Remote Start
Installation Guide
for models:
ca4054
ca4554
2014 Voxx Electronics Corporation. All rights reserved. 4280596

Before You Begin.........................................................................................3
Wire
Connection
Guide...............................................................................4
4 Pin Main Harness ...................................................................................5
3 Pin Parking Light Harness......................................................................6
6 Pin Start Harness ...................................................................................7
4 Pin Alternate Harness.............................................................................8
2 Pin Door Lock Output Harness...............................................................9
Additional
Ports.........................................................................................10
Antenna I LED I Programming Port........................................................ 1
0
OBI
Port...................................................................................................10
Telematic Interface Port...........................................................................10
Set Up
&
Programming
.............................................................................
11
Transmitter Programming........................................................................
11
Manual Feature Programming.................................................................
11
Programming Feature Banks ..................................................................12
Tach Programming ..................................................................................14
Smart Tachless Mode..............................................................................14
Feature
Descriptions
.................................................................................15
Transmitter
Button
Functions
..................................................................19
2 Way
Transmitter
Notifications
...............................................................20
Remote Start
Shutdown
Diagnostics
......................................................20
System
Layout
...........................................................................................
21
2
ca4054 -4554 Install rev A

BEFORE YOU BEGIN
FOR AUTOMATIC TRANSMISSION VEHICLES ONLY.
•
...
.
PROFESSIONAL INSTALLATION
STRONGLY RECOMMENDED
Roll down window to avoid locking keys
in
vehicle
during installation
Avoid mounting components or routing wires near
hot surfaces
Avoid mounting components or routing wires near
moving parts
Tape or loom wires under hood for protection and
appearance
Use a Digital Multi Meter for testing and verifying
circuits. DO NOT USE A TEST LIGHT, OR
"COMPUTER SAFE PROBE" as these can set off air
bags or damage vehicle computers.
Technical Support [phone]
or go to
http://avxtech1.com
2014 Voxx Electronics Corporation.All rights reserved.
3

4
(f)
Zl-
-I
a..
C)
C")
-
_J
1-
0:::
<(
1-
(f)
z
0:::
(0
z~
-(.)
a..o
N_J
4 Pin Main Harness
BLUE/BLACK
START
STATUS
I
ACTIVE OUTPUT ( - )
PURPLE/WHITE TACH INPUT
GRAY
HOOD
PIN INPUT
(-)
BROWN/RED
BRAKE
INPUT ( + )
3 Pin Parking Light Harness
BLACK GROUND
WHITE/RED PARKING LIGHT INPUT
WHITE
PARKING LIGHT OUTPUT
6 Pin Start Harness
PURPLE STARTER
OUTPUT-
MOTOR SIDE
RED BATTERY 12V (
+)
ORANGE ACCESSORY 1 ( + )
PINK/WHITE IGNITION 2 ( + )
RED/WHITE BATTERY 12V (
+)
PINK IGNITION 1 ( + )
4 Pin Alternate Output Harness
BLACK/YELLOW
PULSE
DURING
CRANK
( - )
GREEN/WHITE
PULSE
AFTER
SHUTDOWN
( - )
LT BLUE FACTORY
ARM
I
PULSE
AFTER
START
(-
)
LT
GREEN/BLACK
FACTORY DISARM
I
PULSE
BEFORE
START
( - )
2 Pin Lock Output Harness
BLUE UNLOCK
(-)
OPEN
ca4054-
4554 Install rev A

4 Pin Main Harness
1 BLUE/BLACK START STATUS I ACTIVE OUTPUT ( - )
This wire provides a ground output when the remote start function is activated and
remains until 4 seconds after the remote start is shutdown. Ifthis wire will be used
for multiple application's a 1 amp diode is required in-line with the stripe facing the
control module.
2 PURPLE/WHITE TACH INPUT
Locate the vehicle's ignition coil or fuel injector
in the engine compartment.
Verification: Test using the following procedure:
1. Set voltmeter to AC VOLTS.
2. Attach positive lead of a volt meter to a constant 12-volt source.
3. Attach negative lead of a volt meter to the wire to be tested.
4. Start the engine.
5. Have someone press on the gas pedal slightly as you monitor the meter. If
connected to the correct wire, the voltage reading will increase as the engine's
RPM increases.
Connect the PURPLE/WHITE wire to the negative side
of the vehicle ignition coil or
fuel injector.
3 GRAY HOOD PIN INPUT
(-)
Install a Hood Pin Switch and connect to the GRAY wire. This connection is required
for Remote Start.
Verification: This wire when connected will register ground when the
vehicle's hood is opened.
Connect the GRAY wire to the hood pin.
NOTE: Be sure to loom the wire, and seal the grommet.
2014 Voxx Electronics Corporation. All rights reserved. 5

