Code WingMan Flex Series User manual

Page 1 of 12
Installation and Operation Instructions
WingMan Flex™ Series
Interior Lighting System
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an
intersection, drive against tra󰀩c, respond at a high rate of speed, or walk on or around tra󰀩c lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specications:
Options: 18 LED Multi Color: Red/Blue,
Red/Amber,
Blue Amber,
Red/White,
Blue/White
Size: LONG VERSION:
SHORT VERSION:
MINI VERSION:
43.00”L X1.38”H X8.00” D
22.13”L X1.38”H X8.00” D
11.25”L X1.38”H X8.00” D
Weight: LONG VERSION:
SHORT VERSION:
MINI VERSION:
7.5 lbs
5.5 lbs
4.0 lbs
Input Voltage: 12VDC
Input Current
@ Startup:
(8) Light Hd
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
0.007 Amps
0.007 Amps
0.007 Amps
0.007 Amps
Input Current
@ Power:
(8) Light Hd
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
0.005 Amps
0.005 Amps
0.005 Amps
0.005 Amps
Input Current
@ Max:
(8) Light Hd
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
11.30 Amps
9.20 Amps
6.60 Amps
3.40 Amps

Page 2 of 12
The WingMan Flex can be ordered with a Universal Bracket Kit. The Universal kit includes (2) 90 Degree Universal Mounting Brackets (See
Individual Mounting Bracket Descriptions on page 2). These brackets can be bolted to the Outer Panel of the WingMan Flex and modied as
needed to mount the unit. The WingMan Flex must be hard mounted to the sheet metal of the vehicle to prevent injury to passengers in the
event of a collision. It is the installers responsibility to ensure the product is mounted securely. Make sure proper support is provided between
the vehicle’s sheet metal and the ber/fabric of the package tray area as in many cases there is a substantial air gap between them. In some
cases you will need to self fabricate brackets to adapt the WingMan Flex to your vehicle.
Caution!!! When installing the unit do not push it too hard against the rear window. The unit only needs to just touch the glass
enough to fold the gasket ange back & block out as much ash back light as possible. A broken rear window can result if the unit
is installed too tight against the glass!
For information on how to mount the WingMan Flex™ using vehicle specic kits, please refer to the installation instructions provided with
those kits.
Installation and Mounting Instructions:
CAUTION!
When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines, vehicle upholstery, etc. that
could be damaged.
Bracket Identication:
LONG VERSION
SHORT VERSION MINI VERSION
MOUNTING BRACKET
ALL VERSIONS

Page 3 of 12
Notes:
1. Larger wires and tight connections will provide longer service life for components. For high current wires it is highly recommended
that terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation displacement
connectors (e.g., 3M Scotchlock type connectors).
2. Route wiring using grommets and sealant when passing through compartment walls. Minimize the number of splices to reduce voltage
drop. All wiring should conform to the minimum wire size and other recommendations of the manufacturer and be protected from moving
parts and hot surfaces. Looms, grommets, cable ties, and similar installation hardware should be used to anchor and protect all wiring.
3. Fuses or circuit breakers should be located as close to the power takeo󰀨 points as possible and properly sized to protect the wiring and
devices.
4. Particular attention should be paid to the location and method of making electrical connections and splices to protect these points from
corrosion and loss of conductivity.
5. Ground termination should only be made to substantial chassis components, preferably directly to the vehicle battery.
6. Circuit breakers are very sensitive to high temperatures and will “false trip” when mounted in hot environments or operated close to their
capacity.
It is advisable to leave an extra loop of cable when installing the light bar to allow for future changes or reinstallations.Connect the wires in
the cable for the WingMan Flex Version you are installing as shown in the following diagrams.
Wiring Instructions:
IMPORTANT! This unit is a safety device and it must be connected to its own separate, fused power point to assure its continued operation
should any other electrical accessory fail.
All Multi Color, Single Color & Multi Color / Single Color Combinations, excluding MINI Single Color Version:
FLASH PATTERN CONTROL WIRES
POWER/GROUND CONNECT WIRES TO +12VDC TO PERFORM FUNCTIONS LISTED
RED WIRE----------------------- POWER +12VDC GREEN WIRE------------------- ARROWSTIK RIGHT
PROTECT WITH 20 AMP FUSE
WHITE WIRE---------------------- ARROWSTIK LEFT
BLACK WIRE------------------- GROUND WIRE
GREEN + WHITE------ ARROWSTIK CENTER OUT
PURPLE WIRE------------------ ARROWSTIK FLASH
LIGHT BLUE WIRE----------- SCENE LIGHTS
BLUE WIRE---------------------- DIMMING
YELLOW / BLACK WIRE --- SEQUENCE SELECT
YELLOW WIRE----------------- RATE SELECT
BROWN WIRE------------------ LEVEL 1 FLASH
ORANGE WIRE----------------- LEVEL 2 FLASH
LONG
VERSION
LIGHT BAR CABLE
SHORT
VERSION
MINI
VERSION
WINGMAN FLEX WIRING
MULTI COLOR, SINGLE COLOR & MULTI COLOR / SINGLE COLOR
COMBINATIONS ALL VERSIONS EXCEPT MINI SINGLE COLOR VERSION
FOR MINI SINGLE COLOR VERSION SEE TOP OF PAGE 17
SEE FUSING RECOMMENDATION

