CoCo AFR-100 User manual

USER’S MANUAL
version 1.1
English
AFR-100 FITTING DIMMER/SWITCH

AFR-100 FITTING DIMMER/SWITCH
A
BC
*
A: Fitting for incandescent lamp
B: Search mode button
C: Indicator
* Picture of the AYCT-102
(not included)
1

AFR-100 FITTING DIMMER/SWITCH
2
[1] Screw the fitting receiver into the lamp holder. [2] Screw the incandescent bulb (type E27) into the
fitting receiver.
Use an incandescent bulb with a maximum
rating of 100 Watts, depending on the type of lamp
and armature! See: ‘Safety instructions’
Not all types of incandescent bulbs and fittings
are suitable for this product! Carefully read the
instructions under ‘Safety instructions’ before you
use this product!

AFR-100 FITTING DIMMER/SWITCH
3
[3] Press the search mode button with a pointed
object. The indicator begins to flash.
[4] Send an ‘on’ signal with the transmitter. The
indicator stops flashing as soon as the connection
is made.
See the manual for the transmitter. The
pictured transmitter is not included!
The codes remain in the memory of the fitting,
even if there is a power failure!
A maximum of 6 codes can be programmed
simultaneously!
The search mode is activated for 15 seconds.
If necessary, repeat [3] to activate the search
mode again!

AFR-100 FITTING DIMMER/SWITCH
4
3x
[5] Press the ‘on’ button of the remote control 3
times to dim the light: (1) Press one time: The
mains socket switch switches on. (2) Press again:
The light intensity changes continuously. (3) Press
a third time as soon as the desired light intensity is
reached.
When the dimmer is switched off, it will
remember the most recently selected light intensity
for the next time it is switched on.

AFR-100 FITTING DIMMER/SWITCH
Remarks
Reminders
• This product must be used in combination with at least one COCO transmitter.
• The product is a dimmer/receiver: controls the lamps remotely, without complicated wiring.
• To prevent interference between devices, avoid placing multiple products close to each other. The
minimum distance between units should be approx. 50 cm.
• The wireless system can be indefinitely expanded with other COCO remote controls and/or receivers.
• Your COCO transmitter may have a special ‘group’ button with which multiple receivers can be switched
on and off simultaneously. Repeat [3 - 4] and press the ‘group’ on button of the transmitter in step [4].
• To delete the set codes (clearing the memory): (1) Hold in the search mode button. (2) The indicator
begins flashing after approx. 7 seconds. (3) Release the search mode button. (4) Press the search
mode button again. (5) To confirm, the built-in dimmer switches on and off two times.
• If the product does not work:
- Reset the memory (see previous line) and set the code in the transmitter again (repeat [3 - 4]).
- Check whether the indicator is lit; if not, there may not be any power to the original fitting.
- Make sure the lamp is on (if it is equipped with a switch).
- Make sure the light is not defective.
Safety instructions
• When used with low-energy light bulbs: For this product, only use low-energy light bulbs that may be
dimmed!
• Never use COCO products for life support systems or other applications in which equipment
malfunctions can have life-threatening consequences.
• The mains power must not exceed 230 Volts, 50 Hertz.
• The lamp fitting must be suitable for E27 incandescent bulbs and the lamp armature must have a
diameter of at least 15 centimetres.
• Connecting incorrect lamps and armatures can cause defects, a short circuit and fire. See the overview
of suitable lamp and armature combinations below:
A. Hanging lamp with closed top: Not suitable for this product!
5

AFR-100 FITTING DIMMER/SWITCH
6
B. Hanging lamp with open top and bottom: Use only low-energy light bulbs (max. 30 Watts).
C. Standing lamp with closed top and bottom: Use incandescent or low-energy light bulbs (max. 60
Watts).
D. Standing lamp with open top and bottom: Use incandescent bulbs rated at max. 100 Watts or low-
energy bulbs rated at max. 60 Watts.
A B C D
• This product is not suitable for use in damp areas, areas with highly flammable liquids or vapours, or
areas in which the temperature exceeds 40 °C.
• Do not attempt to repair this product. If the product is damaged or if you are in doubt about the proper
operation, take the product back to the place of purchase.
• Do not use the product in damp areas. Clean the device with a dry cloth.
Wireless
• This product works using a radio signal that passes through walls, windows and doors. The range is
maximum 75 metres in the open air. The range indoors is strongly influenced by local conditions such
as concrete, glass and metals. On average, the indoor range is approximately 30 metres.
• New double glass often includes a thin metallic layer. This type of glazing (“HR glass”) allows most
visible light to pass through but has a negative impact on radio signals. If there is HR glass between the
transmitter and receiver, you should expect a significant reduction of the range of the wireless signal.
• This product operates at a frequency of 433.92 MHz. It complies with the essential requirements and
other conditions of R&TTE Directive 1999/5/EC and can be used in all EU countries.
• There may be restrictions on the use of this device outside the EU. If this device is used outside the EU,
check whether the device complies with the local directives.

AFR-100 FITTING DIMMER/SWITCH
This product complies with the essential requirements and other relevant provisions of the applicable
European directives. The Declaration of Conformity (DoC) is available at www.coco-technology.com.
If possible, submit this product for recycling after use. Do not dispose of the product with household trash.
Warranty and copyright
This device is covered by a 2-year warranty that begins on the day of purchase. Visit www.coco-
technology.com/warranty for additional information. Reprinting of (portions of) this manual without
permission from Pan-Trade International B.V. is expressly prohibited.
7

AFR-100 FITTING DIMMER/SWITCH
8
PAN-TRADE INTERNATIONAL B.V.
P.O. BOX 126
4760 AC ZEVENBERGEN
THE NETHERLANDS
www.coco-technology.com
Declaration of Conformity
Pan-Trade International BV declares that the COCO product, model:
type designation AFR-100 FITTING DIMMER/SWITCH
item number 74028
is in compliance with the essential requirements and other relevant provisions of directives R&TTE
1999/5/EC, EMC 2004/108/EC and LVD 2006/95/EC, and is compatible with the standards EN 300 220-
1/3, EN 55015, EN 301 489-1/3 and EN 60950.
Manufacturer / Authorised representative,
M.A. Hoekstra, managing director
Zevenbergen, 2008-01-30