6
4
BROWN/RED
BRAKE INPUT ( + )
Locate the vehicle's brake light wire at the brake pedal mounted switch. This
connection is required for Remote Start.
Verification:
This wire registers positive voltage when the brake pedal is
pressed.
Connect the
BROWN/RED
wire to the vehicle's brake light wire.
3 Pin Parking Light Harness
1
BLACK
GROUND
Connect the
BLACK
wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection.
The
recommended grounding point is a metal surface in
the driver's side kick panel area.
NOTE:
Do not ground the
BLACK
wire with any other vehicle components.
2
WHITE/RED
PARKING LIGHT
INPUT
3
WHITE
PARKING LIGHT
OUTPUT
Locate the parking light output wire at the vehicle's light switch.
Verification:
This wire registers positive voltage when the parking lights are
turned on.
Positive switching Parking Lights:
Connect the
WHITE/RED
wire to a 15
Amp
max
fused battery source.
Connect the
WHITE
wire to the parking light output wire.
Negative switching Parking Lights:
Connect the
WHITE/RED
wire to a good chassis ground.
Connect the
WHITE
wire to the parking light output wire.
ca4054-
4554 Install rev A

6 Pin Start Harness
1 PURPLE STARTER OUTPUT ( + )
Locate the vehicle starter wire.
Verification: This wire registers voltage onlywhen the key is turned to the
START position.
Connect the PURPLE wire to the
MOTOR SIDE of the vehicle starter wire.
2 RED BATTERY
12V ( +)
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
3
ORANGE ACCESSORY 1 ( + )
Locate the vehicle's accessory wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to ACC
(Accessory) and the ON (or RUN) position. The voltage drops out when the
key is turned to the START (or CRANK) position.
Connect the ORANGE wire to the vehicle's accessory wire.
4 PINK/WHITE IGNITION 2 ( + )
Locate the vehicle's 2nd ignition wire at the ignition switch (if equipped).
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position, but not the
ACC (Accessory) position. The voltage does not
drop out when the key is turned to the START (or
CRANK) position.
Connect the PINK/WHITE wire to the vehicle's ignition 2 wire.
Programmable output: IGN, ACC, Start.
2014 Voxx Electronics Corporation. All rights reserved. 7

8
5 RED/WHITE BATTERY 12V (
+)
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED/WHITE wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 PINK IGNITION 1 (
+)
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.
4 Pin Alternate Output Harness
1 LT GREEN/BLACK FACTORY DISARM I
PULSE BEFORE START ( - )
This wire will supply a ( - ) 200mA pulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm wire
from the key cylinder inside the drivers door.
Verification: This wire registers ground ifthe key is turned to the unlock
position
in the driver's door cylinder.
This output is configurable
in option programming.
2 LT BLUE FACTORYARM I
PULSE AFTER START ( - )
This wire will supply a
(-) 200mA pulse upon successful completion of the remote
start activation sequence and is typically used to re-lock the vehicle's doors upon
remote start if necessary.
This output is configurable in option programming.
ca4054 -4554 Install rev A

3 GREEN/WHITE PULSE AFTER SHUTDOWN ( - )
This wire will supply a
(-) 200mA pulse after the remote start shuts down. This
is typically used to re-lock the vehicle's doors
if they unlock upon remote start
shutdown.
It can also be used to pulse a door pin-switch wire to prevent the vehicle's
accessories from remaining on after remote start shutdown.
This output is configurable in option programming.
4 BLACK/YELLOW PULSE DURING
CRANK (-)
Locate the vehicle's second starter (crank) wire at the ignition switch. (if equipped)
Verification: This wire registers voltage only in the start (crank) position of
the ignition switch.
This wire will supply a ( - ) 200mAoutput and can be configured
in option
programming.
2 Pin Lock Output Harness
1 BLUE UNLOCK
(-)
The door unlock output wire provides an output only while the remote start feature is
active.
2014 Voxx Electronics Corporation. All rights reserved. 9