Page 4 of 12
8 Lighthead Single Color Independent Flashing Version:
DRIVER SIDE PASSENGER SIDE
BROWN
BROWN/WHITE
RED/WHITE
WHITE
ORANGE
GREEN/WHITE
LIGHT BLUE
PURPLE
ALL COLORED WIRES BELOW CONNECT TO +12VDC
BLACK WIRE CONNECTS TO -GROUND
"DO NOT CONNECT UNUSED WIRES TO POWER"
WIRING DIAGRAM
(8) LIGHT HEAD VERSION - SINGLE COLOR INDEPENDANT FLASHING
DRIVER SIDE PASSENGER SIDE
BROWN
BLANK
BRACKET
RED/WHITE
WHITE
ORANGE
GREEN/WHITE
LIGHT BLUE
BLANK
BRACKET
ALL COLORED WIRES BELOW CONNECT TO +12VDC
BLACK WIRE CONNECTS TO -GROUND
"DO NOT CONNECT UNUSED WIRES TO POWER"
WIRING DIAGRAM
(6) LIGHT HEAD - SINGLE COLOR INDEPENDANT FLASHING VERSION
WIRING DIAGRAM
(4) LIGHT HEAD - SINGLE COLOR INDEPENDANT FLASHING VERSION
DRIVER SIDE
ALL COLORED WIRES BELOW CONNECT TO +12VDC
BLACK WIRE CONNECTS TO -GROUND
"DO NOT CONNECT UNUSED WIRES TO POWER"
RED/WHITE
WHITE GREEN/WHITE
ORANGE
PASSENGER SIDE
6 Lighthead Single Color Independent Flashing Version:
4 Lighthead Single Color Independent Flashing Version:

Page 5 of 12
2 Lighthead Single Color Flashing and 2 Lighthead Single Color Independent Flashing Version:
WIRING DIAGRAM
(2) LIGHT HEAD - SINGLE COLOR FLASHING VERSION &
(2) LIGHT HEAD - SINGLE COLOR INDEPENDANT FLASHING VERSION
RED----------------CONNECT TO +12VDC
BLACK------------CONNECT TO - GROUND
WHITE-------------CONNECT TO +12VDC FOR DIMMING FUNCTION
DRIVER SIDE PASSENGER SIDE
8 Lighthead Single Color Narrowstik Controlled Version &
8 Lighthead Single Color Narrowstik Controlled Version (6 Lighthead Arrowstik and End Flash):
DRIVER SIDE PASSENGER SIDE
ORANGE
BLUE
GRAY
GREEN
TAN
VIOLET
YELLOW
BROWN
LIGHT HEADS ARE GROUND SWITCHED - SEE NARROWSTIK INSTALLATION MANUAL
RED & RED/WHITE WIRES CONNECT TO BACK SIDE OF NARROWSTIK CONTROL HEAD +12VDC CONTROL HEAD POWER
COLORED WIRES CONNECT TO THEIR MATCHING COLOR LOCATIONS IN PLUG IN BACK SIDE OF NARROWSTIK CONTROL HD
INTERNAL WIRING DIAGRAM
(8) LIGHT HEAD - SINGLE COLOR NARROWSTIK CONTROLLED VERSION &
(8) LIGHT HEAD - SINGLE COLOR NARROWSTIK CONTROLLED VERSION WITH
(6) LIGHT HEAD ARROWSTIK AND END FLASH
DRIVER SIDE PASSENGER SIDE
ORANGE
BLANK
BRACKET
GRAY
GREEN
TAN
VIOLET
YELLOW
BLANK
BRACKET
LIGHT HEADS ARE GROUND SWITCHED - SEE NARROWSTIK INSTALLATION MANUAL
RED & RED/WHITE WIRES CONNECT TO BACK SIDE OF NARROWSTIK CONTROL HEAD +12VDC CONTROL HEAD POWER
COLORED WIRES CONNECT TO THEIR MATCHING COLOR LOCATIONS IN PLUG IN BACK SIDE OF NARROWSTIK CONTROL HD
INTERNAL WIRING DIAGRAM
(6) LIGHT HEAD - SINGLE COLOR NARROWSTIK CONTROLLED VERSION
6 Lighthead Single Color Narrowstik Controlled Version:

