Bestop HighRock 4x4 Element User manual

INSTALLATION TIME SKILL LEVEL
TOOLS
Vehicle Application
•Jeep CJ7 / YJ Wrangler
1980 - 1995
Part Number: 51808 / 51824
Installation Instructions
HighRock 4x4TM Element™
Lower Door Frame
1/2 Hour 1 - Easy
7/16" and 3/8"
T-50

HighRock 4x4™ Element™ Lower Door Frame – Installation Instructions
Parts List
#10-32 Truss Head Machine
Screw - Black, Qty - 8, Part
Number 316.82
#10-32 Low Profile Nut - Black,
Qty - 8, Part Number 316.94
Door Restraint
Straps, Qty - 2,
Part Number 393.23
It is important that the
Paddle Handle must
align correctly with the
automobile manufacturer’s original equipment steel
latch pin located on the vehicle. Failure to properly
install the paddle handle may result in the door
accidently opening. IMPROPER CLOSURE COULD
RESULT IN SERIOUS INJURY OR DEATH TO THE
OCCUPANTS. WEAR SEAT BELTS AT ALL TIMES.
DRIVE CAREFULLY.
Right Door Frame, Part Number 422.12 (GLOSS FINISH)
Part Number 499.48 (MATTE FINISH)
QTY. 1
Left Door Frame, Part Number 422.00 (GLOSS FINISH)
Part Number 499.47 (MATTE FINISH)
QTY. 1
The Rotary Latch Paddle Handle will
only latch on the automobile manufac-
turer’s original equipment steel latch pin located
on the vehicle. Do Not remove this part.
If your vehicle does not have the latch
pin assembly illustrated here, you
have an incorrect part for your vehicle.
Sport Bar
Original Equipment
Latch Pin
DO NOT REMOVE
View of Driver’s Side Door
Opening from Inside Vehicle
Latches, Rotary Paddle Handle,
Left, Part Number 430.01 - Qty - 1
Right, Part Number 430.00 - Qty - 1
Dome Light Switch
Bracket, Part Number 454.52
Qty - 2
M6 x 10 Button Head
Screw, Qty - 4
Right Shown

HighRock 4x4™ Element™ Lower Door Frame – Installation Instructions
Install Paddle Handle
Install Door
Insert the Paddle Handle into the mounting plate so that the latch mecha-
nism is inside of the vehicle and the Rotary Latch Mechanism is toward
the rear of the door. Align the four holes in the Paddle Handle Assembly
with the four holes in the mounting plate. Insert four #10-32 Truss Head
Machine Screws from the outside and secure them with #10-32 Nuts.
Close the door and adjust the latch to ensure it latches properly.
Tighten the screws once the latch works properly.
Adjust the factory door striker if necessary to ensure the latch engages
properly.
Hold the door straight out from the vehicle with the
hinge pins over the body hinges. Lower the pins
into the hinges. Make sure that the pins are fully
inserted into the body hinges.
Door Pin
Hinge
The Dome Light Switch Bracket is not
used on CJ Models.
Install Dome Light
Switch Bracket
Locate the Dome Light Switch on the vehicle.
Mount the Dome Light Switch Bracket to the Door
in that location. Adjust the bracket location so that
the dome light turns off when the Door is closed.
Repeat on both sides of the vehicle.
Dome Light
Switch
M6 x 10 Button
Head Screws
Dome Light
Switch Bracket
With Door closed
bracket should
press switch
To adjust
the latch
pin, loosen the pin
with a T-50 Torx
driver. Reposition the
pin so it fully engages
into the latch and then
retighten the pin. Be
sure to readjust the
pin if different doors
are used later.
#10-24 Truss Head
Machine Screws and
#10-24 Locknuts
Inside of Door
Rear of
Door
Mounting
Plate
Paddle Handle
Assembly
Rotary Latch
Mechanism
IMPORTANT: You should check the Paddle Handle periodically to ensure
the alignment to the door striker is correct, allowing the door to close prop-
erly, and that the screws are tight. If out of alignment, align and retighten
the screws securely. Repeat for both lower doors. If more adjustment is
needed, adjust the vehicle’s door striker.

HighRock 4x4™ Element™ Lower Door Frame – Installation Instructions
Install Restraint Strap
Locate a Door Restraint Strap in the small parts kit. Slip the loop in one over
the hook on the door frame. Slip the loop in the other end onto the hook on the
vehicle body.
Door Frame
Slip one end of Door
Restraint Strap over
hook on Door Frame
Slip the other end over
the hook in the vehicle