10
Additional Ports
Antenna I LED I Programming Port
Mount the supplied antenna/receiver to a clear spot on the vehicle's windshield that
will not block the driver's vision. A good location
is usually high on the windshield
near the rear view mirror.
Be careful not to mount the antenna/receiver on any
metallic window film, as this will effect system range. Route the antenna/receiver
cable to the control module and plug into the antenna port.
Data Bus Interface Port
This 4 pin port is used for Flashlogic Door Lock and Transponder Databus Interfaces
to communicate with the vehicle's Databus. When using the OBI port to control the
Flashlogic Door Lock and Transponder Interface modules the following options may
be available. Please refer to the 020 (Data to Data) function list available per vehicle
on the tech service web site.
Tach Input Brake Safety Shut Down
Trunk/Hatch Open Diesel Glow Plug Input
Door Lock Control Passlock I Passkey Interface (GM Only)
Dome Light Supervision Transponder Interface Activation
Factory Alarm Arm I Disarm Manual Arm I Disarm Inputs (factory keyless
controls system)
Telematic Interface Port -CA4554 ONLY
This 4 pin port is used for Telematic Interface accessories, such as Car Connection
Pro, which can control some ofthe following features.
Door Unlock Control Trunk Release
Sliding Doors
Car Find AUX Output
Remote Start
ca4054- 4554 Install rev A

Set Up & Programming
Transmitter Programming -Feature Bank 1
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the parking lights will flash (3) three times.
4. Press 1 button of each transmitter you wish to program.
5. The system will respond with 1 light flash for each accepted transmitter.
6. Pressing the override button at anytime during programming will advance to
the next bank.
NOTE: The system will exit transmitter programming after 15 seconds of inactivity.
NOTE: This system has 1 button programming which programs all channels ofthe
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter
in memory.
NOTE: This system has PTN- Programmed Transmitter Notification. Each time the
ignition
is turned ON, the LED will flash the number oftransmitters programmed to the
system.
Manual Feature Programming -Feature Bank 2 - 5
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the parking lights will flash (3) three times.
4. Use the valet/override button to advance through each option bank. For
feature programming advance to Feature Bank
2, 3, 4 or 5, which is (4)
four, (5) five, (6) six and (7) seven parking light flashes.
5. Use the transmitter 0 button to scroll through the selections in each
feature bank, the parking lights will flash to match the feature number.
6. Press the BRAKE to change the desired feature. The LED will flash
indicating the changed feature.
NOTE: The system will remain in feature programming mode as long as the ignition
is on, there is no time limit. To exit programming turn the IGNITION OFF.
2014 Voxx Electronics Corporation. All rights reserved.
11

2
12
Feature Bank 1 - 3 Flashes
Transmitter
Programming
Refer to transmitter programming.
Feature
Bank
2 - 4 Flashes
Feature
Bank
3-
5 Flashes
Factory Disarm
Lt Green
I
Black
1 LED Flash
1 LED
Flash
Factory
Disarm
4 LED
Flash
NIA
Factory Disarm Factory Disarm Factory Disarm
I
Start Status 350mS 500mS
NOTE: On
this
model
the
Lt
Green
I
Black
Output
wire
can
be
configured
in
Bank
3
or
Bank
5.
Any
changes
to
this
feature
in
Bank
5
will
override
changes
made
in
Bank
3.
ca4054-
4554 Install rev A

Feature
Bank
4-
6 Flashes
Feature
Bank
5 - 7
Chirps
4
Pin
Alternate
Output
Control
NOTE: On
this
model
the Lt
Green
I
Black
Output
wire
can
be
configured
in
Bank
3
or
Bank
5.
Any
changes
to
this
feature
in
Bank
5
will
override
changes
made
in
Bank
3.
4 Black I Yellow Output
Ground While
Running
Pulse
During
Ground While
Crank
Running
2014 Voxx Electronics Corporation. All rights reserved.
Ignition Accessory
Ignition Accessory
Pulse During
Crank
13