Page 6 of 12
Fusing Instructions (Independent Flashing Units):
LED Fusing Considerations
Although the average current draw per module is very low, due to the type of circuit used to power each module, the instantaneous peak
current to a module can be signicantly higher during low voltage conditions. To avoid prematurely blowing ATO style fuses or tripping
breakers it is recommended the following rule-of-thumb be used to size fuses or breakers. This is especially important in lightbars with many
LED modules running o󰀨 a single fused source.
Minimum fuse size calculation: 20A
For LED 12 volt electrical current
1.5 X (number of 4, 6, & 9LED modules being fused) = Total Electrical Current at 12.8 VDC or
0.5 X (number of 3LED modules being fused) = Total Electrical Current at 12.8 VDC
LED MODULES
Operating Specications for directional module:
Operating Voltage: 10-16 VDC, Reverse Polarity Protection
Current Draw : Flashing Module
Red/Amber - .25A avg @ 12.8 Volts
Blue/White - .4A avg @ 12.8 Volts
Steady Burn Module
Red/Amber - .5A avg @ 12.8 Volts
Blue/White - .8A avg @ 12.8 Volts
Available Colors - Red , Blue, Amber, and White
Fash Pattern Instructions (Independent Flashing Units):
CAUTION!
This product contains high intensity LED devices. To prevent eye damage, DO NOT stare into the light beam at close range.
INSTALLER NOTE:
FLASH RATE + FLASH SEQUENCE = FLASH PATTERN
Lighthead Flash Sequences - Multi Color
LEFT / RIGHT
(DEFAULT):
PRIMARY & SECONDARY
PRIMARY ONLY - LEVEL - 1 DEFAULT
SECONDARY ONLY
PRIMARY W / SECONDARY POPS
PRIMARY W / SECONDARY RANDOM
EVEN / ODD: PRIMARY & SECONDARY
PRIMARY ONLY - LEVEL - 2 DEFAULT
SECONDARY ONLY
PRIMARY W / SECONDARY POPS
PRIMARY W / SECONDARY RANDOM
RANDOM: PRIMARY & SECONDARY
PRIMARY ONLY
SECONDARY ONLY
PRIMARY W / SECONDARY POPS
PRIMARY W / SECONDARY RANDOM
CYCLE SEQUENCE
RANDOM:
PRIMARY & SECONDARY
PRIMARY ONLY
SECONDARY ONLY
PRIMARY W / SECONDARY POPS
PRIMARY W / SECONDARY RANDOM
ALL ON
RANDOM:
PRIMARY & SECONDARY
SWEEP
LEFT / RIGHT:
SECONDARY ONLY
NULL: ALL LIGHTHEADS OFF
Lighthead Flash Sequences - Multi Color
Double Flash-75 - LEVEL - 2 DEFAULT
Triple Flash-75
Quad Flash-75
Quint Flash-75
Double Flash-150
Triple Flash-150 - LEVEL - 1 DEFAULT
Quad Flash-150
Quint Flash-150
Triple Pop Flash-150
Quad Pop Flash-150
Single Flash-375
Cycle Rates

