been approved by Industry Canada to operate with the antenna types listed
below with the maximum permissible gain and required antenna impedance for each antenna
type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
Immediately following the above notice, the manufacturer shall provide a list of all antenna types
approved for use with the transmitter, indicating the maximum permissible antenna gain (in dBi)
and required impedance for each.
FRENCH: Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son
numéro de modèle s’il fait partie du matériel de catégorie I) a été approuvé par Industrie Canada
pour fonctionner avec les types d’antenne énumérés ci-dessous et ayant un gain admissible
maximal et l’impédance requise pour chaque type d’antenne. Les types d’antenne non inclus
dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits
pour l’exploitation de l’émetteur.
RF Exposure Statement
ENGLISH: This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 40cm between the radiator & your body.
The device is in compliance with RF exposure guidelines, users can obtain Canadian information
on RF exposure and compliance. The minimum distance from body to use the device is 40cm.
FRENCH: Le présent appareil est conforme
Après examen de ce matériel aux conformité ou aux limites d’intensité de champ RF, les
utilisateurs peuvent sur l’exposition aux radiofréquences et compliance d’acquérir les
informationscorrespondantes. La distance minimale du corps à utiliser le dispositif est de 40cm.
IC RSS-GEN, Sec 8.4 Warning Statement
ENGLISH: This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation
of the device.
FRENCH: Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil
ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