Tach Programming
The unit will not operate unless tach is programmed or tachless option is
turned ON. If
an
attempt
is
made
to
start the vehicle via the remote start without first
programming tach, the unit will flash the parking lights 7 times indicating tach has not
been learned and stored. If the tach rate is not properly programmed to the specific
vehicle, the unit may not realize that the vehicle is running
in
certain instances and
reengage the starter motor.
The Remote Start unit will learn the tach rate
of
most vehicle's single coil, multiple coil
packs, or single injector.
To
learn tach:
1.
Turn the ignition key to the ON position.
2.
Press and release the valet/override button 3 times.
3.
Immediately turn the ignition key
OFF.
4.
Press and hold the valet/override button, then start the vehicle using
the
key.
5.
When the unit senses the tach signal, the parking lights will begin to
flash.
6.
Allow the vehicle to settle to a normal idle speed.
7.
Release the valet/program push-button switch. The parking lights will
stay
on
solid indicating that the learned tach signal is stored and the
unit has exited tach learn mode.
NOTE: Ifthe unit fails to learn tach rate due to
an
improper tach connection or a
poor tach source, the parking lights will not flash.
To
correct this situation, locate and
connect the PURPLE/WHITE wire
to
the proper tach signal, and then repeat the tach
learn routine.
Smart Tachless Mode
Smart
Tach
less Mode is available only ifa tach signal has never been learned to the
system and when activated will automatically change the Tach Mode feature
in
option
programming to
Tach
less without the need to enter the feature programming mode.
1.
Activate the remote start. The parking lights should begin flashing 7
times indicating no tach signal has been learned.
2.
Within the 7 flash time period, press and hold the 0 button.
3.
One extended parking light flash (1.5 seconds) will indicate the
system is now
in
tachless mode.
14 ca4054 -4554 Install rev A

Feature Descriptions
Feature Bank 2- Security
1 - 8 Not Available.
9- OBI Port Protocol: Determines the protocol type in which the OBI port uses to
interface with external modules.
OBI Protocol
ADS Protocol
Feature Bank 3 - Output Control
1 -Extended Lock Pulse: Controls the timing of the BLUE unlock output wire.
1 Second -Single 1 second unlock pulse.
3.5 Seconds -Single 3.5 second unlock pulse.
Double Pulse Unlock -Double 1 second unlock pulse.
2 - Factory Disarm -Lt Green/Black Output: Controls the timing of the
LT. GREEN/
BLACK factory disarm wire on the 6 pin output harness only and does not change
the output of the factory disarm wire on the 4 pin alternate output harness.
Factory Disarm -Single 1 second pulse with unlock and remote start
activation.
N/A- Setting not available on this model.
Start
Status- Continuous (-)output during the remote start cycle.
Factory Disarm -Single 350mS second pulse with unlock and remote start
activation.
Factory Disarm -Single 500mS second pulse with unlock and remote start
activation.
NOTE : 4 &5 series product -
On this model the Lt Green I Black Output wire can be
configured in Bank 3 or Bank 5. Any changes to this feature in Bank 5 will override
changes made
in Bank 3.
2014 Voxx Electronics Corporation. All rights reserved. 15

16
Feature Bank 4 - Remote Start Control
1 - Not Available.
2 - Run Time: Controls the time
in
minutes that the vehicle will stay running under
control
of
the remote start until the system times out. The system may also be shut
down at any time by use
of
the transmitter or system shutdowns.
3-
Running Lights: Controls the WHITE parking light output wire during remote
start. Steady -Parking lights constant during the remote start cycle.
Flashing -Parking lights flash at a slow pace during the remote start cycle.
4 -Tach Mode: Determines how the system monitors the engine running during
remote start.
Tach
-Hard wired directly to the tach wire
of
the vehicle to monitor AC
voltage.
Tach
less (Crank Average/Voltage) -Determines crank time by averaging
the last 8 times the vehicle was started with the key and then monitors the
change
in
voltage after remote start.
Hybrid (Crank Average I No Voltage) -Determines crank time by averaging
the last 8 times the vehicle was started with the
key.
DBI
Port -Monitors the vehicle's tach rate through
an
interface module
connected to the DBI port.
5-
Voltage Level: The voltage variance for remote start when set to tachless. (see
tach mode)
HIGH-
The variance
in
battery voltage from before the remote start
is
activated to after the engine
is
running must be greater than 0.5 volts.
LOW -The variance
in
battery voltage from before the remote start
is
activated to after the engine is running may be less than 0.5 volts.
6 -Crank Time: Preset output times for the PURPLE starter wire.
1 Second 0.8 Seconds 1.5 Seconds 2 Seconds 4 Seconds
ca4054-
4554 Install rev A