Page 7 of 12
Scene Steady ArrowStik Pattern ArrowStik Speed
All Primary Build - DEFAULT 0
All Secondary - DEFAULT Build 3 Flash 1
Travel 3 Flash 2
Build / Collapse 3
ArrowStik Overrides All Other functions
Scene Steady Overrides L1 & L2 Flashing
Changing Flash Patterns:
To change the ash patterns on the LED Light Heads, remove the mounting screws that attach the Cover to gain access to the printed circuit
boards inside (see the exploded view on page 11). Momentarily short and release the pattern change prongs as shown below to change
patterns. Carefully replace the cover and fasten cover mounting screws.
Note: Be extremely careful to replace the wiring such that you don’t pinch a wire when you replace the cover. Test the unit to be
sure that it works as intended.
JP1
1. Momentarily short and release
to change patterns.
2. Hold for 5 seconds to reset the
ash pattern to the rst pattern.
Directional Module Flash Pattern
Cycle Flash-70 - (DEFAULT) Variable Flash Single
NFPA Quad Flash-80 Cycle Flash-150
Quad Flash-70 Five Flash-150
Steady Burn Quad Flash-150
Five Flash-70 Triple Flash-150
Triple Flash-70 Double Flash-150
Double Flash-70 Single Flash-150
Single Flash-70 Single Flash-250
Quad Pop Flash-70 Single Flash-375
Triple Pop Flash-70
Torus 3LED PCB Shown
Flash Pattern Header for Torus

Page 8 of 12
All WingMan Rear Bars are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the
life of the product, follow the guide below for information on repair and troubleshooting. Additional information may be obtained from the
factory technical help line at 314-996-2800.
Note: LED modules must be replaced as a module. There are no user serviceable parts.
PROBLEM QUESTIONS POSSIBLE CAUSE SOLUTION
LED module not operating when powered. N/A a. Bad power/ground connection
b. Defective module
a. Fix connection
b. Replace module
Troubleshooting:

Page 9 of 12
Replacement Parts and Accesories (Main Assembly):
LONG VERSION
2
1
8
7
6
5
4
3
9
SHORT VERSION
1S
2S
MINI VERSION
1M
2M
9M
Reference Number Part Description Part Number Quantity
1 Outer Panel LONG Version 155-0280-00 1
1S Outer Panel SHORT Version 155-0285-00 1
1M Outer Panel MINI Version 155-0284-00 1
2 Chassis LONG Version 220-0682-00 1
2S Chassis SHORT Version 220-0681-00 1
2M Chassis MINI Version 220-0680-00 1
3 18LED Multi Color Light Head Module Contact Code 3, Inc for P/N Up to 8
4 9LED Single Color Light Head Module Contact Code 3, Inc for P/N Up to 8
5 6LED Single Color Light Head Module Contact Code 3, Inc for P/N Up to 8
6 4LED Single Color Light Head Module Contact Code 3, Inc for P/N Up to 8
7 3LED Single Color Light Head Module Contact Code 3, Inc for P/N Up to 8
8 Blank Bracket 220-0710-00 Up to 2
9 Wingman Flex Multi Color CC Board 160-0494-00 1
9M 925 Flasher-Single Color MINI Version Only T57198 1

Page 10 of 12
Notes:

Page 11 of 12
Notes:

Page 12 of 12
10986 North Warson Road
St. Louis, MO 63114
Technical Service
[phone]
[email protected]
www.code3esg.com
An ECCO SAFETY GROUP™ Brand
www.eccosafetygroup.com
Product Returns:
If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA
number) before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use
su󰀩cient packing materials to avoid damage to the product being returned while in transit.
*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring
service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products returned to sender after the service has been rendered.
Manufacturer Limited Warranty Policy:
Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which are avail-
able from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-
TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE
MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WAR-
RANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EX-
CLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE
REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-
UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO
THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.
IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY
DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IM-
PROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT
TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdic-
tions do not allow the exclusion or limitation of incidental or consequential damages.
© 2015 Code 3, Inc. all rights reserved.
920-0434-00 Rev. E
Warranty:
