Code 3 MATRIX V2V Owner's manual

Page 1 of 4
Installation and Operation Instructions
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the e󰀨ectiveness of the air bag or become a projectile that could cause serious personal injury or death.
Refer to the vehicle owner’s manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable
mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an
intersection, drive against tra󰀩c, respond at a high rate of speed, or walk on or around tra󰀩c lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specications
Size: 1.875” X 1.875” X 0.75”
Input Voltage: 12-24 VDC
Temp. Range: -40ºC to 65ºC [-40ºF to 149ºF]
V2V Sync Module
Additional Matrix Resources
Product Information: www.code3esg.com/us/en/products/matrix
Training Videos: www.youtube.com/c/Code3Inc
Matrix Software: http://software.code3esg.global/updater/matrix/downloads/Matrix.exe
*V2V is compatible with Matrix v3.5.0 or newer.
Sytem Requirements
Firmware Requirements:
Z3 Siren Firmware:
Siren Node: v2.0 or newer (June 2021 or newer)
Network Node: v2.0 or newer (June 2021 or newer)
*Older sirens are not compatible and will need to be manually ashed.
Lightbar Firmware:
LBC: v1.50
Light Engines: v1.37
Software Requirements:
Matrix v3.5.0 or newer

Page 2 of 4
Before proceeding with installation, plan all wiring and cable routing. Select the mounting location for the product on a at, smooth surface.
Installation and Mounting
Wiring Instructions
The V2V Sync Module, when installed, allows for multiple vehicles to synchronize Matrix
ash patterns, regardless of distance. This unit is not designed to work with with competitor
products.
The V2V Sync Module will need to be connected to the central node of the Matrix system, such
as be a SIB or Matrix Z3 siren. Connect the supplied cable to the AUX 4-pin connector on the
central node.
If using multiple auxiliary devices, such as an OBDII unit, please use the V2V-SPLIT accessory.
If a longer cable is required to reach the desired mounting location, please use V2V-EXT - 2.5M
extension accessory. Multiple V2V-EXT can be used in series if needed.
Conguring the System
After fully installing all Matrix devices intended to be used in the conguration, connect the
Central Node (Z3 or SIB) to a computer and open the Matrix software. Ensure that all devices
are detected. Use the software to build a conguration for the system and export to the devices.
The synching feature will be handled by the software if the V2V module is present when the
conguration is exported.
Note: The V2V sync module will sync the same Matrix ash patterns across multiple vehicles if
they have the same active ash pattern. By design, if di󰀨erent ash patterns are active across
di󰀨erent vehicles, the vehicles will not sync together.
Notes:
1. Larger wires and tight connections will provide longer service life for components. For high current wires it is highly recommended
that terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation displacement
connectors (e.g., 3M Scotchlock type connectors).
2. Route wiring using grommets and sealant when passing through compartment walls. Minimize the number of splices to reduce voltage
drop. All wiring should conform to the minimum wire size and other recommendations of the manufacturer and be protected from moving
parts and hot surfaces. Looms, grommets, cable ties, and similar installation hardware should be used to anchor and protect all wiring.
3. Fuses or circuit breakers should be located as close to the power takeo󰀨 points as possible and properly sized to protect the wiring and
devices.
4. Particular attention should be paid to the location and method of making electrical connections and splices to protect these points from
corrosion and loss of conductivity.
5. Ground termination should only be made to substantial chassis components, preferably directly to the vehicle battery.
6. Circuit breakers are very sensitive to high temperatures and will “false trip” when mounted in hot environments or operated close to their
capacity.
Mount unit with a clear view of the sky on the inside of the vehicle. Possible locations are on top of the dashboard or attached to the vehicle’s
windshield. The unit should not come in direct contact with water. Mount such that the operation of the vehicle is not impeded. Ensure that no
part of this installation interferes with airbag operation.
The V2V unit can be installed using VHB or mounting with screws. VHB tape has been included to mount the system to a dashboard or
interior windshield. Ensure the surface is cleaned rst by using the supplied alcohol and primer. For screw-mounting, use the supplied screws
and mount the V2V unit on a at surface using the two anges on each side of the housing.
CAUTION!
When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines, vehicle upholstery, etc. that
could be damaged.
CAUTION!
Disconnect the battery before wiring up the product, to prevent accidental shorting, arcing and/or electrical shock.
Figure 1
Carefully remove the product and place it on a at surface. Examine the unit for transit damage and locate all parts. If damage is found or
parts are missing, contact the transit company or Code 3. Do not use damaged or broken parts.
Ensure the product voltage is compatible with the planned installation.
Unpacking and Pre-Installation

Page 3 of 4
Troubleshooting
All products are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the life of the
product, follow the guide below for troubleshooting and repair information. If the problem cannot be rectied using the solutions given below,
additional information may be obtained from the manufacturer – contact details are at the end of this document.
Problem Possible Cause(s) Comments / Response
No power Faulty wiring Ensure connector to the central node is secure. Ensure input voltage does not
exceed the range of 10-32 VDC.
No communication Connectivity
It may take a few minutes for the V2V Sync Module to establish GPS commu-
nication. Communication with the GPS satellites can have interference with
buildings. Ensure the unit has an unobstructed view of the sky. During this
time, the Matrix system will be able to synchronize Matrix-controlled devices
on the vehicle, but vehicle-to-vehicle synching will not operate. Once GPS
communication is established, vehicle-to-vehicle synching will operate auto-
matically without any input from the end user.
Not synching ash
patterns between
vehicles
User setup
Ensure both vehicles have Matrix systems installed with V2V sync units.
Ensure both Matrix systems have been congured with V2V device installed.
If chosen ash patterns have di󰀨erent timings or number of steps, synching
may not be possible.

Page 4 of 4
Product Returns:
If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA
number) before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use
su󰀩cient packing materials to avoid damage to the product being returned while in transit.
*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring
service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products returned to sender after the service has been rendered.
Manufacturer Limited Warranty Policy:
Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which are avail-
able from the Manufacturer upon request). This Limited Warranty extends for Thirty-six (36) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-
TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE
MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WAR-
RANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EX-
CLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE
REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-
UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO
THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.
IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY
DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IM-
PROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT
TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdic-
tions do not allow the exclusion or limitation of incidental or consequential damages.
© 2022 Code 3, Inc. all rights reserved.
920-0953-00 Rev. C