7 - Crank Average I Crank Time: The length
of
time
in
which the remote start will
crank the vehicle's starter.
Crank Average -Determines crank time by averaging the last 8 times the
vehicle was started with the
key.
Preset Time -Preset starter output time. (see crank time)
8 - Gas I Diesel: Selects engine type and delay time for the starter output wire during
remote start activation.
Gas-
Gasoline engine, no delay for the starter output wire.
10 Second Delay -Diesel engine, delays the starter output wire for 10
seconds after the ignition has been powered up by the remote start.
15 Second Delay -Diesel engine, delays the starter output wire for 15
seconds after the ignition has been powered up by the remote start.
20 Second Delay -Diesel engine, delays the starter output wire for 20
seconds after the ignition has been powered up by the remote start.
45 Second Delay -Diesel engine, delays the starter output wire for 45
seconds after the ignition has been powered up by the remote start.
9 - Single I Double Pulse Start: Switches the remote start activation between a
single or double press from the transmitter.
10 -IGN 2 Output: Programmable high current output.
Ignition 2 -Ignition output during remote start.
Accessory-
Accessory output during remote start.
Start I Crank -Crank output during remote start.
11
- 2 or 3 Hour Start: When activated, the remote start will activate and run for the
programmed time and shut down every 2 or 3 hours.
12 -14 Not Available.
15 -Accessory Output: Programmable high current output.
Accessory-
Output becomes active with the same timing as the accessory
output, drops out during crank.
Ignition -Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Start I Crank -Output becomes active with the same timing as the starter
output wire, during crank only.
2014 Voxx Electronics Corporation. All rights reserved. 17

18
Feature Bank 5 - 4 Pin Alternate Output Control
1 - Lt Green/Black Output : Controls the LT GREEN/BLACK output activation type
and timing.
Pulse before Start I During Unlock - 1 second pulse when remote start is
activated. Also a 1 second pulse when unlock is pressed.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition -Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory -Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank -Output becomes active with the same timing as the
starter output wire, during crank only.
2 - Lt Blue Output : Controls the LT BLUE output activation type and timing.
Pulse After Start I During Lock - 1 second pulse after the remote start
sequence and has confirmed the vehicle is running.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition -Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory -Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank -Output becomes active with the same timing as the
starter output wire, during crank only.
3- Green/White Output: Controls the GREEN/WHITE output activation type and
timing.
Pulse After Shutdown - 2 second pulse after the remote start has
shutdown.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition -Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory -Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank -Output becomes active with the same timing as the
starter output wire, during crank only.
ca4054- 4554 Install rev A

4 - Black/Yellow Output : Controls the BLACK/YELLOW output activation type and
timing.
Pulse During Crank -Output becomes active with the same timing as the
starter output wire, during crank only.
Ground While Running -Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition -Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory -Output becomes active with the same timing as the accessory
output, drops out during crank.
Transmitter Button Functions
2014 Voxx Electronics Corporation. All rights reserved.
19

20
2 Way Transmitter Notifications- CA4554 ONLY
FUNCTION
Activation
Confirm Remote Start
Remote Start Running
Remote Start Shutdown
Low Battery
BEEPS I LED FLASHES
1 Beep I Flash
4 Beeps
I
Flashes (repeats 3 times)
1 Flash per second for duration run time
3 Long Beeps
I
Flashes (repeats 3 times)
2 Beeps I Flashes when button is pressed
Remote Start Shutdown Diagnostics
If the remote start shuts down or fails to start, the parking lights will flash one
of
the
patterns below indicating the shutdown input.
To
manually enter diagnostics and view the last shutdown, turn the ignition
ON
and
press and hold the 0 button for 3 seconds.
LED FLASHES
3 Flashes
4 Flashes
5 Flashes
7 Flashes
SHUTDOWN ZONE
Hood Input
Brake Input
Remote Start Valet Mode
Manual Transmission Mode not set (manual
transmission models only)
Tach not learned I Crank Average not learned
ca4054 -4554 Install rev A
